Chrome Coated Shafts
1045 Steel - OD Tolerance, .250-.375" OD, +0/-.001", .500-2.00" OD, +0/-.0015", .0001-.0005" Chrome Plating, 10-16rms Micron Finish
1566 Steel - OD Tolerance, .500-1.25" OD, -.0005/-.001", 1.50" OD, -.0006/-.0011", .0005" Chrome Plating, 12rms Micron Finish, Case Hardened
| Part # | Material | Shaft OD | Length | Straightness Tol. | Price | Order Online |
|---|---|---|---|---|---|---|
| Shaft-1190 | 1045 Steel | .250" | 12.00" | .003" per Ft | $17.80 | Add to Order |
| Shaft-1191 | 1045 Steel | .250" | 18.00" | .003" per Ft | $21.80 | Add to Order |
| Shaft-1192 | 1045 Steel | .250" | 24.00" | .003" per Ft | $30.20 | Add to Order |
| Shaft-1193 | 1045 Steel | .250" | 36.00" | .003" per Ft | $38.40 | Add to Order |
| Shaft-1194 | 1045 Steel | .250" | 48.00" | .003" per Ft | $61.88 | Add to Order |
| Shaft-1195 | 1045 Steel | .375" | 12.00" | .003" per Ft | $19.00 | Add to Order |
| Shaft-1196 | 1045 Steel | .375" | 18.00" | .003" per Ft | $23.60 | Add to Order |
| Shaft-1197 | 1045 Steel | .375" | 24.00" | .003" per Ft | $32.60 | Add to Order |
| Shaft-1198 | 1045 Steel | .375" | 36.00" | .003" per Ft | $41.80 | Add to Order |
| Shaft-1199 | 1045 Steel | .375" | 48.00" | .003" per Ft | $67.50 | Add to Order |
| Shaft-1200 | 1045 Steel | .500" | 12.00" | .1875" per Ft | $24.72 | Add to Order |
| Shaft-1201 | 1045 Steel | .500" | 18.00" | .1875" per Ft | $36.84 | Add to Order |
| Shaft-1202 | 1045 Steel | .500" | 24.00" | .1875" per Ft | $48.98 | Add to Order |
| Shaft-1203 | 1045 Steel | .500" | 36.00" | .1875" per Ft | $70.54 | Add to Order |
| Shaft-1204 | 1045 Steel | .500" | 48.00" | .1875" per Ft | $105.57 | Add to Order |
| Shaft-1205 | 1045 Steel | .625" | 12.00" | .125" per 10 Ft | $32.34 | Add to Order |
| Shaft-1206 | 1045 Steel | .625" | 18.00" | .125" per 10 Ft | $48.30 | Add to Order |
| Shaft-1207 | 1045 Steel | .625" | 24.00" | .125" per 10 Ft | $64.22 | Add to Order |
| Shaft-1208 | 1045 Steel | .625" | 36.00" | .125" per 10 Ft | $91.86 | Add to Order |
| Shaft-1209 | 1045 Steel | .625" | 48.00" | .125" per 10 Ft | $137.63 | Add to Order |
| Shaft-1210 | 1045 Steel | .750" | 12.00" | .125" per 10 Ft | $38.96 | Add to Order |
| Shaft-1211 | 1045 Steel | .750" | 18.00" | .125" per 10 Ft | $58.08 | Add to Order |
| Shaft-1212 | 1045 Steel | .750" | 24.00" | .125" per 10 Ft | $77.18 | Add to Order |
| Shaft-1213 | 1045 Steel | .750" | 36.00" | .125" per 10 Ft | $109.46 | Add to Order |
| Shaft-1214 | 1045 Steel | .750" | 48.00" | .125" per 10 Ft | $163.96 | Add to Order |
| Shaft-1215 | 1045 Steel | .875" | 12.00" | .125" per 10 Ft | $48.12 | Add to Order |
| Shaft-1216 | 1045 Steel | .875" | 18.00" | .125" per 10 Ft | $71.74 | Add to Order |
| Shaft-1217 | 1045 Steel | .875" | 24.00" | .125" per 10 Ft | $95.46 | Add to Order |
| Shaft-1218 | 1045 Steel | .875" | 36.00" | .125" per 10 Ft | $134.62 | Add to Order |
