Hardened Precision Metric Shafts
17/4PH Stainless Steel - Straightness Tolerance 3 mm per 300 mm, Case Hardened
316 Stainless Steel - Straightness Tolerance, 1-6 mm OD, .09 mm per 300 mm, 7-10 mm OD, .12 mm per 300 mm
Metric Precision Shafts with Chamfered Ends OD Tolerance +0 mm/-.005 mm, 10rms Micron Finish |
|||||
| Part # | Material | Shaft OD | Length | Price | Order Online |
|---|---|---|---|---|---|
| Shaft-563 | 17-4PH Stainless Steel | 1mm | 300mm | $76.01 | Add to Order |
| Shaft-564 | 17-4PH Stainless Steel | 1.5mm | 300mm | $72.10 | Add to Order |
| Shaft-565 | 17-4PH Stainless Steel | 1.5mm | 500mm | $100.78 | Add to Order |
| Shaft-569 | 17-4PH Stainless Steel | 2.5mm | 300mm | $56.72 | Add to Order |
| Shaft-570 | 17-4PH Stainless Steel | 2.5mm | 600mm | $81.16 | Add to Order |
| Shaft-571 | 17-4PH Stainless Steel | 2.5mm | 900mm | $117.10 | Add to Order |
| Shaft-566 | 17-4PH Stainless Steel | 2mm | 300mm | $62.26 | Add to Order |
| Shaft-567 | 17-4PH Stainless Steel | 2mm | 600mm | $91.92 | Add to Order |
| Shaft-568 | 17-4PH Stainless Steel | 2mm | 900mm | $135.22 | Add to Order |
| Shaft-572 | 17-4PH Stainless Steel | 3mm | 300mm | $68.41 | Add to Order |
| Shaft-573 | 17-4PH Stainless Steel | 3mm | 600mm | $101.86 | Add to Order |
| Shaft-574 | 17-4PH Stainless Steel | 3mm | 900mm | $141.43 | Add to Order |
| Shaft-575 | 17-4PH Stainless Steel | 4mm | 300mm | $90.20 | Add to Order |
| Shaft-576 | 17-4PH Stainless Steel | 4mm | 600mm | $157.62 | Add to Order |
| Shaft-577 | 17-4PH Stainless Steel | 4mm | 900mm | $211.79 | Add to Order |
| Shaft-1632 | 316 Stainless Steel | 1mm | 200mm | $14.47 | Add to Order |
| Shaft-1633 | 316 Stainless Steel | 1mm | 400mm | $32.70 | Add to Order |
| Shaft-1634 | 316 Stainless Steel | 1.5mm | 200mm | $21.81 | Add to Order |
| Shaft-1635 | 316 Stainless Steel | 1.5mm | 400mm | $51.09 | Add to Order |
| Shaft-1636 | 316 Stainless Steel | 2mm | 200mm | $23.23 | Add to Order |
| Shaft-1637 | 316 Stainless Steel | 2mm | 400mm | $42.19 | Add to Order |
| Shaft-1638 | 316 Stainless Steel | 2mm | 600mm | $86.65 | Add to Order |
| Shaft-1639 | 316 Stainless Steel | 2mm | 800mm | $112.50 | Add to Order |
| Shaft-1640 | 316 Stainless Steel | 2.5mm | 200mm | $34.38 | Add to Order |
| Shaft-1641 | 316 Stainless Steel | 2.5mm | 400mm | $58.28 | Add to Order |
| Shaft-1642 | 316 Stainless Steel | 2.5mm | 600mm | $89.15 | Add to Order |
| Shaft-1643 | 316 Stainless Steel | 2.5mm | 800mm | $115.21 | Add to Order |
| Shaft-1644 | 316 Stainless Steel | 3mm | 200mm | $39.18 | Add to Order |
| Shaft-1645 | 316 Stainless Steel | 3mm | 400mm | $70.79 | Add to Order |
| Shaft-1646 | 316 Stainless Steel | 3mm | 600mm | $102.75 | Add to Order |
| Shaft-1647 | 316 Stainless Steel | 3mm | 800mm | $169.33 | Add to Order |
| Shaft-1648 | 316 Stainless Steel | 4mm | 200mm | $39.18 | Add to Order |
| Shaft-1649 | 316 Stainless Steel | 4mm | 400mm | $70.79 | Add to Order |
| Shaft-1650 | 316 Stainless Steel | 4mm | 600mm | $102.75 | Add to Order |
| Shaft-1651 | 316 Stainless Steel | 4mm | 800mm | $169.37 | Add to Order |
| Shaft-1652 | 316 Stainless Steel | 5mm | 200mm | $48.99 | Add to Order |
| Shaft-1653 | 316 Stainless Steel | 5mm | 400mm | $86.22 | Add to Order |
| Shaft-1654 | 316 Stainless Steel | 5mm | 600mm | $117.30 | Add to Order |
| Shaft-1655 | 316 Stainless Steel | 5mm | 800mm | $183.86 | Add to Order |
| Shaft-1656 | 316 Stainless Steel | 6mm | 200mm | $56.01 | Add to Order |
| Shaft-1657 | 316 Stainless Steel | 6mm | 400mm | $89.18 | Add to Order |
| Shaft-1658 | 316 Stainless Steel | 6mm | 600mm | $120.17 | Add to Order |
| Shaft-1659 | 316 Stainless Steel | 6mm | 800mm | $188.21 | Add to Order |
| Shaft-1660 | 316 Stainless Steel | 7mm | 200mm | $62.18 | Add to Order |
| Shaft-1661 | 316 Stainless Steel | 7mm | 400mm | $98.28 | Add to Order |
| Shaft-1662 | 316 Stainless Steel | 7mm | 600mm | $130.01 | Add to Order |
| Shaft-1663 | 316 Stainless Steel | 7mm | 800mm | $195.65 | Add to Order |
| Shaft-1664 | 316 Stainless Steel | 8mm | 200mm | $56.01 | Add to Order |
| Shaft-1665 | 316 Stainless Steel | 8mm | 400mm | $94.71 | Add to Order |
| Shaft-1666 | 316 Stainless Steel | 8mm | 600mm | $127.78 | Add to Order |
| Shaft-1667 | 316 Stainless Steel | 8mm | 800mm | $188.21 | Add to Order |
| Shaft-1668 | 316 Stainless Steel | 9mm | 200mm | $89.71 | Add to Order |
| Shaft-1669 | 316 Stainless Steel | 9mm | 400mm | $168.33 | Add to Order |
| Shaft-1670 | 316 Stainless Steel | 9mm | 600mm | $208.87 | Add to Order |
| Shaft-1671 | 316 Stainless Steel | 9mm | 800mm | $281.67 | Add to Order |
| Shaft-1672 | 316 Stainless Steel | 10mm | 200mm | $107.73 | Add to Order |
| Shaft-1673 | 316 Stainless Steel | 10mm | 400mm | $186.51 | Add to Order |
| Shaft-1674 | 316 Stainless Steel | 10mm | 600mm | $245.16 | Add to Order |
| Shaft-1675 | 316 Stainless Steel | 10mm | 800mm | $324.84 | Add to Order |
| Rev. 09-26, 06-26, 01-23, 02-22 | |||||
