Bullet-Proof Sheets
| Sheet Size | Part # | Color | CG/BR Series | Price Each | Order Online |
|---|---|---|---|---|---|
| .390" x 38" x 96" | KS-3942 | Clear | CG375 | $4,216.38 | Add to Order |
| .390" x 48" x 96" | KS-3954 | Clear | CG375 | $5,326.62 | Add to Order |
| .390" x 60" x 96" | KS-3960 | Clear | CG375 | $6,658.20 | Add to Order |
| .530" x 38" x 96" | KS-3943 | Clear | CG500 | $4,809.06 | Add to Order |
| .530" x 48" x 96" | KS-3955 | Clear | CG500 | $6,075.42 | Add to Order |
| .530" x 60" x 96" | KS-3961 | Clear | CG500 | $7,594.26 | Add to Order |
| .780" x 38" x 96" | KS-3944 | Clear | CG750 | $6,821.76 | Add to Order |
| .780" x 48" x 96" | KS-3956 | Clear | CG750 | $8,618.04 | Add to Order |
| .780" x 60" x 96" | KS-3962 | Clear | CG750 | $10,772.58 | Add to Order |
| .780" x 12" x 12" | KS-1448 | Clear | BR750 | $257.29 | Add to Order |
| .780" x 24" x 24" | KS-1450 | Clear | BR750 | $992.41 | Add to Order |
| .780" x 24" x 48" | KS-1451 | Clear | BR750 | $1,704.24 | Add to Order |
| .780" x 38" x 78" | KS-3938 | Clear | BR750 | $6,195.18 | Add to Order |
| .780" x 38" x 96" | KS-3945 | Clear | BR750 | $7,625.04 | Add to Order |
| .780" x 48" x 60" | KS-3948 | Clear | BR750 | $6,020.58 | Add to Order |
| .780" x 48" x 72" | KS-3951 | Clear | BR750 | $7,366.00 | Add to Order |
| .780" x 48" x 96" | KS-3957 | Clear | BR750 | $9,820.00 | Add to Order |
| .780" x 60" x 96" | KS-3963 | Clear | BR750 | $12,041.16 | Add to Order |
| 1.05" x 38" x 78" | KS-3940 | Clear | BR1000 | $9,204.54 | Add to Order |
| 1.05" x 38" x 96" | KS-3946 | Clear | BR1000 | $11,329.02 | Add to Order |
| 1.05" x 48" x 60" | KS-3949 | Clear | BR1000 | $8,945.16 | Add to Order |
| 1.05" x 48" x 72" | KS-3952 | Clear | BR1000 | $10,734.18 | Add to Order |
| 1.05" x 48" x 96" | KS-3958 | Clear | BR1000 | $12,376.00 | Add to Order |
| 1.05" x 60" x 96" | KS-3964 | Clear | BR1000 | $17,890.26 | Add to Order |
| 1.30" x 12" x 24" | KS-1455 | Clear | BR1250 | $828.38 | Add to Order |
| 1.30" x 24" x 24" | KS-1456 | Clear | BR1250 | $1,463.45 | Add to Order |
| 1.30" x 24" x 48" | KS-1457 | Clear | BR1250 | $2,209.48 | Add to Order |
| 1.30" x 38" x 78" | KS-3941 | Clear | BR1250 | $9,393.30 | Add to Order |
| 1.30" x 38" x 96" | KS-3947 | Clear | BR1250 | $11,561.34 | Add to Order |
| 1.30" x 48" x 60" | KS-3950 | Clear | BR1250 | $9,128.58 | Add to Order |
| 1.30" x 48" x 72" | KS-3953 | Clear | BR1250 | $10,954.26 | Add to Order |
| 1.30" x 48" x 96" | KS-3959 | Clear | BR1250 | $15,118.00 | Add to Order |
| 1.30" x 60" x 96" | KS-3965 | Clear | BR1250 | $18,257.16 | Add to Order |
| Rev. 05-22, 06-21 | |||||
Lead Times May Apply, Call for Volume Discounts
HYGARD®Makrolon® Bullet Resistant Data
|
CG375 3/16" Makrolon® GP Interlayer, 3/16" Makrolon® AR Outerlayer
(2.4 lbs/SF) Guage .390 (+/-5%)
CG375 HPW Level II Step 10, HPW TP0500.02 Level A Ballistics (.38 Special) ASTM F 1233 Class III Step 12 |
