Brass Slotted Round Head Machine Screws
Machine Screws - Round Head Slotted Drive, Class 2A.
Brass - Non-magnetic and good corrosion resistance
| Brass Round Head Slotted Machine Screws | |||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| MSS-9192 | 000-120 | 3/32" | 0.060" | 0.030" | 10 | $25.49 | Add to Order |
| MSS-9193 | 000-120 | 1/8" | 0.060" | 0.030" | 10 | $25.49 | Add to Order |
| MSS-9194 | 000-120 | 3/16" | 0.060" | 0.030" | 10 | $25.49 | Add to Order |
| MSS-516 | 000-120 | 1/4" | 0.062" | 0.032" | 10 | $25.49 | Add to Order |
| MSS-9195 | 00-90 | 3/32" | 0.086" | 0.042" | 10 | $23.23 | Add to Order |
| MSS-9196 | 00-90 | 1/8" | 0.086" | 0.042" | 10 | $23.23 | Add to Order |
| MSS-9197 | 00-90 | 3/16" | 0.086" | 0.042" | 10 | $23.23 | Add to Order |
| MSS-542 | 00-90 | 1/4" | 0.089" | 0.045" | 25 | $58.38 | Add to Order |
| MSS-9198 | 00-90 | 3/8" | 0.086" | 0.042" | 10 | $30.01 | Add to Order |
| MSS-543 | 00-90 | 1/2" | 0.089" | 0.045" | 10 | $30.01 | Add to Order |
| MSS-9199 | 00-96 | 3/32" | 0.086" | 0.042" | 10 | $26.23 | Add to Order |
| MSS-9200B | 00-96 | 1/8" | 0.086" | 0.042" | 10 | $26.23 | Add to Order |
| MSS-9201 | 00-96 | 3/16" | 0.086" | 0.042" | 5 | $13.15 | Add to Order |
| MSS-9202 | 00-96 | 1/4" | 0.086" | 0.042" | 10 | $26.23 | Add to Order |
| MSS-9203 | 00-96 | 3/8" | 0.086" | 0.042" | 10 | $26.25 | Add to Order |
| MSS-9204 | 0-80 | 3/32" | 0.107" | 0.048" | 10 | $23.23 | Add to Order |
| MSS-9205 | 0-80 | 1/8" | 0.113" | 0.053" | 10 | $23.23 | Add to Order |
| MSS-544 | 0-80 | 5/32" | 0.113" | 0.053" | 25 | $58.13 | Add to Order |
| MSS-9206 | 0-80 | 3/16" | 0.113" | 0.053" | 10 | $23.23 | Add to Order |
| MSS-545 | 0-80 | 1/4" | 0.113" | 0.053" | 25 | $58.13 | Add to Order |
| MSS-9207 | 0-80 | 3/8" | 0.113" | 0.053" | 10 | $12.18 | Add to Order |
| MSS-9208 | 0-80 | 1/2" | 0.113" | 0.053" | 10 | $13.15 | Add to Order |
| MSS-9209 | 1-72 | 1/8" | 0.131" | 0.056" | 10 | $23.23 | Add to Order |
| MSS-9210 | 1-72 | 3/16" | 0.131" | 0.056" | 10 | $23.23 | Add to Order |
| MSS-546 | 1-72 | 1/4" | 0.137" | 0.061" | 25 | $58.13 | Add to Order |
| MSS-547 | 1-72 | 1/2" | 0.137" | 0.061" | 10 | $30.01 | Add to Order |
| MSS-401 | 2-56 | 1/8" | 0.162" | 0.069" | 100 | $11.95 | Add to Order |
| MSS-563 | 2-56 | 3/16" | 0.162" | 0.069" | 100 | $13.67 | Add to Order |
| MSS-683 | 2-56 | 1/4" | 0.162" | 0.069" | 100 | $7.39 | Add to Order |
| MSS-684 | 2-56 | 5/16" | 0.162" | 0.069" | 100 | $13.52 | Add to Order |
| MSS-685 | 2-56 | 3/8" | 0.162" | 0.069" | 100 | $14.36 | Add to Order |
| MSS-686 | 2-56 | 1/2" | 0.162" | 0.069" | 100 | $14.97 | Add to Order |
| MSS-687 | 2-56 | 5/8" | 0.162" | 0.069" | 100 | $15.02 | Add to Order |
| MSS-688 | 2-56 | 3/4" | 0.162" | 0.069" | 100 | $13.82 | Add to Order |
