316 Stainless Steel Pan Head Phillips Metric Machine Screws
Machine Screws - Metric Pan Head Phillips Drive, Class 6g, DIN 7985, fully threaded, round top and flat bearing surface.
316 Stainless Steel - Excellent corrosion resistance, withstands chemicals, solvents and chlorides, mildly magnetic. Rockwell Hardness B80, tensile strength 70,000 psi.
| Metric 316 Stainless Steel Pan Head Phillips Screws, Full Threads, Passivated, DIN 7985 |
|||||||||
| Part # | Thread Size (mm) | Pitch (mm) | Length (mm) | Head Dia. (mm) | Head Height. (mm) | Drive Size | Pkg Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| MSS-7141 | M1.6 | 0.35 mm | 3 | 3.2 | 1.42 | No. 0 | 100 | $35.30 | Add to Order |
| MSS-7142 | M1.6 | 0.35 mm | 4 | 3.2 | 1.42 | No. 0 | 100 | $36.27 | Add to Order |
| MSS-7143 | M1.6 | 0.35 mm | 5 | 3.2 | 1.42 | No. 0 | 50 | $20.98 | Add to Order |
| MSS-6261 | M2 | 0.4 mm | 3 | 4 | 1.7 | No. 1 | 100 | $27.68 | Add to Order |
| MSS-6262 | M2 | 0.4 mm | 4 | 4 | 1.7 | No. 1 | 100 | $21.95 | Add to Order |
| MSS-6275 | M2 | 0.4 mm | 5 | 4 | 1.7 | No. 1 | 100 | $21.95 | Add to Order |
| MSS-961 | M2 | 0.4 mm | 6 | 4 | 1.7 | No. 1 | 100 | $24.80 | Add to Order |
| MSS-998 | M2 | 0.4 mm | 8 | 4 | 1.7 | No. 1 | 100 | $27.68 | Add to Order |
| MSS-951 | M2 | 0.4 mm | 10 | 4 | 1.7 | No. 1 | 100 | $28.56 | Add to Order |
| MSS-6264 | M2 | 0.4 mm | 12 | 4 | 1.7 | No. 1 | 100 | $30.01 | Add to Order |
| MSS-6253 | M2 | 0.4 mm | 16 | 4 | 1.7 | No. 1 | 100 | $31.33 | Add to Order |
| MSS-6266 | M2 | 0.4 mm | 20 | 4 | 1.7 | No. 1 | 100 | $34.36 | Add to Order |
| MSS-7144 | M2.5 | 0.45 mm | 3 | 5 | 2.1 | No. 1 | 100 | $16.23 | Add to Order |
| MSS-6267 | M2.5 | 0.45 mm | 4 | 5 | 2.1 | No. 1 | 100 | $21.00 | Add to Order |
| MSS-986 | M2.5 | 0.45 mm | 5 | 5 | 2.1 | No. 1 | 100 | $18.73 | Add to Order |
| MSS-1012 | M2.5 | 0.45 mm | 6 | 5 | 2.1 | No. 1 | 100 | $17.03 | Add to Order |
| MSS-1013 | M2.5 | 0.45 mm | 8 | 5 | 2.1 | No. 1 | 100 | $16.63 | Add to Order |
| MSS-1014 | M2.5 | 0.45 mm | 10 | 5 | 2.1 | No. 1 | 100 | $23.77 | Add to Order |
| MSS-1015 | M2.5 | 0.45 mm | 12 | 5 | 2.1 | No. 1 | 100 | $25.37 | Add to Order |
| MSS-1016 | M2.5 | 0.45 mm | 16 | 5 | 2.1 | No. 1 | 100 | $25.62 | Add to Order |
