G5 + G9 Glass Reinforced Melamine
↓ G9 Rods & Sheets ↓
NEMA grades G5 and G9 Glass-Cloth-Reinforced Melamine has a natural color of grayish brown. These grades are composed of a continuous glass woven cloth base impregnated with a melamine resin binder. Melamine resins are the hardest, most rigid and abrasion-resistant of the standard resins employed in the production of industrial laminates. However, prolonged exposure to high temperature can adversely affect its mechanical and electrical strength properties. Arc resistance, however, may remain unaffected despite excessive thermal exposure. g5 and G9 is also caustic resistant. G9 is more resistant to the elements of the environment. Therefore, G9 can be safely substituted where G5 is called for.
NEMA G-5 certs to MIL-I-24768/8 GMG, IEC 60893-3 Type 3 MF GC 201
NEMA G-9 certs to MIL-I-24768/1 GME, IEC 60893-3 Type 3 MF GC 201
Technical Data • Chemical Resistance • G9 90° Angles
| G9 Round Rods - 4 Foot Standard Lengths | |||
| Part # | Diameter (in.) | Price Per Foot | Order Online |
|---|---|---|---|
| KR-1258 | .062" | $3.93 | Add to Order |
| KR-1259 | .093" | $3.43 | Add to Order |
| KR-1260 | .125" | $3.48 | Add to Order |
| KR-1261 | .156" | $3.59 | Add to Order |
| KR-1262 | .187" | $5.67 | Add to Order |
| KR-1263 | .250" | $6.58 | Add to Order |
| KR-1264 | .312" | $8.09 | Add to Order |
| KR-1265 | .375" | $10.19 | Add to Order |
| KR-1266 | .437" | $14.12 | Add to Order |
| KR-1267 | .500" | $16.12 | Add to Order |
| KR-886J | .563" | $21.50 | Add to Order |
| KR-1268 | .625" | $25.04 | Add to Order |
| KR-1269 | .750" | $33.07 | Add to Order |
| KR-1270 | .875" | $41.83 | Add to Order |
| KR-1271 | 1.000" | $35.33 | Add to Order |
| KR-1272 | 1.125" | $40.95 | Add to Order |
| KR-1270A | 1.250" | $47.29 | Add to Order |
| KR-886F | 1.375" | $56.45 | Add to Order |
| KR-1271A | 1.500" | $66.92 | Add to Order |
| KR-1272A | 1.625" | $76.18 | Add to Order |
| KR-1273 | 1.750" | $94.02 | Add to Order |
| KR-1274 | 2.000" | $140.79 | Add to Order |
| KR-1275 | 2.250" | $175.97 | Add to Order |
| KR-1276 | 2.500" | $217.13 | Add to Order |
| Tolerances | |||
| Under 1.375" Dia. | ±.001" | ||
| 1.375" Dia. & Over | ±.003" | ||
| Rev. 01-22 | |||
| G9
Sheets / Plates Thickness Tolerances |
|||||
| Part # | Thickness (in.) | Width (in.) | Length (in.) | Price | Order Online |
|---|---|---|---|---|---|
| KS-5863 | .031 | 12 | 12 | $14.50 | Add to Order |
| KS-1938 | .063 | 12 | 12 | $30.74 | Add to Order |
| KS-1952 | .125 | 12 | 12 | $50.16 | Add to Order |
| KS-1959 | .188 | 12 | 12 | $40.93 | Add to Order |
| KS-1966 | .250 | 12 | 12 | $133.27 | Add to Order |
| KS-1980 | .375 | 12 | 12 | $175.37 | Add to Order |