|
CG500 1/8"
Makrolon® AR Interlayer,
1/4" Makrolon® GP, 1/8" Makrolon®
AR Outerlayer (3.3 lbs/SF) Guage .530 (+/-5%)
CG500 HPW Level II Step 12, HPW TP0500.02 Level A Ballistics (.38 Special) ASTM F 1233 Class III Step 15 |
|
CG750 1/8" Makrolon® AR Interlayer,
1/4" Makrolon® GP, 1/8" Makrolon AR Outerlayer
(4.9 lbs/SF) Guage .780 (+/-5%)
CG750 HPW Level IV Step 31, HPW TP0500.02 Level B Ballistics (9mm) ASTM F 1233 Class IV Step 26 |
|
BR750 1/8" Makrolon® AR Interlayer,
1/2" Makrolon® GP, 1/8" Makrolon® AR Outerlayer (5.1 lbs/SF) Guage
.775 (+/-8%)
BR750 UL Level 1, HPW TP0500.02 Level B Ballistics (9mm) |
|
BR1000 1/8" Makrolon® AR Interlayer,
3/8" Makrolon® GP, 3/8" Makrolon® GP, (Double Layer), 1/8" Makrolon®
AR Outerlayer (6.5 lbs/SF) Guage 1.05 (+/-5%)
BR1000 HPW Level V Step 42, HPW TP0500.02 Level B Ballistics (9mm) ASTM F 1233 Class V UL Level 2 |
|
BR1250 1/8" Makrolon® AR Interlayer,
1/2" Makrolon® GP, 1/2" Makrolon® GP, (Double Layer), 1/8" Makrolon®
AR Outerlayer (8.1 lbs/SF) Guage 1.30 (+/-5%)
BR1250 HPW Level V, HPW TP0500.02 Level C Ballistics (.44 Magnum) ASTM F 1233 Class IV Step 38 UL Level 3 |
HYGARD® BR-750
HYGARD® BR-750 is a three ply HYZOD® polycarbonate and acrylic laminate for security applications that require UL Listed Level I bullet resisting glazing. HYGARD® BR-750 features abrasion and UV resistant surfaces for extended service life in harsh environments.
APPLICATIONS
HYGARD® BR-750 is used as bullet-resistant glazing in a wide variety of security applications. Installations include convenience stores, specialty retailers, banks government and detention facilities, as well as other cash transaction areas.
GLAZING INFORMATION
Use of structural security framing systems with equal or greater forced entry and/or ballistics ratings as the selected HYGARD® Laminate is recommended.
Size HYGARD® laminates to allow for a minimum of one (1) inch edge engagement in the frame with sufficient rabbet depth for material expansion (approx. 1/16/ft.).
Use wet or dry sealants/gaskets that are compatible with polycarbonate.
Remove protective masking after glazing operations are completed and before prolonged exposure to direct sunlight, moisture, or high temperature.
PRODUCT SPECIFICATION
HYGARD® BR-750 polycarbonate laminate:
Three ply, clear HYZOD® polycarbonate and acrylic sheet constructed as follows:
1/8 HYZOD® with high performance AR abrasion-resistant surface
acrylic sheet
1/8 HYZOD® with high performance AR abrasion-resistant surface
Material shall have a flexural strength of at least 13,500 psi per ASTM D-790; and shall have AR (high performance abrasion-resistant) surfaces for enhanced service life and resistance to marring. Material shall exhibit a self ignition temperature of 1077F and a flash ignition temperature of 872F (ASTM D-1929), and conform with ICBO & BOCA Model Building Codes as a CC-2 rated Approved Light Transmitting Plastic.
