1/4" Wall LE Linen Phenolic Tubes
NEMA grades L and LE Linen Cotton-Cloth Reinforced Phenolics naturally have a light tan to brown color. This grade is composed of a continuous cotton woven cloth impregnated with a phenolic resin binder. The finer weave allows for machining more intricate details than canvas grade, such as gear teeth. Canvas phenolic still provides electrical insulation than LE, but LE resists moisture better than canvas.
NEMA LE certs to MIL-I-24768/13 FBE, IEC 60893-3 Type 4 PF CC 305
Tolerances • Technical Data • Chemical Resistance • Other Wall Sizes
Tubes are manufactured in random lengths between 30" and 36".
The pricing and minimum orders are based on the 36".
Tubes can also be produced in 42" to 48" random lengths for the same price per foot.
Measured lengths of 36"±1" and 48"±1" are also available (call for pricing)
| L/LE Tubes - .250" Wall Thickness | |||||
| Part # | OD (in.) | ID (in.) | Minimum Order | Price Per Foot | Order Online |
|---|---|---|---|---|---|
| KM-5191 | .688 | .187 | 15 Feet | $70.13 | Add to Order |
| KM-5073 | .750 | .250 | 15 Feet | $76.65 | Add to Order |
| KM-5212 | .813 | .312 | 15 Feet | $83.18 | Add to Order |
| KM-5202 | .875 | .375 | 21 Feet | $49.75 | Add to Order |
| KM-15097 | .938 | .437 | 21 Feet | $53.38 | Add to Order |
| KM-2204 | 1.000 | .500 | 18 Feet | $57.00 | Add to Order |
| KM-2209 | 1.063 | .562 | 18 Feet | $60.63 | Add to Order |
| KM-2215 | 1.125 | .625 | 18 Feet | $65.60 | Add to Order |
| KM-13967 | 1.187 | .687 | 15 Feet | $69.30 | Add to Order |
| KM-2224 | 1.250 | .750 | 15 Feet | $73.00 | Add to Order |
| KM-13968 | 1.312 | .812 | 15 Feet | $76.70 | Add to Order |
| KM-2229 | 1.375 | .875 | 15 Feet | $80.40 | Add to Order |
| KM-13969 | 1.437 | .937 | 12 Feet | $84.10 | Add to Order |
| KM-2235 | 1.500 | 1.00 | 12 Feet | $87.80 | Add to Order |
| KM-13970 | 1.562 | 1.062 | 12 Feet | $91.45 | Add to Order |
| KM-13971 | 1.625 | 1.125 | 12 Feet | $95.18 | Add to Order |
| KM-13972 | 1.688 | 1.187 | 12 Feet | $98.85 | Add to Order |
| KM-2239 | 1.750 | 1.250 | 12 Feet | $102.58 | Add to Order |
| KM-13984 | 1.812 | 1.312 | 12 Feet | $106.25 | Add to Order |
| KM-13974 | 1.875 | 1.375 | 12 Feet | $109.98 | Add to Order |
| KM-13965 | 1.937 | 1.437 | 9 Feet | $113.63 | Add to Order |
| KM-2243 | 2.000 | 1.500 | 9 Feet | $117.38 | Add to Order |
| KM-13976 | 2.062 | 1.562 | 9 Feet | $121.02 | Add to Order |
| KM-13977 | 2.125 | 1.625 | 9 Feet | $124.75 | Add to Order |
| KM-13978 | 2.188 | 1.687 | 9 Feet | $128.42 | Add to Order |
| KM-2248 | 2.250 | 1.750 | 9 Feet | $132.15 | Add to Order |
| KM-13979 | 2.312 | 1.812 | 9 Feet | $135.83 | Add to Order |
