Zinc-Plated Steel Spring Pins
| Zinc Plated Steel Slotted Spring Pins | |||||||
| Part # | Dia | Length | Wall Thickness | Breaking Strength LBS | Pkg Qty | Pkg Price | Order Online |
|---|---|---|---|---|---|---|---|
| SP-696 | 1/16" | 3/16" | 0.012" | 420 | 500 | $40.91 | Add to Order |
| SP-711 | 1/16" | 1/4" | 0.012" | 420 | 500 | $34.21 | Add to Order |
| SP-710 | 1/16" | 5/16" | 0.012" | 420 | 500 | $39.23 | Add to Order |
| SP-793 | 1/16" | 3/8" | 0.012" | 420 | 500 | $36.50 | Add to Order |
| SP-858 | 1/16" | 7/16" | 0.012" | 420 | 500 | $39.90 | Add to Order |
| SP-831 | 1/16" | 1/2" | 0.012" | 420 | 250 | $21.63 | Add to Order |
| SP-817 | 1/16" | 9/16" | 0.012" | 420 | 250 | $28.43 | Add to Order |
| SP-816 | 1/16" | 5/8" | 0.012" | 420 | 250 | $21.08 | Add to Order |
| SP-815 | 1/16" | 11/16" | 0.012" | 420 | 250 | $31.04 | Add to Order |
| SP-814 | 1/16" | 3/4" | 0.012" | 420 | 250 | $25.66 | Add to Order |
| SP-032 | 1/16" | 13/16" | 0.012" | 420 | 100 | $15.67 | Add to Order |
| SP-813 | 1/16" | 7/8" | 0.012" | 420 | 100 | $16.15 | Add to Order |
| SP-033 | 1/16" | 15/16" | 0.012" | 420 | 100 | $16.09 | Add to Order |
| SP-812 | 1/16" | 1" | 0.012" | 420 | 100 | $23.94 | Add to Order |
| SP-811 | 5/64" | 3/16" | 0.018" | 750 | 250 | $52.40 | Add to Order |
| SP-810 | 5/64" | 1/4" | 0.018" | 750 | 250 | $29.40 | Add to Order |
| SP-809 | 5/64" | 5/16" | 0.018" | 750 | 250 | $29.36 | Add to Order |
| SP-808 | 5/64" | 3/8" | 0.018" | 750 | 250 | $27.89 | Add to Order |
| SP-658 | 5/64" | 7/16" | 0.018" | 750 | 250 | $40.30 | Add to Order |
| SP-510 | 5/64" | 1/2" | 0.018" | 750 | 250 | $25.89 | Add to Order |
| SP-707 | 5/64" | 9/16" | 0.018" | 750 | 250 | $29.99 | Add to Order |
| SP-558 | 5/64" | 5/8" | 0.018" | 750 | 250 | $29.44 | Add to Order |
| SP-557 | 5/64" | 11/16" | 0.018" | 750 | 250 | $44.10 | Add to Order |
| SP-556 | 5/64" | 3/4" | 0.018" | 750 | 250 | $24.97 | Add to Order |
| SP-555 | 5/64" | 13/16" | 0.018" | 750 | 250 | $41.50 | Add to Order |
| SP-554 | 5/64" | 7/8" | 0.018" | 750 | 100 | $14.62 | Add to Order |
| SP-682 | 5/64" | 1" | 0.018" | 750 | 250 | $39.50 | Add to Order |
| SP-681 | 5/64" | 1 1/4" | 0.018" | 750 | 250 | $36.54 | Add to Order |
| SP-680 | 5/64" | 1 1/2" | 0.018" | 750 | 250 | $39.17 | Add to Order |
| SP-553 | 3/32" | 3/16" | 0.022" | 1,000 | 100 | $14.62 | Add to Order |
| SP-679 | 3/32" | 1/4" | 0.022" | 1,000 | 500 | $32.76 | Add to Order |
| SP-678 | 3/32" | 5/16" | 0.022" | 1,000 | 100 | $10.00 | Add to Order |
| SP-677 | 3/32" | 3/8" | 0.022" | 1,000 | 500 | $44.86 | Add to Order |