| MSS-689 | 2-56 | 1" | 0.162" | 0.069" | 100 | $19.03 | Add to Order |
| MSS-548 | 3-48 | 1/8" | 0.187" | 0.078" | 100 | $13.65 | Add to Order |
| MSS-549 | 3-48 | 3/16" | 0.187" | 0.078" | 100 | $16.36 | Add to Order |
| MSS-550 | 3-48 | 1/4" | 0.187" | 0.078" | 100 | $16.42 | Add to Order |
| MSS-540 | 3-48 | 3/8" | 0.187" | 0.078" | 100 | $18.50 | Add to Order |
| MSS-529 | 3-48 | 1/2" | 0.187" | 0.078" | 100 | $18.71 | Add to Order |
| MSS-518 | 3-48 | 3/4" | 0.187" | 0.078" | 100 | $20.66 | Add to Order |
| MSS-531 | 3-48 | 7/8" | 0.187" | 0.078" | 100 | $25.56 | Add to Order |
| MSS-532 | 4-40 | 1/8" | 0.211" | 0.086" | 100 | $14.51 | Add to Order |
| MSS-533 | 4-40 | 3/16" | 0.211" | 0.086" | 100 | $14.99 | Add to Order |
| MSS-534 | 4-40 | 1/4" | 0.211" | 0.086" | 100 | $9.14 | Add to Order |
| MSS-535 | 4-40 | 5/16" | 0.211" | 0.086" | 100 | $17.93 | Add to Order |
| MSS-536 | 4-40 | 3/8" | 0.211" | 0.086" | 100 | $10.29 | Add to Order |
| MSS-537 | 4-40 | 1/2" | 0.211" | 0.086" | 100 | $10.58 | Add to Order |
| MSS-538 | 4-40 | 5/8" | 0.211" | 0.086" | 100 | $15.48 | Add to Order |
| MSS-539 | 4-40 | 3/4" | 0.211" | 0.086" | 100 | $12.98 | Add to Order |
| MSS-469 | 4-40 | 1" | 0.211" | 0.086" | 100 | $19.53 | Add to Order |
| MSS-398 | 4-40 | 1 1/8" | 0.211" | 0.086" | 100 | $25.56 | Add to Order |
| MSS-492 | 4-40 | 1 1/4" | 0.211" | 0.086" | 100 | $16.25 | Add to Order |
| MSS-402 | 4-40 | 1 1/2" | 0.211" | 0.086" | 100 | $26.73 | Add to Order |
| MSS-403 | 4-40 | 2" | 0.211" | 0.086" | 50 | $23.60 | Add to Order |
| MSS-404 | 5-40 | 1/4" | 0.236" | 0.095" | 100 | $17.79 | Add to Order |
| MSS-405 | 5-40 | 3/8" | 0.236" | 0.095" | 100 | $18.31 | Add to Order |
| MSS-406 | 5-40 | 1/2" | 0.236" | 0.095" | 100 | $20.73 | Add to Order |
| MSS-407 | 5-40 | 5/8" | 0.236" | 0.095" | 100 | $23.92 | Add to Order |
| MSS-408 | 5-40 | 3/4" | 0.236" | 0.095" | 100 | $26.57 | Add to Order |
| MSS-409 | 5-40 | 1" | 0.236" | 0.095" | 100 | $34.21 | Add to Order |
| MSS-423 | 5-40 | 1 1/4" | 0.236" | 0.095" | 100 | $39.50 | Add to Order |
| MSS-411 | 5-40 | 1 1/2" | 0.236" | 0.095" | 50 | $24.78 | Add to Order |
| MSS-400 | 6-32 | 1/8" | 0.260" | 0.103" | 100 | $20.10 | Add to Order |
| MSS-413 | 6-32 | 3/16" | 0.260" | 0.103" | 100 | $19.99 | Add to Order |
| MSS-414 | 6-32 | 1/4" | 0.260" | 0.103" | 100 | $13.65 | Add to Order |
| MSS-415 | 6-32 | 5/16" | 0.260" | 0.103" | 100 | $22.11 | Add to Order |
| MSS-416 | 6-32 | 3/8" | 0.260" | 0.103" | 100 | $15.08 | Add to Order |
| MSS-417 | 6-32 | 1/2" | 0.260" | 0.103" | 100 | $19.11 | Add to Order |
| MSS-418 | 6-32 | 5/8" | 0.260" | 0.103" | 100 | $14.34 | Add to Order |
| MSS-419 | 6-32 | 3/4" | 0.260" | 0.103" | 100 | $20.18 | Add to Order |