| KM-13980 | 2.375 | 1.875 | 9 Feet | $139.55 | Add to Order |
| KM-13981 | 2.437 | 1.937 | 9 Feet | $143.20 | Add to Order |
| KM-2253 | 2.500 | 2.000 | 9 Feet | $146.93 | Add to Order |
| KM-13982 | 2.562 | 2.062 | 9 Feet | $150.60 | Add to Order |
| KM-13983 | 2.625 | 2.125 | 9 Feet | $154.33 | Add to Order |
| KM-13955 | 2.688 | 2.187 | 9 Feet | $158.00 | Add to Order |
| KM-2258 | 2.750 | 2.250 | 9 Feet | $161.73 | Add to Order |
| KM-13953 | 2.812 | 2.312 | 9 Feet | $165.40 | Add to Order |
| KM-13973 | 2.875 | 2.375 | 6 Feet | $169.13 | Add to Order |
| KM-13947 | 2.937 | 2.437 | 6 Feet | $172.78 | Add to Order |
| KM-2263 | 3.000 | 2.500 | 6 Feet | $176.50 | Add to Order |
| KM-13948 | 3.062 | 2.562 | 6 Feet | $180.17 | Add to Order |
| KM-13949 | 3.125 | 2.625 | 6 Feet | $183.90 | Add to Order |
| KM-13950 | 3.188 | 2.687 | 6 Feet | $187.58 | Add to Order |
| KM-2268 | 3.250 | 2.750 | 6 Feet | $191.30 | Add to Order |
| KM-13951 | 3.312 | 2.812 | 6 Feet | $194.98 | Add to Order |
| KM-13952 | 3.375 | 2.875 | 6 Feet | $198.70 | Add to Order |
| KM-13964 | 3.437 | 2.937 | 6 Feet | $202.35 | Add to Order |
| KM-2273 | 3.500 | 3.000 | 6 Feet | $206.08 | Add to Order |
| KM-13954 | 3.562 | 3.062 | 6 Feet | $209.75 | Add to Order |
| KM-13945 | 3.625 | 3.125 | 6 Feet | $213.48 | Add to Order |
| KM-13956 | 3.687 | 3.187 | 6 Feet | $217.15 | Add to Order |
| KM-2278 | 3.750 | 3.250 | 6 Feet | $220.88 | Add to Order |
| KM-13957 | 3.812 | 3.312 | 6 Feet | $224.53 | Add to Order |
| KM-13958 | 3.875 | 3.375 | 6 Feet | $228.25 | Add to Order |
| KM-13959 | 3.937 | 3.437 | 6 Feet | $231.92 | Add to Order |
| KM-2283 | 4.000 | 3.500 | 6 Feet | $235.65 | Add to Order |
| KM-13960 | 4.062 | 3.562 | 6 Feet | $239.33 | Add to Order |
| KM-13961 | 4.125 | 3.625 | 6 Feet | $243.05 | Add to Order |
| KM-13962 | 4.187 | 3.687 | 6 Feet | $246.73 | Add to Order |
| KM-2288 | 4.250 | 3.750 | 6 Feet | $250.45 | Add to Order |
| KM-13963 | 4.312 | 3.812 | 6 Feet | $254.10 | Add to Order |
| KM-13993 | 4.375 | 3.875 | 6 Feet | $257.83 | Add to Order |
| KM-14024 | 4.437 | 3.937 | 6 Feet | $261.50 | Add to Order |
| KM-2293 | 4.500 | 4.000 | 6 Feet | $265.23 | Add to Order |
| KM-13975 | 4.562 | 4.062 | 6 Feet | $268.90 | Add to Order |
| KM-14007 | 4.625 | 4.125 | 6 Feet | $272.63 | Add to Order |
| KM-14008 | 4.687 | 4.187 | 6 Feet | $276.30 | Add to Order |
| KM-14009 | 4.750 | 4.250 | 6 Feet | $280.03 | Add to Order |
| KM-14010 | 4.812 | 4.312 | 6 Feet | $283.68 | Add to Order |
| KM-14011 | 4.875 | 4.375 | 6 Feet | $287.40 | Add to Order |
| KM-14012 | 4.937 | 4.438 | 6 Feet | $291.08 | Add to Order |
| KM-2298 | 5.00 | 4.500 | 6 Feet | $294.80 | Add to Order |