HYGARD® BR1000
HYGARD BR-1000 is a four-ply HYZOD® polycarbonate laminate for use in security applications that require UL Listed Level 2 bullet-resisting glazing. HYGARD® BR-1000 is hard coated with abrasion and UV resistant surfaces for extended service life in harsh environments.
APPLICATIONS
HYGARD® BR-1000 is used as containment and bullet-resistant glazing in a wide variety of high level security applications. Installations include 24-hour convenience stores, specialty retailers, banks, governmental and detention facilities, as well as other cash transaction areas.
FORCED ENTRY, BALLISTICS RATINGS
HP White TP-500.02 Level V Sequence 42
HP White TP-500.02 Level B Ballistics (9mm)
ASTM F1233 Class V
ASTM F-1233 Ballistics (.38 Super)
UL 752 Level 2 HPSA (.357 Mag)
GLAZING INFORMATION
Use of structural security framing systems with equal or greater forced entry and/or ballistics ratings as the selected HYGARD® Laminate is recommended.
Size HYGARD® laminates to allow for a minimum of one (1) inch edge engagement in the frame, with sufficient rabbet depth for material expansion (approx. 1/16/ft.).
Use wet or dry sealants/gaskets that are compatible with polycarbonate.
Remove protective masking after glazing operations are completed and before prolonged exposure to direct sunlight, moisture, or high temperature.
PRODUCT SPECIFICATION
Four ply, clear HYZOD® polycarbonate sheet constructed as follows:
1/8 HYZOD with high performance AR abrasion-resistant surface
3/8 HYZOD polycarbonate sheet
3/8 HYZOD polycarbonate sheet
1/8 HYZOD with high performance AR abrasion-resistant surface
Material shall have a flexural strength of at least 13,500 psi per ASTM D-790; and shall have AR (high performance abrasion-resistant) surfaces for enhanced service life and resistance to marring. Material shall conform with ICBO & BOCA Model Building Codes as a CC-1 rated Approved Light Transmitting Plastic.
HYGARD® BR-1250
HYGARD® BR-1250 is a fourply HYZOD® polycarbonate laminate for use in security applications that require UL Listed Level III bullet-resisting glazing. HYGARD® BR-1250 is hard coated with abrasion and UV resistant surfaces for extended service life in harsh environments.
APPLICATIONS
HYGARD® BR-1250 is used as containment and bullet resistant glazing in a wide variety of high level security applications. Installations include 24 hour convenience stores, specialty retailers, banks, governmental and detention facilities, as well as other cash transaction areas.
GLAZING INFORMATION
Use of structural security framing systems with equal or greater forced entry and/or ballistics ratings as the selected HYGARD® Laminate is recommended.
Size HYGARD® laminates to allow for a minimum of one (1) inch edge engagement in the frame, with sufficient rabbet depth for material expansion (approx. 1/16/ft.).
Use wet or dry sealants/gaskets that are compatible with polycarbonate.
Remove protective masking after glazing operations are completed and before prolonged exposure to direct sunlight, moisture, or high temperature.
PRODUCT SPECIFICATION
HYGARD® BR-1250 polycarbonate laminate:
Four ply, clear HYZOD® polycarbonate sheet constructed as follows:
1/8 HYZOD® with high performance AR abrasion-resistant surface
HYZOD® polycarbonate sheet
HYZOD® polycarbonate sheet
1/8 HYZOD® with high performance AR abrasion-resistant surface
Material shall have a flexural strength of at least 13,500 psi per ASTM D-790; and shall have AR (high performance abrasion-resistant) surfaces for enhanced service life and resistance to marring. Material shall exhibit a self ignition temperature of 1077F and a flash ignition temperature of 872F (ASTM D-1929), and conform with ICBO & BOCA Model Building Codes as a CC-1 rated Approved Light Transmitting Plastic.
