1018 Carbon Steel Metric Threaded Rods
1018 is among the most commonly available grades available in the world.
| Metric Thread Low Strength Steel Threaded
Rods RH Rockwell B49, Tensile Strength 50,000 psi |
||||
| Part # | Length | Thread Pitch (mm) | Price Each | Order Online |
|---|---|---|---|---|
| ↓ M4 Thread ↓ | ||||
| MTR-5626 | 150 mm | 0.5 | $33.23 | Add to Order |
| MTR-5627 | 300 mm | 0.5 | $54.18 | Add to Order |
| MTR-5628 | 1 m | 0.5 | $82.01 | Add to Order |
| ↓ M5 Thread Size ↓ | ||||
| MTR-5629 | 50 mm | 0.5 | $18.20 | Add to Order |
| MTR-5630 | 80 mm | 0.5 | $20.25 | Add to Order |
| MTR-5631 | 100 mm | 0.5 | $23.31 | Add to Order |
| MTR-5632 | 300 mm | 0.5 | $32.45 | Add to Order |
| MTR-5633 | 1 m | 0.5 | $142.31 | Add to Order |
| ↓ M6 Thread Size ↓ | ||||
| MTR-5634 | 1 m | 0.75 | $155.63 | Add to Order |
| ↓ M8 Thread Size ↓ | ||||
| MTR-5635 | 30 mm | 1 | $25.61 | Add to Order |
| MTR-5636 | 40 mm | 1 | $26.78 | Add to Order |
| MTR-5637 | 50 mm | 1 | $27.92 | Add to Order |
| MTR-5638 | 80 mm | 1 | $15.41 | Add to Order |
| MTR-5639 | 150 mm | 1 | $17.87 | Add to Order |
| MTR-5640 | 300 mm | 1 | $31.37 | Add to Order |
| MTR-5641 | 1 m | 1 | $55.71 | Add to Order |
| ↓ M10 Thread Size ↓ | ||||
| MTR-5642 | 40 mm | 1.25 | $29.09 | Add to Order |
| MTR-5643 | 50 mm | 1.25 | $30.26 | Add to Order |
| MTR-5644 | 60 mm | 1.25 | $32.99 | Add to Order |
| MTR-5645 | 80 mm | 1 | $17.87 | Add to Order |
| MTR-5646 | 80 mm | 1.25 | $19.78 | Add to Order |
| MTR-5647 | 150 mm | 1 | $21.69 | Add to Order |
| MTR-5648 | 150 mm | 1.25 | $25.16 | Add to Order |
| MTR-5649 | 300 mm | 1 | $41.60 | Add to Order |
| MTR-5650 | 300 mm | 1.25 | $45.83 | Add to Order |
| MTR-5651 | 1 m | 1 | $99.52 | Add to Order |
| MTR-5652 | 1 m | 1.25 | $91.60 | Add to Order |
| ↓ M12 Thread Size ↓ | ||||
| MTR-5653 | 40 mm | 1.25 | $33.37 | Add to Order |
| MTR-5654 | 50 mm | 1.25 | $34.52 | Add to Order |
| MTR-5655 | 60 mm | 1.25 | $36.86 | Add to Order |
| MTR-5656 | 150 mm | 1 | $55.51 | Add to Order |
| MTR-5657 | 150 mm | 1.25 | $31.14 | Add to Order |
| MTR-5658 | 150 mm | 1.5 | $27.52 | Add to Order |
| MTR-5659 | 300 mm | 1 | $93.31 | Add to Order |
| MTR-5660 | 300 mm | 1.25 | $55.15 | Add to Order |
| MTR-5661 | 300 mm | 1.5 | $39.17 | Add to Order |
| MTR-5662 | 1 m | 1 | $54.65 | Add to Order |
| MTR-5663 | 1 m | 1.25 | $153.72 | Add to Order |
| MTR-5664 | 1 m | 1.5 | $92.05 | Add to Order |
| ↓ M14 Thread Size ↓ | ||||
| MTR-5665 | 150 mm | 1.5 | $25.38 | Add to Order |
| MTR-5666 | 300 mm | 1.5 | $60.50 | Add to Order |
| MTR-5667 | 1 m | 1.5 | $110.57 | Add to Order |
| ↓ M16 Thread Size ↓ | ||||
| MTR-5668 | 60 mm | 1.5 | $61.29 | Add to Order |
| MTR-5669 | 80 mm | 1.5 | $79.52 | Add to Order |
| MTR-5670 | 100 mm | 1.5 | $92.32 | Add to Order |
| MTR-5671 | 150 mm | 1.5 | $29.52 | Add to Order |