| KM-14013 | 5.062 | 4.562 | 6 Feet | $298.48 | Add to Order |
| KM-14025 | 5.125 | 4.625 | 6 Feet | $302.20 | Add to Order |
| KM-14015 | 5.187 | 4.687 | 6 Feet | $305.85 | Add to Order |
| KM-14005 | 5.250 | 4.750 | 6 Feet | $309.60 | Add to Order |
| KM-14017 | 5.312 | 4.812 | 6 Feet | $313.25 | Add to Order |
| KM-14018 | 5.375 | 4.875 | 3 Feet | $351.63 | Add to Order |
| KM-14019 | 5.437 | 4.937 | 3 Feet | $355.70 | Add to Order |
| KM-2303 | 5.500 | 5.000 | 3 Feet | $359.83 | Add to Order |
| KM-14020 | 5.562 | 5.062 | 3 Feet | $363.90 | Add to Order |
| KM-14021 | 5.625 | 5.125 | 3 Feet | $368.03 | Add to Order |
| KM-14022 | 5.688 | 5.187 | 3 Feet | $372.10 | Add to Order |
| KM-14023 | 5.750 | 5.250 | 3 Feet | $376.23 | Add to Order |
| KM-13995 | 5.812 | 5.313 | 3 Feet | $380.30 | Add to Order |
| KM-14016 | 5.875 | 5.375 | 3 Feet | $384.43 | Add to Order |
| KM-14014 | 5.938 | 5.437 | 3 Feet | $388.50 | Add to Order |
| KM-13986 | 6.000 | 5.500 | 3 Feet | $392.63 | Add to Order |
| KM-13987 | 6.063 | 5.562 | 3 Feet | $396.70 | Add to Order |
| KM-13988 | 6.125 | 5.625 | 3 Feet | $400.83 | Add to Order |
| KM-13989 | 6.187 | 5.687 | 3 Feet | $404.90 | Add to Order |
| KM-13990 | 6.250 | 5.750 | 3 Feet | $409.05 | Add to Order |
| KM-13991 | 6.312 | 5.812 | 3 Feet | $413.10 | Add to Order |
| KM-13992 | 6.375 | 5.875 | 3 Feet | $417.25 | Add to Order |
| KM-14004 | 6.437 | 5.937 | 3 Feet | $421.30 | Add to Order |
| KM-2315 | 6.500 | 6.000 | 3 Feet | $425.45 | Add to Order |
| KM-14058 | 6.562 | 6.062 | 3 Feet | $392.70 | Add to Order |
| KM-13994 | 6.625 | 6.125 | 3 Feet | $396.63 | Add to Order |
| KM-13985 | 6.688 | 6.187 | 3 Feet | $400.48 | Add to Order |
| KM-13996 | 6.750 | 6.250 | 3 Feet | $404.40 | Add to Order |
| KM-13997 | 6.812 | 6.312 | 3 Feet | $408.25 | Add to Order |
| KM-13998 | 6.875 | 6.375 | 3 Feet | $412.18 | Add to Order |
| KM-13999 | 6.938 | 6.437 | 3 Feet | $416.03 | Add to Order |
| KM-14000 | 7.000 | 6.500 | 3 Feet | $419.95 | Add to Order |
| KM-14001 | 7.062 | 6.562 | 3 Feet | $423.80 | Add to Order |
| KM-14002 | 7.125 | 6.625 | 3 Feet | $427.73 | Add to Order |
| KM-13935 | 7.187 | 6.687 | 3 Feet | $431.58 | Add to Order |
| KM-14006 | 7.250 | 6.750 | 3 Feet | $435.50 | Add to Order |
| KM-13946 | 7.312 | 6.812 | 3 Feet | $439.38 | Add to Order |
| KM-13886 | 7.375 | 6.875 | 3 Feet | $443.28 | Add to Order |
| KM-13887 | 7.437 | 6.938 | 3 Feet | $447.15 | Add to Order |
| KM-13888 | 7.500 | 7.000 | 3 Feet | $451.05 | Add to Order |
| KM-13889 | 7.562 | 7.062 | 3 Feet | $454.93 | Add to Order |
| KM-13890 | 7.625 | 7.125 | 3 Feet | $458.83 | Add to Order |
| KM-13891 | 7.688 | 7.187 | 3 Feet | $462.70 | Add to Order |