| SP-676 | 3/32" | 7/16" | 0.022" | 1,000 | 500 | $56.36 | Add to Order |
| SP-675 | 3/32" | 1/2" | 0.022" | 1,000 | 250 | $26.31 | Add to Order |
| SP-674 | 3/32" | 9/16" | 0.022" | 1,000 | 250 | $34.88 | Add to Order |
| SP-632 | 3/32" | 5/8" | 0.022" | 1,000 | 250 | $27.89 | Add to Order |
| SP-631 | 3/32" | 11/16" | 0.022" | 1,000 | 250 | $38.56 | Add to Order |
| SP-630 | 3/32" | 3/4" | 0.022" | 1,000 | 250 | $32.34 | Add to Order |
| SP-629 | 3/32" | 13/16" | 0.022" | 1,000 | 250 | $34.42 | Add to Order |
| SP-628 | 3/32" | 7/8" | 0.022" | 1,000 | 250 | $38.16 | Add to Order |
| SP-034 | 3/32" | 15/16" | 0.022" | 1,000 | 250 | $39.52 | Add to Order |
| SP-627 | 3/32" | 1" | 0.022" | 1,000 | 250 | $40.11 | Add to Order |
| SP-626 | 3/32" | 1 1/8" | 0.022" | 1,000 | 250 | $44.29 | Add to Order |
| SP-625 | 3/32" | 1 1/4" | 0.022" | 1,000 | 100 | $26.19 | Add to Order |
| SP-624 | 3/32" | 1 3/8" | 0.022" | 1,000 | 100 | $30.93 | Add to Order |
| SP-1155 | 3/32" | 1 1/2" | 0.022" | 1,000 | 100 | $23.69 | Add to Order |
| SP-659 | 1/8" | 1/4" | 0.028" | 1,750 | 250 | $45.61 | Add to Order |
| SP-645 | 1/8" | 5/16" | 0.028" | 1,750 | 250 | $36.37 | Add to Order |
| SP-644 | 1/8" | 3/8" | 0.028" | 1,750 | 250 | $20.54 | Add to Order |
| SP-643 | 1/8" | 7/16" | 0.028" | 1,750 | 250 | $32.40 | Add to Order |
| SP-642 | 1/8" | 1/2" | 0.028" | 1,750 | 250 | $22.70 | Add to Order |
| SP-641 | 1/8" | 9/16" | 0.028" | 1,750 | 250 | $30.22 | Add to Order |
| SP-640 | 1/8" | 5/8" | 0.028" | 1,750 | 250 | $24.42 | Add to Order |
| SP-639 | 1/8" | 11/16" | 0.028" | 1,750 | 250 | $31.94 | Add to Order |
| SP-638 | 1/8" | 3/4" | 0.028" | 1,750 | 250 | $30.41 | Add to Order |
| SP-637 | 1/8" | 13/16" | 0.028" | 1,750 | 250 | $45.65 | Add to Order |
| SP-671 | 1/8" | 7/8" | 0.028" | 1,750 | 250 | $40.47 | Add to Order |
| SP-036 | 1/8" | 15/16" | 0.028" | 1,750 | 100 | $21.23 | Add to Order |
| SP-646 | 1/8" | 1" | 0.028" | 1,750 | 250 | $37.86 | Add to Order |
| SP-648 | 1/8" | 1 1/8" | 0.028" | 1,750 | 100 | $27.28 | Add to Order |
| SP-683 | 1/8" | 1 1/4" | 0.028" | 1,750 | 100 | $20.41 | Add to Order |
| SP-660 | 1/8" | 1 3/8" | 0.028" | 1,750 | 100 | $20.39 | Add to Order |
| SP-672 | 1/8" | 1 1/2" | 0.028" | 1,750 | 100 | $26.04 | Add to Order |
| SP-684 | 1/8" | 1 5/8" | 0.028" | 1,750 | 100 | $31.00 | Add to Order |
| SP-670 | 1/8" | 1 3/4" | 0.028" | 1,750 | 100 | $28.48 | Add to Order |
| SP-669 | 1/8" | 1 7/8" | 0.028" | 1,750 | 100 | $33.10 | Add to Order |
| SP-668 | 1/8" | 2" | 0.028" | 1,750 | 100 | $28.90 | Add to Order |
