5086-H32 Aluminum Sheets and Plates

5086 Aluminum Sheets

5086-H32 Aluminum Sheets, Marine Grade

Unpolished Mill Finish, H32 Temper, ASTM B209

Width and Length tolerance is +/-.063

Technical Data

 Indicates, Ships Motor Cargo

Part # Thickness Thickness Tolerance Width Length Price Each Order Online
MS-9472 0.063" +/-.003 2" 24" $26.66 Add to Order
MS-9473 0.063" +/ -.003 4" 24" $49.52 Add to Order
MS-12000 0.063" +/ -.003 6" 6" $22.86 Add to Order
MS-9474 0.063" +/-.003 6" 12" $38.10 Add to Order
MS-9475 0.063" +/ -.003 6" 24" $61.70 Add to Order
MS-2535 0.063" +/ -.003 12" 12" $95.93 Add to Order
MS-2606 0.063" +/-.003 12" 24" $125.71 Add to Order
MS-2611 0.063" +/-.003 24" 24" $215.98 Add to Order
MS-2433 0.063" +/-.003 24" 48" $256.67 Add to Order
MS-9476 0.090" +/ -.005 2" 24" $34.98 Add to Order
MS-9477 0.090" +/ -.005 4" 24" $64.94 Add to Order
MS-12001 0.090" +/-.005 6" 6" $29.98 Add to Order
MS-9478 0.090" +/ -.005 6" 12" $49.96 Add to Order
MS-9479 0.090" +/ -.005 6" 24" $80.94 Add to Order
MS-2534 0.090" +/ -.0045 12" 12" $83.94 Add to Order
MS-2605 0.090" +/ -.0045 12" 24" $187.35 Add to Order
MS-2633 0.090" +/-.0045 24" 24" $370.95 Add to Order
MS-2432 0.090" +/-.0045 24" 48" $661.98 Add to Order
MS-717 0.090" +/-.0045 48" 96" $562.32 Add to Order
MS-709 0.090" +/-.0045 48" 144" $828.48 Add to Order
MS-9480 0.125" +/ -.006 2" 24" $35.86 Add to Order
MS-9481 0.125" +/ -.006 4" 24" $66.62 Add to Order
MS-12002 0.125" +/-.006 6" 6" $30.74 Add to Order
MS-9482 0.125" +/ -.006 6" 12" $51.24 Add to Order
MS-9483 0.125" +/ -.006 6" 24" $83.00 Add to Order
MS-2618 0.125" +/-.0055 12" 12" $102.48 Add to Order
MS-2604 0.125" +/-.0055 12" 24" $192.15 Add to Order
MS-2632 0.125" +/-.0055 24" 24" $345.88 Add to Order
MS-2422 0.125" +/-.0055 24" 48" $678.93 Add to Order
MS-707 0.125" +/-.0055 48" 96" $795.26 Add to Order
MS-7690 0.125" +/-.0055 48" 120" $981.62 Add to Order
MS-706 0.125" +/-.0055 48" 144" $1,154.62 Add to Order
MS-9484 0.190" +/-.009 2" 24" $43.66 Add to Order
MS-9485 0.190" +/-.009 4" 24" $81.10 Add to Order
MS-12003Q 0.190" +/-.009 6" 6" $37.44 Add to Order
MS-9486 0.190" +/-.009 6" 12" $62.38 Add to Order
MS-9487 0.190" +/-.009 6" 24" $101.06 Add to Order
MS-2608 0.190" +/-.009 12" 12" $99.82 Add to Order
MS-2626 0.190" +/-.009 12" 24" $187.16 Add to Order
MS-2631 0.190" +/-.009 24" 24" $336.88 Add to Order
MS-2430 0.190" +/-.009 24" 48" $411.02 Add to Order
MS-9488 0.250" +/-.014 2" 24" $73.56 Add to Order
MS-9489 0.250" +/-.014 4" 24" $114.42 Add to Order
MS-12004H 0.250" +/-.014 6" 6" $57.22 Add to Order
MS-9490 0.250" +/-.014 6" 12" $98.08 Add to Order
MS-9491 0.250" +/-.014 6" 24" $148.76 Add to Order
MS-2607 0.250" +/-.014 12" 12" $154.48 Add to Order
MS-2628 0.250" +/-.014 12" 24" $277.90 Add to Order
MS-2434 0.250" +/-.014 24" 24" $490.40 Add to Order
MS-2438 0.250" +/-.014 24" 48" $915.40 Add to Order
MS-7697 0.250" +/-.014 48" 144" $2,244.16
MS-9492 0.375" +/-.017 2" 24" $94.30 Add to Order
MS-9493 0.375" +/-.017 4" 24" $136.20 Add to Order
MS-12009Q 0.375" +/-.017 6" 6" $73.34 Add to Order
MS-9494 0.375" +/-.017 6" 12" $115.24 Add to Order
MS-9495 0.375" +/-.017 6" 24" $201.16 Add to Order
MS-9496 0.375" +/-.017 12" 12" $199.06 Add to Order
MS-9497 0.375" +/-.017 12" 24" $356.22 Add to Order
MS-9498 0.375" +/-.017 24" 24" $628.64 Add to Order
MS-9499 0.375" +/-.017 24" 48" $1,173.44 Add to Order
MS-9500 0.500" +/-.023 2" 24" $121.92 Add to Order
MS-9501 0.500" +/-.023 4" 24" $176.12 Add to Order
MS-12010 0.500" +/-.023 6" 6" $94.84 Add to Order
MS-9502 0.500" +/-.023 6" 12" $149.02 Add to Order
MS-9503 0.500" +/-.023 6" 24" $273.66 Add to Order
MS-9504 0.500" +/-.023 12" 12" $270.94 Add to Order
MS-9505 0.500" +/-.023 12" 24" $487.70 Add to Order
MS-9506 0.500" +/-.023 24" 24" $839.94 Add to Order
MS-9507 0.500" +/-.023 24" 48" $1,544.40 Add to Order
MS-9508 0.500" +/-.023 2" 24" $196.08 Add to Order
MS-9509 0.500" +/-.023 4" 24" $274.52 Add to Order
MS-12011 0.500" +/-.023 6" 6" $156.86 Add to Order
MS-9510 0.500" +/-.023 6" 12" $396.08 Add to Order
MS-9511 0.500" +/-.023 6" 24" $396.08 Add to Order
MS-9512 0.500" +/-.023 12" 12" $392.16 Add to Order
MS-9513 0.750" +/-.031 12" 24" $705.88 Add to Order
MS-9514 0.750" +/-.031 24" 24" $1,215.68 Add to Order
MS-9515 0.750" +/-.031 24" 48" $2,235.30 Add to Order
MS-9516 1.00" +/-.039 2" 24" $300.50 Add to Order
MS-9517 1.00" +/-.039 4" 24" $420.70 Add to Order
MS-12012 1.00" +/-.039 6" 6" $240.40 Add to Order
MS-9518 1.00" +/-.039 6" 12" $360.60 Add to Order
MS-9519 1.00" +/-.039 6" 24" $607.02 Add to Order
MS-9520 1.00" +/-.039 12" 12" $601.02 Add to Order
MS-9521 1.00" +/-.039 12" 24" $1,081.82 Add to Order
MS-9522 1.00" +/-.039 24" 24" $1,863.14 Add to Order
MS-9523 1.00" +/-.039 24" 48" $3,425.78 Add to Order
Rev. 06-24, 03-24, 10-23, 08-23
<<