| MTR-5672 | 300 mm | 1.5 | $58.73 | Add to Order |
| MTR-5673 | 1 m | 1.5 | $91.71 | Add to Order |
| ↓ M18 Thread Size ↓ | ||||
| MTR-5674 | 150 mm | 1.5 | $40.79 | Add to Order |
| MTR-5675 | 300 mm | 1.5 | $103.16 | Add to Order |
| MTR-5676 | 1 m | 1.5 | $286.02 | Add to Order |
| ↓ M20 Thread Size ↓ | ||||
| MTR-5677 | 80 mm | 1.5 | $79.92 | Add to Order |
| MTR-5678 | 100 mm | 1.5 | $95.83 | Add to Order |
| MTR-5679 | 300 mm | 1.5 | $111.62 | Add to Order |
| MTR-5680 | 1 m | 1.5 | $189.77 | Add to Order |
| ↓ M22 Thread Size ↓ | ||||
| MTR-5681 | 150 mm | 1.5 | $96.64 | Add to Order |
| MTR-5682 | 300 mm | 1.5 | $127.06 | Add to Order |
| MTR-5683 | 1 m | 1.5 | $159.86 | Add to Order |
| ↓ M24 Thread Size ↓ | ||||
| MTR-5684 | 150 mm | 1.5 | $100.67 | Add to Order |
| MTR-5685 | 300 mm | 1.5 | $133.76 | Add to Order |
| MTR-5686 | 300 mm | 2 | $121.41 | Add to Order |
| MTR-5687 | 1 m | 1.5 | $180.00 | Add to Order |
| MTR-5688 | 1 m | 2 | $225.00 | Add to Order |
| ↓ M27 Thread Size ↓ | ||||
| MTR-5689 | 300 mm | 2 | $149.42 | Add to Order |
| MTR-5690 | 1 m | 2 | $174.94 | Add to Order |
| ↓ M30 Thread Size ↓ | ||||
| MTR-5691 | 300 mm | 2 | $172.69 | Add to Order |
| MTR-5692 | 1 m | 1.5 | $244.28 | Add to Order |
| MTR-5693 | 1 m | 2 | $282.85 | Add to Order |
| ↓ M36 Thread Size ↓ | ||||
| MTR-5694 | 300 mm | 3 | $162.86 | Add to Order |
| MTR-5695 | 1 m | 3 | $179.84 | Add to Order |
| Rev. 04-23, 11-22, 02-22, 06-21 | ||||
| Metric Left Handed Low Strength Steel Threaded Rods Rockwell B49, Tensile Strength 50,000 psi |
||||
| Part # | Length | Thread Pitch (mm) | Price Each | Order Online |
|---|---|---|---|---|
| ↓ M6 Thread ↓ | ||||
| MTR-5738 | 1 m | 1 | $28.90 | Add to Order |
| ↓ M10 Thread Size ↓ | ||||
| MTR-5740 | 1 m | 1.5 | $32.30 | Add to Order |
| ↓ M12 Thread Size ↓ | ||||
| MTR-5741 | 300 mm | 1.75 | $30.07 | Add to Order |
| MTR-5742 | 1 m | 1.75 | $40.09 | Add to Order |
| ↓ M14 Thread Size ↓ | ||||
| MTR-5743 | 1 m | 2 | $57.92 | Add to Order |
| ↓ M16 Thread Size ↓ | ||||
| MTR-5744 | 300 mm | 2 | $53.70 | Add to Order |
| MTR-5745 | 1 m | 2 | $71.59 | Add to Order |
| ↓ M20 Thread Size ↓ | ||||
| MTR-5746 | 300 mm | 2.5 | $80.18 | Add to Order |
| MTR-5747 | 1 m | 2.5 | $114.55 | Add to Order |
| ↓ M24 Thread Size ↓ | ||||
| MTR-5748 | 1 m | 3 | $210.00 | Add to Order |
| Rev. 04-23, 11-22, 02-22 | ||||
| Tensile Strength | 64,000 PSI |
| Yield Strength | 44,000 PSI |
| Elongation | 35% |
| Brinnell | 126 HB |
The following specifications cover Carbon Steel 1018
AMS 5069ASTM A29 (1018)
ASTM A510 (1018)
ASTM A512 (1018)
ASTM A513
ASTM A519 (1018)
ASTM A544 (1018)
ASTM A545 (1018)
ASTM A548 (1018)
ASTM A549 (1018)
ASTM A576 (1018)
ASTM A635 (1018)
ASTM A659 (1018)
MIL J-1397 (1018)
MIL J-403 (1018)
MIL J-412 (1018)
MIL S-11310 (CS 1018)
SAE J1397
SAE J403
SAE J412
UNS G10180