| SP-667 | 1/8" | 2 1/4" | 0.028" | 1,750 | 100 | $14.01 | Add to Order |
| SP-047 | 5/32" | 3/8" | 0.032" | 2,500 | 100 | $23.75 | Add to Order |
| SP-049 | 5/32" | 7/16" | 0.032" | 2,500 | 100 | $48.09 | Add to Order |
| SP-664 | 5/32" | 1/2" | 0.032" | 2,500 | 100 | $19.80 | Add to Order |
| SP-051 | 5/32" | 9/16" | 0.032" | 2,500 | 100 | $37.13 | Add to Order |
| SP-663 | 5/32" | 5/8" | 0.032" | 2,500 | 100 | $15.56 | Add to Order |
| SP-662 | 5/32" | 3/4" | 0.032" | 2,500 | 100 | $20.48 | Add to Order |
| SP-633 | 5/32" | 7/8" | 0.032" | 2,500 | 100 | $15.56 | Add to Order |
| SP-673 | 5/32" | 1" | 0.032" | 2,500 | 100 | $22.41 | Add to Order |
| SP-636 | 5/32" | 1 1/8" | 0.032" | 2,500 | 100 | $24.97 | Add to Order |
| SP-608 | 5/32" | 1 1/4" | 0.032" | 2,500 | 100 | $27.66 | Add to Order |
| SP-607 | 5/32" | 1 3/8" | 0.032" | 2,500 | 100 | $27.97 | Add to Order |
| SP-606 | 5/32" | 1 1/2" | 0.032" | 2,500 | 100 | $31.48 | Add to Order |
| SP-605 | 5/32" | 1 3/4" | 0.032" | 2,500 | 100 | $39.65 | Add to Order |
| SP-604 | 5/32" | 2" | 0.032" | 2,500 | 100 | $51.39 | Add to Order |
| SP-603 | 5/32" | 2 1/2" | 0.032" | 2,500 | 100 | $43.51 | Add to Order |
| SP-602 | 3/16" | 3/8" | 0.04" | 4,100 | 100 | $23.75 | Add to Order |
| SP-601 | 3/16" | 7/16" | 0.04" | 4,100 | 100 | $18.08 | Add to Order |
| SP-600 | 3/16" | 1/2" | 0.04" | 4,100 | 250 | $41.98 | Add to Order |
| SP-599 | 3/16" | 9/16" | 0.04" | 4,100 | 100 | $22.89 | Add to Order |
| SP-586 | 3/16" | 5/8" | 0.04" | 4,100 | 250 | $37.57 | Add to Order |
| SP-597 | 3/16" | 11/16" | 0.04" | 4,100 | 100 | $24.11 | Add to Order |
| SP-609 | 3/16" | 3/4" | 0.04" | 4,100 | 250 | $46.37 | Add to Order |
| SP-595 | 3/16" | 13/16" | 0.04" | 4,100 | 100 | $35.62 | Add to Order |
| SP-594 | 3/16" | 7/8" | 0.04" | 4,100 | 100 | $18.42 | Add to Order |
| SP-593 | 3/16" | 1" | 0.04" | 4,100 | 100 | $22.32 | Add to Order |
| SP-592 | 3/16" | 1 1/8" | 0.04" | 4,100 | 100 | $26.00 | Add to Order |
| SP-591 | 3/16" | 1 1/4" | 0.04" | 4,100 | 100 | $28.27 | Add to Order |
| SP-590 | 3/16" | 1 3/8" | 0.04" | 4,100 | 100 | $35.26 | Add to Order |
| SP-589 | 3/16" | 1 1/2" | 0.04" | 4,100 | 100 | $31.31 | Add to Order |
| SP-588 | 3/16" | 1 5/8" | 0.04" | 4,100 | 100 | $27.28 | Add to Order |
| SP-587 | 3/16" | 1 3/4" | 0.04" | 4,100 | 100 | $36.10 | Add to Order |
| SP-621 | 3/16" | 1 7/8" | 0.04" | 4,100 | 100 | $33.10 | Add to Order |
| SP-623 | 3/16" | 2" | 0.04" | 4,100 | 100 | $40.93 | Add to Order |
| SP-610 | 3/16" | 2 1/4" | 0.04" | 4,100 | 50 | $19.34 | Add to Order |
| SP-622 | 3/16" | 2 1/2" | 0.04" | 4,100 | 50 | $20.12 | Add to Order |