| KM-13892 | 7.750 | 7.250 | 3 Feet | $466.63 | Add to Order |
| KM-13904 | 7.812 | 7.312 | 3 Feet | $470.48 | Add to Order |
| KM-13894 | 7.875 | 7.375 | 3 Feet | $474.40 | Add to Order |
| KM-13885 | 7.938 | 7.437 | 3 Feet | $478.25 | Add to Order |
| KM-13896 | 8.000 | 7.500 | 3 Feet | $482.18 | Add to Order |
| KM-13897 | 8.062 | 7.562 | 3 Feet | $486.03 | Add to Order |
| KM-13898 | 8.125 | 7.625 | 3 Feet | $489.95 | Add to Order |
| KM-13899 | 8.188 | 7.687 | 3 Feet | $493.80 | Add to Order |
| KM-13900 | 8.250 | 7.750 | 3 Feet | $497.73 | Add to Order |
| KM-13901 | 8.312 | 7.812 | 3 Feet | $501.58 | Add to Order |
| KM-13902 | 8.375 | 7.875 | 3 Feet | $505.50 | Add to Order |
| KM-13903 | 8.437 | 7.937 | 3 Feet | $509.35 | Add to Order |
| KM-13875 | 8.500 | 8.000 | 3 Feet | $513.28 | Add to Order |
| KM-13893 | 8.625 | 8.125 | 3 Feet | $521.05 | Add to Order |
| KM-13867 | 8.688 | 8.187 | 3 Feet | $524.90 | Add to Order |
| KM-13868 | 8.750 | 8.250 | 3 Feet | $528.83 | Add to Order |
| KM-13869 | 8.812 | 8.312 | 3 Feet | $532.68 | Add to Order |
| KM-13870 | 8.875 | 8.375 | 3 Feet | $536.60 | Add to Order |
| KM-13871 | 8.938 | 8.437 | 3 Feet | $540.48 | Add to Order |
| KM-13872 | 9.000 | 8.500 | 3 Feet | $544.38 | Add to Order |
| KM-13884 | 9.062 | 8.562 | 3 Feet | $548.25 | Add to Order |
| KM-13874 | 9.125 | 8.625 | 3 Feet | $552.15 | Add to Order |
| KM-13865 | 9.188 | 8.687 | 3 Feet | $556.03 | Add to Order |
| KM-13876 | 9.250 | 8.75 | 3 Feet | $559.93 | Add to Order |
| KM-13877 | 9.312 | 8.812 | 3 Feet | $563.80 | Add to Order |
| KM-13878 | 9.375 | 8.875 | 3 Feet | $567.73 | Add to Order |
| KM-13879 | 9.437 | 8.937 | 3 Feet | $571.58 | Add to Order |
| KM-13880 | 9.500 | 9.000 | 3 Feet | $575.50 | Add to Order |
| KM-13881 | 9.563 | 9.062 | 3 Feet | $579.35 | Add to Order |
| KM-13882 | 9.625 | 9.125 | 3 Feet | $583.28 | Add to Order |
| KM-13906 | 9.688 | 9.187 | 3 Feet | $587.13 | Add to Order |
| KM-13866 | 9.750 | 9.250 | 3 Feet | $591.05 | Add to Order |
| KM-13895 | 9.812 | 9.312 | 3 Feet | $594.90 | Add to Order |
| KM-13926 | 9.875 | 9.375 | 3 Feet | $598.83 | Add to Order |
| KM-13927 | 9.937 | 9.437 | 3 Feet | $602.68 | Add to Order |
| KM-13928 | 10.000 | 9.500 | 3 Feet | $606.60 | Add to Order |
| KM-13929 | 10.062 | 9.562 | 3 Feet | $610.45 | Add to Order |
| KM-13930 | 10.125 | 9.625 | 3 Feet | $614.38 | Add to Order |
| KM-13931 | 10.187 | 9.687 | 3 Feet | $618.23 | Add to Order |
| KM-13932 | 10.250 | 9.750 | 3 Feet | $622.15 | Add to Order |
| KM-13944 | 10.313 | 9.813 | 3 Feet | $626.00 | Add to Order |
| KM-13934 | 10.375 | 9.875 | 3 Feet | $629.93 | Add to Order |
| KM-13925 | 10.437 | 9.937 | 3 Feet | $633.78 | Add to Order |