| Shaft-1219 | 1045 Steel | .875" | 48.00" | .125" per 10 Ft | $201.65 | Add to Order |
| Shaft-1220 | 1045 Steel | 1.00" | 12.00" | .125" per 10 Ft | $48.88 | Add to Order |
| Shaft-1221 | 1045 Steel | 1.00" | 18.00" | .125" per 10 Ft | $72.90 | Add to Order |
| Shaft-1222 | 1045 Steel | 1.00" | 24.00" | .125" per 10 Ft | $96.88 | Add to Order |
| Shaft-1223 | 1045 Steel | 1.00" | 36.00" | .125" per 10 Ft | $134.22 | Add to Order |
| Shaft-1224 | 1045 Steel | 1.00" | 48.00" | .125" per 10 Ft | $201.06 | Add to Order |
| Shaft-1225 | 1045 Steel | 1.125" | 12.00" | .125" per 10 Ft | $60.46 | Add to Order |
| Shaft-1226 | 1045 Steel | 1.125" | 18.00" | .125" per 10 Ft | $90.16 | Add to Order |
| Shaft-1227 | 1045 Steel | 1.125" | 24.00" | .125" per 10 Ft | $119.86 | Add to Order |
| Shaft-1228 | 1045 Steel | 1.125" | 36.00" | .125" per 10 Ft | $165.78 | Add to Order |
| Shaft-1229 | 1045 Steel | 1.125" | 48.00" | .125" per 10 Ft | $248.33 | Add to Order |
| Shaft-1230 | 1045 Steel | 1.25" | 12.00" | .125" per 10 Ft | $67.96 | Add to Order |
| Shaft-1231 | 1045 Steel | 1.25" | 18.00" | .125" per 10 Ft | $101.66 | Add to Order |
| Shaft-1232 | 1045 Steel | 1.25" | 24.00" | .125" per 10 Ft | $135.20 | Add to Order |
| Shaft-1233 | 1045 Steel | 1.25" | 36.00" | .125" per 10 Ft | $185.52 | Add to Order |
| Shaft-1234 | 1045 Steel | 1.25" | 48.00" | .125" per 10 Ft | $277.83 | Add to Order |
| Shaft-1235 | 1045 Steel | 1.50" | 12.00" | .125" per 10 Ft | $97.18 | Add to Order |
| Shaft-1236 | 1045 Steel | 1.50" | 18.00" | .125" per 10 Ft | $144.84 | Add to Order |
| Shaft-1237 | 1045 Steel | 1.50" | 24.00" | .125" per 10 Ft | $192.70 | Add to Order |
| Shaft-1238 | 1045 Steel | 1.50" | 36.00" | .125" per 10 Ft | $264.18 | Add to Order |
| Shaft-1239 | 1045 Steel | 1.50" | 48.00" | .125" per 10 Ft | $395.62 | Add to Order |
| Shaft-1240 | 1045 Steel | 1.75" | 12.00" | .125" per 10 Ft | $129.44 | Add to Order |
| Shaft-1241 | 1045 Steel | 1.75" | 18.00" | .125" per 10 Ft | $192.26 | Add to Order |
| Shaft-1242 | 1045 Steel | 1.75" | 24.00" | .125" per 10 Ft | $256.66 | Add to Order |
| Shaft-1243 | 1045 Steel | 1.75" | 36.00" | .125" per 10 Ft | $349.12 | Add to Order |
| Shaft-1244 | 1045 Steel | 1.75" | 48.00" | .125" per 10 Ft | $525.92 | Add to Order |
| Shaft-1245 | 1045 Steel | 2.00" | 12.00" | .125" per 10 Ft | $166.28 | Add to Order |
| Shaft-1246 | 1045 Steel | 2.00" | 18.00" | .125" per 10 Ft | $248.40 | Add to Order |
| Shaft-1247 | 1045 Steel | 2.00" | 24.00" | .125" per 10 Ft | $329.72 | Add to Order |
| Shaft-1248 | 1045 Steel | 2.00" | 36.00" | .125" per 10 Ft | $453.62 | Add to Order |
| Shaft-1249 | 1045 Steel | 2.00" | 48.00" | .125" per 10 Ft | $674.57 | Add to Order |
| Shaft-253 | 1566 Steel | .500" | 6.00" | .002" per Ft | $27.66 | Add to Order |
| Shaft-254 | 1566 Steel | .500" | 12.00" | .002" per Ft | $55.32 | Add to Order |
