Slotted 420 Stainless Spring Pins
Click Here for Coiled 420 SS Spring Pins
420 Stainless Steel Slotted Spring Pins | |||||||
Part # | Dia. | Length | Wall | Breaking Strength LBS | Pkg Qty | Pkg. Price | Order Online |
---|---|---|---|---|---|---|---|
SP-178 | 1/16" | 3/16" | 0.012" | 420 | 100 | $10.56 | Add to Order |
SP-179 | 1/16" | 1/4" | 0.012" | 420 | 100 | $11.05 | Add to Order |
SP-180 | 1/16" | 5/16" | 0.012" | 420 | 100 | $10.75 | Add to Order |
SP-181 | 1/16" | 3/8" | 0.012" | 420 | 100 | $11.19 | Add to Order |
SP-182 | 1/16" | 7/16" | 0.012" | 420 | 100 | $11.66 | Add to Order |
SP-183 | 1/16" | 1/2" | 0.012" | 420 | 100 | $12.58 | Add to Order |
SP-954 | 1/16" | 9/16" | 0.012" | 420 | 100 | $24.84 | Add to Order |
SP-184 | 1/16" | 5/8" | 0.012" | 420 | 100 | $13.46 | Add to Order |
SP-939 | 1/16" | 11/16" | 0.012" | 420 | 100 | $12.31 | Add to Order |
SP-185 | 1/16" | 3/4" | 0.012" | 420 | 100 | $17.43 | Add to Order |
SP-1336 | 1/16" | 13/16" | 0.012" | 420 | 100 | $18.19 | Add to Order |
SP-186 | 1/16" | 7/8" | 0.012" | 420 | 100 | $28.18 | Add to Order |
SP-1337 | 1/16" | 15/16" | 0.012" | 420 | 100 | $22.24 | Add to Order |
SP-187 | 1/16" | 1" | 0.012" | 420 | 100 | $33.22 | Add to Order |
SP-937 | 5/64" | 3/16" | 0.018" | 800 | 100 | $24.34 | Add to Order |
SP-936 | 5/64" | 1/4" | 0.018" | 800 | 100 | $10.65 | Add to Order |
SP-935 | 5/64" | 5/16" | 0.018" | 800 | 100 | $24.97 | Add to Order |
SP-188 | 5/64" | 3/8" | 0.018" | 800 | 100 | $12.35 | Add to Order |
SP-934 | 5/64" | 7/16" | 0.018" | 800 | 100 | $25.35 | Add to Order |
SP-189 | 5/64" | 1/2" | 0.018" | 800 | 100 | $12.33 | Add to Order |
SP-932 | 5/64" | 9/16" | 0.018" | 800 | 50 | $24.15 | Add to Order |
SP-190 | 5/64" | 5/8" | 0.018" | 800 | 100 | $14.01 | Add to Order |
SP-966 | 5/64" | 11/16" | 0.018" | 800 | 100 | $34.00 | Add to Order |
SP-191 | 5/64" | 3/4" | 0.018" | 800 | 50 | $19.51 | Add to Order |
SP-968 | 5/64" | 13/16" | 0.018" | 800 | 50 | $20.39 | Add to Order |
SP-943 | 5/64" | 7/8" | 0.018" | 800 | 100 | $29.65 | Add to Order |
SP-192 | 5/64" | 1" | 0.018" | 800 | 100 | $42.67 | Add to Order |
SP-977 | 5/64" | 1 1/4" | 0.018" | 800 | 100 | $33.64 | Add to Order |
SP-755 | 5/64" | 1 1/2" | 0.018" | 800 | 50 | $19.87 | Add to Order |
SP-976 | 3/32" | 3/16" | 0.022" | 1,000 | 100 | $15.06 | Add to Order |
SP-194 | 3/32" | 1/4" | 0.022" | 1,000 | 100 | $11.17 | Add to Order |
SP-195 | 3/32" | 5/16" | 0.022" | 1,000 | 100 | $12.01 | Add to Order |
