18-8 Stainless Slotted Truss Head Machine Screws
Machine Screws - Truss Head Slotted Drive, Class 2A, *Fully Threaded
18-8 Stainless Steel - Excellent corrosion resistance, mildly magnetic.
| 18-8 Stainless Steel Slotted Truss Head Machine Screws PT threads have a minimum thread length of 1.50" |
||||||||
| Part # | Thread Size | Length | Threads | Head Dia. | Head Height | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| MSS-2817 | 4-40 | 3/16" | FT | 0.257" | 0.069" | 100 | $10.50 | Add to Order |
| MSS-2818 | 4-40 | 1/4" | FT | 0.257" | 0.069" | 100 | $10.71 | Add to Order |
| MSS-6380 | 4-40 | 3/8" | FT | 0.257" | 0.069" | 100 | $11.63 | Add to Order |
| MSS-2786 | 4-40 | 1/2" | FT | 0.257" | 0.069" | 100 | $12.81 | Add to Order |
| MSS-2809 | 4-40 | 1" | FT | 0.257" | 0.069" | 100 | $16.53 | Add to Order |
| MSS-2807 | 6-32 | 3/16" | FT | 0.321" | 0.086" | 100 | $14.39 | Add to Order |
| MSS-2775 | 6-32 | 1/4" | FT | 0.321" | 0.086" | 100 | $6.93 | Add to Order |
| MSS-2776 | 6-32 | 5/16" | FT | 0.321" | 0.086" | 100 | $8.78 | Add to Order |
| MSS-2777 | 6-32 | 3/8" | FT | 0.321" | 0.086" | 100 | $6.36 | Add to Order |
| MSS-2778 | 6-32 | 1/2" | FT | 0.321" | 0.086" | 100 | $6.47 | Add to Order |
| MSS-2779 | 6-32 | 3/4" | FT | 0.321" | 0.086" | 100 | $11.99 | Add to Order |
| MSS-2780 | 6-32 | 1" | FT | 0.321" | 0.086" | 100 | $21.27 | Add to Order |
| MSS-2781 | 8-32 | 1/4" | FT | 0.384" | 0.102" | 100 | $8.06 | Add to Order |
| MSS-2782 | 8-32 | 5/16" | FT | 0.384" | 0.102" | 100 | $12.98 | Add to Order |
| MSS-2783 | 8-32 | 3/8" | FT | 0.384" | 0.102" | 100 | $8.99 | Add to Order |
| MSS-2796 | 8-32 | 7/16" | FT | 0.384" | 0.102" | 100 | $20.69 | Add to Order |
| MSS-2785 | 8-32 | 1/2" | FT | 0.384" | 0.102" | 100 | $14.11 | Add to Order |
| MSS-2774 | 8-32 | 5/8" | FT | 0.384" | 0.102" | 100 | $15.52 | Add to Order |
| MSS-2787 | 8-32 | 3/4" | FT | 0.384" | 0.102" | 100 | $17.87 | Add to Order |
| MSS-2788 | 8-32 | 1" | FT | 0.384" | 0.102" | 100 | $19.76 | Add to Order |
| MSS-2789 | 8-32 | 1 1/4" | FT | 0.384" | 0.102" | 100 | $15.94 | Add to Order |
| MSS-2790 | 8-32 | 1 1/2" | FT | 0.384" | 0.102" | 50 | $21.19 | Add to Order |
| MSS-2791 | 10-24 | 1/4" | FT | 0.448" | 0.128" | 100 | $17.16 | Add to Order |
| MSS-2792 | 10-24 | 3/8" | FT | 0.448" | 0.128" | 100 | $17.45 | Add to Order |
| MSS-2793 | 10-24 | 1/2" | FT | 0.448" | 0.128" | 100 | $14.28 | Add to Order |
| MSS-2794 | 10-24 | 5/8" | FT | 0.448" | 0.128" | 100 | $21.13 | Add to Order |
| MSS-2795 | 10-24 | 3/4" | FT | 0.448" | 0.128" | 100 | $23.16 | Add to Order |
| MSS-2725 | 10-24 | 1" | FT | 0.448" | 0.128" | 100 | $26.99 | Add to Order |
| MSS-2654 | 10-24 | 1 1/4" | FT | 0.448" | 0.128" | 100 | $24.09 | Add to Order |
| MSS-2748 | 10-24 | 1 1/2" | FT | 0.448" | 0.128" | 100 | $13.76 | Add to Order |
| MSS-2658 | 10-24 | 2" | FT | 0.448" | 0.128" | 50 | $22.72 | Add to Order |
