18-8 Black Oxide Truss Head Phillips Machine Screws
Machine Screws - Truss Head Phillips Drive, Black Oxide Finish, Class 2A, fully threaded, round low profile head.
18-8 Stainless Steel - Excellent corrosion resistance, mildly magnetic.
| Black Oxide 18-8 Stainless Steel Truss Head Phillips FT Machine Screws | ||||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Drive Size | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| MSS-6119 | 4-40 | 3/16" | 0.257" | 0.069" | No. 1 | 100 | $24.11 | Add to Order |
| MSS-6120 | 4-40 | 1/4" | 0.257" | 0.069" | No. 1 | 100 | $20.41 | Add to Order |
| MSS-6121 | 4-40 | 3/8" | 0.257" | 0.069" | No. 1 | 100 | $25.37 | Add to Order |
| MSS-6122 | 4-40 | 1/2" | 0.257" | 0.069" | No. 1 | 100 | $21.53 | Add to Order |
| MSS-6156 | 6-32 | 3/16" | 0.321" | 0.086" | No. 2 | 50 | $16.74 | Add to Order |
| MSS-2652 | 6-32 | 1/4" | 0.321" | 0.086" | No. 2 | 50 | $17.28 | Add to Order |
| MSS-6157 | 6-32 | 5/16" | 0.321" | 0.086" | No. 2 | 50 | $13.52 | Add to Order |
| MSS-2653 | 6-32 | 3/8" | 0.321" | 0.086" | No. 2 | 50 | $18.73 | Add to Order |
| MSS-2690 | 6-32 | 1/2" | 0.321" | 0.086" | No. 2 | 50 | $20.18 | Add to Order |
| MSS-2643 | 8-32 | 1/4" | 0.384" | 0.102" | No. 2 | 25 | $15.14 | Add to Order |
| MSS-6158 | 8-32 | 5/16" | 0.384" | 0.102" | No. 2 | 50 | $21.29 | Add to Order |
| MSS-2678 | 8-32 | 3/8" | 0.384" | 0.102" | No. 2 | 25 | $13.00 | Add to Order |
| MSS-2704 | 8-32 | 1/2" | 0.384" | 0.102" | No. 2 | 25 | $13.21 | Add to Order |
| MSS-6159 | 8-32 | 5/8" | 0.384" | 0.102" | No. 2 | 25 | $14.03 | Add to Order |
| MSS-6127 | 8-32 | 3/4" | 0.384" | 0.102" | No. 2 | 25 | $15.33 | Add to Order |
| MSS-6125 | 8-32 | 1" | 0.384" | 0.102" | No. 2 | 25 | $19.93 | Add to Order |
| MSS-2705 | 10-24 | 3/8" | 0.448" | 0.128" | No. 2 | 25 | $19.28 | Add to Order |
| MSS-2706 | 10-24 | 1/2" | 0.448" | 0.128" | No. 2 | 25 | $18.31 | Add to Order |
| MSS-2707 | 10-24 | 3/4" | 0.448" | 0.128" | No. 2 | 10 | $11.55 | Add to Order |
| MSS-6148 | 10-24 | 1" | 0.448" | 0.128" | No. 2 | 10 | $10.98 | Add to Order |
| MSS-2708 | 10-32 | 3/8" | 0.448" | 0.128" | No. 2 | 25 | $16.07 | Add to Order |
| MSS-2709 | 10-32 | 1/2" | 0.448" | 0.128" | No. 2 | 25 | $18.31 | Add to Order |
| MSS-6117 | 10-32 | 5/8" | 0.448" | 0.128" | No. 2 | 25 | $19.01 | Add to Order |
| MSS-2710 | 10-32 | 3/4" | 0.448" | 0.128" | No. 2 | 10 | $11.55 | Add to Order |
| MSS-6118 | 10-32 | 1" | 0.448" | 0.128" | No. 2 | 10 | $9.09 | Add to Order |
| MSS-2711 | 1/4"-20 | 1/2" | 0.573" | 0.150" | No. 3 | 10 | $15.14 | Add to Order |
| MSS-2712 | 1/4"-20 | 3/4" | 0.573" | 0.150" | No. 3 | 10 | $19.32 | Add to Order |
| MSS-2726 | 1/4"-20 | 1" | 0.573" | 0.150" | No. 3 | 10 | $25.60 | Add to Order |
| MSS-2714 | 1/4"-20 | 1 1/4" | 0.573" | 0.150" | No. 3 | 10 | $25.39 | Add to Order |
| MSS-2936 | 1/4"-20 | 1 1/2 | 0.573" | 0.150" | No. 3 | 5 | $14.72 | Add to Order |
| Rev. 11-22, 03-22 | ||||||||