| KM-13936 | 10.500 | 10.00 | 3 Feet | $637.70 | Add to Order |
| KM-13937 | 10.563 | 10.062 | 3 Feet | $641.58 | Add to Order |
| KM-13938 | 10.625 | 10.125 | 3 Feet | $645.48 | Add to Order |
| KM-13939 | 10.688 | 10.187 | 3 Feet | $649.35 | Add to Order |
| KM-13940 | 10.750 | 10.250 | 3 Feet | $653.25 | Add to Order |
| KM-13941 | 10.813 | 10.312 | 3 Feet | $657.13 | Add to Order |
| KM-13942 | 10.875 | 10.375 | 3 Feet | $661.03 | Add to Order |
| KM-13943 | 10.937 | 10.437 | 3 Feet | $664.90 | Add to Order |
| KM-13915 | 11.000 | 10.500 | 3 Feet | $668.82 | Add to Order |
| KM-13913 | 11.062 | 10.562 | 3 Feet | $672.68 | Add to Order |
| KM-13933 | 11.125 | 10.625 | 3 Feet | $676.60 | Add to Order |
| KM-13907 | 11.188 | 10.687 | 3 Feet | $680.45 | Add to Order |
| KM-13908 | 11.250 | 10.750 | 3 Feet | $684.38 | Add to Order |
| KM-13909 | 11.313 | 10.812 | 3 Feet | $688.23 | Add to Order |
| KM-13910 | 11.375 | 10.875 | 3 Feet | $692.15 | Add to Order |
| KM-13911 | 11.437 | 10.937 | 3 Feet | $696.00 | Add to Order |
| KM-13912 | 11.500 | 11.000 | 3 Feet | $699.93 | Add to Order |
| KM-13924 | 11.562 | 11.062 | 3 Feet | $703.78 | Add to Order |
| KM-13914 | 11.625 | 11.125 | 3 Feet | $707.70 | Add to Order |
| KM-13905 | 11.687 | 11.187 | 3 Feet | $711.55 | Add to Order |
| KM-13916 | 11.750 | 11.250 | 3 Feet | $715.48 | Add to Order |
| KM-13917 | 11.812 | 11.312 | 3 Feet | $719.33 | Add to Order |
| KM-13918 | 11.875 | 11.375 | 3 Feet | $723.25 | Add to Order |
| KM-13919 | 11.937 | 11.437 | 3 Feet | $727.10 | Add to Order |
| KM-13920 | 12.000 | 11.500 | 3 Feet | $731.03 | Add to Order |
| KM-13921 | 12.062 | 11.562 | 3 Feet | $734.88 | Add to Order |
| KM-13922 | 12.125 | 11.625 | 3 Feet | $738.80 | Add to Order |
| KM-13923 | 12.187 | 11.687 | 3 Feet | $742.68 | Add to Order |
| KM-14047 | 12.250 | 11.750 | 3 Feet | $746.58 | Add to Order |
| KM-14168 | 12.313 | 11.812 | 3 Feet | $750.45 | Add to Order |
| KM-14003 | 12.375 | 11.875 | 3 Feet | $754.35 | Add to Order |
| KM-14129 | 12.437 | 11.937 | 3 Feet | $758.23 | Add to Order |
| KM-14130 | 12.500 | 12.000 | 3 Feet | $762.13 | Add to Order |
| KM-14131 | 12.562 | 12.062 | 3 Feet | $766.00 | Add to Order |
| KM-14132 | 12.625 | 12.125 | 3 Feet | $769.93 | Add to Order |
| KM-14133 | 12.687 | 12.187 | 3 Feet | $773.78 | Add to Order |
| KM-14134 | 12.750 | 12.250 | 3 Feet | $777.70 | Add to Order |
| KM-14146 | 12.812 | 12.312 | 3 Feet | $781.55 | Add to Order |
| KM-14136 | 12.875 | 12.375 | 3 Feet | $785.48 | Add to Order |
| KM-14127 | 12.937 | 12.437 | 3 Feet | $789.33 | Add to Order |
| KM-14138 | 13.000 | 12.500 | 3 Feet | $793.25 | Add to Order |
| KM-14139 | 13.062 | 12.562 | 3 Feet | $797.10 | Add to Order |