| MSS-2659 | 10-32 | 1/4" | FT | 0.448" | 0.128" | 100 | $28.54 | Add to Order |
| MSS-2660 | 10-32 | 5/16" | FT | 0.448" | 0.128" | 100 | $29.21 | Add to Order |
| MSS-2661 | 10-32 | 3/8" | FT | 0.448" | 0.128" | 100 | $30.28 | Add to Order |
| MSS-2662 | 10-32 | 1/2" | FT | 0.448" | 0.128" | 100 | $32.09 | Add to Order |
| MSS-2663 | 10-32 | 5/8" | FT | 0.448" | 0.128" | 100 | $32.30 | Add to Order |
| MSS-2664 | 10-32 | 3/4" | FT | 0.448" | 0.128" | 100 | $38.20 | Add to Order |
| MSS-2665 | 10-32 | 1" | FT | 0.448" | 0.128" | 50 | $23.04 | Add to Order |
| MSS-2679 | 10-32 | 1 1/4" | FT | 0.448" | 0.128" | 50 | $28.14 | Add to Order |
| MSS-2667 | 10-32 | 1 1/2" | FT | 0.448" | 0.128" | 50 | $27.64 | Add to Order |
| MSS-2656 | 10-32 | 2" | FT | 0.448" | 0.128" | 25 | $18.27 | Add to Order |
| MSS-2669 | 12-24 | 1/2" | FT | 0.511" | 0.134" | 50 | $18.44 | Add to Order |
| MSS-2670 | 12-24 | 1" | FT | 0.511" | 0.134" | 50 | $26.38 | Add to Order |
| MSS-2671 | 1/4"-20 | 3/8" | FT | 0.573" | 0.150" | 50 | $11.47 | Add to Order |
| MSS-2672 | 1/4"-20 | 1/2" | FT | 0.573" | 0.150" | 50 | $11.24 | Add to Order |
| MSS-2673 | 1/4"-20 | 5/8" | FT | 0.573" | 0.150" | 50 | $20.81 | Add to Order |
| MSS-2674 | 1/4"-20 | 3/4" | FT | 0.573" | 0.150" | 50 | $16.42 | Add to Order |
| MSS-2675 | 1/4"-20 | 7/8" | FT | 0.573" | 0.150" | 50 | $3.82 | Add to Order |
| MSS-2676 | 1/4"-20 | 1" | FT | 0.573" | 0.150" | 25 | $18.61 | Add to Order |
| MSS-2677 | 1/4"-20 | 1 1/4" | FT | 0.573" | 0.150" | 25 | $19.57 | Add to Order |
| MSS-2645 | 1/4"-20 | 1 1/2" | FT | 0.573" | 0.150" | 25 | $19.13 | Add to Order |
| MSS-2668 | 1/4"-20 | 1 3/4" | FT | 0.573" | 0.150" | 25 | $22.87 | Add to Order |
| MSS-2666 | 1/4"-20 | 2" | FT | 0.573" | 0.150" | 10 | $10.42 | Add to Order |
| MSS-2634 | 1/4"-20 | 2 1/2" | PT | 0.573" | 0.150" | 10 | $11.76 | Add to Order |
| MSS-2635 | 1/4"-20 | 3" | PT | 0.573" | 0.150" | 10 | $16.04 | Add to Order |
| MSS-2636 | 1/4"-28 | 5/8" | FT | 0.573" | 0.150" | 25 | $14.91 | Add to Order |
| MSS-2637 | 1/4"-28 | 1" | FT | 0.573" | 0.150" | 25 | $22.09 | Add to Order |
| MSS-2638 | 5/16"-18 | 1/2" | FT | 0.698" | 0.183" | 25 | $16.93 | Add to Order |
| MSS-2640 | 5/16"-18 | 3/4" | FT | 0.698" | 0.183" | 25 | $11.80 | Add to Order |
| MSS-2641 | 5/16"-18 | 1" | FT | 0.698" | 0.183" | 10 | $12.01 | Add to Order |
| MSS-2642 | 5/16"-18 | 1 1/2" | FT | 0.698" | 0.183" | 10 | $13.88 | Add to Order |
| MSS-2655 | 5/16"-18 | 2" | FT | 0.698" | 0.183" | 10 | $18.77 | Add to Order |
| MSS-2644 | 3/8"-16 | 3/4" | FT | 0.823" | 0.215" | 10 | $17.56 | Add to Order |
| MSS-2633 | 3/8"-16 | 1" | FT | 0.823" | 0.215" | 10 | $18.42 | Add to Order |
| MSS-2646 | 3/8"-16 | 1 1/2" | FT | 0.823" | 0.215" | 10 | $23.21 | Add to Order |
| MSS-2647 | 3/8"-16 | 2" | FT | 0.823" | 0.215" | 10 | $27.17 | Add to Order |
| Rev. 10-23, 08-23, 02-23, 11-22 | ||||||||