SP-196 | 3/32" | 3/8" | 0.022" | 1,000 | 100 | $12.66 | Add to Order |
SP-197 | 3/32" | 7/16" | 0.022" | 1,000 | 100 | $14.32 | Add to Order |
SP-198 | 3/32" | 1/2" | 0.022" | 1,000 | 100 | $14.99 | Add to Order |
SP-199 | 3/32" | 9/16" | 0.022" | 1,000 | 100 | $15.18 | Add to Order |
SP-200 | 3/32" | 5/8" | 0.022" | 1,000 | 100 | $15.86 | Add to Order |
SP-975 | 3/32" | 11/16" | 0.022" | 1,000 | 100 | $27.85 | Add to Order |
SP-201 | 3/32" | 3/4" | 0.022" | 1,000 | 100 | $17.51 | Add to Order |
SP-974 | 3/32" | 13/16" | 0.022" | 1,000 | 100 | $30.60 | Add to Order |
SP-202 | 3/32" | 7/8" | 0.022" | 1,000 | 100 | $20.52 | Add to Order |
SP-1338 | 3/32" | 15/16" | 0.022" | 1,000 | 100 | $26.21 | Add to Order |
SP-203 | 3/32" | 1" | 0.022" | 1,000 | 100 | $23.65 | Add to Order |
SP-204 | 3/32" | 1 1/8" | 0.022" | 1,000 | 100 | $26.67 | Add to Order |
SP-205 | 3/32" | 1 1/4" | 0.022" | 1,000 | 50 | $19.80 | Add to Order |
SP-973 | 3/32" | 1 3/8" | 0.022" | 1,000 | 50 | $19.68 | Add to Order |
SP-972 | 3/32" | 1 1/2" | 0.022" | 1,000 | 100 | $31.33 | Add to Order |
SP-550 | 1/8" | 1/4" | 0.028" | 1,750 | 100 | $15.29 | Add to Order |
SP-206 | 1/8" | 5/16" | 0.028" | 1,750 | 100 | $21.78 | Add to Order |
SP-207 | 1/8" | 3/8" | 0.028" | 1,750 | 100 | $13.76 | Add to Order |
SP-208 | 1/8" | 7/16" | 0.028" | 1,750 | 100 | $15.69 | Add to Order |
SP-537 | 1/8" | 1/2" | 0.028" | 1,750 | 100 | $14.66 | Add to Order |
SP-548 | 1/8" | 9/16" | 0.028" | 1,750 | 100 | $17.60 | Add to Order |
SP-209 | 1/8" | 5/8" | 0.028" | 1,750 | 100 | $18.77 | Add to Order |
SP-560 | 1/8" | 11/16" | 0.028" | 1,750 | 100 | $20.50 | Add to Order |
SP-210 | 1/8" | 3/4" | 0.028" | 1,750 | 100 | $19.32 | Add to Order |
SP-546 | 1/8" | 13/16" | 0.028" | 1,750 | 100 | $24.23 | Add to Order |
SP-211 | 1/8" | 7/8" | 0.028" | 1,750 | 100 | $24.68 | Add to Order |
SP-1339 | 1/8" | 15/16" | 0.028" | 1,750 | 100 | $35.60 | Add to Order |
SP-212 | 1/8" | 1" | 0.028" | 1,750 | 100 | $30.68 | Add to Order |
SP-213 | 1/8" | 1 1/8" | 0.028" | 1,750 | 100 | $33.45 | Add to Order |
SP-214 | 1/8" | 1 1/4" | 0.028" | 1,750 | 50 | $22.43 | Add to Order |
SP-215 | 1/8" | 1 3/8" | 0.028" | 1,750 | 50 | $20.58 | Add to Order |
SP-216 | 1/8" | 1 1/2" | 0.028" | 1,750 | 50 | $21.80 | Add to Order |
SP-217 | 1/8" | 1 5/8" | 0.028" | 1,750 | 50 | $25.52 | Add to Order |
SP-218 | 1/8" | 1 3/4" | 0.028" | 1,750 | 50 | $22.83 | Add to Order |
SP-545 | 1/8" | 1 7/8" | 0.028" | 1,750 | 50 | $33.81 | Add to Order |
SP-543 | 1/8" | 2" | 0.028" | 1,750 | 25 | $13.31 | Add to Order |
