18-8 Stainless Steel Spring Pins
Jump to: Coiled 18-8 Stainless Spring Pins
| 18-8 Stainless Steel Slotted Spring Pins | |||||||
| Part # | Diameter | Length | Wall | Breaking Strength LBS | Pkg Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| SP-753 | 1/16" | 3/16" | 0.012" | 240 | 100 | $7.54 | Add to Order |
| SP-751 | 1/16" | 1/4" | 0.012" | 240 | 100 | $6.97 | Add to Order |
| SP-750 | 1/16" | 5/16" | 0.012" | 240 | 100 | $7.27 | Add to Order |
| SP-749 | 1/16" | 3/8" | 0.012" | 240 | 100 | $7.33 | Add to Order |
| SP-748 | 1/16" | 7/16" | 0.012" | 240 | 100 | $8.57 | Add to Order |
| SP-734 | 1/16" | 1/2" | 0.012" | 240 | 100 | $7.54 | Add to Order |
| SP-745 | 1/16" | 9/16" | 0.012" | 240 | 100 | $13.71 | Add to Order |
| SP-757 | 1/16" | 5/8" | 0.012" | 240 | 100 | $8.06 | Add to Order |
| SP-743 | 1/16" | 11/16" | 0.012" | 240 | 100 | $9.91 | Add to Order |
| SP-742 | 1/16" | 3/4" | 0.012" | 240 | 100 | $11.07 | Add to Order |
| SP-068 | 1/16" | 13/16" | 0.012" | 240 | 100 | $12.92 | Add to Order |
| SP-741 | 1/16" | 7/8" | 0.012" | 240 | 100 | $24.51 | Add to Order |
| SP-070 | 1/16" | 15/16" | 0.012" | 240 | 100 | $32.32 | Add to Order |
| SP-740 | 1/16" | 1" | 0.012" | 240 | 100 | $14.95 | Add to Order |
| SP-739 | 5/64" | 3/16" | 0.018" | 420 | 100 | $7.67 | Add to Order |
| SP-738 | 5/64" | 1/4" | 0.018" | 420 | 100 | $8.06 | Add to Order |
| SP-737 | 5/64" | 5/16" | 0.018" | 420 | 100 | $7.77 | Add to Order |
| SP-736 | 5/64" | 3/8" | 0.018" | 420 | 100 | $7.96 | Add to Order |
| SP-769 | 5/64" | 7/16" | 0.018" | 420 | 100 | $9.16 | Add to Order |
| SP-771 | 5/64" | 1/2" | 0.018" | 420 | 100 | $8.59 | Add to Order |
| SP-762 | 5/64" | 9/16" | 0.018" | 420 | 100 | $9.87 | Add to Order |
| SP-761 | 5/64" | 5/8" | 0.018" | 420 | 100 | $10.08 | Add to Order |
| SP-760 | 5/64" | 11/16" | 0.018" | 420 | 100 | $12.31 | Add to Order |
| SP-759 | 5/64" | 3/4" | 0.018" | 420 | 100 | $12.73 | Add to Order |
| SP-732 | 5/64" | 13/16" | 0.018" | 420 | 100 | $13.33 | Add to Order |
| SP-695 | 5/64" | 7/8" | 0.018" | 420 | 100 | $29.02 | Add to Order |
| SP-744 | 5/64" | 1" | 0.018" | 420 | 100 | $17.96 | Add to Order |
| SP-706 | 5/64" | 1 1/4" | 0.018" | 420 | 100 | $39.59 | Add to Order |
| SP-704 | 5/64" | 1 1/2" | 0.018" | 420 | 100 | $21.74 | Add to Order |
| SP-752 | 3/32" | 3/16" | 0.022" | 600 | 100 | $20.12 | Add to Order |
| SP-747 | 3/32" | 1/4" | 0.022" | 600 | 100 | $8.42 | Add to Order |
| SP-735 | 3/32" | 5/16" | 0.022" | 600 | 100 | $7.96 | Add to Order |