| KM-14140 | 13.125 | 12.625 | 3 Feet | $801.03 | Add to Order |
| KM-14141 | 13.187 | 12.687 | 3 Feet | $804.88 | Add to Order |
| KM-13664 | 13.250 | 12.750 | 3 Feet | $808.80 | Add to Order |
| KM-13665 | 13.312 | 12.813 | 3 Feet | $812.65 | Add to Order |
| KM-13666 | 13.375 | 12.875 | 3 Feet | $816.58 | Add to Order |
| KM-13667 | 13.437 | 12.937 | 3 Feet | $820.43 | Add to Order |
| KM-13668 | 13.500 | 13.000 | 3 Feet | $824.35 | Add to Order |
| KM-13669 | 13.562 | 13.062 | 3 Feet | $828.20 | Add to Order |
| KM-13681 | 13.625 | 13.125 | 3 Feet | $832.13 | Add to Order |
| KM-13671 | 13.687 | 13.187 | 3 Feet | $835.97 | Add to Order |
| KM-13662 | 13.750 | 13.250 | 3 Feet | $839.90 | Add to Order |
| KM-13673 | 13.812 | 13.312 | 3 Feet | $843.78 | Add to Order |
| KM-13674 | 13.875 | 13.375 | 3 Feet | $847.68 | Add to Order |
| KM-13675 | 13.937 | 13.437 | 3 Feet | $851.55 | Add to Order |
| KM-13676 | 14.000 | 13.500 | 3 Feet | $855.45 | Add to Order |
| KM-13677 | 14.062 | 13.562 | 3 Feet | $859.33 | Add to Order |
| KM-13678 | 14.125 | 13.625 | 3 Feet | $863.23 | Add to Order |
| KM-14059 | 14.187 | 13.687 | 3 Feet | $867.10 | Add to Order |
| KM-13679 | 14.250 | 13.750 | 3 Feet | $871.03 | Add to Order |
| KM-14057 | 14.312 | 13.812 | 3 Feet | $874.88 | Add to Order |
| KM-13612 | 14.375 | 13.875 | 3 Feet | $878.80 | Add to Order |
| KM-13683 | 14.437 | 13.937 | 3 Feet | $882.65 | Add to Order |
| KM-13623 | 14.500 | 14.000 | 3 Feet | $886.58 | Add to Order |
| KM-13563 | 14.562 | 14.062 | 3 Feet | $890.43 | Add to Order |
| KM-13564 | 14.625 | 14.125 | 3 Feet | $894.35 | Add to Order |
| KM-13565 | 14.687 | 14.187 | 3 Feet | $898.20 | Add to Order |
| KM-13566 | 14.750 | 14.250 | 3 Feet | $902.13 | Add to Order |
| KM-13567 | 14.812 | 14.312 | 3 Feet | $905.97 | Add to Order |
| KM-13568 | 14.875 | 14.375 | 3 Feet | $909.90 | Add to Order |
| KM-13569 | 14.937 | 14.437 | 3 Feet | $913.75 | Add to Order |
| KM-13581 | 15.000 | 14.500 | 3 Feet | $917.68 | Add to Order |
| KM-13571 | 15.062 | 14.562 | 3 Feet | $921.53 | Add to Order |
| KM-13562 | 15.125 | 14.625 | 3 Feet | $925.45 | Add to Order |
| KM-13573 | 15.187 | 14.687 | 3 Feet | $929.30 | Add to Order |
| KM-14142 | 15.250 | 14.750 | 3 Feet | $933.23 | Add to Order |
| KM-14143 | 15.312 | 14.812 | 3 Feet | $937.07 | Add to Order |
| KM-14144 | 15.375 | 14.875 | 3 Feet | $941.00 | Add to Order |
| KM-14145 | 15.437 | 14.937 | 3 Feet | $944.88 | Add to Order |
| KM-14117 | 15.500 | 15.000 | 3 Feet | $948.78 | Add to Order |
| KM-14115 | 15.562 | 15.062 | 3 Feet | $952.65 | Add to Order |
| KM-14135 | 15.625 | 15.125 | 3 Feet | $956.55 | Add to Order |