| MSS-420 | 6-32 | 7/8" | 0.260" | 0.103" | 100 | $35.51 | Add to Order |
| MSS-421 | 6-32 | 1" | 0.260" | 0.103" | 100 | $24.53 | Add to Order |
| MSS-389 | 6-32 | 1 1/4" | 0.260" | 0.103" | 100 | $37.91 | Add to Order |
| MSS-412 | 6-32 | 1 1/2" | 0.260" | 0.103" | 50 | $31.88 | Add to Order |
| MSS-410 | 6-32 | 1 3/4" | 0.260" | 0.103" | 100 | $48.64 | Add to Order |
| MSS-378 | 6-32 | 2" | 0.260" | 0.103" | 100 | $48.64 | Add to Order |
| MSS-379 | 8-32 | 3/16" | 0.309" | 0.120" | 100 | $26.44 | Add to Order |
| MSS-380 | 8-32 | 1/4" | 0.309" | 0.120" | 100 | $22.85 | Add to Order |
| MSS-381 | 8-32 | 5/16" | 0.309" | 0.120" | 100 | $28.18 | Add to Order |
| MSS-382 | 8-32 | 3/8" | 0.309" | 0.120" | 100 | $26.71 | Add to Order |
| MSS-383 | 8-32 | 1/2" | 0.309" | 0.120" | 50 | $11.17 | Add to Order |
| MSS-384 | 8-32 | 5/8" | 0.309" | 0.120" | 50 | $12.77 | Add to Order |
| MSS-385 | 8-32 | 3/4" | 0.309" | 0.120" | 50 | $15.33 | Add to Order |
| MSS-386 | 8-32 | 7/8" | 0.309" | 0.120" | 50 | $23.67 | Add to Order |
| MSS-399 | 8-32 | 1" | 0.309" | 0.120" | 50 | $19.32 | Add to Order |
| MSS-388 | 8-32 | 1 1/4" | 0.309" | 0.120" | 50 | $21.80 | Add to Order |
| MSS-377 | 8-32 | 1 1/2" | 0.309" | 0.120" | 50 | $27.01 | Add to Order |
| MSS-390 | 8-32 | 2" | 0.309" | 0.120" | 25 | $26.31 | Add to Order |
| MSS-392 | 8-32 | 2 1/2" | 0.309" | 0.120" | 25 | $32.49 | Add to Order |
| MSS-393 | 8-32 | 3" | 0.309" | 0.120" | 25 | $34.82 | Add to Order |
| MSS-394 | 10-24 | 1/4" | 0.359" | 0.137" | 100 | $33.18 | Add to Order |
| MSS-395 | 10-24 | 3/8" | 0.359" | 0.137" | 50 | $14.81 | Add to Order |
| MSS-396 | 10-24 | 1/2" | 0.359" | 0.137" | 50 | $16.59 | Add to Order |
| MSS-397 | 10-24 | 5/8" | 0.359" | 0.137" | 50 | $17.85 | Add to Order |
| MSS-434 | 10-24 | 3/4" | 0.359" | 0.137" | 50 | $21.90 | Add to Order |
| MSS-387 | 10-24 | 1" | 0.359" | 0.137" | 50 | $23.48 | Add to Order |
| MSS-422 | 10-24 | 1 1/4" | 0.359" | 0.137" | 50 | $27.93 | Add to Order |
| MSS-448 | 10-24 | 1 1/2" | 0.359" | 0.137" | 25 | $21.48 | Add to Order |
| MSS-449 | 10-24 | 2" | 0.359" | 0.137" | 25 | $30.58 | Add to Order |
| MSS-450 | 10-24 | 2 1/2" | 0.359" | 0.137" | 10 | $14.47 | Add to Order |
| MSS-451 | 10-24 | 3" | 0.359" | 0.137" | 10 | $15.86 | Add to Order |
| MSS-452 | 10-32 | 1/4" | 0.359" | 0.137" | 100 | $36.10 | Add to Order |
| MSS-453 | 10-32 | 5/16" | 0.359" | 0.137" | 100 | $36.96 | Add to Order |
| MSS-454 | 10-32 | 3/8" | 0.359" | 0.137" | 100 | $41.66 | Add to Order |
| MSS-455 | 10-32 | 1/2" | 0.359" | 0.137" | 50 | $24.40 | Add to Order |
| MSS-456 | 10-32 | 5/8" | 0.359" | 0.137" | 50 | $25.07 | Add to Order |
| MSS-470 | 10-32 | 3/4" | 0.359" | 0.137" | 50 | $29.34 | Add to Order |