| SP-705 | 3/32" | 3/8" | 0.022" | 600 | 100 | $9.51 | Add to Order |
| SP-703 | 3/32" | 7/16" | 0.022" | 600 | 100 | $11.82 | Add to Order |
| SP-702 | 3/32" | 1/2" | 0.022" | 600 | 100 | $10.71 | Add to Order |
| SP-701 | 3/32" | 9/16" | 0.022" | 600 | 100 | $10.82 | Add to Order |
| SP-700 | 3/32" | 5/8" | 0.022" | 600 | 100 | $11.99 | Add to Order |
| SP-699 | 3/32" | 11/16" | 0.022" | 600 | 100 | $13.99 | Add to Order |
| SP-698 | 3/32" | 3/4" | 0.022" | 600 | 100 | $14.01 | Add to Order |
| SP-685 | 3/32" | 13/16" | 0.022" | 600 | 100 | $16.46 | Add to Order |
| SP-717 | 3/32" | 7/8" | 0.022" | 600 | 100 | $16.80 | Add to Order |
| SP-780 | 3/32" | 15/16" | 0.022" | 600 | 100 | $24.84 | Add to Order |
| SP-716 | 3/32" | 1" | 0.022" | 600 | 100 | $17.68 | Add to Order |
| SP-715 | 3/32" | 1 1/8" | 0.022" | 600 | 100 | $12.98 | Add to Order |
| SP-714 | 3/32" | 1 1/4" | 0.022" | 600 | 100 | $21.88 | Add to Order |
| SP-713 | 3/32" | 1 3/8" | 0.022" | 600 | 100 | $39.52 | Add to Order |
| SP-712 | 3/32" | 1 1/2" | 0.022" | 600 | 100 | $20.43 | Add to Order |
| SP-746 | 1/8" | 1/4" | 0.028" | 1,000 | 100 | $12.62 | Add to Order |
| SP-1061 | 1/8" | 5/16" | 0.028" | 1,000 | 100 | $12.31 | Add to Order |
| SP-779 | 1/8" | 3/8" | 0.028" | 1,000 | 100 | $10.16 | Add to Order |
| SP-778 | 1/8" | 7/16" | 0.028" | 1,000 | 100 | $11.00 | Add to Order |
| SP-777 | 1/8" | 1/2" | 0.028" | 1,000 | 100 | $11.66 | Add to Order |
| SP-776 | 1/8" | 9/16" | 0.028" | 1,000 | 100 | $13.71 | Add to Order |
| SP-775 | 1/8" | 5/8" | 0.028" | 1,000 | 100 | $13.17 | Add to Order |
| SP-774 | 1/8" | 11/16" | 0.028" | 1,000 | 100 | $15.39 | Add to Order |
| SP-773 | 1/8" | 3/4" | 0.028" | 1,000 | 100 | $15.50 | Add to Order |
| SP-758 | 1/8" | 13/16" | 0.028" | 1,000 | 100 | $15.50 | Add to Order |
| SP-770 | 1/8" | 7/8" | 0.028" | 1,000 | 100 | $18.67 | Add to Order |
| SP-1301 | 1/8" | 15/16" | 0.028" | 1,000 | 100 | $18.67 | Add to Order |
| SP-782 | 1/8" | 1" | 0.028" | 1,000 | 100 | $19.40 | Add to Order |
| SP-768 | 1/8" | 1 1/8" | 0.028" | 1,000 | 100 | $27.09 | Add to Order |
| SP-767 | 1/8" | 1 1/4" | 0.028" | 1,000 | 100 | $25.10 | Add to Order |
| SP-766 | 1/8" | 1 3/8" | 0.028" | 1,000 | 100 | $32.15 | Add to Order |
| SP-764 | 1/8" | 1 1/2" | 0.028" | 1,000 | 100 | $30.32 | Add to Order |
| SP-763 | 1/8" | 1 5/8" | 0.028" | 1,000 | 100 | $35.75 | Add to Order |
| SP-708 | 1/8" | 1 3/4" | 0.028" | 1,000 | 50 | $32.38 | Add to Order |
| SP-694 | 1/8" | 1 7/8" | 0.028" | 1,000 | 50 | $40.74 | Add to Order |
