Clear Acrylic Tubes
Two grades are available; extruded and cast.
Extruded offers good clarity at an economical price
Cast
offers consistent and superior clarity for more high tech applications.
We also offer Square Tubes Further Below.
Chemical Resistance Chart
| Extruded Acrylic Round Tubing
Tubes are shipped in Kraft Corrugated packaging for protection from transit damage. There is an additional package fee based on the diameter. |
||||||
| Part # | OD (in.) | ID (in.) | Wall (in.) | Minimum Order | Price Per 6 Feet | Order Online |
|---|---|---|---|---|---|---|
| KM-671 | .250 | .125 | .063 | 300' | $1.50 | Add to Order |
| KM-2140 | .312 | .187 | .063 | 216' | $1.80 | Add to Order |
| KM-4603 | .375 | .125 | .125 | 150' | $3.60 | Add to Order |
| KM-4604 | .375 | .250 | .063 | 180' | $2.25 | Add to Order |
| KM-672 | .500 | .250 | .125 | 96' | $6.00 | Add to Order |
| KM-2143 | .625 | .375 | .125 | 60' | $6.45 | Add to Order |
| KM-2142 | .625 | .500 | .063 | 96' | $4.15 | Add to Order |
| KM-673 | .750 | .500 | .125 | 60' | $7.77 | Add to Order |
| KM-2146 | .875 | .625 | .125 | 54' | $9.00 | Add to Order |
| KM-2147 | 1.00 | .875 | .063 | 72' | $6.45 | Add to Order |
| KM-675 | 1.25 | 1.00 | .125 | 48' | $12.75 | Add to Order |
| KM-2162 | 1.50 | 1.00 | .250 | 24' | $8.08 | Add to Order |
| KM-2925A | 1.625 | 1.375 | .125 | 24' | $17.10 | Add to Order |
| KM-2150 | 1.75 | 1.50 | .125 | 36' | $18.45 | Add to Order |
| KM-2153 | 2.75 | 2.50 | .125 | 18' | $35.10 | Add to Order |
| KM-2154 | 3.00 | 2.75 | .125 | 18' | $35.70 | Add to Order |
| KM-677 | 3.25 | 3.00 | .125 | 12' | $40.35 | Add to Order |
| KM-2156 | 3.50 | 3.25 | .125 | 6' | $43.35 | Add to Order |
| KM-2157 | 3.75 | 3.50 | .125 | 6' | $49.65 | Add to Order |
| KM-2167 | 4.00 | 3.50 | .250 | 6' | $155.25 | Add to Order |
| KM-2158 | 4.00 | 3.75 | .125 | 6' | $53.25 | Add to Order |
| KM-5748 | 4.25 | 3.75 | .250 | 6' | $86.85 | Add to Order |
| KM-2168 | 4.50 | 4.00 | .250 | 6' | $181.20 | Add to Order |
| KM-2159 | 4.50 | 4.25 | .125 | 6' | $58.50 | Add to Order |
| KM-2160 | 5.00 | 4.75 | .125 | 6' | $68.70 | Add to Order |
| KM-7987 | 5.25 | 5.00 | .125 | 6' | $158.40 | Add to Order |
| KM-8015 | 5.50 | 5.00 | .250 | 6' | $283.50 | Add to Order |
| KM-8016 | 6.00 | 5.50 | .250 | 6' | $309.30 | Add to Order |
| Rev. 09-22, 04-22, 03-22, 07-21 | ||||||
| Extruded OD Tolerances | |
| OD | Tolerance |
| .250" to "500 | +/-.010" |
| .625" to 1.0" | +/-.015" |
| 1.125" to 1.375" | +/-.020" |
| 1.50" to 2.0" | +/-.025" |
