Zinc Plated Pan Head Phillips Metric Machine Screws
Machine Screws - Pan Head Phillips Drive, Zinc Plated, Class 6h, Fully Threaded.
| Metric Zinc Plated Steel Pan Head Phillips Machine Screws, Full Threads, DIN 7985 | |||||||||
| Part # | Thread Size | Pitch | Length (mm) | Head Dia. (mm) | Head Height (mm) | Drive Size | Pkg Qty. | Pkg Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| MSS-7201 | M1.6 | 0.35 mm | 2 | 3.2 | 1.3 | No. 0 | 50 | $25.28 | Add to Order |
| MSS-1350 | M1.6 | 0.35 mm | 3 | 3.2 | 1.3 | No. 0 | 50 | $26.71 | Add to Order |
| MSS-1318 | M1.6 | 0.35 mm | 4 | 3.2 | 1.3 | No. 0 | 25 | $19.03 | Add to Order |
| MSS-1905 | M1.6 | 0.35 mm | 5 | 3.2 | 1.3 | No. 0 | 25 | $19.03 | Add to Order |
| MSS-2067 | M1.6 | 0.35 mm | 6 | 3.2 | 1.3 | No. 0 | 25 | $20.35 | Add to Order |
| MSS-2187 | M1.6 | 0.35 mm | 8 | 3.2 | 1.3 | No. 0 | 25 | $21.32 | Add to Order |
| MSS-2188 | M2 | 0.4 mm | 2 | 4 | 1.6 | No. 1 | 100 | $16.28 | Add to Order |
| MSS-2189 | M2 | 0.4 mm | 3 | 4 | 1.6 | No. 1 | 100 | $10.86 | Add to Order |
| MSS-2190 | M2 | 0.4 mm | 4 | 4 | 1.6 | No. 1 | 100 | $8.09 | Add to Order |
| MSS-2191 | M2 | 0.4 mm | 5 | 4 | 1.6 | No. 1 | 100 | $8.09 | Add to Order |
| MSS-2192 | M2 | 0.4 mm | 6 | 4 | 1.6 | No. 1 | 100 | $7.14 | Add to Order |
| MSS-2193 | M2 | 0.4 mm | 8 | 4 | 1.6 | No. 1 | 100 | $7.62 | Add to Order |
| MSS-2194 | M2 | 0.4 mm | 10 | 4 | 1.6 | No. 1 | 100 | $7.04 | Add to Order |
| MSS-2195 | M2 | 0.4 mm | 12 | 4 | 1.6 | No. 1 | 100 | $7.56 | Add to Order |
| MSS-7202 | M2 | 0.4 mm | 14 | 4 | 1.6 | No. 1 | 100 | $25.20 | Add to Order |
| MSS-2209 | M2 | 0.4 mm | 16 | 4 | 1.6 | No. 1 | 100 | $7.56 | Add to Order |
| MSS-2197 | M2 | 0.4 mm | 20 | 4 | 1.6 | No. 1 | 100 | $7.79 | Add to Order |
| MSS-2186 | M2.5 | 0.45 mm | 3 | 5 | 2 | No. 1 | 100 | $12.77 | Add to Order |
| MSS-2199 | M2.5 | 0.45 mm | 4 | 5 | 2 | No. 1 | 100 | $4.85 | Add to Order |
| MSS-2200 | M2.5 | 0.45 mm | 5 | 5 | 2 | No. 1 | 100 | $7.33 | Add to Order |
| MSS-2201 | M2.5 | 0.45 mm | 6 | 5 | 2 | No. 1 | 100 | $7.62 | Add to Order |
| MSS-2202 | M2.5 | 0.45 mm | 8 | 5 | 2 | No. 1 | 100 | $7.69 | Add to Order |
| MSS-2203 | M2.5 | 0.45 mm | 10 | 5 | 2 | No. 1 | 100 | $7.69 | Add to Order |
| MSS-2204 | M2.5 | 0.45 mm | 12 | 5 | 2 | No. 1 | 100 | $7.92 | Add to Order |
| MSS-7203 | M2.5 | 0.45 mm | 14 | 5 | 2 | No. 1 | 100 | $15.75 | Add to Order |