| KS-1988 | .500 | 12 | 12 | $241.46 | Add to Order |
| KS-5871 | .031 | 12 | 24 | $55.34 | Add to Order |
| KS-1939 | .063 | 12 | 24 | $57.78 | Add to Order |
| KS-1953 | .125 | 12 | 24 | $48.00 | Add to Order |
| KS-1960 | .188 | 12 | 24 | $80.91 | Add to Order |
| KS-1967 | .250 | 12 | 24 | $115.39 | Add to Order |
| KS-1982 | .375 | 12 | 24 | $173.14 | Add to Order |
| KS-1989 | .500 | 12 | 24 | $432.07 | Add to Order |
| KS-1941 | .063 | 12 | 48 | $198.50 | Add to Order |
| KS-1948 | .094 | 12 | 48 | $112.74 | Add to Order |
| KS-1955 | .125 | 12 | 48 | $347.64 | Add to Order |
| KS-1969 | .250 | 12 | 48 | $679.80 | Add to Order |
| KS-5879 | .031 | 24 | 24 | $51.48 | Add to Order |
| KS-1942 | .063 | 24 | 24 | $66.17 | Add to Order |
| KS-1956 | .125 | 24 | 24 | $119.32 | Add to Order |
| KS-1963 | .188 | 24 | 24 | $200.79 | Add to Order |
| KS-1970 | .250 | 24 | 24 | $286.32 | Add to Order |
| KS-1985 | .375 | 24 | 24 | $583.01 | Add to Order |
| KS-1992 | .500 | 24 | 24 | $812.59 | Add to Order |
| KS-5887 | .031 | 24 | 36 | $61.25 | Add to Order |
| KS-1943 | .063 | 24 | 36 | $133.07 | Add to Order |
| KS-1957 | .125 | 24 | 36 | $144.82 | Add to Order |
| KS-1964 | .188 | 24 | 36 | $243.70 | Add to Order |
| KS-1971 | .250 | 24 | 36 | $347.54 | Add to Order |
| KS-1986 | .375 | 24 | 36 | $957.89 | Add to Order |
| KS-1993 | .500 | 24 | 36 | $1,322.35 | Add to Order |
| KS-1944 | .063 | 24 | 48 | $382.26 | Add to Order |
| KS-1958 | .125 | 24 | 48 | $679.80 | Add to Order |
| KS-1972 | .250 | 24 | 48 | $1,346.14 | Add to Order |
| KS-5710 | .062 | 36 | 48 | $144.82 | Add to Order |
| KS-5972 | .094 | 36 | 48 | $224.47 | Add to Order |
| KS-5897 | .125 | 36 | 48 | $326.56 | Add to Order |
| KS-5898 | .188 | 36 | 48 | $491.20 | Add to Order |
| KS-5899 | .250 | 36 | 48 | $603.34 | Add to Order |
| KS-5901 | .375 | 36 | 48 | $693.86 | Add to Order |
| KS-5975 | .500 | 36 | 48 | $1,313.46 | Add to Order |
| KS-5976 | .625 | 36 | 48 | $1,508.40 | Add to Order |
| KS-5977 | .750 | 36 | 48 | $1,810.06 | Add to Order |
| KS-5978 | .875 | 36 | 48 | $2,111.74 | Add to Order |
| KS-5979 | 1.00 | 36 | 48 | $2,411.47 | Add to Order |
| KS-5980 | 1.25 | 36 | 48 | $3,016.78 | Add to Order |
| KS-5981 | 1.50 | 36 | 48 | $3,620.11 | Add to Order |
| KS-5625CE | 1.75 | 36 | 48 | $4,223.50 | Add to Order |
| KS-5982 | 2.00 | 36 | 48 | $3,640.46 | Add to Order |
| Rev. 10-23, 05-23, 04-23, 10-22 | |||||
| Plus/Minus | .031 ± .005" | .062 ± .0075" | .093 ± .009" | .125 ± .012" |
| .156 ± .015" | .188 ± .019" | .250 ± .022" | .313 ± .026" | .375 ± .030" |
| .438 ± .033" | .500 ± .036" | .625 ± .040" | .750 ± .043" | .875 ± .046" |
| 1.00 ± .049" | 1.25 ± .055" | 1.50 ± .061" | 1.75 ± .065" | 2.00 ± .067" |