| 2.25" to 3.0" | +/-.030" |
| 3.25" to 4.0" | +/-.040" |
| 4.25" to 6.0" | +/-.060" |
| 6.50" to 8.0" | +/-.125" |
| 8.50" and Larger | +/-.250" |
| Cast Acrylic Round Tubes, Clear
5 Foot Standard Lengths, Unless Noted * Available in 6 Foot Lengths |
||||
| Part # | OD (in.) | ID (in.) | Price Per Foot | Order Online |
|---|---|---|---|---|
| KM-829 | 1.50 | 1.00 | $179.46 | Add to Order |
| KM-830 | 1.50 | 1.125 | $137.16 | Add to Order |
| KM-23683 | 1.50 | 1.187 | $164.56 | Add to Order |
| KM-831 | 1.50 | 1.25 | $142.20 | Add to Order |
| KM-832 | 1.75 | 1.250 | $182.06 | Add to Order |
| KM-833 | 1.75 | 1.375 | $170.76 | Add to Order |
| KM-834 | 1.75 | 1.50 | $148.92 | Add to Order |
| KM-835 | 2.00 | 1.50 | $178.14 | Add to Order |
| KM-836 | 2.00 | 1.625 | $173.98 | Add to Order |
| KM-837 | 2.00 | 1.75 | $151.60 | Add to Order |
| KM-838 | 2.25 | 1.75 | $131.36 | Add to Order |
| KM-839 | 2.25 | 2.00 | $128.86 | Add to Order |
| KM-840 | 2.50 | 2.00 | $190.08 | Add to Order |
| KM-841 | 2.50 | 2.125 | $174.50 | Add to Order |
| KM-842 | 2.50 | 2.25 | $160.16 | Add to Order |
| KM-843 | 2.75 | 2.25 | $193.32 | Add to Order |
| KM-844 | 2.75 | 2.375 | $193.32 | Add to Order |
| KM-845 | 2.75 | 2.50 | $161.02 | Add to Order |
| KM-846 | 3.00 | 2.50 | $194.30 | Add to Order |
| KM-849 | 3.00 | 2.625 | $179.72 | Add to Order |
| KM-850 | 3.00 | 2.75 | $162.84 | Add to Order |
| KM-851 | 3.25 | 2.75 | $195.12 | Add to Order |
| KM-852 | 3.25 | 2.875 | $180.60 | Add to Order |
| KM-853 | 3.25 | 3.00 | $167.46 | Add to Order |
| KM-854 | 3.50 | 3.00 | $197.60 | Add to Order |
| KM-855 | 3.50 | 3.125 | $179.50 | Add to Order |
| KM-856 | 3.50 | 3.25 | $171.58 | Add to Order |
| KM-5495 | 3.75 | 3.25 | $191.72 | Add to Order |
| KM-2742 | 3.75 | 3.375 | $188.56 | Add to Order |
| KM-2737 | 3.75 | 3.50 | $188.56 | Add to Order |
| KM-857 | 4.00 | 3.25 | $386.50 | Add to Order |
| KM-861 | 4.00 | 3.50 | $204.16 | Add to Order |
| KM-862 | 4.00 | 3.625 | $190.58 | Add to Order |
| KM-860 | 4.00 | 3.75 | $176.06 | Add to Order |
| KM-2746 | 4.25 | 3.75 | $198.82 | Add to Order |
| KM-2743 | 4.25 | 3.875 | $191.84 | Add to Order |
| KM-2738 | 4.25 | 4.00 | $179.72 | Add to Order |
| KM-864 | 4.50 | 3.75 | $408.04 | Add to Order |
| KM-865 | 4.50 | 4.00 | $203.66 | Add to Order |
| KM-866 | 4.50 | 4.125 | $199.20 | Add to Order |
| KM-867 | 4.50 | 4.25 | $181.74 | Add to Order |
| KM-2750 | 4.75 | 4.00 | $415.06 | Add to Order |
| KM-2747 | 4.75 | 4.25 | $207.88 | Add to Order |