SP-542 | 1/8" | 2 1/4" | 0.028" | 1,750 | 25 | $13.46 | Add to Order |
SP-541 | 1/8" | 2 1/2" | 0.028" | 1,750 | 25 | $21.00 | Add to Order |
SP-219 | 5/32" | 3/8" | 0.032" | 2,500 | 100 | $25.41 | Add to Order |
SP-1344 | 5/32" | 7/16" | 0.032" | 2,500 | 100 | $35.47 | Add to Order |
SP-220 | 5/32" | 1/2" | 0.032" | 2,500 | 100 | $28.71 | Add to Order |
SP-1345 | 5/32" | 9/16" | 0.032" | 2,500 | 100 | $27.43 | Add to Order |
SP-221 | 5/32" | 5/8" | 0.032" | 2,500 | 100 | $27.09 | Add to Order |
SP-222 | 5/32" | 3/4" | 0.032" | 2,500 | 100 | $29.23 | Add to Order |
SP-223 | 5/32" | 7/8" | 0.032" | 2,500 | 100 | $34.76 | Add to Order |
SP-224 | 5/32" | 1" | 0.032" | 2,500 | 50 | $20.18 | Add to Order |
SP-225 | 5/32" | 1 1/8" | 0.032" | 2,500 | 50 | $20.08 | Add to Order |
SP-226 | 5/32" | 1 1/4" | 0.032" | 2,500 | 50 | $24.86 | Add to Order |
SP-540 | 5/32" | 1 3/8" | 0.032" | 2,500 | 25 | $11.80 | Add to Order |
SP-227 | 5/32" | 1 1/2" | 0.032" | 2,500 | 25 | $12.60 | Add to Order |
SP-539 | 5/32" | 1 3/4" | 0.032" | 2,500 | 25 | $13.08 | Add to Order |
SP-228 | 5/32" | 2" | 0.032" | 2,500 | 25 | $15.33 | Add to Order |
SP-228B | 5/32" | 2 1/2" | 0.032" | 2,500 | 25 | $19.40 | Add to Order |
SP-229 | 3/16" | 3/8" | 0.04" | 4,000 | 50 | $12.45 | Add to Order |
SP-772 | 3/16" | 7/16" | 0.04" | 4,000 | 25 | $28.31 | Add to Order |
SP-230 | 3/16" | 1/2" | 0.04" | 4,000 | 50 | $13.25 | Add to Order |
SP-231 | 3/16" | 9/16" | 0.04" | 4,000 | 50 | $15.50 | Add to Order |
SP-232 | 3/16" | 5/8" | 0.04" | 4,000 | 50 | $16.23 | Add to Order |
SP-544 | 3/16" | 11/16" | 0.04" | 4,000 | 50 | $16.13 | Add to Order |
SP-233 | 3/16" | 3/4" | 0.04" | 4,000 | 50 | $17.01 | Add to Order |
SP-538 | 3/16" | 13/16" | 0.04" | 4,000 | 50 | $19.64 | Add to Order |
SP-234 | 3/16" | 7/8" | 0.04" | 4,000 | 50 | $19.26 | Add to Order |
SP-235 | 3/16" | 1" | 0.04" | 4,000 | 50 | $21.21 | Add to Order |
SP-572 | 3/16" | 1 1/8" | 0.04" | 4,000 | 50 | $25.05 | Add to Order |
SP-236 | 3/16" | 1 1/4" | 0.04" | 4,000 | 50 | $25.49 | Add to Order |
SP-237 | 3/16" | 1 3/8" | 0.04" | 4,000 | 50 | $27.59 | Add to Order |
SP-238 | 3/16" | 1 1/2" | 0.04" | 4,000 | 25 | $15.39 | Add to Order |
SP-549 | 3/16" | 1 5/8" | 0.04" | 4,000 | 25 | $19.24 | Add to Order |
SP-239 | 3/16" | 1 3/4" | 0.04" | 4,000 | 25 | $18.71 | Add to Order |
SP-583 | 3/16" | 1 7/8" | 0.04" | 4,000 | 25 | $21.00 | Add to Order |
SP-240 | 3/16" | 2" | 0.04" | 4,000 | 25 | $20.64 | Add to Order |
SP-582 | 3/16" | 2 1/4" | 0.04" | 4,000 | 25 | $21.25 | Add to Order |