| Shaft-255 | 1566 Steel | .500" | 18.00" | .002" per Ft | $82.96 | Add to Order |
| Shaft-256 | 1566 Steel | .500" | 24.00" | .002" per Ft | $110.76 | Add to Order |
| Shaft-257 | 1566 Steel | .500" | 36.00" | .002" per Ft | $125.58 | Add to Order |
| Shaft-258 | 1566 Steel | .500" | 48.00" | .002" per Ft | $249.26 | Add to Order |
| Shaft-259 | 1566 Steel | .625" | 6.00" | .002" per Ft | $34.40 | Add to Order |
| Shaft-1119 | 1566 Steel | .625" | 12.00" | .002" per Ft | $68.80 | Add to Order |
| Shaft-261 | 1566 Steel | .625" | 18.00" | .002" per Ft | $103.28 | Add to Order |
| Shaft-262 | 1566 Steel | .625" | 24.00" | .002" per Ft | $104.84 | Add to Order |
| Shaft-263 | 1566 Steel | .625" | 36.00" | .002" per Ft | $206.42 | Add to Order |
| Shaft-264 | 1566 Steel | .625" | 48.00" | .002" per Ft | $309.76 | Add to Order |
| Shaft-265 | 1566 Steel | .750" | 6.00" | .002" per Ft | $41.96 | Add to Order |
| Shaft-266 | 1566 Steel | .750" | 12.00" | .002" per Ft | $64.64 | Add to Order |
| Shaft-267 | 1566 Steel | .750" | 18.00" | .002" per Ft | $125.62 | Add to Order |
| Shaft-268 | 1566 Steel | .750" | 24.00" | .002" per Ft | $167.68 | Add to Order |
| Shaft-269 | 1566 Steel | .750" | 36.00" | .002" per Ft | $251.20 | Add to Order |
| Shaft-270 | 1566 Steel | .750" | 48.00" | .002" per Ft | $376.90 | Add to Order |
| Shaft-271 | 1566 Steel | 1.00" | 6.00" | .002" per Ft | $52.46 | Add to Order |
| Shaft-272 | 1566 Steel | 1.00" | 12.00" | .002" per Ft | $104.90 | Add to Order |
| Shaft-273 | 1566 Steel | 1.00" | 18.00" | .002" per Ft | $118.74 | Add to Order |
| Shaft-274 | 1566 Steel | 1.00" | 24.00" | .002" per Ft | $163.06 | Add to Order |
| Shaft-275 | 1566 Steel | 1.00" | 36.00" | .002" per Ft | $314.86 | Add to Order |
| Shaft-276 | 1566 Steel | 1.00" | 48.00" | .002" per Ft | $356.24 | Add to Order |
| Shaft-277 | 1566 Steel | 1.25" | 6.00" | .002" per Ft | $69.22 | Add to Order |
| Shaft-278 | 1566 Steel | 1.25" | 12.00" | .002" per Ft | $138.60 | Add to Order |
| Shaft-279 | 1566 Steel | 1.25" | 18.00" | .002" per Ft | $207.96 | Add to Order |
| Shaft-280 | 1566 Steel | 1.25" | 24.00" | .002" per Ft | $277.10 | Add to Order |
| Shaft-281 | 1566 Steel | 1.25" | 36.00" | .002" per Ft | $415.70 | Add to Order |
| Shaft-282 | 1566 Steel | 1.25" | 48.00" | .002" per Ft | $623.56 | Add to Order |
| Shaft-283 | 1566 Steel | 1.50" | 6.00" | .002" per Ft | $84.40 | Add to Order |
| Shaft-284 | 1566 Steel | 1.50" | 12.00" | .002" per Ft | $168.76 | Add to Order |
| Shaft-285 | 1566 Steel | 1.50" | 18.00" | .002" per Ft | $253.06 | Add to Order |
| Shaft-286 | 1566 Steel | 1.50" | 24.00" | .002" per Ft | $337.48 | Add to Order |
| Shaft-287 | 1566 Steel | 1.50" | 36.00" | .002" per Ft | $506.18 | Add to Order |
| Shaft-288 | 1566 Steel | 1.50" | 48.00" | .002" per Ft | $788.65 | Add to Order |
| Rev. 04-23, 01-23, 06-22, 02-22 | ||||||