| MSS-458 | 10-32 | 7/8" | 0.359" | 0.137" | 50 | $37.09 | Add to Order |
| MSS-447 | 10-32 | 1" | 0.359" | 0.137" | 50 | $24.15 | Add to Order |
| MSS-460 | 10-32 | 1 1/4" | 0.359" | 0.137" | 25 | $22.18 | Add to Order |
| MSS-461 | 10-32 | 1 1/2" | 0.359" | 0.137" | 25 | $24.97 | Add to Order |
| MSS-462 | 10-32 | 1 3/4" | 0.359" | 0.137" | 25 | $26.29 | Add to Order |
| MSS-463 | 10-32 | 2" | 0.359" | 0.137" | 25 | $31.94 | Add to Order |
| MSS-464 | 10-32 | 2 1/2" | 0.359" | 0.137" | 10 | $17.45 | Add to Order |
| MSS-465 | 10-32 | 3" | 0.359" | 0.137" | 10 | $19.99 | Add to Order |
| MSS-466 | 12-24 | 3/8" | 0.408" | 0.153" | 50 | $12.77 | Add to Order |
| MSS-467 | 12-24 | 1/2" | 0.408" | 0.153" | 50 | $21.29 | Add to Order |
| MSS-468 | 12-24 | 3/4" | 0.408" | 0.153" | 25 | $18.25 | Add to Order |
| MSS-436 | 12-24 | 1" | 0.408" | 0.153" | 25 | $25.47 | Add to Order |
| MSS-459 | 12-24 | 1 1/2" | 0.408" | 0.153" | 25 | $31.63 | Add to Order |
| MSS-457 | 12-24 | 2" | 0.408" | 0.153" | 10 | $16.82 | Add to Order |
| MSS-425 | 1/4"-20 | 1/4" | 0.472" | 0.175" | 50 | $32.40 | Add to Order |
| MSS-426 | 1/4"-20 | 3/8" | 0.472" | 0.175" | 25 | $22.03 | Add to Order |
| MSS-427 | 1/4"-20 | 1/2" | 0.472" | 0.175" | 25 | $23.88 | Add to Order |
| MSS-428 | 1/4"-20 | 5/8" | 0.472" | 0.175" | 50 | $35.74 | Add to Order |
| MSS-429 | 1/4"-20 | 3/4" | 0.472" | 0.175" | 50 | $28.35 | Add to Order |
| MSS-430 | 1/4"-20 | 1" | 0.472" | 0.175" | 25 | $34.19 | Add to Order |
| MSS-431 | 1/4"-20 | 1 1/4" | 0.472" | 0.175" | 25 | $38.07 | Add to Order |
| MSS-432 | 1/4"-20 | 1 1/2" | 0.472" | 0.175" | 10 | $18.44 | Add to Order |
| MSS-433 | 1/4"-20 | 1 3/4" | 0.472" | 0.175" | 10 | $17.64 | Add to Order |
| MSS-435 | 1/4"-20 | 2" | 0.472" | 0.175" | 10 | $21.34 | Add to Order |
| MSS-424 | 1/4"-20 | 2 1/2" | 0.472" | 0.175" | 10 | $25.52 | Add to Order |
| MSS-437 | 1/4"-20 | 3" | 0.472" | 0.175" | 10 | $29.32 | Add to Order |
| MSS-438 | 5/16"-18 | 1/2" | 0.590" | 0.216" | 10 | $15.58 | Add to Order |
| MSS-439 | 5/16"-18 | 3/4" | 0.590" | 0.216" | 10 | $19.99 | Add to Order |
| MSS-440 | 5/16"-18 | 1" | 0.590" | 0.216" | 10 | $8.67 | Add to Order |
| MSS-441 | 5/16"-18 | 1 1/2" | 0.590" | 0.216" | 10 | $26.44 | Add to Order |
| MSS-442 | 5/16"-18 | 2" | 0.590" | 0.216" | 5 | $17.03 | Add to Order |
| MSS-9211 | 3/8"-16 | 1/2" | 0.708" | 0.256" | 10 | $23.84 | Add to Order |
| MSS-9212 | 3/8"-16 | 3/4" | 0.708" | 0.256" | 5 | $18.25 | Add to Order |
| MSS-9213 | 3/8"-16 | 1" | 0.708" | 0.256" | 5 | $18.69 | Add to Order |
| MSS-9214 | 3/8"-16 | 1 1/2" | 0.708" | 0.256" | 5 | $23.23 | Add to Order |
| MSS-9215 | 3/8"-16 | 2" | 0.708" | 0.256" | 5 | $22.28 | Add to Order |
| Rev. 10-23, 08-23, 02-23, 11-22 | |||||||
