17-4PH Stainless Steel Plates
Type 17-4 is a martensitic precipitation hardening (maraging) steel that combines high strength and hardness with excellent corrosion resistance. A simple one-step aging treatment in the range of 900 to 1150 hardens the alloy to its design strength levels.
Also known as type 630, it can be precipitation hardened by a low cost treatment. 630 is magnetic in both the solution annealed and precipitation hardened conditions.
Magnetic - ASTM A693 - Annealed - Unpolished Mill Finish.
Chemical Composition:Chrome: 15.50 - 17.50
Nickel: 3.00 - 5.00
Carbon: .07 max.
Manganese: 1.00 max.
Silicon: 1.00 max.
Molybdenum: --
Copper: 3.00 - 5.00
| 17-4PH Stainless Steel Sheets & Plates | |||||
| Part # | Thickness | Width | Length | Price Each | Order Online |
|---|---|---|---|---|---|
| MS-9986 | .031" | 12.00" | 12.00" | $84.86 | Add to Order |
| MS-9987 | .031" | 12.00" | 24.00" | $154.28 | Add to Order |
| MS-9988 | .031" | 12.00" | 36.00" | $214.28 | Add to Order |
| MS-9989 | .040" | 12.00" | 12.00" | $99.86 | Add to Order |
| MS-9990 | .040" | 12.00" | 24.00" | $181.56 | Add to Order |
| MS-9991 | .040" | 12.00" | 36.00" | $252.18 | Add to Order |
| MS-9992 | .050" | 12.00" | 12.00" | $109.04 | Add to Order |
| MS-9993 | .050" | 12.00" | 24.00" | $198.26 | Add to Order |
| MS-9994 | .050" | 12.00" | 36.00" | $275.36 | Add to Order |
| MS-9995 | .062" | 12.00" | 12.00" | $133.28 | Add to Order |
| MS-9996 | .062" | 12.00" | 24.00" | $242.34 | Add to Order |
| MS-9997 | .062" | 12.00" | 36.00" | $336.58 | Add to Order |
| MS-9998 | .080" | 12.00" | 12.00" | $159.92 | Add to Order |
| MS-9999 | .080" | 12.00" | 24.00" | $290.76 | Add to Order |
| MS-10000 | .080" | 12.00" | 36.00" | $403.84 | Add to Order |
| MS-10001 | .090" | 12.00" | 12.00" | $175.92 | Add to Order |
| MS-10002 | .090" | 12.00" | 24.00" | $319.86 | Add to Order |
| MS-10003 | .090" | 12.00" | 36.00" | $444.24 | Add to Order |
| MS-10004 | .100" | 12.00" | 12.00" | $238.34 | Add to Order |
| MS-10005 | .100" | 12.00" | 24.00" | $433.34 | Add to Order |
| MS-10006 | .100" | 12.00" | 36.00" | $601.86 | Add to Order |
| MS-10007 | .125" | 12.00" | 12.00" | $246.04 | Add to Order |
| MS-10008 | .125" | 12.00" | 24.00" | $447.34 | Add to Order |
| MS-10009 | .125" | 12.00" | 36.00" | $621.30 | Add to Order |
| MS-7668 | .187" | 12.00" | 12.00" | $294.18 | Add to Order |
| MS-2243 | .187" | 12.00" | 24.00" | $534.86 | Add to Order |
| MS-7667 | .250" | 12.00" | 12.00" | $354.00 | Add to Order |
| MS-2250 | .250" | 12.00" | 24.00" | $644.00 | Add to Order |
| MS-2253 | .375" | 12.00" | 12.00" | $959.88 | Add to Order |
| MS-2258 | .375" | 12.00" | 24.00" | $1,745.24 | Add to Order |
| MS-2252 | .500" | 12.00" | 12.00" | $1,269.60 | Add to Order |
| MS-7638 | .500" | 12.00" | 24.00" | $2,308.36 | Add to Order |
| Rev. 05-23, 09-22, 02-22, 11-21 | |||||
Thickness Tolerances:
.187" - .250" (+.045")
.375" - .500" (.055")
Width and Length Tolerance : +/-.0625"
