Polycarbonate Tubes
Polycarbonate tubes give extraordinary design and fabrication opportunities. It can be machined, drilled, cut and sawed, and is easily joined with solvents and adhesives. It is Weather Resistant to Underwriters Laboratories (UL) 94 HB Ratings
Close Up Large Polycarbonate Tube Pictures for 1/16", 1/8" and 1/ 4" Wall
|
Polycarbonate Round Tubing Standard length is 8 feet. Cut lengths available for tubes under 7" wide. |
|||||
| Part # | OD (in.) | ID (in.) | Wall (in.) | Price Per Foot | Order Online |
|---|---|---|---|---|---|
| KM-8024Z | .250 | .125 | .062 | $1.80 | Add to Order |
| KM-8025Z | .312 | .187 | .062 | $2.20 | Add to Order |
| KM-2100W | .312 | .250 | .031 | $4.29 | Add to Order |
| KM-2105K | .375 | .125 | .125 | $2.14 | Add to Order |
| KM-936 | .375 | .250 | .063 | $1.01 | Add to Order |
| KM-8026Z | .500 | .187 | .156 | $5.42 | Add to Order |
| KM-2105L | .500 | .250 | .125 | $3.95 | Add to Order |
| KM-8450Z | .500 | .250 | .125 BLACK | $3.39 / 4 Ft Min. | Add to Order |
| KM-937 | .500 | .375 | .063 | $1.35 | Add to Order |
| KM-2105M | .625 | .375 | .125 | $3.49 | Add to Order |
| KM-938 | .625 | .500 | .063 | $1.29 | Add to Order |
| KM-9000-P | .750 | .250 | .250 | $6.10 | Add to Order |
| KM-8454Z | .750 | .500 | .125 BLACK | $6.58 | Add to Order |
| KM-2100G | .750 | .500 | .125 | $3.23 | Add to Order |
| KM-939 | .750 | .625 | .063 | $1.74 | Add to Order |
| KM-2170 | .875 | .750 | .063 | $2.37 | Add to Order |
| KM-8045Z | 1.00 | .500 | .250 | $15.95 | Add to Order |
| KM-940 | 1.00 | .750 | .125 | $4.45 | Add to Order |
| KM-8449Z | 1.00 | .750 | .125 BLACK | $8.42 / 4 Ft Min. | Add to Order |
| KM-941 | 1.00 | .875 | .063 | $2.61 | Add to Order |
| KM-5323 | 1.125 | .875 | .187 | $11.49 | Add to Order |
| KM-2171 | 1.125 | 1.00 | .063 | $3.22 | Add to Order |
| KM-8046Z | 1.25 | .750 | .250 | $16.46 | Add to Order |
| KM-942 | 1.25 | 1.00 | .125 | $6.88 | Add to Order |
| KM-8447Z | 1.25 | 1.00 | .125 BLACK | $13.79 / 4 Ft Min. | Add to Order |
| KM-2172 | 1.25 | 1.125 | .063 | $2.91 | Add to Order |
| KM-8028Z | 1.375 | 1.125 | .125 | $12.57 | Add to Order |
| KM-8047Z | 1.50 | 1.00 | .250 | $38.18 | Add to Order |
| KM-943 | 1.50 | 1.25 | .125 | $8.22 | Add to Order |
| KM-8446Z | 1.50 | 1.25 | .125 BLACK | $14.52 / 4 Ft Min. | Add to Order |
| KM-944 | 1.50 | 1.375 | .063 | $3.84 | Add to Order |
| KM-8029Z | 1.625 | 1.375 | .125 | $16.42 | Add to Order |
| KM-8027Z | 1.625 | 1.5 | .063 | $9.79 | Add to Order |
| KM-9001-P | 1.75 | 1.25 | .250 | $23.75 | Add to Order |
