Oil Filled Cast Nylon Rods
Nycast® Nyloil® was developed to extend the wear-resistant properties of unlubricated or dry lubricated materials such as MoS2 filled nylons. It lasts 5 to 7 times longer than unlubricated or MoS2 dry lubricated cast nylons, has 25% lower coefficient of friction, machines faster, and has more dimensional stability with reduced moisture absorption.
|
Cast Nylon Oil Filled Rod
Green Color - 26" Standard Lengths |
|||
| Diameter (in.) | Part # | Price Per Foot | Order Online |
|---|---|---|---|
| 1.00 | KR-1469 | $57.40 | Add to Order |
| 1.25 | KR-1470 | $54.63 | Add to Order |
| 1.50 | KR-1471 | $57.35 | Add to Order |
| 1.75 | KR-1472 | $64.85 | Add to Order |
| 2.00 | KR-1449 | $67.86 | Add to Order |
| 2.25 | KR-5310 | $81.45 | Add to Order |
| 2.50 | KR-1473 | $91.62 | Add to Order |
| 2.75 | KR-5311 | $105.75 | Add to Order |
| 3.00 | KR-1450 | $100.78 | Add to Order |
| 3.25 | KR-5360 | $115.67 | Add to Order |
| 3.50 | KR-5348 | $144.97 | Add to Order |
| 3.75 | KR-5362 | $255.54 | Add to Order |
| 4.00 | KR-1450A | $174.78 | Add to Order |
| 4.25 | KR-5363 | $112.07 | Add to Order |
| 4.50 | KR-5364 | $202.20 | Add to Order |
| 4.75 | KR-5365 | $406.48 | Add to Order |
| 5.00 | KR-1451 | $271.24 | Add to Order |
| 5.25 | KR-5366 | $452.70 | Add to Order |
| 5.50 | KR-5367 | $293.96 | Add to Order |
| 6.00 | KR-1452 | $648.55 | Add to Order |
| 6.25 | KR-1452Q | $776.00 | Add to Order |
| 6.50 | KR-5369 | $689.38 | Add to Order |
| 6.75 | KR-5370 | $840.16 | Add to Order |
| 7.00 | KR-5371 | $414.80 | Add to Order |
| 7.25 | KR-5336 | $846.75 | Add to Order |
| 8.00 | KR-1474 | $1,226.74 | Add to Order |
| Rev. 01-24, 10-23, 04-23, 12-22 | |||
Oil-Filled Nylon Technical Data
| Density | Tensile Strength |
Compressive Strength |
Shore Hardness |
Coefficient of Friction |
Continuous Operating Temp |
Wear Resistance Index |
| g/cm3 | N/mm2 | N/mm2 | 'D' Scale | Sample on Steel |
oC | Units |
| 1.12 | 65-70 | 85-100 | 80-85 | 0.10 0.13 |
-80 +125 |
25 |