| SP-693 | 1/8" | 2" | 0.028" | 1,000 | 25 | $27.57 | Add to Order |
| SP-692 | 1/8" | 2 1/4" | 0.028" | 1,000 | 25 | $22.55 | Add to Order |
| SP-691 | 1/8" | 2 1/2" | 0.028" | 1,000 | 25 | $34.25 | Add to Order |
| SP-690 | 5/32" | 3/8" | 0.032" | 1,450 | 50 | $26.25 | Add to Order |
| SP-1279 | 5/32" | 7/16" | 0.032" | 1,450 | 100 | $18.23 | Add to Order |
| SP-689 | 5/32" | 1/2" | 0.032" | 1,450 | 100 | $18.44 | Add to Order |
| SP-1306 | 5/32" | 9/16" | 0.032" | 1,450 | 100 | $19.95 | Add to Order |
| SP-688 | 5/32" | 5/8" | 0.032" | 1,450 | 100 | $18.92 | Add to Order |
| SP-687 | 5/32" | 3/4" | 0.032" | 1,450 | 100 | $22.93 | Add to Order |
| SP-686 | 5/32" | 7/8" | 0.032" | 1,450 | 100 | $26.12 | Add to Order |
| SP-720 | 5/32" | 1" | 0.032" | 1,450 | 100 | $26.82 | Add to Order |
| SP-722 | 5/32" | 1 1/8" | 0.032" | 1,450 | 100 | $41.73 | Add to Order |
| SP-697 | 5/32" | 1 1/4" | 0.032" | 1,450 | 100 | $36.27 | Add to Order |
| SP-731 | 5/32" | 1 3/8" | 0.032" | 1,450 | 25 | $17.28 | Add to Order |
| SP-1282 | 5/32" | 1 1/2" | 0.032" | 1,450 | 25 | $12.90 | Add to Order |
| SP-730 | 5/32" | 1 3/4" | 0.032" | 1,450 | 50 | $32.40 | Add to Order |
| SP-729 | 5/32" | 2" | 0.032" | 1,450 | 25 | $57.44 | Add to Order |
| SP-728 | 5/32" | 2 1/2" | 0.032" | 1,450 | 10 | $21.23 | Add to Order |
| SP-727 | 3/16" | 3/8" | 0.04" | 2,250 | 50 | $32.63 | Add to Order |
| SP-726 | 3/16" | 7/16" | 0.04" | 2,250 | 25 | $26.50 | Add to Order |
| SP-725 | 3/16" | 1/2" | 0.04" | 2,250 | 100 | $23.60 | Add to Order |
| SP-724 | 3/16" | 9/16" | 0.04" | 2,250 | 50 | $17.62 | Add to Order |
| SP-723 | 3/16" | 5/8" | 0.04" | 2,250 | 50 | $21.50 | Add to Order |
| SP-709 | 3/16" | 11/16" | 0.04" | 2,250 | 100 | $37.93 | Add to Order |
| SP-721 | 3/16" | 3/4" | 0.04" | 2,250 | 50 | $24.15 | Add to Order |
| SP-733 | 3/16" | 13/16" | 0.04" | 2,250 | 25 | $21.13 | Add to Order |
| SP-719 | 3/16" | 7/8" | 0.04" | 2,250 | 50 | $26.33 | Add to Order |
| SP-781 | 3/16" | 1" | 0.04" | 2,250 | 100 | $39.69 | Add to Order |
| SP-854 | 3/16" | 1 1/8" | 0.04" | 2,250 | 50 | $30.87 | Add to Order |
| SP-853 | 3/16" | 1 1/4" | 0.04" | 2,250 | 50 | $31.04 | Add to Order |
| SP-852 | 3/16" | 1 3/8" | 0.04" | 2,250 | 50 | $38.09 | Add to Order |
| SP-718 | 3/16" | 1 1/2" | 0.04" | 2,250 | 50 | $42.08 | Add to Order |
| SP-851 | 3/16" | 1 5/8" | 0.04" | 2,250 | 25 | $25.07 | Add to Order |
| SP-850 | 3/16" | 1 3/4" | 0.04" | 2,250 | 50 | $48.49 | Add to Order |
| SP-849 | 3/16" | 1 7/8" | 0.04" | 2,250 | 25 | $36.35 | Add to Order |