| SP-634 | 3/16" | 2 3/4" | 0.04" | 4,100 | 50 | $17.60 | Add to Order |
| SP-620 | 3/16" | 3" | 0.04" | 4,100 | 50 | $35.36 | Add to Order |
| SP-598 | 7/32" | 1/2" | 0.048" | 5,500 | 100 | $55.78 | Add to Order |
| SP-619 | 7/32" | 5/8" | 0.048" | 5,500 | 100 | $58.67 | Add to Order |
| SP-618 | 7/32" | 3/4" | 0.048" | 5,500 | 100 | $32.59 | Add to Order |
| SP-617 | 7/32" | 1" | 0.048" | 5,500 | 100 | $34.36 | Add to Order |
| SP-616 | 7/32" | 1 1/4" | 0.048" | 5,500 | 100 | $30.49 | Add to Order |
| SP-615 | 7/32" | 1 1/2" | 0.048" | 5,500 | 100 | $58.17 | Add to Order |
| SP-613 | 7/32" | 1 3/4" | 0.048" | 5,500 | 50 | $22.76 | Add to Order |
| SP-612 | 7/32" | 2" | 0.048" | 5,500 | 50 | $23.02 | Add to Order |
| SP-611 | 7/32" | 2 1/4" | 0.048" | 5,500 | 50 | $26.65 | Add to Order |
| SP-614 | 7/32" | 2 1/2" | 0.048" | 5,500 | 50 | $24.15 | Add to Order |
| SP-904 | 7/32" | 2 3/4" | 0.048" | 5,500 | 50 | $33.64 | Add to Order |
| SP-1203 | 7/32" | 3" | 0.048" | 5,500 | 50 | $54.64 | Add to Order |
| SP-1150 | 1/4" | 1/2" | 0.048" | 7,000 | 50 | $25.37 | Add to Order |
| SP-052 | 1/4" | 9/16" | 0.048" | 7,000 | 100 | $39.06 | Add to Order |
| SP-1149 | 1/4" | 5/8" | 0.048" | 7,000 | 100 | $32.32 | Add to Order |
| SP-055 | 1/4" | 11/16" | 0.048" | 7,000 | 100 | $42.15 | Add to Order |
| SP-057 | 1/4" | 3/4" | 0.048" | 7,000 | 100 | $29.27 | Add to Order |
| SP-1147 | 1/4" | 7/8" | 0.048" | 7,000 | 100 | $29.27 | Add to Order |
| SP-1146 | 1/4" | 1" | 0.048" | 7,000 | 100 | $36.90 | Add to Order |
| SP-1128 | 1/4" | 1 1/8" | 0.048" | 7,000 | 100 | $81.98 | Add to Order |
| SP-1144 | 1/4" | 1 1/4" | 0.048" | 7,000 | 100 | $53.05 | Add to Order |
| SP-1143 | 1/4" | 1 3/8" | 0.048" | 7,000 | 100 | $51.37 | Add to Order |
| SP-1142 | 1/4" | 1 1/2" | 0.048" | 7,000 | 50 | $25.64 | Add to Order |
| SP-058 | 1/4" | 1 5/8" | 0.048" | 7,000 | 50 | $32.57 | Add to Order |
| SP-1140 | 1/4" | 1 3/4" | 0.048" | 7,000 | 50 | $28.71 | Add to Order |
| SP-356 | 1/4" | 1 7/8" | 0.048" | 7,000 | 50 | $25.56 | Add to Order |
| SP-1136 | 1/4" | 2" | 0.048" | 7,000 | 50 | $33.81 | Add to Order |
| SP-1152 | 1/4" | 2 1/4" | 0.048" | 7,000 | 50 | $37.02 | Add to Order |
| SP-1138 | 1/4" | 2 1/2" | 0.048" | 7,000 | 50 | $42.42 | Add to Order |
| SP-1137 | 1/4" | 2 3/4" | 0.048" | 7,000 | 50 | $31.08 | Add to Order |
| SP-1135 | 1/4" | 3" | 0.048" | 7,000 | 25 | $26.10 | Add to Order |
| SP-1134 | 1/4" | 3 1/4" | 0.048" | 7,000 | 25 | $29.48 | Add to Order |
| SP-1133 | 1/4" | 3 1/2" | 0.048" | 7,000 | 25 | $21.48 | Add to Order |