| KM-2744 | 4.75 | 4.375 | $200.90 | Add to Order |
| KM-2739 | 4.75 | 4.50 | $200.90 | Add to Order |
| KM-868 | 5.00 | 4.25 | $434.20 | Add to Order |
| KM-869 | 5.00 | 4.50 | $212.20 | Add to Order |
| KM-870 | 5.00 | 4.625 | $203.08 | Add to Order |
| KM-871 | 5.00 | 4.75 | $187.42 | Add to Order |
| KM-2758 | 5.25 | 4.875 | $222.60 | Add to Order |
| KM-2775 | 5.25 | 4.50 | $448.16 | Add to Order |
| KM-2767 | 5.25 | 4.75 | $234.74 | Add to Order |
| KM-2751 | 5.25 | 5.00 | $194.96 | Add to Order |
| KM-872 | 5.50 | 4.75 | $440.88 | Add to Order |
| KM-873 | 5.50 | 5.00 | $232.92 | Add to Order |
| KM-875 | 5.50 | 5.250 | $199.96 | Add to Order |
| KM-2768 | 5.75 | 5.25 | $234.96 | Add to Order |
| KM-2759 | 5.75 | 5.375 | $208.16 | Add to Order |
| KM-2752 | 5.75 | 5.50 | $217.96 | Add to Order |
| KM-876 | 6.00 | 5.25 | $518.24 | Add to Order |
| KM-877 | 6.00 | 5.50 | $227.40 | Add to Order |
| KM-878 | 6.00 | 5.625 | $202.44 | Add to Order |
| KM-879 | 6.00 | 5.575 | $213.54 | Add to Order |
| KM-665 | 6.00 | 5.750 | $213.54 | Add to Order |
| KM-880 | 7.00 | 6.25 | $897.92 | Add to Order |
| KM-882 | 7.00 | 6.625 | $239.38 | Add to Order |
| KM-881 | 7.00 | 6.50 | $263.70 | Add to Order |
| KM-883 | 7.00 | 6.75 | $243.47 | Add to Order |
| KM-886 | 8.00 | 7.625 | $255.20 | Add to Order |
| KM-884 | 8.00 | 7.25 | $939.32 | Add to Order |
| KM-885 | 8.00 | 7.75 | $345.84 | Add to Order |
| KM-887 | 8.00 | 7.75 | $247.18 | Add to Order |
| KM-5259 | 10.00 | 8.00 | $9,654.04 (6 Ft. Length) | Add to Order |
| KM-901 | 12.00 | 11.50 | $2,179.08 (2 Ft Length) | Add to Order |
| KM-902Y | 13.00 | 12.25 | $7,542.00 (90" Length) | Add to Order |
| KM-23684 | 14.00 | 13.25 | $1,688.73 (5 Ft Length) | Add to Order |
| KM-23681 | 14.00 | 13.625 | $3,327.15 (5 Ft Length) | Add to Order |
| KM-907 | 15.00 | 14.50 | $1,821.80 (2 Ft Length*) | Add to Order |
| KM-908 | 15.00 | 14.75 | $1,618.04 (2 Ft Length*) | Add to Order |
| KM-909 | 16.00 | 15.00 | $3,668.00 (2 Ft Length*) | Add to Order |
| KM-910 | 16.00 | 15.50 | $2,711.52 (2 Ft Length*) | Add to Order |
| KM-912 | 18.00 | 17.50 | $2,290.37 (2 Ft Length*) | Add to Order |
| KM-590X | 20.00 | 18.00 | $11,898.25 (4 ft Length) | Crating Charge Applies |
| KM-5366P | 20.00 | 19.00 | $9,757.75 (4 ft Length) | Crating Charge Applies |
| KM-5366 | 20.00 | 19.50 | $17,148.52 (4 ft Length) | Crating Charge Applies |
| KM-5356R | 24.00 | 22.50 | $10,147.50 ( 4 Ft Length) | Crating Charge Applies |
| KM-7980 | 24.00 | 23.00 | $7,024.15 (4 ft Length) | Crating Charge Applies |
