Phenolic Rectangular Bars

Phenolic Bars are cut from full sheets, and are available in the grades and thicknesses listed below.

Technical Data & Chemical Resistance


G10/FR4 Cut-to-Size Bars

.031" Thick Bars .062" Thick Bars .093" Thick Bars
.125" Thick Bars .156" Thick Bars .187" Thick Bars
.250" Thick Bars .375" Thick Bars .500" Thick Bars
1.00" Thick Bars

↓ LE-Linen and XX Paper Reinforced Bars ↓

LE Linen Bars - Standard Lengths of 48"
Thickness (in.) Width (in.) Part # Price Per Foot Order Online
.062 2.00 KBS-2263 $5.12 Add to Order
.125 2.00 KBS-2264 $9.82 Add to Order
.125 3.00 KBS-2325 $12.20 Add to Order
.188 2.00 KBS-2265 $13.90 Add to Order
.188 3.00 KBS-2326 $19.46 Add to Order
.250 2.00 KBS-2327 $16.86 Add to Order
.250 3.00 KBS-2349 $24.54 Add to Order
.375 2.00 KBS-2329 $26.48 Add to Order
.375 3.00 KBS-2324 $38.52 Add to Order
.500 2.00 KBS-2330 $33.60 Add to Order
.500 3.00 KBS-2334 $48.88 Add to Order
Rev. 04-23, 06-22, 06-21


Paper Phenolic Bars
XX Paper Phenolic Bars

NEMA XX certs to MIL-I-24768/11 PBG, IEC 60893-3 Type 4 PF CP 203

Standard Lengths of 48"

Thickness (in.) Width (in.) Part # Price Per Foot Order Online
.031 2.00 KBS-2321 $1.68 Add to Order
.031 3.00 KBS-2277 $40.82 Add to Order
.062 2.00 KBS-2307 $2.06 Add to Order
.062 3.00 KBS-3009 $13.38 Add to Order
.125 2.00 KBS-2286 $3.38 Add to Order
.125 3.00 KBS-2275 $4.54 Add to Order
.188 2.00 KBS-2278 $65.15 Add to Order
.188 3.00 KBS-2274 $6.66 Add to Order
.250 2.00 KBS-3018 $6.20 Add to Order
.250 3.00 KBS-3015 $8.10 Add to Order
.313 2.00 KBS-3019 $9.18 Add to Order
.375 2.00 KBS-3020 $8.68 Add to Order
.500 2.00 KBS-3021 $11.28 Add to Order
.500 3.00 KBS-3000 $15.66 Add to Order
1.00 4.00 KBS-3011 $48.42 Add to Order
Rev. 04-23, 11-22, 06-22, 06-21
<<