| KM-945 | 1.75 | 1.50 | .125 | $9.21 | Add to Order |
| KM-8448Z | 1.75 | 1.50 | .125 BLACK | $17.13 / 4 Ft Min. | Add to Order |
| KM-2173 | 1.75 | 1.625 | .063 | $5.73 | Add to Order |
| KM-8030Z | 1.875 | 1.625 | .125 | $21.35 | Add to Order |
| KM-8048Z | 2.00 | 1.50 | .250 | $44.01 | Add to Order |
| KM-946 | 2.00 | 1.75 | .125 | $10.65 | Add to Order |
| KM-8453Z | 2.00 | 1.75 | .125 BLACK | $19.80 / 4Ft Min. | Add to Order |
| KM-2174 | 2.00 | 1.875 | .063 | $5.69 | Add to Order |
| KM-8049Z | 2.25 | 1.75 | .250 | $28.79 | Add to Order |
| KM-947 | 2.25 | 2.00 | .125 | $10.79 | Add to Order |
| KM-8452Z | 2.25 | 2.00 | .125 BLACK | $24.20 / 4 Ft Min. | Add to Order |
| KM-2175 | 2.25 | 2.125 | .063 | $8.39 | Add to Order |
| KM-8050Z | 2.50 | 2.00 | .250 | $30.34 | Add to Order |
| KM-948 | 2.50 | 2.25 | .125 | $9.31 | Add to Order |
| KM-8451Z | 2.50 | 2.25 | .125 BLACK | $29.48 / 4 Ft Min. | Add to Order |
| KM-2176 | 2.50 | 2.375 | .063 | $7.10 | Add to Order |
| KM-8051Z | 2.75 | 2.25 | .250 | $67.36 | Add to Order |
| KM-949 | 2.75 | 2.50 | .125 | $14.48 | Add to Order |
| KM-2177 | 2.75 | 2.625 | .063 | $8.20 | Add to Order |
| KM-8052Z | 3.00 | 2.50 | .250 | $66.59 | Add to Order |
| KM-950 | 3.00 | 2.75 | .125 | $14.98 | Add to Order |
| KM-2178 | 3.00 | 2.875 | .063 | $7.78 | Add to Order |
| KM-4704 | 3.125 | 3.00 | .063 | $10.56 | Add to Order |
| KM-8053Z | 3.25 | 2.75 | .250 | $72.00 | Add to Order |
| KM-682 | 3.25 | 3.00 | .125 | $17.39 | Add to Order |
| KM-8054Z | 3.50 | 3.00 | .250 | $42.59 | Add to Order |
| KM-951 | 3.50 | 3.25 | .125 | $22.32 | Add to Order |
| KM-8055Z | 3.75 | 3.25 | .250 | $85.41 | Add to Order |
| KM-8031Z | 3.75 | 3.50 | .125 | $43.20 | Add to Order |
| KM-8056Z | 4.00 | 3.50 | .250 | $53.17 | Add to Order |
| KM-6831 | 4.00 | 3.75 | .125 | $20.26 | Add to Order |
| KM-8032Z | 4.25 | 4.00 | .125 | $57.47 | Add to Order |
| KM-8033Z | 4.50 | 4.25 | .125 | $41.92 | Add to Order |
| KM-8057Z | 4.50 | 4.00 | .250 | $66.89 | Add to Order |
| KM-8058Z | 4.75 | 4.25 | .250 | $105.54 | Add to Order |
| KM-8034Z | 4.75 | 4.50 | .125 | $64.42 | Add to Order |
| KM-8059Z | 5.00 | 4.50 | .250 | $69.90 | Add to Order |
| KM-8068Z | 5.00 | 4.62 | .187 | $61.47 | Add to Order |
| KM-953 | 5.00 | 4.75 | .125 | $35.55 | Add to Order |
| KM-8060Z | 5.25 | 4.75 | .250 | $121.84 | Add to Order |
| KM-8036Z | 5.25 | 5.00 | .125 | $69.67 | Add to Order |
| KM-8061Z | 5.50 | 5.00 | .250 | $79.99 | Add to Order |
| KM-8037Z | 5.50 | 5.25 | .125 | $87.13 | Add to Order |
| KM-8062Z | 6.00 | 5.50 | .250 | $134.64 | Add to Order |
