Zinc Plated Steel Round Head Combination Drive Machine Screws
Machine Screws - Round Head Combination Drive, Zinc Plated, Class 2A, *Fully Threaded
Steel / Zinc Plated - Good rust resistance.
| Zinc Plated Round Head Combination Phillips Slotted Machine Screws | ||||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Drive Size | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| MSS-9626 | 2-56 | 1/4" | 0.162" | 0.069" | No. 1 | 100 | $5.96 | Add to Order |
| MSS-9627 | 2-56 | 3/8" | 0.162" | 0.069" | No. 1 | 100 | $6.51 | Add to Order |
| MSS-9628 | 4-40 | 1/4" | 0.211" | 0.086" | No. 1 | 100 | $2.21 | Add to Order |
| MSS-9629 | 4-40 | 3/8" | 0.211" | 0.086" | No. 1 | 100 | $9.81 | Add to Order |
| MSS-9630 | 4-40 | 1/2" | 0.211" | 0.086" | No. 1 | 100 | $19.15 | Add to Order |
| MSS-9631 | 6-32 | 1/4" | 0.260" | 0.103" | No. 2 | 100 | $3.63 | Add to Order |
| MSS-681 | 6-32 | 3/8" | 0.260" | 0.103" | No. 2 | 100 | $11.19 | Add to Order |
| MSS-670 | 6-32 | 1/2" | 0.260" | 0.103" | No. 2 | 100 | $7.48 | Add to Order |
| MSS-9632 | 6-32 | 5/8" | 0.260" | 0.103" | No. 2 | 100 | $4.16 | Add to Order |
| MSS-659 | 6-32 | 3/4" | 0.260" | 0.103" | No. 2 | 100 | $9.70 | Add to Order |
| MSS-672 | 6-32 | 1" | 0.260" | 0.103" | No. 2 | 100 | $9.70 | Add to Order |
| MSS-673 | 6-32 | 1 1/4" | 0.260" | 0.103" | No. 2 | 100 | $12.75 | Add to Order |
| MSS-674 | 6-32 | 1 1/2" | 0.260" | 0.103" | No. 2 | 100 | $13.84 | Add to Order |
| MSS-675 | 6-32 | 2" | 0.260" | 0.103" | No. 2 | 100 | $17.35 | Add to Order |
| MSS-676 | 6-32 | 3" | 0.260" | 0.103" | No. 2 | 100 | $23.94 | Add to Order |
| MSS-677 | 6-32 | 4" | 0.260" | 0.103" | No. 2 | 50 | $18.73 | Add to Order |
| MSS-678 | 8-32 | 1/4" | 0.309" | 0.120" | No. 2 | 100 | $13.04 | Add to Order |
| MSS-679 | 8-32 | 3/8" | 0.309" | 0.120" | No. 2 | 100 | $10.42 | Add to Order |
| MSS-716 | 8-32 | 1/2" | 0.309" | 0.120" | No. 2 | 100 | $9.32 | Add to Order |
| MSS-9633 | 8-32 | 5/8" | 0.309" | 0.120" | No. 2 | 100 | $6.57 | Add to Order |
| MSS-669 | 8-32 | 3/4" | 0.309" | 0.120" | No. 2 | 100 | $9.91 | Add to Order |
| MSS-704 | 8-32 | 1" | 0.309" | 0.120" | No. 2 | 100 | $10.50 | Add to Order |
| MSS-730 | 8-32 | 1 1/4" | 0.309" | 0.120" | No. 2 | 100 | $12.39 | Add to Order |
| MSS-731 | 8-32 | 1 1/2" | 0.309" | 0.120" | No. 2 | 100 | $14.70 | Add to Order |
| MSS-732 | 8-32 | 2" | 0.309" | 0.120" | No. 2 | 100 | $19.76 | Add to Order |
| MSS-733 | 8-32 | 2 1/2" | 0.309" | 0.120" | No. 2 | 100 | $25.41 | Add to Order |
| MSS-734 | 8-32 | 3" | 0.309" | 0.120" | No. 2 | 100 | $29.19 | Add to Order |
| MSS-9634 | 10-24 | 3/8" | 0.359" | 0.137" | No. 2 | 100 | $4.52 | Add to Order |
| MSS-735 | 10-24 | 1/2" | 0.359" | 0.137" | No. 2 | 100 | $9.72 | Add to Order |
| MSS-9635 | 10-24 | 5/8" | 0.359" | 0.137" | No. 2 | 100 | $6.41 | Add to Order |
