Nylon 6/6 Slotted Pan Head Machine Screws
Machine Screws - Pan Head Slotted, Class 2A, Fully Threaded.
| White Nylon Pan Head Slotted FT Fully Threaded Machine Screws | |||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| MSS-9020 | 0-80 | 1/8" | 0.116" | 0.044" | 100 | $34.88 | Add to Order |
| MSS-9021 | 0-80 | 3/16" | 0.116" | 0.044" | 100 | $36.16 | Add to Order |
| MSS-9022 | 0-80 | 1/4" | 0.116" | 0.044" | 100 | $37.51 | Add to Order |
| MSS-9023 | 2-56 | 3/32" | 0.167" | 0.053" | 100 | $25.37 | Add to Order |
| MSS-9024 | 2-56 | 1/8" | 0.167" | 0.053" | 100 | $23.58 | Add to Order |
| MSS-9025 | 2-56 | 3/16" | 0.167" | 0.053" | 100 | $23.73 | Add to Order |
| MSS-9026 | 2-56 | 1/4" | 0.167" | 0.053" | 100 | $23.86 | Add to Order |
| MSS-9027 | 2-56 | 5/16" | 0.167" | 0.053" | 100 | $24.13 | Add to Order |
| MSS-9028 | 2-56 | 3/8" | 0.167" | 0.053" | 100 | $24.28 | Add to Order |
| MSS-9029 | 2-56 | 7/16" | 0.167" | 0.053" | 100 | $24.40 | Add to Order |
| MSS-9030 | 2-56 | 1/2" | 0.167" | 0.053" | 100 | $24.40 | Add to Order |
| MSS-9031 | 2-56 | 3/4" | 0.167" | 0.053" | 100 | $24.82 | Add to Order |
| MSS-9032 | 2-56 | 1" | 0.167" | 0.053" | 100 | $24.95 | Add to Order |
| MSS-9033 | 4-40 | 3/16" | 0.219" | 0.068" | 100 | $23.73 | Add to Order |
| MSS-9034 | 4-40 | 1/4" | 0.219" | 0.068" | 100 | $23.86 | Add to Order |
| MSS-9035 | 4-40 | 9/32" | 0.219" | 0.068" | 100 | $24.00 | Add to Order |
| MSS-9036 | 4-40 | 5/16" | 0.219" | 0.068" | 100 | $24.13 | Add to Order |
| MSS-9037 | 4-40 | 3/8" | 0.219" | 0.068" | 100 | $24.28 | Add to Order |
| MSS-9038 | 4-40 | 1/2" | 0.219" | 0.068" | 100 | $24.40 | Add to Order |
| MSS-9039 | 4-40 | 5/8" | 0.219" | 0.068" | 100 | $24.55 | Add to Order |
| MSS-9040 | 4-40 | 3/4" | 0.219" | 0.068" | 100 | $24.82 | Add to Order |
| MSS-9041 | 4-40 | 1" | 0.219" | 0.068" | 100 | $24.95 | Add to Order |
| MSS-9042 | 6-32 | 3/16" | 0.270" | 0.082" | 100 | $24.55 | Add to Order |
| MSS-9043 | 6-32 | 1/4" | 0.270" | 0.082" | 100 | $24.82 | Add to Order |
| MSS-9044 | 6-32 | 5/16" | 0.270" | 0.082" | 100 | $24.95 | Add to Order |
| MSS-9045 | 6-32 | 3/8" | 0.270" | 0.082" | 100 | $25.10 | Add to Order |
| MSS-9046 | 6-32 | 1/2" | 0.270" | 0.082" | 100 | $25.22 | Add to Order |
| MSS-9047 | 6-32 | 5/8" | 0.270" | 0.082" | 100 | $25.37 | Add to Order |
| MSS-9048 | 6-32 | 3/4" | 0.270" | 0.082" | 100 | $14.03 | Add to Order |
