3/4" Screw Size Spacers
3/8" Screw Size Spacers OD Tol. +/- .003", ID Tol. +.010"/- 0 |
|||||||
| Part # | Material | OD | ID | Length | Pkg Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| Spacer-1687 | 18-8 Stainless Steel | .750" | .380" | .375" | 1 | $28.06 | Add to Order |
| Spacer-1688 | 18-8 Stainless Steel | .750" | .380" | .500" | 1 | $28.08 | Add to Order |
| Spacer-1689 | 18-8 Stainless Steel | .750" | .380" | .625" | 1 | $27.91 | Add to Order |
| Spacer-1690 | 18-8 Stainless Steel | .750" | .380" | .750" | 1 | $27.91 | Add to Order |
| Spacer-1691 | 18-8 Stainless Steel | .750" | .380" | .875" | 1 | $30.68 | Add to Order |
| Spacer-1692 | 18-8 Stainless Steel | .750" | .380" | 1.25" | 1 | $30.83 | Add to Order |
| Spacer-1693 | 18-8 Stainless Steel | .750" | .380" | 1.50" | 1 | $35.70 | Add to Order |
| Spacer-1694 | 18-8 Stainless Steel | .750" | .380" | 1.75" | 1 | $36.04 | Add to Order |
| Spacer-1695 | 18-8 Stainless Steel | .750" | .380" | 2.00" | 1 | $40.19 | Add to Order |
| Spacer-2024 | Aluminum | .750" | .380" | .375" | 1 | $5.80 | Add to Order |
| Spacer-2025 | Aluminum | .750" | .380" | .500" | 1 | $5.80 | Add to Order |
| Spacer-2026 | Aluminum | .750" | .380" | .625" | 1 | $5.75 | Add to Order |
| Spacer-2027 | Aluminum | .750" | .380" | .750" | 1 | $6.87 | Add to Order |
| Spacer-2028 | Aluminum | .750" | .380" | .875" | 1 | $6.66 | Add to Order |
| Spacer-2029 | Aluminum | .750" | .380" | 1.00" | 1 | $7.20 | Add to Order |
| Spacer-2032 | Aluminum | .750" | .380" | 1.75" | 1 | $13.02 | Add to Order |
| Spacer-2033 | Aluminum | .750" | .380" | 2.00" | 1 | $13.02 | Add to Order |
| Spacer-4048 | Nylon 6-6 Natural | .750" | .380" | .375" | 25 | $34.84 | Add to Order |
| Spacer-4050 | Nylon 6-6 Natural | .750" | .380" | .500" | 25 | $31.06 | Add to Order |
| Spacer-4052 | Nylon 6-6 Natural | .750" | .380" | .625" | 25 | $38.49 | Add to Order |
| Spacer-4054 | Nylon 6-6 Natural | .750" | .380" | .750" | 25 | $34.31 | Add to Order |
| Spacer-4056 | Nylon 6-6 Natural | .750" | .380" | .875" | 25 | $42.17 | Add to Order |
| Spacer-4058 | Nylon 6-6 Natural | .750" | .380" | 1.00" | 25 | $43.97 | Add to Order |
| Spacer-4061 | Nylon 6-6 Natural | .750" | .380" | 1.25" | 10 | $32.17 | Add to Order |
| Spacer-4064 | Nylon 6-6 Natural | .750" | .380" | 1.50" | 10 | $33.68 | Add to Order |
| Spacer-4067 | Nylon 6-6 Natural | .750" | .380" | 1.75" | 10 | $35.13 | Add to Order |
| Spacer-4070 | Nylon 6-6 Natural | .750" | .380" | 2.00" | 10 | $36.60 | Add to Order |
| Spacer-3179 | Nylon 6-6 Natural | .750" | .380" | 2.25" | 10 | $38.09 | Add to Order |
| Spacer-3239 | Nylon 6-6 Natural | .750" | .380" | 2.50" | 10 | $39.56 | Add to Order |
| Spacer-1854 | Zinc Plated Brass | .750" | .380" | .375" | 1 | $16.34 | Add to Order |
| Spacer-1855 | Zinc Plated Brass | .750" | .380" | .500" | 1 | $19.43 | Add to Order |
| Spacer-1856 | Zinc Plated Brass | .750" | .380" | .625" | 1 | $21.44 | Add to Order |
| Spacer-1857 | Zinc Plated Brass | .750" | .380" | .750" | 1 | $23.75 | Add to Order |
| Spacer-1858 | Zinc Plated Brass | .750" | .380" | .875" | 1 | $22.55 | Add to Order |
| Spacer-3073 | Zinc Plated Brass | .750" | .380" | 1.00" | 1 | $27.85 | Add to Order |
| Spacer-1860 | Zinc Plated Brass | .750" | .380" | 1.25" | 1 | $30.45 | Add to Order |
| Spacer-1861 | Zinc Plated Brass | .750" | .380" | 1.50" | 1 | $30.95 | Add to Order |
| Spacer-1862 | Zinc Plated Brass | .750" | .380" | 1.75" | 1 | $36.14 | Add to Order |
| Spacer-1863 | Zinc Plated Brass | .750" | .380" | 2.00" | 1 | $36.88 | Add to Order |
| Spacer-2216 | Zinc Plated Steel | .750" | .380" | .375" | 1 | $6.93 | Add to Order |
| Spacer-2217 | Zinc Plated Steel | .750" | .380" | .500" | 1 | $8.51 | Add to Order |
| Spacer-2218 | Zinc Plated Steel | .750" | .380" | .625" | 1 | $9.70 | Add to Order |
| Spacer-2219 | Zinc Plated Steel | .750" | .380" | .750" | 1 | $11.68 | Add to Order |
| Spacer-2220 | Zinc Plated Steel | .750" | .380" | .875" | 1 | $12.05 | Add to Order |
| Spacer-2221 | Zinc Plated Steel | .750" | .380" | 1.00" | 1 | $13.80 | Add to Order |
| Spacer-2222 | Zinc Plated Steel | .750" | .380" | 1.25" | 1 | $15.58 | Add to Order |
| Spacer-2223 | Zinc Plated Steel | .750" | .380" | 1.50" | 1 | $18.90 | Add to Order |
| Spacer-2224 | Zinc Plated Steel | .750" | .380" | 1.75" | 1 | $22.62 | Add to Order |
| Spacer-2225 | Zinc Plated Steel | .750" | .380" | 2.00" | 1 | $28.06 | Add to Order |
| Rev. 08-23, 03-23, 06-22 | |||||||
|
Screw size number |
SAE diameter (inch) |
Metric diameter (mm) |
Screw size number |
SAE diameter (inch) |
Metric diameter (mm) |
|
| #0 | 0.060 | 1.524 | #9 | 0.177 | 4.496 | |
| #1 | 0.073 | 1.854 | #10 | 0.190 | 4.826 | |
| #2 | 0.086 | 2.184 | #11 | 0.203 | 5.156 | |
| #3 | 0.099 | 2.515 | #12 | 0.216 | 5.486 | |
| #4 | 0.122 | 3.099 | #14 | 0.242 | 6.147 | |
| #5 | 0.125 | 3.175 | #16 | 0.268 | 6.807 | |
| #6 | 0.138 | 3.505 | #18 | 0.294 | 7.468 | |
| #7 | 0.151 | 3.835 | #20 | 0.320 | 8.128 | |
| #8 | 0.164 | 4.166 | #24 | 0.372 | 9.449 |