SP-756 | 3/16" | 2 1/2" | 0.04" | 4,000 | 25 | $25.00 | Add to Order |
SP-581 | 3/16" | 2 3/4" | 0.04" | 4,000 | 50 | $55.52 | Add to Order |
SP-580 | 3/16" | 3" | 0.04" | 4,000 | 10 | $17.50 | Add to Order |
SP-242 | 7/32" | 1/2" | 0.048" | 5,500 | 50 | $14.95 | Add to Order |
SP-243 | 7/32" | 5/8" | 0.048" | 5,500 | 25 | $9.26 | Add to Order |
SP-1346 | 7/32" | 3/4" | 0.048" | 5,500 | 25 | $10.67 | Add to Order |
SP-245 | 7/32" | 1" | 0.048" | 5,500 | 25 | $13.67 | Add to Order |
SP-244 | 7/32" | 1 1/4" | 0.048" | 5,500 | 25 | $16.53 | Add to Order |
SP-246 | 7/32" | 1 1/2" | 0.048" | 5,500 | 25 | $19.51 | Add to Order |
SP-247 | 7/32" | 1 3/4" | 0.048" | 5,500 | 25 | $22.32 | Add to Order |
SP-248 | 7/32" | 2" | 0.048" | 5,500 | 25 | $25.33 | Add to Order |
SP-574 | 7/32" | 2 1/4" | 0.048" | 5,500 | 10 | $13.33 | Add to Order |
SP-249 | 7/32" | 2 1/2" | 0.048" | 5,500 | 10 | $12.66 | Add to Order |
SP-579 | 7/32" | 2 3/4" | 0.048" | 5,500 | 10 | $26.38 | Add to Order |
SP-578 | 7/32" | 3" | 0.048" | 5,500 | 10 | $18.90 | Add to Order |
SP-250 | 1/4" | 1/2" | 0.048" | 7,000 | 100 | $30.51 | Add to Order |
SP-1347 | 1/4" | 9/16" | 0.048" | 7,000 | 50 | $29.65 | Add to Order |
SP-251 | 1/4" | 5/8" | 0.048" | 7,000 | 50 | $20.92 | Add to Order |
SP-1348 | 1/4" | 11/16" | 0.048" | 7,000 | 50 | $30.16 | Add to Order |
SP-252 | 1/4" | 3/4" | 0.048" | 7,000 | 50 | $29.23 | Add to Order |
SP-253 | 1/4" | 7/8" | 0.048" | 7,000 | 50 | $30.43 | Add to Order |
SP-254 | 1/4" | 1" | 0.048" | 7,000 | 25 | $18.61 | Add to Order |
SP-255 | 1/4" | 1 1/8" | 0.048" | 7,000 | 25 | $19.17 | Add to Order |
SP-256 | 1/4" | 1 1/4" | 0.048" | 7,000 | 25 | $23.44 | Add to Order |
SP-577 | 1/4" | 1 3/8" | 0.048" | 7,000 | 25 | $24.74 | Add to Order |
SP-257 | 1/4" | 1 1/2" | 0.048" | 7,000 | 25 | $25.58 | Add to Order |
SP-258 | 1/4" | 1 5/8" | 0.048" | 7,000 | 25 | $33.92 | Add to Order |
SP-259 | 1/4" | 1 3/4" | 0.048" | 7,000 | 10 | $16.13 | Add to Order |
SP-260 | 1/4" | 1 7/8" | 0.048" | 7,000 | 10 | $13.29 | Add to Order |
SP-261 | 1/4" | 2" | 0.048" | 7,000 | 10 | $12.73 | Add to Order |
SP-262 | 1/4" | 2 1/4" | 0.048" | 7,000 | 10 | $14.81 | Add to Order |
SP-263 | 1/4" | 2 1/2" | 0.048" | 7,000 | 10 | $16.86 | Add to Order |
SP-576 | 1/4" | 2 3/4" | 0.048" | 7,000 | 10 | $17.18 | Add to Order |
SP-264 | 1/4" | 3" | 0.048" | 7,000 | 10 | $20.56 | Add to Order |
SP-265 | 1/4" | 3 1/4" | 0.048" | 7,000 | 10 | $26.21 | Add to Order |