| SP-848 | 3/16" | 2" | 0.04" | 2,250 | 25 | $35.68 | Add to Order |
| SP-847 | 3/16" | 2 1/4" | 0.04" | 2,250 | 25 | $39.90 | Add to Order |
| SP-846 | 3/16" | 2 1/2" | 0.04" | 2,250 | 50 | $58.67 | Add to Order |
| SP-832 | 3/16" | 2 3/4" | 0.04" | 2,250 | 10 | $34.73 | Add to Order |
| SP-844 | 3/16" | 3" | 0.04" | 2,250 | 10 | $27.43 | Add to Order |
| SP-856 | 7/32" | 1/2" | 0.048" | 3,000 | 50 | $17.24 | Add to Order |
| SP-842 | 7/32" | 5/8" | 0.048" | 3,000 | 50 | $27.89 | Add to Order |
| SP-841 | 7/32" | 3/4" | 0.048" | 3,000 | 50 | $34.50 | Add to Order |
| SP-840 | 7/32" | 1" | 0.048" | 3,000 | 50 | $39.82 | Add to Order |
| SP-839 | 7/32" | 1 1/4" | 0.048" | 3,000 | 25 | $26.12 | Add to Order |
| SP-838 | 7/32" | 1 1/2" | 0.048" | 3,000 | 25 | $27.26 | Add to Order |
| SP-837 | 7/32" | 1 3/4" | 0.048" | 3,000 | 25 | $37.15 | Add to Order |
| SP-836 | 7/32" | 2" | 0.048" | 3,000 | 25 | $36.10 | Add to Order |
| SP-835 | 7/32" | 2 1/4" | 0.048" | 3,000 | 10 | $25.47 | Add to Order |
| SP-834 | 7/32" | 2 1/2" | 0.048" | 3,000 | 10 | $19.03 | Add to Order |
| SP-868 | 7/32" | 2 3/4" | 0.048" | 3,000 | 10 | $52.46 | Add to Order |
| SP-843 | 7/32" | 3" | 0.048" | 3,000 | 10 | $53.34 | Add to Order |
| SP-1307 | 1/4" | 3/8" | 0.048" | 4,000 | 50 | $41.37 | Add to Order |
| SP-845 | 1/4" | 1/2" | 0.048" | 4,000 | 25 | $14.57 | Add to Order |
| SP-1308 | 1/4" | 9/16" | 0.048" | 4,000 | 50 | $29.74 | Add to Order |
| SP-880 | 1/4" | 5/8" | 0.048" | 4,000 | 50 | $30.30 | Add to Order |
| SP-1309 | 1/4" | 11/16" | 0.048" | 4,000 | 50 | $26.40 | Add to Order |
| SP-879 | 1/4" | 3/4" | 0.048" | 4,000 | 50 | $36.16 | Add to Order |
| SP-878 | 1/4" | 7/8" | 0.048" | 4,000 | 50 | $38.58 | Add to Order |
| SP-877 | 1/4" | 1" | 0.048" | 4,000 | 50 | $43.01 | Add to Order |
| SP-876 | 1/4" | 1 1/8" | 0.048" | 4,000 | 25 | $31.00 | Add to Order |
| SP-875 | 1/4" | 1 1/4" | 0.048" | 4,000 | 25 | $30.09 | Add to Order |
| SP-874 | 1/4" | 1 3/8" | 0.048" | 4,000 | 25 | $26.96 | Add to Order |
| SP-873 | 1/4" | 1 1/2" | 0.048" | 4,000 | 25 | $28.73 | Add to Order |
| SP-872 | 1/4" | 1 5/8" | 0.048" | 4,000 | 25 | $29.40 | Add to Order |
| SP-871 | 1/4" | 1 3/4" | 0.048" | 4,000 | 25 | $35.89 | Add to Order |
| SP-857 | 1/4" | 1 7/8" | 0.048" | 4,000 | 10 | $21.17 | Add to Order |
| SP-869 | 1/4" | 2" | 0.048" | 4,000 | 10 | $21.25 | Add to Order |
| SP-881 | 1/4" | 2 1/4" | 0.048" | 4,000 | 10 | $25.68 | Add to Order |
| SP-867 | 1/4" | 2 1/2" | 0.048" | 4,000 | 10 | $23.04 | Add to Order |