| MSS-9049 | 6-32 | 1" | 0.270" | 0.082" | 100 | $25.77 | Add to Order |
| MSS-9050 | 8-32 | 1/4" | 0.322" | 0.096" | 100 | $25.77 | Add to Order |
| MSS-9051 | 8-32 | 3/8" | 0.322" | 0.096" | 100 | $25.91 | Add to Order |
| MSS-9052 | 8-32 | 1/2" | 0.322" | 0.096" | 100 | $26.04 | Add to Order |
| MSS-9053 | 8-32 | 5/8" | 0.322" | 0.096" | 100 | $26.04 | Add to Order |
| MSS-9054 | 8-32 | 3/4" | 0.322" | 0.096" | 100 | $26.19 | Add to Order |
| MSS-9055 | 8-32 | 1" | 0.322" | 0.096" | 100 | $26.31 | Add to Order |
| MSS-9056 | 8-32 | 1 1/4" | 0.322" | 0.096" | 100 | $26.86 | Add to Order |
| MSS-9057 | 8-32 | 1 1/2" | 0.322" | 0.096" | 100 | $27.28 | Add to Order |
| MSS-9058 | 10-24 | 1/4" | 0.373" | 0.110" | 100 | $27.41 | Add to Order |
| MSS-9059 | 10-24 | 1/2" | 0.373" | 0.110" | 100 | $27.95 | Add to Order |
| MSS-9060 | 10-24 | 3/4" | 0.373" | 0.110" | 100 | $28.37 | Add to Order |
| MSS-9061 | 10-24 | 1" | 0.373" | 0.110" | 100 | $28.50 | Add to Order |
| MSS-9062 | 10-24 | 1 1/2" | 0.373" | 0.110" | 100 | $29.04 | Add to Order |
| MSS-9063 | 10-32 | 1/8" | 0.373" | 0.110" | 100 | $27.28 | Add to Order |
| MSS-9064 | 10-32 | 1/4" | 0.373" | 0.110" | 100 | $27.41 | Add to Order |
| MSS-9065 | 10-32 | 3/8" | 0.373" | 0.110" | 100 | $27.83 | Add to Order |
| MSS-9066 | 10-32 | 1/2" | 0.373" | 0.110" | 100 | $27.95 | Add to Order |
| MSS-9067 | 10-32 | 5/8" | 0.373" | 0.110" | 100 | $28.10 | Add to Order |
| MSS-9068 | 10-32 | 3/4" | 0.373" | 0.110" | 100 | $28.37 | Add to Order |
| MSS-9069 | 10-32 | 1" | 0.373" | 0.110" | 100 | $28.50 | Add to Order |
| MSS-9070 | 10-32 | 1 1/2" | 0.373" | 0.110" | 100 | $29.04 | Add to Order |
| MSS-9071 | 10-32 | 2" | 0.373" | 0.110" | 100 | $32.17 | Add to Order |
| MSS-9072 | 1/4"-20 | 1/4" | 0.492" | 0.144" | 100 | $31.23 | Add to Order |
| MSS-9073 | 1/4"-20 | 3/8" | 0.492" | 0.144" | 100 | $25.20 | Add to Order |
| MSS-9074 | 1/4"-20 | 1/2" | 0.492" | 0.144" | 100 | $31.63 | Add to Order |
| MSS-9075 | 1/4"-20 | 5/8" | 0.492" | 0.144" | 100 | $31.77 | Add to Order |
| MSS-9076 | 1/4"-20 | 3/4" | 0.492" | 0.144" | 100 | $31.90 | Add to Order |
| MSS-9077 | 1/4"-20 | 1" | 0.492" | 0.144" | 100 | $32.17 | Add to Order |
| MSS-9078 | 1/4"-20 | 1 1/2" | 0.492" | 0.144" | 100 | $32.99 | Add to Order |
| MSS-9079 | 1/4"-20 | 2" | 0.492" | 0.144" | 100 | $36.12 | Add to Order |
| Rev. 03-25, 08-23, 11-22, 03-22 | |||||||