SP-266 | 1/4" | 3 1/2" | 0.048" | 7,000 | 10 | $23.50 | Add to Order |
SP-1349 | 1/4" | 4" | 0.048" | 7,000 | 5 | $34.61 | Add to Order |
SP-267 | 5/16" | 3/4" | 0.062" | 10,000 | 25 | $21.82 | Add to Order |
SP-268 | 5/16" | 1" | 0.062" | 10,000 | 25 | $26.42 | Add to Order |
SP-269 | 5/16" | 1 1/4" | 0.062" | 10,000 | 25 | $31.00 | Add to Order |
SP-241 | 5/16" | 1 1/2" | 0.062" | 10,000 | 10 | $14.97 | Add to Order |
SP-270 | 5/16" | 1 3/4" | 0.062" | 10,000 | 10 | $18.10 | Add to Order |
SP-271 | 5/16" | 2" | 0.062" | 10,000 | 10 | $19.66 | Add to Order |
SP-272 | 5/16" | 2 1/4" | 0.062" | 10,000 | 10 | $21.53 | Add to Order |
SP-273 | 5/16" | 2 1/2" | 0.062" | 10,000 | 10 | $23.54 | Add to Order |
SP-1350 | 5/16" | 2 3/4" | 0.062" | 10,000 | 10 | $42.67 | Add to Order |
SP-274 | 5/16" | 3" | 0.062" | 10,000 | 10 | $25.96 | Add to Order |
SP-575 | 5/16" | 3 1/4" | 0.062" | 10,000 | 5 | $22.97 | Add to Order |
SP-275 | 5/16" | 3 1/2" | 0.062" | 10,000 | 5 | $17.16 | Add to Order |
SP-561 | 5/16" | 3 3/4" | 0.062" | 10,000 | 5 | $34.13 | Add to Order |
SP-573 | 5/16" | 4" | 0.062" | 10,000 | 5 | $28.58 | Add to Order |
SP-276 | 3/8" | 3/4" | 0.077" | 16,000 | 10 | $15.67 | Add to Order |
SP-277 | 3/8" | 1" | 0.077" | 16,000 | 10 | $18.21 | Add to Order |
SP-278 | 3/8" | 1 1/4" | 0.077" | 16,000 | 10 | $23.50 | Add to Order |
SP-279 | 3/8" | 1 1/2" | 0.077" | 16,000 | 10 | $26.42 | Add to Order |
SP-280 | 3/8" | 1 3/4" | 0.077" | 16,000 | 10 | $30.07 | Add to Order |
SP-585 | 3/8" | 2" | 0.077" | 16,000 | 5 | $17.12 | Add to Order |
SP-571 | 3/8" | 2 1/4" | 0.077" | 16,000 | 5 | $21.69 | Add to Order |
SP-281 | 3/8" | 2 1/2" | 0.077" | 16,000 | 5 | $22.50 | Add to Order |
SP-570 | 3/8" | 2 3/4" | 0.077" | 16,000 | 5 | $24.28 | Add to Order |
SP-282 | 3/8" | 3" | 0.077" | 16,000 | 5 | $26.27 | Add to Order |
SP-569 | 3/8" | 3 1/4" | 0.077" | 16,000 | 1 | $21.34 | Add to Order |
SP-567 | 3/8" | 3 1/2" | 0.077" | 16,000 | 1 | $5.78 | Add to Order |
SP-566 | 3/8" | 3 3/4" | 0.077" | 16,000 | 1 | $11.45 | Add to Order |
SP-283 | 3/8" | 4" | 0.077" | 16,000 | 1 | $7.18 | Add to Order |
SP-565 | 7/16" | 1 3/4" | 0.077" | 19,000 | 5 | $26.23 | Add to Order |
SP-564 | 7/16" | 2" | 0.077" | 19,000 | 5 | $20.37 | Add to Order |
SP-563 | 7/16" | 2 1/2" | 0.077" | 19,000 | 5 | $24.40 | Add to Order |
SP-568 | 7/16" | 3" | 0.077" | 19,000 | 5 | $28.46 | Add to Order |
SP-562 | 7/16" | 4" | 0.077" | 19,000 | 1 | $7.25 | Add to Order |
SP-535 | 1/2" | 1 1/4" | 0.094" | 26,000 | 5 | $19.80 | Add to Order |
