Extruded PTFE Tubes
Virgin Extruded PTFE Tubing is The best chemically resistant tubing available and it handles temperatures up to 500°F.
PTFE
Typical Properties
PTFE
Chemical Resistance
Click Here for Molded PTFE Tubes
Click Here for Extruded Micro-Tubing
| PTFE Virgin Extruded Tubing - Coiled | |||||
| Part # | OD (in.) | ID (in.) | Wall Thickness (in.) | Price | Order Online |
|---|---|---|---|---|---|
| KM-5297 | .062 | .031 | .016 | $159.75 per 50 ft | Add to Order |
| KM-5394 | .125 | .062 | .031 | $136.71 per 50 ft | Add to Order |
| KM-5271Q | .156 | .093 | .031 | $209.05 per 50 ft | Add to Order |
| KM-4828 | .188 | .063 | .062 | $569.25 per 100 ft | Add to Order |
| KM-5346 | .188 | .125 | .031 | $222.75 per 50 ft | Add to Order |
| KM-4838 | .250 | .156 | .047 | $337.50 per 25 ft | Add to Order |
| KM-5444 | .250 | .187 | .031 | $287.12 per 50 ft | Add to Order |
| KM-5443 | .313 | .187 | .062 | $728.69 per 50 ft | Add to Order |
| KM-5440 | .375 | .312 | .031 | $522.86 per 50 ft | Add to Order |
| KM-4840 | .438 | .313 | .062 | $1,251.92 per 50 ft | Add to Order |
| KM-5438 | .438 | .375 | .031 | $555.17 per 50 ft | Add to Order |
| KM-5437 | .500 | .375 | .062 | $1,290.11 per 50 ft | Add to Order |
| KM-5436 | .500 | .437 | .031 | $703.71 per 50 ft | Add to Order |
| KM-5422 | .562 | .437 | .062 | $2,143.75 per 50 ft | Add to Order |
| KM-5434 | .562 | .500 | .031 | $1,153.75 per 50 ft | Add to Order |
| KM-5461 | .625 | .500 | .062 | $946.44 per 25 ft | Add to Order |
| KM-4815 | .688 | .563 | .062 | $1,134.56 per 25 ft | Add to Order |
| KM-5460 | .688 | .625 | .031 | $1,310.63 per 50 ft | Add to Order |
| KM-5447 | .750 | .625 | .062 | $1,030.10 per 25 ft | Add to Order |
| KM-5429 | .875 | .750 | .062 | $1,205.19 per 25 ft | Add to Order |
| Rev. 03-25, 03-24, 10-23, 04-23 | |||||
| PTFE
Extruded Straight Tubes
6 Foot Standard Lengths |
|||||
| Part # | OD (in.) | ID (in.) | Wall Thickness (in.) | Price Per Foot | Order Online |
|---|---|---|---|---|---|
| KM-611 | .250 | .125 | .062 | $13.64 | Add to Order |
| KM-1094 | .250 | .062 | .093 | $15.66 | Add to Order |
| KM-1095 | .312 | .187 | .062 | $6.50 | Add to Order |
| KM-621 | .375 | .250 | .062 | $9.04 | Add to Order |
| KM-1096 | .437 | .312 | .062 | $9.93 | Add to Order |
| KM-1098 | .500 | .375 | .062 | $12.53 | Add to Order |
| KM-1097 | .500 | .312 | .093 | $13.23 | Add to Order |
| KM-622 | .500 | .250 | .125 | $9.45 | Add to Order |
| KM-1099 | .562 | .437 | .062 | $9.47 | Add to Order |
| KM-1102 | .625 | .500 | .062 | $15.55 | Add to Order |
| KM-4475 | .625 | .375 | .125 | $15.55 | Add to Order |
| KM-4473 | .625 | .250 | .187 | $25.25 | Add to Order |
| KM-1106 | .750 | .625 | .062 | $11.03 | Add to Order |
| KM-623 | .750 | .500 | .125 | $23.99 | Add to Order |
| KM-4476 | .750 | .375 | .187 | $34.09 | Add to Order |
| KM-1103 | .750 | .250 | .250 | $38.41 | Add to Order |
| KM-1108 | .875 | .625 | .125 | $28.78 | Add to Order |
| KM-1107 | .875 | .375 | .250 | $48.08 | Add to Order |
| KM-4848 | 1.00 | .875 | .062 | $46.06 | Add to Order |
| KM-625 | 1.00 | .750 | .125 | $33.55 | Add to Order |
| KM-4480 | 1.00 | .625 | .187 | $46.71 | Add to Order |
| KM-624 | 1.00 | .500 | .250 | $57.44 | Add to Order |
| KM-4488 | 1.25 | 1.00 | .062 | $43.56 | Add to Order |
| KM-1111 | 1.25 | .875 | .187 | $55.33 | Add to Order |
| KM-1114 | 1.375 | 1.00 | .187 | $61.81 | Add to Order |
| KM-1113 | 1.375 | .875 | .250 | $77.92 | Add to Order |
| KM-4492 | 1.50 | 1.25 | .125 | $57.46 | Add to Order |
| KM-626 | 1.50 | 1.00 | .250 | $95.74 | Add to Order |
| KM-4497 | 1.75 | 1.50 | .125 | $71.03 | Add to Order |
| KM-4496 | 1.75 | 1.375 | .187 | $88.81 | Add to Order |
| KM-1118 | 1.875 | 1.50 | .187 | $97.18 | Add to Order |
| KM-4500 | 2.00 | 1.75 | .125 | $165.53 | Add to Order |
| KM-1119 | 2.00 | 1.50 | .250 | $122.56 | Add to Order |
| KM-4498 | 2.25 | 1.50 | .375 | $197.28 | Add to Order |
| KM-4503 | 2.50 | 2.00 | .250 | $317.43 | Add to Order |
| KM-618 | 3.00 | 2.00 | .500 | $389.68 | Add to Order |
| Rev. 11-25, 04-23, 09-22, 03-22 | |||||
OD tolerance is +.032" for ODs 1/4"
to 1 1/2"
and +.065" for ODs 1 3/4"
and greater.
ID tolerance is -.032" for IDs 1/16"
to 1 1/4"
and -.065" for IDs 1 3/8"
and greater.