| MSS-2205 | M2.5 | 0.45 mm | 16 | 5 | 2 | No. 1 | 100 | $10.10 | Add to Order |
| MSS-2206 | M2.5 | 0.45 mm | 20 | 5 | 2 | No. 1 | 100 | $11.42 | Add to Order |
| MSS-2207 | M2.5 | 0.45 mm | 25 | 5 | 2 | No. 1 | 100 | $15.75 | Add to Order |
| MSS-2175 | M2.5 | 0.45 mm | 30 | 5 | 2 | No. 1 | 100 | $16.82 | Add to Order |
| MSS-2198 | M3 | 0.5 mm | 3 | 6 | 2.4 | No. 1 | 100 | $11.42 | Add to Order |
| MSS-2196 | M3 | 0.5 mm | 4 | 6 | 2.4 | No. 1 | 100 | $8.59 | Add to Order |
| MSS-2164 | M3 | 0.5 mm | 5 | 6 | 2.4 | No. 1 | 100 | $6.97 | Add to Order |
| MSS-2165 | M3 | 0.5 mm | 6 | 6 | 2.4 | No. 1 | 100 | $7.04 | Add to Order |
| MSS-2166 | M3 | 0.5 mm | 8 | 6 | 2.4 | No. 1 | 100 | $6.97 | Add to Order |
| MSS-2167 | M3 | 0.5 mm | 10 | 6 | 2.4 | No. 1 | 100 | $7.35 | Add to Order |
| MSS-2168 | M3 | 0.5 mm | 12 | 6 | 2.4 | No. 1 | 100 | $7.69 | Add to Order |
| MSS-2169 | M3 | 0.5 mm | 14 | 6 | 2.4 | No. 1 | 100 | $8.61 | Add to Order |
| MSS-2170 | M3 | 0.5 mm | 16 | 6 | 2.4 | No. 1 | 100 | $9.93 | Add to Order |
| MSS-2171 | M3 | 0.5 mm | 18 | 6 | 2.4 | No. 1 | 100 | $11.91 | Add to Order |
| MSS-2172 | M3 | 0.5 mm | 20 | 6 | 2.4 | No. 1 | 100 | $8.93 | Add to Order |
| MSS-2185 | M3 | 0.5 mm | 22 | 6 | 2.4 | No. 1 | 100 | $13.06 | Add to Order |
| MSS-2174 | M3 | 0.5 mm | 25 | 6 | 2.4 | No. 1 | 100 | $9.85 | Add to Order |
| MSS-2163 | M3 | 0.5 mm | 30 | 6 | 2.4 | No. 1 | 100 | $10.75 | Add to Order |
| MSS-2176 | M3 | 0.5 mm | 35 | 6 | 2.4 | No. 1 | 100 | $14.66 | Add to Order |
| MSS-2177 | M3 | 0.5 mm | 40 | 6 | 2.4 | No. 1 | 100 | $13.27 | Add to Order |
| MSS-2178 | M3 | 0.5 mm | 45 | 6 | 2.4 | No. 1 | 50 | $22.72 | Add to Order |
| MSS-2179 | M3 | 0.5 mm | 50 | 6 | 2.4 | No. 1 | 25 | $8.65 | Add to Order |
| MSS-7204 | M3 | 0.5 mm | 60 | 6 | 2.4 | No. 1 | 10 | $11.45 | Add to Order |
| MSS-2180 | M3.5 | 0.6 mm | 5 | 7 | 2.7 | No. 2 | 100 | $15.54 | Add to Order |
| MSS-2181 | M3.5 | 0.6 mm | 6 | 7 | 2.7 | No. 2 | 100 | $10.37 | Add to Order |
| MSS-2182 | M3.5 | 0.6 mm | 8 | 7 | 2.7 | No. 2 | 100 | $10.86 | Add to Order |
| MSS-2183 | M3.5 | 0.6 mm | 10 | 7 | 2.7 | No. 2 | 100 | $13.13 | Add to Order |
| MSS-2220 | M3.5 | 0.6 mm | 12 | 7 | 2.7 | No. 2 | 100 | $11.21 | Add to Order |
| MSS-2173 | M3.5 | 0.6 mm | 16 | 7 | 2.7 | No. 2 | 100 | $12.98 | Add to Order |