SP-498 | 1/2" | 1 1/2" | 0.094" | 26,000 | 5 | $19.95 | Add to Order |
SP-547 | 1/2" | 1 3/4" | 0.094" | 26,000 | 5 | $22.47 | Add to Order |
SP-509 | 1/2" | 2" | 0.094" | 26,000 | 1 | $7.98 | Add to Order |
SP-508 | 1/2" | 2 1/4" | 0.094" | 26,000 | 1 | $9.79 | Add to Order |
SP-507 | 1/2" | 2 1/2" | 0.094" | 26,000 | 1 | $9.66 | Add to Order |
SP-506 | 1/2" | 2 3/4" | 0.094" | 26,000 | 1 | $9.01 | Add to Order |
SP-505 | 1/2" | 3" | 0.094" | 26,000 | 1 | $9.30 | Add to Order |
SP-504 | 1/2" | 3 1/4" | 0.094" | 26,000 | 1 | $17.03 | Add to Order |
SP-503 | 1/2" | 3 1/2" | 0.094" | 26,000 | 1 | $11.80 | Add to Order |
SP-502 | 1/2" | 3 3/4" | 0.094" | 26,000 | 1 | $19.26 | Add to Order |
SP-501 | 1/2" | 4" | 0.094" | 26,000 | 1 | $14.22 | Add to Order |
Rev. 04-23, 01-23, 12-22, 03-22 |
Tolerances |
|
Lengths 0-1.0" | +/-.015" |
Lengths 1.125"-2.0" | +/-.020" |
Lengths 2.25"-3.0" | +/-.025" |
Lengths 3.25" and up | +/-.030" |
Lengths 0-24mm | +/- .40mm |
Lengths 26mm-50mm | +/- .50mm |
Lengths 55mm-60mm | +/- .60mm |
Lengths 80mm and up | +/- .75mm |
Metric | Imperial Inches | ||||||||||||||||||||
Nominal Dia. | M2 | M2.5 | M3 | M4 | M5 | M6 | M8 | 1/16" | 5/64" | 3/32" | 1/8" | 5/32" | 3/16" | 7/32" | 1/4" | 5/16" | 3/8" | 7/16" | 1/2" | 5/8" | |
Act. Dia | Min. mm | 2.13 | 2.65 | 3.15 | 4.20 | 5.25 | 6.25 | 8.30 | 0.066 | 0.083 | 0.099 | 0.131 | 0.162 | 0.194 | 0.226 | 0.258 | 0.321 | 0.385 | 0.448 | 0.513 | 0.640 |
Max. mm | 2.25 | 2.78 | 3.30 | 4.40 | 5.50 | 6.50 | 8.63 | 0.069 | 0.086 | 0.103 | 0.135 | 0.137 | 0.199 | 0.232 | 0.264 | 0.330 | 0.395 | 0.459 | 0.524 | 0.653 | |
Wall Thickness | * | * | * | * | * | * | * | 0.012 | 0.018 | 0.022 | 0.028 | 0.032 | 0.040 | 0.048 | 0.048 | 0.062 | 0.077 | 0.077 | 0.094 | 0.125 | |
Suggested | Min. mm | 2.00 | 2.50 | 3.00 | 4.00 | 5.10 | 6.00 | 8.00 | 0.062 | 0.078 | 0.094 | 0.125 | 0.156 | 0.187 | 0.219 | 0.250 | 0.312 | 0.375 | 0.437 | 0.500 | 0.625 |
Hole Size | Max. mm | 2.10 | 2.60 | 3.10 | 4.12 | 5.12 | 6.12 | 8.15 | 0.065 | 0.081 | 0.097 | 0.129 | 0.160 | 0.192 | 0.224 | 0.256 | 0.318 | 0.382 | 0.445 | 0.510 | 0.636 |
Shear Strength Lbs | 562 | 876 | 1236 | 2158 | 3372 | 4945 | 8767 | * | * | * | * | * | * | * | * | * | * | * | * | * | |
Shear Strength Lbs 18-8 SS | * | * | * | * | * | * | * | 250 | 460 | 670 | 1090 | 1600 | 2425 | 3400 | 4100 | 6300 | 9500 | 11500 | 15800 | 18800 | |
Shear Strength Lbs 420 SS | * | * | * | * | * | * | * | 430 | 800 | 1150 | 1875 | 2750 | 4150 | 5850 | 7050 | 10800 | 16300 | 19800 | 27100 | 46000 |