| KM-14109 | 15.687 | 15.187 | 3 Feet | $960.43 | Add to Order |
| KM-14110 | 15.750 | 15.250 | 3 Feet | $964.33 | Add to Order |
| KM-14111 | 15.812 | 15.312 | 3 Feet | $968.20 | Add to Order |
| KM-14112 | 15.875 | 15.375 | 3 Feet | $972.13 | Add to Order |
| KM-14113 | 15.937 | 15.437 | 3 Feet | $975.97 | Add to Order |
| KM-14114 | 16.000 | 15.500 | 3 Feet | $979.90 | Add to Order |
| KM-14126 | 16.062 | 15.562 | 3 Feet | $983.75 | Add to Order |
| KM-14116 | 16.125 | 15.625 | 3 Feet | $987.68 | Add to Order |
| KM-14107 | 16.187 | 15.687 | 3 Feet | $991.53 | Add to Order |
| KM-14118 | 16.250 | 15.750 | 3 Feet | $995.45 | Add to Order |
| KM-14119 | 16.312 | 15.812 | 3 Feet | $999.30 | Add to Order |
| KM-14120 | 16.375 | 15.875 | 3 Feet | $1,003.23 | Add to Order |
| KM-14121 | 16.437 | 15.937 | 3 Feet | $1,007.07 | Add to Order |
| KM-14122 | 16.500 | 16.000 | 3 Feet | $1,011.00 | Add to Order |
| KM-14123 | 16.562 | 16.062 | 3 Feet | $1,014.85 | Add to Order |
| KM-14124 | 16.625 | 16.125 | 3 Feet | $1,018.78 | Add to Order |
| KM-14125 | 16.687 | 16.187 | 3 Feet | $1,022.63 | Add to Order |
| KM-14155 | 16.750 | 16.250 | 3 Feet | $1,026.55 | Add to Order |
| KM-14186 | 16.812 | 16.312 | 3 Feet | $1,030.40 | Add to Order |
| KM-14137 | 16.875 | 16.375 | 3 Feet | $1,034.33 | Add to Order |
| KM-14169 | 16.937 | 16.437 | 3 Feet | $1,038.18 | Add to Order |
| KM-14170 | 17.000 | 16.500 | 3 Feet | $1,042.10 | Add to Order |
| KM-14171 | 17.062 | 16.562 | 3 Feet | $1,045.95 | Add to Order |
| KM-14172 | 17.125 | 16.625 | 3 Feet | $1,049.88 | Add to Order |
| KM-14173 | 17.187 | 16.687 | 3 Feet | $1,053.75 | Add to Order |
| KM-14174 | 17.250 | 16.750 | 3 Feet | $1,057.65 | Add to Order |
| KM-14175 | 17.312 | 16.812 | 3 Feet | $1,061.53 | Add to Order |
| KM-14187 | 17.375 | 16.875 | 3 Feet | $1,065.43 | Add to Order |
| KM-14177 | 17.437 | 16.937 | 3 Feet | $1,069.30 | Add to Order |
| KM-14167 | 17.500 | 17.000 | 3 Feet | $1,073.23 | Add to Order |
| KM-14179 | 17.562 | 17.062 | 3 Feet | $1,077.08 | Add to Order |
| KM-14180 | 17.625 | 17.125 | 3 Feet | $1,081.00 | Add to Order |
| KM-14181 | 17.687 | 17.187 | 3 Feet | $1,084.85 | Add to Order |
| KM-14182 | 17.750 | 17.250 | 3 Feet | $1,088.78 | Add to Order |
| KM-14183 | 17.812 | 17.312 | 3 Feet | $1,092.63 | Add to Order |
| KM-14184 | 17.875 | 17.375 | 3 Feet | $1,096.55 | Add to Order |
| KM-14185 | 17.937 | 17.437 | 3 Feet | $1,100.40 | Add to Order |
| KM-14157 | 18.000 | 17.500 | 3 Feet | $1,104.33 | Add to Order |
| KM-14178 | 18.062 | 17.562 | 3 Feet | $1,108.18 | Add to Order |
| KM-14176 | 18.125 | 17.625 | 3 Feet | $1,112.10 | Add to Order |
| KM-14148 | 18.187 | 17.687 | 3 Feet | $1,115.95 | Add to Order |
