316 Stainless Steel Shim

Technical Data

316 stainless steel shim

316 Stainless Steel Shim

Full Hard Temper: AMS-5524 ASTM-A-240
Part # Thickness Width (in.) Length (in.) Price Ea. Order Online
MS-8931 0.002 6.00 50 $27.12 Add to Order
MS-8945 0.002 6.00 100 $28.58 Add to Order
MS-8959 0.002 12.00 50 $87.56 Add to Order
MS-8973 0.002 12.00 100 $58.68 Add to Order
MS-8932 0.003 6.00 50 $35.52 Add to Order
MS-8946 0.003 6.00 100 $29.30 Add to Order
MS-9464 0.003 8.00 12 $24.06 Add to Order
MS-8960 0.003 12.00 50 $95.54 Add to Order
MS-8974 0.003 12.00 100 $140.83 Add to Order
MS-8933 0.004 6.00 50 $72.80 Add to Order
MS-8947 0.004 6.00 100 $47.40 Add to Order
MS-8961 0.004 12.00 50 $180.55 Add to Order
MS-8975 0.004 12.00 100 $143.69 Add to Order
MS-8934 0.005 6.00 50 $36.89 Add to Order
MS-8948 0.005 6.00 100 $36.00 Add to Order
MS-8962 0.005 12.00 50 $52.88 Add to Order
MS-8976 0.005 12.00 100 $93.77 Add to Order
MS-8936 0.007 6.00 50 $136.11 Add to Order
MS-8950 0.007 6.00 100 $165.16 Add to Order
MS-8964 0.007 12.00 50 $145.02 Add to Order
MS-8978 0.007 12.00 100 173.15 Add to Order
MS-8938 0.010 6.00 50 $43.95 Add to Order
MS-8952 0.010 6.00 100 $68.58 Add to Order
MS-8966 0.010 12.00 50 $69.93 Add to Order
MS-8980 0.010 12.00 100 $119.67 Add to Order
MS-8940 0.015 6.00 50 $131.72 Add to Order
MS-8954 0.015 6.00 100 $90.12 Add to Order
MS-8968 0.015 12.00 50 $234.40 Add to Order
MS-8982 0.015 12.00 100 $517.10 Add to Order
MS-8941 0.020 6.00 50 $84.04 Add to Order
MS-8955 0.020 6.00 100 $87.96 Add to Order
MS-8969 0.020 12.00 50 $88.18 Add to Order
MS-8983 0.020 12.00 100 $153.34 Add to Order
MS-8942 0.025 6.00 50 $160.58 Add to Order
MS-8956 0.025 6.00 100 $289.10 Add to Order
MS-8970 0.025 12.00 50 $379.40 Add to Order
MS-8984 0.025 12.00 100 $190.85 Add to Order
Rev. 07-25, 03-25, 06-24, 05-23



Thickness Tolerances
Width Tolerance +/-.005", Length Tolerance +/-.125"
.001, .002 + / - 0.0001"
.003 + / - 0.00015"
.004 + / - 0.0002"
.005 + / - 0.00025"
.006-.010 + / - 0.0005"
.012 + / - 0.0006"
.015-.031 + / - 0.001"