| SP-866 | 1/4" | 2 3/4" | 0.048" | 4,000 | 10 | $50.38 | Add to Order |
| SP-865 | 1/4" | 3" | 0.048" | 4,000 | 10 | $20.12 | Add to Order |
| SP-864 | 1/4" | 3 1/4" | 0.048" | 4,000 | 10 | $23.92 | Add to Order |
| SP-863 | 1/4" | 3 1/2" | 0.048" | 4,000 | 10 | $19.74 | Add to Order |
| SP-1310 | 1/4" | 4" | 0.048" | 4,000 | 5 | $27.95 | Add to Order |
| SP-862 | 5/16" | 3/4" | 0.062" | 6,000 | 25 | $26.92 | Add to Order |
| SP-861 | 5/16" | 1" | 0.062" | 6,000 | 25 | $34.99 | Add to Order |
| SP-860 | 5/16" | 1 1/4" | 0.062" | 6,000 | 10 | $20.12 | Add to Order |
| SP-859 | 5/16" | 1 1/2" | 0.062" | 6,000 | 10 | $22.68 | Add to Order |
| SP-830 | 5/16" | 1 3/4" | 0.062" | 6,000 | 10 | $26.71 | Add to Order |
| SP-870 | 5/16" | 2" | 0.062" | 6,000 | 10 | $24.76 | Add to Order |
| SP-833 | 5/16" | 2 1/4" | 0.062" | 6,000 | 10 | $25.68 | Add to Order |
| SP-805 | 5/16" | 2 1/2" | 0.062" | 6,000 | 10 | $34.27 | Add to Order |
| SP-804 | 5/16" | 2 3/4" | 0.062" | 6,000 | 10 | $35.05 | Add to Order |
| SP-803 | 5/16" | 3" | 0.062" | 6,000 | 10 | $35.70 | Add to Order |
| SP-802 | 5/16" | 3 1/4" | 0.062" | 6,000 | 5 | $27.74 | Add to Order |
| SP-801 | 5/16" | 3 1/2" | 0.062" | 6,000 | 1 | $3.61 | Add to Order |
| SP-800 | 5/16" | 3 3/4" | 0.062" | 6,000 | 5 | $21.99 | Add to Order |
| SP-799 | 5/16" | 4" | 0.062" | 6,000 | 5 | $23.50 | Add to Order |
| SP-798 | 3/8" | 3/4" | 0.077" | 9,000 | 5 | $11.91 | Add to Order |
| SP-797 | 3/8" | 1" | 0.077" | 9,000 | 10 | $23.77 | Add to Order |
| SP-796 | 3/8" | 1 1/4" | 0.077" | 9,000 | 10 | $30.72 | Add to Order |
| SP-783 | 3/8" | 1 1/2" | 0.077" | 9,000 | 10 | $35.28 | Add to Order |
| SP-794 | 3/8" | 1 3/4" | 0.077" | 9,000 | 10 | $24.74 | Add to Order |
| SP-806 | 3/8" | 2" | 0.077" | 9,000 | 10 | $27.68 | Add to Order |
| SP-792 | 3/8" | 2 1/4" | 0.077" | 9,000 | 5 | $17.28 | Add to Order |
| SP-791 | 3/8" | 2 1/2" | 0.077" | 9,000 | 5 | $18.42 | Add to Order |
| SP-789 | 3/8" | 2 3/4" | 0.077" | 9,000 | 5 | $20.94 | Add to Order |
| SP-788 | 3/8" | 3" | 0.077" | 9,000 | 5 | $21.25 | Add to Order |
| SP-787 | 3/8" | 3 1/4" | 0.077" | 9,000 | 1 | $7.12 | Add to Order |
| SP-786 | 3/8" | 3 1/2" | 0.077" | 9,000 | 1 | $4.22 | Add to Order |
| SP-785 | 3/8" | 3 3/4" | 0.077" | 9,000 | 1 | $7.56 | Add to Order |
| SP-784 | 3/8" | 4" | 0.077" | 9,000 | 1 | $5.54 | Add to Order |
| SP-790 | 7/16" | 1 3/4" | 0.077" | 11,000 | 5 | $30.81 | Add to Order |
| SP-818 | 7/16" | 2" | 0.077" | 11,000 | 1 | $6.05 | Add to Order |