| MSS-2208 | M3.5 | 0.6 mm | 20 | 7 | 2.7 | No. 2 | 100 | $15.65 | Add to Order |
| MSS-2234 | M3.5 | 0.6 mm | 25 | 7 | 2.7 | No. 2 | 25 | $6.59 | Add to Order |
| MSS-2235 | M3.5 | 0.6 mm | 30 | 7 | 2.7 | No. 2 | 25 | $7.12 | Add to Order |
| MSS-2236 | M4 | 0.7 mm | 4 | 8 | 3.1 | No. 2 | 100 | $15.75 | Add to Order |
| MSS-2237 | M4 | 0.7 mm | 5 | 8 | 3.1 | No. 2 | 100 | $6.97 | Add to Order |
| MSS-2238 | M4 | 0.7 mm | 6 | 8 | 3.1 | No. 2 | 100 | $8.69 | Add to Order |
| MSS-2239 | M4 | 0.7 mm | 8 | 8 | 3.1 | No. 2 | 100 | $9.03 | Add to Order |
| MSS-2240 | M4 | 0.7 mm | 10 | 8 | 3.1 | No. 2 | 100 | $9.79 | Add to Order |
| MSS-2241 | M4 | 0.7 mm | 12 | 8 | 3.1 | No. 2 | 100 | $10.21 | Add to Order |
| MSS-2242 | M4 | 0.7 mm | 14 | 8 | 3.1 | No. 2 | 100 | $11.59 | Add to Order |
| MSS-2256 | M4 | 0.7 mm | 16 | 8 | 3.1 | No. 2 | 100 | $12.94 | Add to Order |
| MSS-2244 | M4 | 0.7 mm | 18 | 8 | 3.1 | No. 2 | 100 | $15.67 | Add to Order |
| MSS-2233 | M4 | 0.7 mm | 20 | 8 | 3.1 | No. 2 | 100 | $14.28 | Add to Order |
| MSS-2246 | M4 | 0.7 mm | 25 | 8 | 3.1 | No. 2 | 100 | $15.92 | Add to Order |
| MSS-2247 | M4 | 0.7 mm | 30 | 8 | 3.1 | No. 2 | 100 | $13.69 | Add to Order |
| MSS-2248 | M4 | 0.7 mm | 35 | 8 | 3.1 | No. 2 | 100 | $14.24 | Add to Order |
| MSS-2249 | M4 | 0.7 mm | 40 | 8 | 3.1 | No. 2 | 100 | $16.46 | Add to Order |
| MSS-2250 | M4 | 0.7 mm | 45 | 8 | 3.1 | No. 2 | 100 | $17.01 | Add to Order |
| MSS-2251 | M4 | 0.7 mm | 50 | 8 | 3.1 | No. 2 | 100 | $35.34 | Add to Order |
| MSS-2252 | M4 | 0.7 mm | 55 | 8 | 3.1 | No. 2 | 25 | $11.63 | Add to Order |
| MSS-2253 | M4 | 0.7 mm | 60 | 8 | 3.1 | No. 2 | 25 | $17.72 | Add to Order |
| MSS-2254 | M4 | 0.7 mm | 70 | 8 | 3.1 | No. 2 | 10 | $9.30 | Add to Order |
| MSS-2222 | M4 | 0.7 mm | 80 | 8 | 3.1 | No. 2 | 10 | $11.30 | Add to Order |
| MSS-2245 | M5 | 0.8 mm | 5 | 10 | 3.8 | No. 2 | 50 | $19.68 | Add to Order |
| MSS-2243 | M5 | 0.8 mm | 6 | 10 | 3.8 | No. 2 | 100 | $13.78 | Add to Order |
| MSS-2211 | M5 | 0.8 mm | 8 | 10 | 3.8 | No. 2 | 100 | $12.73 | Add to Order |
| MSS-2212 | M5 | 0.8 mm | 10 | 10 | 3.8 | No. 2 | 100 | $14.99 | Add to Order |
| MSS-2213 | M5 | 0.8 mm | 12 | 10 | 3.8 | No. 2 | 100 | $17.28 | Add to Order |
| MSS-2214 | M5 | 0.8 mm | 14 | 10 | 3.8 | No. 2 | 100 | $22.05 | Add to Order |
| MSS-2215 | M5 | 0.8 mm | 16 | 10 | 3.8 | No. 2 | 100 | $15.04 | Add to Order |
