Copper Foil - Conductive Tapes
The acrylic adhesive which is uniformly dispersed with conductive spheres to provide a very low rate of electrical resistance through the tape.
1 Oz Copper Foil, 60 Lb Paper Release Liner
Adhesion: 40 ounces per inch (to stainless steel)
Tensile Strength: 25 pounds per inch (longitudinal)
Service/Operating Temperature: up to 310F
Elongation: 5%
Electrical Resistance: 0.003 ohms/sq in.
Core: 3" diameter neutral
| Copper
Foil Tapes
Conductive Acrylic Adhesive |
||||||
| Part # | Tape Width | Adhesive Thickness | Overall Thickness | Length | Price Each | Order Online |
|---|---|---|---|---|---|---|
| TAPE-192 | .250" | .0021" | .0035" | 18' | $28.67 | Add to Order |
| TAPE-194 | .250" | .0021" | .0035" | 54' | $44.69 | Add to Order |
| TAPE-195 | .500" | .0021" | .0035" | 18' | $50.27 | Add to Order |
| TAPE-197 | .500" | .0021" | .0035" | 54' | $87.44 | Add to Order |
| TAPE-199 | .750" | .0021" | .0035" | 18' | $68.54 | Add to Order |
| TAPE-201 | .750" | .0021" | .0035" | 54' | $134.46 | Add to Order |
| TAPE-204 | 1.00" | .0021" | .0035" | 18' | $72.77 | Add to Order |
| TAPE-206 | 1.00" | .0021" | .0035" | 54' | $168.17 | Add to Order |
| TAPE-208 | 2.00" | .0021" | .0035" | 18' | $139.41 | Add to Order |
| TAPE-210 | 2.00" | .0021" | .0035" | 54' | $347.63 | Add to Order |
| TAPE-214 | 3.00" | .0021" | .0035" | 18' | $203.09 | Add to Order |
| TAPE-212 | 3.00" | .0021" | .0035" | 54' | $477.44 | Add to Order |
| Rev. 02-22 | ||||||
