PEEK Pan Head Phillips Metric Machine Screws
Machine Screws - Pan Head Phillips Drive, fully threaded.
PEEK - water and steam resistant. Maximum temperature is 500°F. Tan.
| Metric PEEK Pan Head Phillips Machine Screws, Full Thread, Beige, -60° to 500° |
|||||||||
| Part # | Thread Size (mm) | Pitch (mm) | Length (mm) | Head Dia. (mm) | Head Height. (mm) | Drive Size | Pkg Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| MSS-7396 | M3 | 0.5 mm | 5 | 5.4 | 1.5 | No. 1 | 10 | $13.57 | Add to Order |
| MSS-7397 | M3 | 0.5 mm | 6 | 5.4 | 1.5 | No. 1 | 10 | $14.07 | Add to Order |
| MSS-7398 | M3 | 0.5 mm | 8 | 5.4 | 1.5 | No. 1 | 10 | $17.49 | Add to Order |
| MSS-7399 | M3 | 0.5 mm | 10 | 5.4 | 1.5 | No. 1 | 5 | $13.29 | Add to Order |
| MSS-7400 | M3 | 0.5 mm | 12 | 5.4 | 1.5 | No. 1 | 5 | $13.73 | Add to Order |
| MSS-7401 | M4 | 0.7 mm | 6 | 8 | 2.5 | No. 2 | 5 | $16.34 | Add to Order |
| MSS-7402 | M4 | 0.7 mm | 8 | 8 | 2.5 | No. 2 | 5 | $16.72 | Add to Order |
| MSS-7403 | M4 | 0.7 mm | 10 | 8 | 2.5 | No. 2 | 5 | $16.97 | Add to Order |
| MSS-7404 | M4 | 0.7 mm | 12 | 8 | 2.5 | No. 2 | 5 | $20.33 | Add to Order |
| MSS-7405 | M4 | 0.7 mm | 16 | 8 | 2.5 | No. 2 | 5 | $22.22 | Add to Order |
| MSS-7406 | M5 | 0.8 mm | 8 | 9.4 | 2.7 | No. 2 | 1 | $6.26 | Add to Order |
| MSS-7407 | M5 | 0.8 mm | 10 | 9.4 | 2.7 | No. 2 | 1 | $6.59 | Add to Order |
| MSS-7408 | M5 | 0.8 mm | 12 | 9.4 | 2.7 | No. 2 | 1 | $6.74 | Add to Order |
| MSS-7409 | M5 | 0.8 mm | 16 | 9.4 | 2.7 | No. 2 | 1 | $6.83 | Add to Order |
| MSS-7410 | M5 | 0.8 mm | 20 | 9.4 | 2.7 | No. 2 | 1 | $8.13 | Add to Order |
| MSS-7411 | M6 | 1 mm | 10 | 12 | 3.3 | No. 3 | 1 | $10.79 | Add to Order |
| MSS-7412 | M6 | 1 mm | 12 | 12 | 3.3 | No. 3 | 1 | $11.05 | Add to Order |
| MSS-7413 | M6 | 1 mm | 16 | 12 | 3.3 | No. 3 | 1 | $12.71 | Add to Order |
| MSS-7414 | M6 | 1 mm | 20 | 12 | 3.3 | No. 3 | 1 | $12.94 | Add to Order |
| MSS-7415 | M6 | 1 mm | 25 | 12 | 3.3 | No. 3 | 1 | $13.38 | Add to Order |
| Rev. 10-23, 02-23, 11-22 | |||||||||
