PEEK Tapes
ASTM D1000, ASTM D3759, ASTM D140
Tensile : 36 Lb/In
Elongation: 165%
Dielectric Strength: 8800
V/Mil
Max. Oper. Temp 350F- Acrylic,
Silicone 450F
| Victrex
PEEK
Pressure Sensitive Tapes
Abrasion Resistant/One Side Adhesive |
||||||
| Part # | Tape Width | Adhesive Thickness | Overall Thickness | Length | Price Each | Order Online |
|---|---|---|---|---|---|---|
| ↓ Acrylic Adhesive ↓ | ||||||
| TAPE-530 | .500" | .002" | .004" | 15' | $26.51 | Add to Order |
| TAPE-531 | .500" | .005" | .007" | 15' | $32.33 | Add to Order |
| TAPE-532 | .500" | .010" | .012" | 15' | $47.68 | Add to Order |
| TAPE-539 | 1.00" | .002" | .004" | 15' | $53.01 | Add to Order |
| TAPE-541 | 1.00" | .005" | .007" | 15' | $48.46 | Add to Order |
| TAPE-542 | 1.00" | .005" | .007" | 108' | $221.76 | Add to Order |
| TAPE-543 | 1.00" | .010" | .012" | 15' | $95.33 | Add to Order |
| TAPE-560 | 2.00" | .002" | .004" | 15' | $129.33 | Add to Order |
| TAPE-561 | 2.00" | .005" | .007" | 15' | $129.33 | Add to Order |
| TAPE-562 | 2.00" | .010" | .012" | 15' | $190.64 | Add to Order |
| TAPE-571 | 6.00" | .002" | .004" | 6.00" | $12.72 | Add to Order |
| TAPE-572 | 6.00" | .005" | .007" | 6.00" | $30.87 | Add to Order |
| TAPE-573 | 6.00" | .010" | .012" | 6.00" | $35.39 | Add to Order |
| TAPE-551 | 12.00" | .002" | .004" | 12.00" | $38.16 | Add to Order |
| TAPE-552 | 12.00" | .005" | .007" | 12.00" | $81.83 | Add to Order |
| TAPE-553 | 12.00" | .010" | .012" | 12.00" | $194.49 | Add to Order |
| ↓ Silicone Adhesive ↓ | ||||||
| TAPE-533 | .500" | .002" | .004" | 15' | $39.78 | Add to Order |
| TAPE-534 | .500" | .005" | .007" | 15' | $47.86 | Add to Order |
| TAPE-535 | .500" | .010" | .012" | 15' | $45.00 | Add to Order |
| TAPE-544 | 1.00" | .002" | .004" | 15' | $79.49 | Add to Order |
| TAPE-549 | 1.00" | .005" | .007" | 15' | $95.69 | Add to Order |
| TAPE-550 | 1.00" | .010" | .012" | 15' | $90.00 | Add to Order |
| TAPE-548 | 1.00" | .010" | .012" | 108' | $324.00 | Add to Order |
| TAPE-563 | 2.00" | .002" | .004" | 15' | $158.98 | Add to Order |
| TAPE-569 | 2.00" | .005" | .007" | 15' | $191.41 | Add to Order |
| TAPE-570 | 2.00" | .010" | .012" | 15' | $180.00 | Add to Order |
| TAPE-568 | 2.00" | .010" | .012" | 108' | $648.00 | Add to Order |
| TAPE-574 | 6.00" | .002" | .004" | 6.00" | $21.71 | Add to Order |
| TAPE-576 | 6.00" | .005" | .007" | 6.00" | $28.71 | Add to Order |
| TAPE-575 | 6.00" | .010" | .012" | 6.00" | $48.65 | Add to Order |
| TAPE-554 | 12.00" | .002" | .004" | 12.00" | $86.72 | Add to Order |
| TAPE-555 | 12.00" | .005" | .007" | 12.00" | $114.75 | Add to Order |
| TAPE-556 | 12.00" | .010" | .012" | 12.00" | $194.49 | Add to Order |
| Rev. 02-23, 02-22 | ||||||