| KM-8069Z | 6.00 | 5.625 | .187 | $129.19 | Add to Order |
| KM-954 | 6.00 | 5.75 | .125 | $39.56 | Add to Order |
| KM-8038Z | 6.50 | 6.25 | .125 | $150.35 | Add to Order |
| KM-8063Z | 7.00 | 6.50 | .250 | $157.86 | Add to Order |
| KM-2100J | 7.00 | 6.75 | .125 | $65.27 | Add to Order |
| KM-8064Z | 7.50 | 7.00 | .250 | $163.00 / 8 Ft Min. | Add to Order |
| KM-8039Z | 7.50 | 7.25 | .125 | $178.47 / 8 Ft Min. | Add to Order |
| KM-8065Z | 8.00 | 7.50 | .250 | $204.37 / 8 Ft Min. | Add to Order |
| KM-955 | 8.00 | 7.75 | .125 | $55.77/ 8 Ft Min. | Add to Order |
| KM-8040Z | 8.50 | 8.25 | .125 | $222.26 / 8 Ft Min. | Add to Order |
| KM-8066Z | 9.00 | 8.50 | .250 | $241.83 / 8 Ft Min. | Add to Order |
| KM-8041Z | 9.00 | 8.75 | .125 | $265.07 / 8 Ft Min. | Add to Order |
| KM-8042Z | 9.50 | 9.25 | .125 | $298.11 / 8 Ft Min. | Add to Order |
| KM-5606Z | 10.00 | 9.50 | .250 | $233.89 / 8 Ft Min. | Add to Order |
| KM-8043Z | 10.00 | 9.75 | .125 | $268.08 / 8 Ft Min. | Add to Order |
| KM-8067Z | 12.00 | 11.50 | .250 | $303.43 / 8 Ft Min. | Add to Order |
| KM-8044Z | 12.00 | 11.75 | .125 | $386.61 / 8 Ft Min. | Add to Order |
| KM-24075 | 14.00 | 13.75 | .125 | $571.55 / 8 Ft Min. | Add to Order |
| KM-24076 | 14.00 | 13.50 | .250 | $1,028.71 / 8 Ft Min. | Add to Order |
| Rev. 06-24, 03-24, 01-24, 08-23 | |||||
NOTE: Polycarbonate Tubes are not Pressure or Vacuum Rated
Tolerances: Tubes
.375"-2.00" OD Dia Tol +/-.025", ID Tol +/-.025"
2.125"-4.00" OD Dia +/-.045", ID Tol +/-.035"
4.25"-5.00" OD Dia +/-.065", ID Tol +/-.045"
5.25"-7.75" OD Dia +/-.070", ID Tol +/-.060"
8.00"-9.00" +Dia +/-.095", ID Tol +/-.100"
10.0"-14.0" Dia +/-.250"
| Polycarbonate Extruded Square Tubing, Clear
Wall Thickness Tolerance : All Sizes : +/-.008" |
|||||||
| Part # | Outer Width (in.) | Inside Width (in.) | Wall Thickness (in.) | Width Tolerance | Price | Length (ft) | Order Online |
|---|---|---|---|---|---|---|---|
| KTBS-086 | 0.500 | 0.375 | 0.062 | +/-.010" | $68.11 | 6 | Add to Order |
| KTBS-120 | 0.625 | 0.375 | 0.125 | +/-.020" | $62.92 | 8 | Add to Order |
| KTBS-087 | 0.750 | 0.625 | 0.062 | +/-.020" | $63.94 | 6 | Add to Order |
| KTBS-121 | 0.750 | 0.500 | 0.125 | +/-.020" | $61.75 | 8 | Add to Order |
| KTBS-088 | 1.00 | 0.840 | 0.080 | +/-.020" | $99.36 | 6 | Add to Order |
| KTBS-122 | 1.00 | 0.750 | 0.125 | +/-.020" | $73.61 | 8 | Add to Order |
| KTBS-089 | 2.00 | 1.840 | 0.080 | +/-.030" | $198.72 | 6 | Add to Order |
| KTBS-123 | 2.00 | 1.750 | 0.125 | +/-.030" | $171.78 | 8 | Add to Order |
| Rev. 08-23, 04-23, 10-22, 09-22 | |||||||