| SP-651 | 1/4" | 4" | 0.048" | 7,000 | 5 | $17.87 | Add to Order |
| SP-1132 | 5/16" | 3/4" | 0.062" | 10,000 | 50 | $29.80 | Add to Order |
| SP-1131 | 5/16" | 1" | 0.062" | 10,000 | 50 | $27.51 | Add to Order |
| SP-1130 | 5/16" | 1 1/4" | 0.062" | 10,000 | 50 | $31.67 | Add to Order |
| SP-1164 | 5/16" | 1 1/2" | 0.062" | 10,000 | 50 | $42.11 | Add to Order |
| SP-1139 | 5/16" | 1 3/4" | 0.062" | 10,000 | 50 | $56.28 | Add to Order |
| SP-1141 | 5/16" | 2" | 0.062" | 10,000 | 25 | $28.50 | Add to Order |
| SP-1176 | 5/16" | 2 1/4" | 0.062" | 10,000 | 25 | $31.16 | Add to Order |
| SP-1175 | 5/16" | 2 1/2" | 0.062" | 10,000 | 25 | $34.27 | Add to Order |
| SP-1174 | 5/16" | 2 3/4" | 0.062" | 10,000 | 25 | $26.19 | Add to Order |
| SP-1173 | 5/16" | 3" | 0.062" | 10,000 | 25 | $32.05 | Add to Order |
| SP-1172 | 5/16" | 3 1/4" | 0.062" | 10,000 | 10 | $15.71 | Add to Order |
| SP-1171 | 5/16" | 3 1/2" | 0.062" | 10,000 | 25 | $41.79 | Add to Order |
| SP-1170 | 5/16" | 3 3/4" | 0.062" | 10,000 | 10 | $17.96 | Add to Order |
| SP-1169 | 5/16" | 4" | 0.062" | 10,000 | 10 | $20.54 | Add to Order |
| SP-1168 | 3/8" | 3/4" | 0.077" | 16,000 | 25 | $34.40 | Add to Order |
| SP-1167 | 3/8" | 1" | 0.077" | 16,000 | 25 | $35.26 | Add to Order |
| SP-1153 | 3/8" | 1 1/4" | 0.077" | 16,000 | 50 | $69.85 | Add to Order |
| SP-1165 | 3/8" | 1 1/2" | 0.077" | 16,000 | 25 | $38.49 | Add to Order |
| SP-1177 | 3/8" | 1 3/4" | 0.077" | 16,000 | 25 | $42.76 | Add to Order |
| SP-1163 | 3/8" | 2" | 0.077" | 16,000 | 25 | $46.52 | Add to Order |
| SP-1162 | 3/8" | 2 1/4" | 0.077" | 16,000 | 25 | $55.19 | Add to Order |
| SP-1161 | 3/8" | 2 1/2" | 0.077" | 16,000 | 25 | $47.50 | Add to Order |
| SP-1160 | 3/8" | 2 3/4" | 0.077" | 16,000 | 10 | $16.44 | Add to Order |
| SP-1159 | 3/8" | 3" | 0.077" | 16,000 | 10 | $25.70 | Add to Order |
| SP-1158 | 3/8" | 3 1/4" | 0.077" | 16,000 | 10 | $21.65 | Add to Order |
| SP-1157 | 3/8" | 3 1/2" | 0.077" | 16,000 | 10 | $21.48 | Add to Order |
| SP-1156 | 3/8" | 3 3/4" | 0.077" | 16,000 | 10 | $20.18 | Add to Order |
| SP-1126 | 3/8" | 4" | 0.077" | 16,000 | 10 | $22.60 | Add to Order |
| SP-1166 | 7/16" | 1 3/4" | 0.077" | 19,800 | 25 | $64.26 | Add to Order |
| SP-1129 | 7/16" | 2" | 0.077" | 19,800 | 25 | $71.25 | Add to Order |
| SP-1101 | 7/16" | 2 1/2" | 0.077" | 19,800 | 10 | $29.40 | Add to Order |
| SP-1100 | 7/16" | 3" | 0.077" | 19,800 | 10 | $38.86 | Add to Order |
| SP-1099 | 7/16" | 4" | 0.077" | 19,800 | 10 | $31.29 | Add to Order |
| SP-1098 | 1/2" | 1 1/4" | 0.094" | 26,000 | 10 | $19.30 | Add to Order |