316 Stainless Steel Shim



316 Stainless Steel Shim, Full Hard Temper

ASTM A666
Part # Thickness Width (in.) Length (in.) Price Ea. Order Online
MS-9462 0.001 8.00 12 $23.66 Add to Order
MS-9463 0.002 8.00 12 $21.12 Add to Order
MS-9446 0.002 24.00 50 $178.74 Add to Order
MS-9454 0.002 24.00 100 $334.00 Add to Order
MS-9447 0.003 24.00 50 $204.70 Add to Order
MS-9455 0.003 24.00 100 $383.38 Add to Order
MS-9465 0.004 8.00 12 $26.46 Add to Order
MS-9448 0.004 24.00 50 $242.20 Add to Order
MS-9456 0.004 24.00 100 $453.68 Add to Order
MS-9466 0.005 8.00 12 $26.52 Add to Order
MS-9449 0.005 24.00 50 $250.60 Add to Order
MS-9457 0.005 24.00 100 $469.30 Add to Order
MS-9467 0.007 8.00 12 $34.66 Add to Order
MS-9450 0.007 24.00 50 $313.98 Add to Order
MS-9457B 0.007 24.00 100 $590.66 Add to Order
MS-9468 0.010 8.00 12 $38.44 Add to Order
MS-9450B 0.010 24.00 50 $339.86 Add to Order
MS-9458 0.010 24.00 100 $639.54 Add to Order
MS-9469 0.012 8.00 12 $42.22 Add to Order
MS-9470 0.015 8.00 12 $43.98 Add to Order
MS-9451 0.015 24.00 50 $430.80 Add to Order
MS-9459 0.015 24.00 100 $814.06 Add to Order
MS-9471 0.020 8.00 12 $51.62 Add to Order
MS-9452 0.020 24.00 50 $445.76 Add to Order
MS-9460 0.020 24.00 100 $872.32 Add to Order
MS-9453 0.025 24.00 50 $613.60 Add to Order
MS-9461 0.025 24.00 100 $1,163.44 Add to Order
Rev. 03-25, 05-23, 09-22, 10-21



316 Stainless Steel Shim, Soft Temper

ASTM A240 and ASTM A666
Part # Thickness Width (in.) Length (in.) Price Each Order Online
MS-9406 0.004 2.00 60 $40.46 Add to Order
MS-9416 0.004 2.00 120 $67.42 Add to Order
MS-9418 0.004 6.00 60 $106.46 Add to Order
MS-9417 0.004 6.00 120 $177.44 Add to Order
MS-9407 0.005 2.00 60 $46.44 Add to Order
MS-9421 0.005 2.00 120 $77.40 Add to Order
MS-9419 0.005 6.00 60 $122.20 Add to Order
MS-9420 0.005 6.00 120 $203.66 Add to Order
MS-9408 0.006 2.00 60 $48.48 Add to Order
MS-9422 0.006 2.00 120 $80.82 Add to Order
MS-9424 0.006 6.00 60 $127.60 Add to Order
MS-9423 0.006 6.00 120 $212.66 Add to Order
MS-9409 0.008 2.00 60 $60.94 Add to Order
MS-9427 0.008 2.00 120 $101.56 Add to Order
MS-9425 0.008 6.00 60 $160.36 Add to Order
MS-9426 0.008 6.00 120 $267.26 Add to Order
MS-9410 0.010 2.00 60 $61.12 Add to Order
MS-9428 0.010 2.00 120 $101.86 Add to Order
MS-9430 0.010 6.00 60 $160.82 Add to Order
MS-9429 0.010 6.00 120 $268.04 Add to Order
MS-9411 0.012 2.00 60 $67.90 Add to Order
MS-9433 0.012 2.00 120 $113.16 Add to Order
MS-9431 0.012 6.00 60 $178.66 Add to Order
MS-9432 0.012 6.00 120 $297.78 Add to Order
MS-9412 0.015 2.00 60 $76.18 Add to Order
MS-9434 0.015 2.00 120 $126.98 Add to Order
MS-9435 0.015 6.00 60 $200.48 Add to Order
MS-9445 0.015 6.00 120 $334.14 Add to Order
MS-9413 0.020 2.00 60 $94.32 Add to Order
MS-9438 0.020 2.00 120 $157.20 Add to Order
MS-9436 0.020 6.00 60 $248.20 Add to Order
MS-9437 0.020 6.00 120 $413.66 Add to Order
MS-9414 0.025 2.00 60 $110.94 Add to Order
MS-9439 0.025 2.00 120 $184.88 Add to Order
MS-9441 0.025 6.00 60 $291.92 Add to Order
MS-9440 0.025 6.00 120 $486.54 Add to Order
MS-9415 0.031 2.00 60 $130.96 Add to Order
MS-9444 0.031 2.00 120 $218.26 Add to Order
MS-9442 0.031 6.00 60 $344.62 Add to Order
MS-9443 0.031 6.00 120 $574.36 Add to Order
Rev. 05-23, 09-22, 10-21, 06-21
<<