| KM-14149 | 18.250 | 17.750 | 3 Feet | $1,119.88 | Add to Order |
| KM-14150 | 18.312 | 17.812 | 3 Feet | $1,123.73 | Add to Order |
| KM-14151 | 18.375 | 17.875 | 3 Feet | $1,127.65 | Add to Order |
| KM-14152 | 18.437 | 17.937 | 3 Feet | $1,131.50 | Add to Order |
| KM-14153 | 18.500 | 18.000 | 3 Feet | $1,135.43 | Add to Order |
| KM-14154 | 18.562 | 18.062 | 3 Feet | $1,139.27 | Add to Order |
| KM-14166 | 18.625 | 18.125 | 3 Feet | $1,143.20 | Add to Order |
| KM-14156 | 18.687 | 18.187 | 3 Feet | $1,147.05 | Add to Order |
| KM-14147 | 18.750 | 18.250 | 3 Feet | $1,150.98 | Add to Order |
| KM-14158 | 18.812 | 18.312 | 3 Feet | $1,154.85 | Add to Order |
| KM-14159 | 18.875 | 18.375 | 3 Feet | $1,158.75 | Add to Order |
| KM-14160 | 18.937 | 18.437 | 3 Feet | $1,162.63 | Add to Order |
| KM-14161 | 19.000 | 18.500 | 3 Feet | $1,166.53 | Add to Order |
| KM-14162 | 19.062 | 18.563 | 3 Feet | $1,170.40 | Add to Order |
| KM-14163 | 19.125 | 18.625 | 3 Feet | $1,174.30 | Add to Order |
| KM-14164 | 19.187 | 18.687 | 3 Feet | $1,178.18 | Add to Order |
| KM-14165 | 19.250 | 18.750 | 3 Feet | $1,182.10 | Add to Order |
| KM-14087 | 19.312 | 18.812 | 3 Feet | $1,185.95 | Add to Order |
| KM-14027 | 19.375 | 18.875 | 3 Feet | $1,189.88 | Add to Order |
| KM-14108 | 19.437 | 18.937 | 3 Feet | $1,193.73 | Add to Order |
| KM-14048 | 19.500 | 19.000 | 3 Feet | $1,197.65 | Add to Order |
| KM-14049 | 19.562 | 19.062 | 3 Feet | $1,201.50 | Add to Order |
| KM-14050 | 19.625 | 19.125 | 3 Feet | $1,205.43 | Add to Order |
| KM-14051 | 19.687 | 19.187 | 3 Feet | $1,209.27 | Add to Order |
| KM-14052 | 19.750 | 19.250 | 3 Feet | $1,213.20 | Add to Order |
| KM-14053 | 19.812 | 19.312 | 3 Feet | $1,217.05 | Add to Order |
| KM-14065 | 19.875 | 19.375 | 3 Feet | $1,220.98 | Add to Order |
| KM-14055 | 19.937 | 19.437 | 3 Feet | $1,224.83 | Add to Order |
| KM-14046 | 20.000 | 19.500 | 3 Feet | $1,228.75 | Add to Order |
| Rev. 04-23, 08-22, 04-22, 11-21 | |||||
| Phenolic Tube Tolerances | |||
| 3 Foot Lengths: 33" ± 3" 4 Foot Lengths: 45" ± 3" Tighter tolerances of 36" ± 1" and 48" ± 1" can be quoted on request. |
|||
| ↑ Length ↑ | ↓ Inside Diameter ↓ | ||
| ↓ Outside Diameter ↓ | Turned OD Tolerance |
Steel Mandrel |
Built-up Mandrel |
| 0.125" to 0.749" | ±.005" | ±.003" | - |
| 0.750" to 1.999" | ±.005" | ±.004" | - |
| 2.000" to 4.000" | ±.008" | ±.006" | - |
| 4.001" - 12.000" | ±.025" ** | ±.010" | - |
| 12.001" - 18.000" | ±.030" ** | ±.030" | ±.060" |
| 18.001" - 24.000" | ±.035" ** | ±.040" | ±.075" |
| 24.001" - 48.000" | ±.040" ** | ±.060" | ±.090" |
|
** Tubes over 8.00" OD are supplied as wound, which
** Tubes turned to the listed OD tolerance
|
|||