| SP-1097 | 1/2" | 1 1/2" | 0.094" | 26,000 | 25 | $77.45 | Add to Order |
| SP-1096 | 1/2" | 1 3/4" | 0.094" | 26,000 | 10 | $27.97 | Add to Order |
| SP-1095 | 1/2" | 2" | 0.094" | 26,000 | 10 | $33.45 | Add to Order |
| SP-1094 | 1/2" | 2 1/4" | 0.094" | 26,000 | 10 | $23.31 | Add to Order |
| SP-1093 | 1/2" | 2 1/2" | 0.094" | 26,000 | 10 | $40.82 | Add to Order |
| SP-1092 | 1/2" | 2 3/4" | 0.094" | 26,000 | 10 | $49.77 | Add to Order |
| SP-1079 | 1/2" | 3" | 0.094" | 26,000 | 10 | $41.29 | Add to Order |
| SP-1090 | 1/2" | 3 1/4" | 0.094" | 26,000 | 10 | $35.74 | Add to Order |
| SP-1102 | 1/2" | 3 1/2" | 0.094" | 26,000 | 10 | $30.28 | Add to Order |
| SP-1088 | 1/2" | 3 3/4" | 0.094" | 26,000 | 5 | $17.22 | Add to Order |
| SP-1087 | 1/2" | 4" | 0.094" | 26,000 | 5 | $18.21 | Add to Order |
| Rev. 10-23, 04-23, 12-22, 11-22 | |||||||
|
Tolerances |
|
| Lengths 0-1.0" | +/-.015" |
| Lengths 1.125"-2.0" | +/-.020" |
| Lengths 2.25"-3.0" | +/-.025" |
| Lengths 3.25" and up | +/-.030" |
| Lengths 0-24mm | +/- .40mm |
| Lengths 26mm-50mm | +/- .50mm |
| Lengths 55mm-60mm | +/- .60mm |
| Lengths 80mm and up | +/- .75mm |
| Metric | Imperial Inches | ||||||||||||||||||||
| Nominal Dia. | M2 | M2.5 | M3 | M4 | M5 | M6 | M8 | 1/16" | 5/64" | 3/32" | 1/8" | 5/32" | 3/16" | 7/32" | 1/4" | 5/16" | 3/8" | 7/16" | 1/2" | 5/8" | |
| Act. Dia | Min. mm | 2.13 | 2.65 | 3.15 | 4.20 | 5.25 | 6.25 | 8.30 | 0.066 | 0.083 | 0.099 | 0.131 | 0.162 | 0.194 | 0.226 | 0.258 | 0.321 | 0.385 | 0.448 | 0.513 | 0.640 |
| Max. mm | 2.25 | 2.78 | 3.30 | 4.40 | 5.50 | 6.50 | 8.63 | 0.069 | 0.086 | 0.103 | 0.135 | 0.137 | 0.199 | 0.232 | 0.264 | 0.330 | 0.395 | 0.459 | 0.524 | 0.653 | |
| Wall Thickness | * | * | * | * | * | * | * | 0.012 | 0.018 | 0.022 | 0.028 | 0.032 | 0.040 | 0.048 | 0.048 | 0.062 | 0.077 | 0.077 | 0.094 | 0.125 | |
| Suggested | Min. mm | 2.00 | 2.50 | 3.00 | 4.00 | 5.10 | 6.00 | 8.00 | 0.062 | 0.078 | 0.094 | 0.125 | 0.156 | 0.187 | 0.219 | 0.250 | 0.312 | 0.375 | 0.437 | 0.500 | 0.625 |
| Hole Size | Max. mm | 2.10 | 2.60 | 3.10 | 4.12 | 5.12 | 6.12 | 8.15 | 0.065 | 0.081 | 0.097 | 0.129 | 0.160 | 0.192 | 0.224 | 0.256 | 0.318 | 0.382 | 0.445 | 0.510 | 0.636 |
| Shear Strength Lbs | 562 | 876 | 1236 | 2158 | 3372 | 4945 | 8767 | * | * | * | * | * | * | * | * | * | * | * | * | * | |
| Shear Strength Lbs 18-8 SS | * | * | * | * | * | * | * | 250 | 460 | 670 | 1090 | 1600 | 2425 | 3400 | 4100 | 6300 | 9500 | 11500 | 15800 | 18800 | |
| Shear Strength Lbs 420 SS | * | * | * | * | * | * | * | 430 | 800 | 1150 | 1875 | 2750 | 4150 | 5850 | 7050 | 10800 | 16300 | 19800 | 27100 | 46000 | |