| MSS-2216 | M5 | 0.8 mm | 18 | 10 | 3.8 | No. 2 | 100 | $23.44 | Add to Order |
| MSS-2217 | M5 | 0.8 mm | 20 | 10 | 3.8 | No. 2 | 100 | $18.12 | Add to Order |
| MSS-2218 | M5 | 0.8 mm | 25 | 10 | 3.8 | No. 2 | 100 | $20.73 | Add to Order |
| MSS-2219 | M5 | 0.8 mm | 30 | 10 | 3.8 | No. 2 | 100 | $29.34 | Add to Order |
| MSS-2232 | M5 | 0.8 mm | 35 | 10 | 3.8 | No. 2 | 100 | $31.71 | Add to Order |
| MSS-2221 | M5 | 0.8 mm | 40 | 10 | 3.8 | No. 2 | 100 | $23.77 | Add to Order |
| MSS-2210 | M5 | 0.8 mm | 45 | 10 | 3.8 | No. 2 | 25 | $24.61 | Add to Order |
| MSS-2223 | M5 | 0.8 mm | 50 | 10 | 3.8 | No. 2 | 25 | $19.47 | Add to Order |
| MSS-2224 | M5 | 0.8 mm | 60 | 10 | 3.8 | No. 2 | 25 | $23.04 | Add to Order |
| MSS-2225 | M5 | 0.8 mm | 70 | 10 | 3.8 | No. 2 | 10 | $18.38 | Add to Order |
| MSS-2226 | M5 | 0.8 mm | 80 | 10 | 3.8 | No. 2 | 5 | $9.77 | Add to Order |
| MSS-2227 | M6 | 1 mm | 6 | 12 | 4.6 | No. 3 | 50 | $21.65 | Add to Order |
| MSS-2228 | M6 | 1 mm | 8 | 12 | 4.6 | No. 3 | 100 | $15.39 | Add to Order |
| MSS-2229 | M6 | 1 mm | 10 | 12 | 4.6 | No. 3 | 100 | $19.89 | Add to Order |
| MSS-2230 | M6 | 1 mm | 12 | 12 | 4.6 | No. 3 | 100 | $20.96 | Add to Order |
| MSS-2231 | M6 | 1 mm | 14 | 12 | 4.6 | No. 3 | 100 | $32.80 | Add to Order |
| MSS-2161 | M6 | 1 mm | 16 | 12 | 4.6 | No. 3 | 100 | $22.64 | Add to Order |
| MSS-2090 | M6 | 1 mm | 18 | 12 | 4.6 | No. 3 | 25 | $22.85 | Add to Order |
| MSS-2184 | M6 | 1 mm | 20 | 12 | 4.6 | No. 3 | 100 | $28.16 | Add to Order |
| MSS-2094 | M6 | 1 mm | 22 | 12 | 4.6 | No. 3 | 25 | $8.21 | Add to Order |
| MSS-2095 | M6 | 1 mm | 25 | 12 | 4.6 | No. 3 | 100 | $31.19 | Add to Order |
| MSS-2096 | M6 | 1 mm | 30 | 12 | 4.6 | No. 3 | 50 | $21.46 | Add to Order |
| MSS-2097 | M6 | 1 mm | 35 | 12 | 4.6 | No. 3 | 50 | $23.48 | Add to Order |
| MSS-2098 | M6 | 1 mm | 40 | 12 | 4.6 | No. 3 | 50 | $25.94 | Add to Order |
| MSS-2099 | M6 | 1 mm | 45 | 12 | 4.6 | No. 3 | 50 | $31.40 | Add to Order |
| MSS-2100 | M6 | 1 mm | 50 | 12 | 4.6 | No. 3 | 50 | $35.57 | Add to Order |
| MSS-2101 | M6 | 1 mm | 60 | 12 | 4.6 | No. 3 | 25 | $29.90 | Add to Order |
| MSS-7205 | M6 | 1 mm | 65 | 12 | 4.6 | No. 3 | 10 | $17.85 | Add to Order |
| MSS-2115 | M6 | 1 mm | 70 | 12 | 4.6 | No. 3 | 10 | $12.26 | Add to Order |
| MSS-2103 | M6 | 1 mm | 75 | 12 | 4.6 | No. 3 | 10 | $14.91 | Add to Order |