| SP-820 | 7/16" | 2 1/2" | 0.077" | 11,000 | 5 | $20.35 | Add to Order |
| SP-795 | 7/16" | 3" | 0.077" | 11,000 | 5 | $17.41 | Add to Order |
| SP-829 | 7/16" | 4" | 0.077" | 11,000 | 1 | $9.81 | Add to Order |
| SP-828 | 1/2" | 1 1/4" | 0.094" | 15,000 | 5 | $20.92 | Add to Order |
| SP-827 | 1/2" | 1 1/2" | 0.094" | 15,000 | 1 | $4.47 | Add to Order |
| SP-826 | 1/2" | 1 3/4" | 0.094" | 15,000 | 5 | $17.07 | Add to Order |
| SP-825 | 1/2" | 2" | 0.094" | 15,000 | 1 | $4.68 | Add to Order |
| SP-824 | 1/2" | 2 1/4" | 0.094" | 15,000 | 1 | $7.48 | Add to Order |
| SP-823 | 1/2" | 2 1/2" | 0.094" | 15,000 | 5 | $23.48 | Add to Order |
| SP-822 | 1/2" | 2 3/4" | 0.094" | 15,000 | 5 | $28.43 | Add to Order |
| SP-821 | 1/2" | 3" | 0.094" | 15,000 | 1 | $7.79 | Add to Order |
| SP-807 | 1/2" | 3 1/4" | 0.094" | 15,000 | 1 | $10.58 | Add to Order |
| SP-819 | 1/2" | 3 1/2" | 0.094" | 15,000 | 1 | $12.64 | Add to Order |
| SP-552 | 1/2" | 3 3/4" | 0.094" | 15,000 | 1 | $8.82 | Add to Order |
| SP-551 | 1/2" | 4" | 0.094" | 15,000 | 1 | $9.35 | Add to Order |
| Rev. 04-23, 01-23, 12-22, 03-22 | |||||||
| Passivated 18-8 Stainless Steel Coiled Spring Pins, ASME B18.8.2 |
||||||
| Part # | Dia. | Length | Breaking Strength LBS | Pkg Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|
| SP-1501 | 1/32" | 1/8" | Not Rated | 25 | $22.62 | Add to Order |
| SP-971 | 1/32" | 3/16" | Not Rated | 25 | $10.06 | Add to Order |
| SP-970 | 1/32" | 1/4" | Not Rated | 25 | $14.47 | Add to Order |
| SP-969 | 1/32" | 3/8" | Not Rated | 25 | $10.65 | Add to Order |
| SP-955 | 1/32" | 1/2" | Not Rated | 25 | $11.68 | Add to Order |
| SP-1502 | 1/32" | 5/8" | Not Rated | 25 | $41.48 | Add to Order |
| SP-967 | 0.039" | 3/16" | Not Rated | 25 | $21.97 | Add to Order |
| SP-979 | 0.039" | 1/4" | Not Rated | 25 | $22.22 | Add to Order |
| SP-965 | 0.039" | 3/8" | Not Rated | 25 | $22.72 | Add to Order |
| SP-964 | 0.039" | 1/2" | Not Rated | 25 | $23.25 | Add to Order |
| SP-963 | 3/64" | 3/16" | Not Rated | 25 | $11.17 | Add to Order |
| SP-962 | 3/64" | 1/4" | Not Rated | 25 | $10.82 | Add to Order |
| SP-961 | 3/64" | 3/8" | Not Rated | 25 | $13.13 | Add to Order |
| SP-960 | 3/64" | 1/2" | Not Rated | 25 | $14.66 | Add to Order |
| SP-1503 | 0.052" | 1/8" | 160 | 25 | $17.24 | Add to Order |
| SP-1504 | 0.052" | 1/4" | 160 | 25 | $31.06 | Add to Order |
| SP-1505 | 0.052" | 3/8" | 160 | 25 | $20.03 | Add to Order |
| SP-1506 | 0.052" | 1/2" | 160 | 25 | $55.38 | Add to Order |
| SP-1507 | 1/16" | 5/16" | 240 | 100 | $33.08 | Add to Order |