| KM-5356P | 27.50 | 26.00 | $23,773.05 (84" Length) | Crating Charge Applies |
| KM-5356N | 27.50 | 26.50 | $17,003.70 (84" Length) | Crating Charge Applies |
| KM-913G | 27.50 | 27.00 | $13,939.00 (4 Ft Length) | Crating Charge Applies |
| KM-115T | 32.60 | 31.85 | $9,373.30 (4 Ft Length) | Crating Charge Applies |
| KM-913Q | 32.60 | 32.10 | $8,393.77 (4 Ft Length) | Crating Charge Applies |
| KM-23309 | 36.00 | 35.00 | $13,241.80 (4 Ft Length) | Crating Charge Applies |
| KM-5367 | 44.70 | 43.95 | $23,841.85 (90" Length) | Crating Charge Applies |
| KM-5333 | 44.70 | 43.20 | $36,969.05 (90" Length) | Crating Charge Applies |
| KM-5368 | 44.70 | 43.70 | $29,685.65 (90" Length) | Crating Charge Applies |
| KM-5358 | 44.70 | 42.70 | $44,498.70 (90" Length) | Crating Charge Applies |
| KM-5356 | 72.00 | 70.00 | $50,283.75 (90" Length) | Crating Charge Applies |
| KM-5356T | 96.00 | 94.00 | $98,262.00 (90" Length) | Crating Charge Applies |
| Rev. 04-23, 01-23, 09-22, 06-22 | ||||
Wall Thickness Tolerances:
.250" (+/-.045")
.375" (+/-.055")
.500" (+/-.065")
.750" (+/-.090")
Outside Diameter Tolerances:
1.50" to 3.00" (+/-.020")3.25" to 3.75" (+/-.030")
4.0" to 12.0" (+/-.065")
13" to 18" (+/-.080")
20" to 27.5" (+/-.100")
32.6" (+.250"/-.100")
36" (+/-.100")
42.5" (+0.00"/-.280")
44.7" to 60" (+/-.100")
72" (+.100"/-.300")
96" (+.100"/-.500")
| Acrylic
Square Tubing
Always Shipped in Full Uncut 6ft Lengths Tubes are shipped in Kraft Corrugated packaging for protection from transit damage. There is an additional package fee based on the diameter. |
||||||
| Part # | Outer Width (in.) | Wall (in.) | Length | Minimum Order | Price | Order Online |
|---|---|---|---|---|---|---|
| KTBS-014B | .375 | .063 | 6 ft | 72' | $5.58 | Add to Order |
| KTBS-002 | .500 | .063 | 6 ft | 90' | $5.19 | Add to Order |
| KTBS-057 | .625 | .063 | 6 ft | 54' | $12.40 | Add to Order |
| KTBS-099 | .750 | .125 | 6 ft | 48' | $35.37 | Special Order |
| KTBS-001 | .750 | .063 | 6 ft | 48' | $12.40 | Add to Order |
| KTBS-048 | 1.00 | .063 | 6 ft | 48' | $16.88 | Add to Order |
| KTBS-049 | 1.25 | .125 | 6 ft | 48' | $24.57 | Add to Order |
| KTBS-056 | 1.50 | .125 | 6 ft | 18' | $57.71 | Add to Order |
| KTBS-059 | 2.00 | .125 | 6 ft | 12' | $37.92 | Add to Order |
| KTBS-051 | 2.25 | .125 | 6 ft | 96' | $45.45 | Add to Order |
| KTBS-053 | 2.50 | .125 | 6 ft | 12' | $99.81 | Add to Order |
| KTBS-052 | 3.00 | .125 | 6 ft | 12' | $109.82 | Add to Order |
| Rev. 08-23, 04-23, 06-22, 01-22 | ||||||