| MSS-2092 | M6 | 1 mm | 80 | 12 | 4.6 | No. 3 | 5 | $13.52 | Add to Order |
| MSS-7206 | M6 | 1 mm | 90 | 12 | 4.6 | No. 3 | 5 | $12.73 | Add to Order |
| MSS-7207 | M6 | 1 mm | 100 | 12 | 4.6 | No. 3 | 5 | $13.13 | Add to Order |
| MSS-2105 | M8 | 1.25 mm | 10 | 16 | 6 | No. 4 | 10 | $12.01 | Add to Order |
| MSS-2106 | M8 | 1.25 mm | 12 | 16 | 6 | No. 4 | 10 | $16.93 | Add to Order |
| MSS-2107 | M8 | 1.25 mm | 16 | 16 | 6 | No. 4 | 25 | $22.11 | Add to Order |
| MSS-2108 | M8 | 1.25 mm | 20 | 16 | 6 | No. 4 | 25 | $24.84 | Add to Order |
| MSS-2109 | M8 | 1.25 mm | 25 | 16 | 6 | No. 4 | 25 | $28.52 | Add to Order |
| MSS-2110 | M8 | 1.25 mm | 30 | 16 | 6 | No. 4 | 10 | $18.38 | Add to Order |
| MSS-2111 | M8 | 1.25 mm | 35 | 16 | 6 | No. 4 | 10 | $21.13 | Add to Order |
| MSS-2112 | M8 | 1.25 mm | 40 | 16 | 6 | No. 4 | 10 | $25.98 | Add to Order |
| MSS-2113 | M8 | 1.25 mm | 45 | 16 | 6 | No. 4 | 5 | $16.99 | Add to Order |
| MSS-2081 | M8 | 1.25 mm | 50 | 16 | 6 | No. 4 | 5 | $20.14 | Add to Order |
| MSS-2104 | M8 | 1.25 mm | 60 | 16 | 6 | No. 4 | 5 | $25.52 | Add to Order |
| MSS-2102 | M8 | 1.25 mm | 70 | 16 | 6 | No. 4 | 1 | $5.84 | Add to Order |
| MSS-2070 | M8 | 1.25 mm | 80 | 16 | 6 | No. 4 | 1 | $5.96 | Add to Order |
| MSS-7208 | M8 | 1.25 mm | 90 | 16 | 6 | No. 4 | 1 | $5.59 | Add to Order |
| MSS-7209 | M8 | 1.25 mm | 100 | 16 | 6 | No. 4 | 1 | $7.20 | Add to Order |
| MSS-2071 | M10 | 1.5 mm | 16 | 20 | 7.5 | No. 4 | 1 | $8.90 | Add to Order |
| MSS-2072 | M10 | 1.5 mm | 20 | 20 | 7.5 | No. 4 | 1 | $8.59 | Add to Order |
| MSS-2073 | M10 | 1.5 mm | 25 | 20 | 7.5 | No. 4 | 1 | $10.10 | Add to Order |
| MSS-2074 | M10 | 1.5 mm | 30 | 20 | 7.5 | No. 4 | 1 | $9.14 | Add to Order |
| MSS-2075 | M10 | 1.5 mm | 35 | 20 | 7.5 | No. 4 | 1 | $8.44 | Add to Order |
| MSS-2076 | M10 | 1.5 mm | 40 | 20 | 7.5 | No. 4 | 1 | $10.98 | Add to Order |
| MSS-7210 | M10 | 1.5 mm | 45 | 20 | 7.5 | No. 4 | 1 | $5.21 | Add to Order |
| MSS-7211 | M10 | 1.5 mm | 50 | 20 | 7.5 | No. 4 | 1 | $5.46 | Add to Order |
| MSS-7212 | M10 | 1.5 mm | 60 | 20 | 7.5 | No. 4 | 1 | $6.01 | Add to Order |
| MSS-7213 | M10 | 1.5 mm | 70 | 20 | 7.5 | No. 4 | 1 | $5.88 | Add to Order |
| MSS-7214 | M10 | 1.5 mm | 80 | 20 | 7.5 | No. 4 | 1 | $6.97 | Add to Order |
| Rev. 10-23, 02-23, 11-22, 03-22 | |||||||||