| SP-1508 | 1/16" | 1/2" | 240 | 100 | $34.29 | Add to Order |
| SP-1509 | 7/64" | 1/4" | 750 | 25 | $29.84 | Add to Order |
| SP-1510 | 7/64" | 1/2" | 750 | 25 | $22.89 | Add to Order |
| SP-1511 | 1/8" | 3/8" | 900 | 25 | $15.67 | Add to Order |
| SP-1512 | 1/8" | 1/2" | 900 | 25 | $17.47 | Add to Order |
| SP-1513 | 1/8" | 9/16" | 900 | 25 | $18.98 | Add to Order |
| SP-1514 | 1/8" | 3/4" | 900 | 25 | $20.18 | Add to Order |
| SP-1515 | 1/8" | 15/16" | 900 | 10 | $15.75 | Add to Order |
| SP-1516 | 1/4" | 1" | 4,000 | 10 | $20.39 | Add to Order |
| SP-1517 | 1/4" | 1 1/2" | 4,000 | 10 | $33.73 | Add to Order |
| SP-1518 | 1/4" | 2" | 4,000 | 10 | $44.12 | Add to Order |
| Rev. 04-23, 12-22, 07-22, 03-22 | ||||||
|
Tolerances |
|
| Lengths 0-1.0" | +/-.015" |
| Lengths 1.125"-2.0" | +/-.020" |
| Lengths 2.25"-3.0" | +/-.025" |
| Lengths 3.25" and up | +/-.030" |
| Lengths 0-24mm | +/- .40mm |
| Lengths 26mm-50mm | +/- .50mm |
| Lengths 55mm-60mm | +/- .60mm |
| Lengths 80mm and up | +/- .75mm |
| Metric | Imperial Inches | ||||||||||||||||||||
| Nominal Dia. | M2 | M2.5 | M3 | M4 | M5 | M6 | M8 | 1/16" | 5/64" | 3/32" | 1/8" | 5/32" | 3/16" | 7/32" | 1/4" | 5/16" | 3/8" | 7/16" | 1/2" | 5/8" | |
| Act. Dia | Min. mm | 2.13 | 2.65 | 3.15 | 4.20 | 5.25 | 6.25 | 8.30 | 0.066 | 0.083 | 0.099 | 0.131 | 0.162 | 0.194 | 0.226 | 0.258 | 0.321 | 0.385 | 0.448 | 0.513 | 0.640 |
| Max. mm | 2.25 | 2.78 | 3.30 | 4.40 | 5.50 | 6.50 | 8.63 | 0.069 | 0.086 | 0.103 | 0.135 | 0.137 | 0.199 | 0.232 | 0.264 | 0.330 | 0.395 | 0.459 | 0.524 | 0.653 | |
| Wall Thickness | * | * | * | * | * | * | * | 0.012 | 0.018 | 0.022 | 0.028 | 0.032 | 0.040 | 0.048 | 0.048 | 0.062 | 0.077 | 0.077 | 0.094 | 0.125 | |
| Suggested | Min. mm | 2.00 | 2.50 | 3.00 | 4.00 | 5.10 | 6.00 | 8.00 | 0.062 | 0.078 | 0.094 | 0.125 | 0.156 | 0.187 | 0.219 | 0.250 | 0.312 | 0.375 | 0.437 | 0.500 | 0.625 |
| Hole Size | Max. mm | 2.10 | 2.60 | 3.10 | 4.12 | 5.12 | 6.12 | 8.15 | 0.065 | 0.081 | 0.097 | 0.129 | 0.160 | 0.192 | 0.224 | 0.256 | 0.318 | 0.382 | 0.445 | 0.510 | 0.636 |
| Shear Strength Lbs | 562 | 876 | 1236 | 2158 | 3372 | 4945 | 8767 | * | * | * | * | * | * | * | * | * | * | * | * | * | |
| Shear Strength Lbs 18-8 SS | * | * | * | * | * | * | * | 250 | 460 | 670 | 1090 | 1600 | 2425 | 3400 | 4100 | 6300 | 9500 | 11500 | 15800 | 18800 | |
| Shear Strength Lbs 420 SS | * | * | * | * | * | * | * | 430 | 800 | 1150 | 1875 | 2750 | 4150 | 5850 | 7050 | 10800 | 16300 | 19800 | 27100 | 46000 | |
