Metric Steel Cone Point Set Screws
| Metric Alloy Steel Cone Point Set Screws | |||||||
| Part # | Thread Size | Pitch (mm) | Overall Length (mm) | Cone Point Angle | Pkg. Price | Order Online | Pkg. Qty |
|---|---|---|---|---|---|---|---|
| SSS-2806 | M2.5 | 0.45 mm | 3 | 120° | $10.61 | Add to Order | 10 |
| SSS-2807 | M2.5 | 0.45 mm | 6 | 90° | $10.37 | Add to Order | 10 |
| SSS-660 | M3 | 0.5 mm | 3 | 120° | $20.69 | Add to Order | 50 |
| SSS-661 | M3 | 0.5 mm | 4 | 90° | $21.99 | Add to Order | 50 |
| SSS-662 | M3 | 0.5 mm | 5 | 90° | $21.76 | Add to Order | 50 |
| SSS-663 | M3 | 0.5 mm | 6 | 90° | $23.63 | Add to Order | 50 |
| SSS-664 | M3 | 0.5 mm | 8 | 90° | $24.89 | Add to Order | 50 |
| SSS-665 | M4 | 0.7 mm | 4 | 120° | $18.21 | Add to Order | 50 |
| SSS-666 | M4 | 0.7 mm | 5 | 90° | $15.98 | Add to Order | 50 |
| SSS-667 | M4 | 0.7 mm | 6 | 90° | $19.74 | Add to Order | 50 |
| SSS-668 | M4 | 0.7 mm | 8 | 90° | $16.91 | Add to Order | 50 |
| SSS-669 | M4 | 0.7 mm | 10 | 90° | $20.77 | Add to Order | 50 |
| SSS-670 | M4 | 0.7 mm | 12 | 90° | $21.84 | Add to Order | 50 |
| SSS-2808B | M4 | 0.7 mm | 16 | 90° | $5.92 | Add to Order | 25 |
| SSS-2809 | M4 | 0.7 mm | 20 | 90° | $19.24 | Add to Order | 25 |
| SSS-671 | M5 | 0.8 mm | 5 | 120° | $21.99 | Add to Order | 50 |
| SSS-672 | M5 | 0.8 mm | 6 | 90° | $21.25 | Add to Order | 50 |
| SSS-673 | M5 | 0.8 mm | 8 | 90° | $20.43 | Add to Order | 50 |
| SSS-674 | M5 | 0.8 mm | 10 | 90° | $18.46 | Add to Order | 50 |
| SSS-675 | M5 | 0.8 mm | 12 | 90° | $18.61 | Add to Order | 50 |
| SSS-676 | M5 | 0.8 mm | 16 | 90° | $18.94 | Add to Order | 50 |
| SSS-677 | M5 | 0.8 mm | 20 | 90° | $15.81 | Add to Order | 25 |
| SSS-678 | M6 | 1 mm | 6 | 120° | $22.07 | Add to Order | 50 |
| SSS-679 | M6 | 1 mm | 8 | 90° | $18.59 | Add to Order | 50 |
| SSS-680 | M6 | 1 mm | 10 | 90° | $18.79 | Add to Order | 50 |
| SSS-681 | M6 | 1 mm | 12 | 90° | $22.58 | Add to Order | 50 |
| SSS-682 | M6 | 1 mm | 16 | 90° | $25.10 | Add to Order | 50 |
| SSS-683 | M6 | 1 mm | 20 | 90° | $11.53 | Add to Order | 25 |
| SSS-684 | M6 | 1 mm | 25 | 90° | $22.39 | Add to Order | 25 |
| SSS-685 | M6 | 1 mm | 30 | 90° | $27.51 | Add to Order | 25 |
| SSS-686 | M8 | 1.25 mm | 8 | 120° | $25.49 | Add to Order | 50 |
| SSS-687 | M8 | 1.25 mm | 10 | 90° | $20.18 | Add to Order | 50 |
| SSS-688 | M8 | 1.25 mm | 12 | 90° | $26.10 | Add to Order | 50 |
| SSS-689 | M8 | 1.25 mm | 16 | 90° | $22.64 | Add to Order | 25 |
| SSS-690 | M8 | 1.25 mm | 20 | 90° | $25.35 | Add to Order | 25 |
| SSS-691 | M8 | 1.25 mm | 22 | 90° | $25.39 | Add to Order | 10 |
| SSS-2810 | M8 | 1.25 mm | 25 | 90° | $13.59 | Add to Order | 10 |
| SSS-692 | M8 | 1.25 mm | 30 | 90° | $15.06 | Add to Order | 10 |
| SSS-693 | M8 | 1.25 mm | 40 | 90° | $17.22 | Add to Order | 10 |
| SSS-694 | M8 | 1.25 mm | 50 | 90° | $27.26 | Add to Order | 10 |
| SSS-695 | M10 | 1.5 mm | 10 | 120° | $22.30 | Add to Order | 25 |
| SSS-696 | M10 | 1.5 mm | 12 | 90° | $26.06 | Add to Order | 25 |
| SSS-697 | M10 | 1.5 mm | 16 | 90° | $30.49 | Add to Order | 25 |
| SSS-698 | M10 | 1.5 mm | 20 | 90° | $23.75 | Add to Order | 25 |
| SSS-699 | M10 | 1.5 mm | 25 | 90° | $18.56 | Add to Order | 10 |
| SSS-700 | M10 | 1.5 mm | 30 | 90° | $22.79 | Add to Order | 10 |
| SSS-701 | M10 | 1.5 mm | 40 | 90° | $34.02 | Add to Order | 10 |
| SSS-702 | M10 | 1.5 mm | 50 | 90° | $23.75 | Add to Order | 5 |
| SSS-703 | M12 | 1.75 mm | 12 | 120° | $19.70 | Add to Order | 10 |
| SSS-704 | M12 | 1.75 mm | 16 | 90° | $17.49 | Add to Order | 10 |
| SSS-705 | M12 | 1.75 mm | 20 | 90° | $23.63 | Add to Order | 10 |
| SSS-706 | M12 | 1.75 mm | 25 | 90° | $24.97 | Add to Order | 10 |
| SSS-707 | M12 | 1.75 mm | 30 | 90° | $30.49 | Add to Order | 10 |
| SSS-708 | M12 | 1.75 mm | 40 | 90° | $24.28 | Add to Order | 5 |
| SSS-709 | M12 | 1.75 mm | 50 | 90° | $25.37 | Add to Order | 5 |
| SSS-712 | M16 | 2 mm | 25 | 90° | $29.38 | Add to Order | 5 |
| SSS-715 | M16 | 2 mm | 50 | 90° | $6.89 | Add to Order | 1 |
| Rev. 11-22, 03-22 | |||||||