| MSS-736 | 10-24 | 3/4" | 0.359" | 0.137" | No. 2 | 100 | $14.78 | Add to Order |
| MSS-746 | 10-24 | 1" | 0.359" | 0.137" | No. 2 | 100 | $14.70 | Add to Order |
| MSS-738 | 10-24 | 1 1/4" | 0.359" | 0.137" | No. 2 | 100 | $17.14 | Add to Order |
| MSS-752 | 10-24 | 1 1/2" | 0.359" | 0.137" | No. 2 | 100 | $18.84 | Add to Order |
| MSS-740 | 10-24 | 2" | 0.359" | 0.137" | No. 2 | 100 | $23.60 | Add to Order |
| MSS-9636 | 10-24 | 3" | 0.359" | 0.137" | No. 2 | 100 | $25.81 | Add to Order |
| MSS-729 | 10-24 | 4" | 0.359" | 0.137" | No. 2 | 50 | $28.43 | Add to Order |
| MSS-742 | 10-24 | 5" | 0.359" | 0.137" | No. 2 | 25 | $24.13 | Add to Order |
| MSS-743 | 10-32 | 3/8" | 0.359" | 0.137" | No. 2 | 100 | $10.84 | Add to Order |
| MSS-744 | 10-32 | 1/2" | 0.359" | 0.137" | No. 2 | 100 | $13.69 | Add to Order |
| MSS-9637 | 10-32 | 5/8" | 0.359" | 0.137" | No. 2 | 100 | $5.15 | Add to Order |
| MSS-745 | 10-32 | 3/4" | 0.359" | 0.137" | No. 2 | 100 | $14.39 | Add to Order |
| MSS-746 | 10-32 | 1" | 0.359" | 0.137" | No. 2 | 100 | $14.70 | Add to Order |
| MSS-747 | 10-32 | 1 1/4" | 0.359" | 0.137" | No. 2 | 100 | $16.21 | Add to Order |
| MSS-748 | 10-32 | 1 1/2" | 0.359" | 0.137" | No. 2 | 100 | $18.84 | Add to Order |
| MSS-749 | 10-32 | 2" | 0.359" | 0.137" | No. 2 | 100 | $23.60 | Add to Order |
| MSS-9638 | 10-32 | 3" | 0.359" | 0.137" | No. 2 | 100 | $21.90 | Add to Order |
| MSS-750 | 1/4"-20 | 3/8" | 0.472" | 0.175" | No. 3 | 100 | $15.12 | Add to Order |
| MSS-718 | 1/4"-20 | 1/2" | 0.472" | 0.175" | No. 3 | 100 | $15.12 | Add to Order |
| MSS-9639 | 1/4"-20 | 5/8" | 0.472" | 0.175" | No. 3 | 100 | $9.49 | Add to Order |
| MSS-741 | 1/4"-20 | 3/4" | 0.472" | 0.175" | No. 3 | 100 | $15.62 | Add to Order |
| MSS-739 | 1/4"-20 | 1" | 0.472" | 0.175" | No. 3 | 100 | $21.36 | Add to Order |
| MSS-707 | 1/4"-20 | 1 1/4" | 0.472" | 0.175" | No. 3 | 100 | $23.96 | Add to Order |
| MSS-708 | 1/4"-20 | 1 1/2" | 0.472" | 0.175" | No. 3 | 100 | $28.25 | Add to Order |
| MSS-9640 | 1/4"-20 | 1 3/4" | 0.472" | 0.175" | No. 3 | 25 | $15.90 | Add to Order |
| MSS-709 | 1/4"-20 | 2" | 0.472" | 0.175" | No. 3 | 100 | $29.09 | Add to Order |
| MSS-710 | 1/4"-20 | 2 1/2" | 0.472" | 0.175" | No. 3 | 50 | $22.39 | Add to Order |
| MSS-711 | 1/4"-20 | 3" | 0.472" | 0.175" | No. 3 | 50 | $26.19 | Add to Order |
| MSS-712 | 1/4"-20 | 4" | 0.472" | 0.175" | No. 3 | 25 | $27.51 | Add to Order |
| MSS-713 | 1/4"-20 | 5" | 0.472" | 0.175" | No. 3 | 25 | $27.72 | Add to Order |
| MSS-714 | 1/4"-20 | 6" | 0.472" | 0.175" | No. 3 | 25 | $33.92 | Add to Order |
| MSS-715 | 3/8"-16 | 4" | 0.708" | 0.256" | No. 4 | 5 | $22.26 | Add to Order |
| MSS-9641 | 3/8"-16 | 5" | 0.708" | 0.256" | No. 4 | 10 | $12.94 | Add to Order |
| MSS-9642 | 3/8"-16 | 6" | 0.708" | 0.256" | No. 4 | 10 | $17.18 | Add to Order |
| Rev. 10-23, 02-23, 11-22, 03-22 | ||||||||