| MSS-1017 | M2.5 | 0.45 mm | 20 | 5 | 2.1 | No. 1 | 100 | $30.41 | Add to Order |
| MSS-6268 | M2.5 | 0.45 mm | 25 | 5 | 2.1 | No. 1 | 50 | $25.20 | Add to Order |
| MSS-7145 | M3 | 0.5 mm | 3 | 6 | 2.5 | No. 1 | 100 | $29.57 | Add to Order |
| MSS-1018 | M3 | 0.5 mm | 4 | 6 | 2.5 | No. 1 | 100 | $17.62 | Add to Order |
| MSS-1019 | M3 | 0.5 mm | 5 | 6 | 2.5 | No. 1 | 100 | $18.40 | Add to Order |
| MSS-1020 | M3 | 0.5 mm | 6 | 6 | 2.5 | No. 1 | 100 | $19.36 | Add to Order |
| MSS-1034 | M3 | 0.5 mm | 8 | 6 | 2.5 | No. 1 | 100 | $19.70 | Add to Order |
| MSS-1022 | M3 | 0.5 mm | 10 | 6 | 2.5 | No. 1 | 100 | $20.58 | Add to Order |
| MSS-1011 | M3 | 0.5 mm | 12 | 6 | 2.5 | No. 1 | 100 | $24.19 | Add to Order |
| MSS-6269 | M3 | 0.5 mm | 14 | 6 | 2.5 | No. 1 | 100 | $27.83 | Add to Order |
| MSS-1024 | M3 | 0.5 mm | 16 | 6 | 2.5 | No. 1 | 100 | $29.48 | Add to Order |
| MSS-6270 | M3 | 0.5 mm | 18 | 6 | 2.5 | No. 1 | 100 | $27.91 | Add to Order |
| MSS-1025 | M3 | 0.5 mm | 20 | 6 | 2.5 | No. 1 | 100 | $24.95 | Add to Order |
| MSS-1026 | M3 | 0.5 mm | 25 | 6 | 2.5 | No. 1 | 100 | $29.95 | Add to Order |
| MSS-1027 | M3 | 0.5 mm | 30 | 6 | 2.5 | No. 1 | 100 | $38.14 | Add to Order |
| MSS-1028 | M3 | 0.5 mm | 35 | 6 | 2.5 | No. 1 | 100 | $38.20 | Add to Order |
| MSS-1029 | M3 | 0.5 mm | 40 | 6 | 2.5 | No. 1 | 100 | $26.61 | Add to Order |
| MSS-6271 | M3 | 0.5 mm | 45 | 6 | 2.5 | No. 1 | 50 | $36.54 | Add to Order |
| MSS-6272 | M3 | 0.5 mm | 50 | 6 | 2.5 | No. 1 | 25 | $21.71 | Add to Order |
| MSS-7146 | M3 | 0.5 mm | 60 | 6 | 2.4 | No. 1 | 25 | $27.99 | Add to Order |
| MSS-7147 | M4 | 0.7 mm | 4 | 8 | 3.2 | No. 2 | 100 | $35.30 | Add to Order |
| MSS-1030 | M4 | 0.7 mm | 5 | 8 | 3.2 | No. 2 | 100 | $32.68 | Add to Order |
| MSS-1031 | M4 | 0.7 mm | 6 | 8 | 3.2 | No. 2 | 100 | $32.93 | Add to Order |
| MSS-1032 | M4 | 0.7 mm | 8 | 8 | 3.2 | No. 2 | 100 | $33.75 | Add to Order |
| MSS-1000M | M4 | 0.7 mm | 10 | 8 | 3.2 | No. 2 | 100 | $20.98 | Add to Order |
| MSS-1023 | M4 | 0.7 mm | 12 | 8 | 3.2 | No. 2 | 50 | $20.50 | Add to Order |
| MSS-6273 | M4 | 0.7 mm | 14 | 8 | 3.2 | No. 2 | 50 | $30.53 | Add to Order |
| MSS-1021 | M4 | 0.7 mm | 16 | 8 | 3.2 | No. 2 | 50 | $22.05 | Add to Order |
| MSS-6300 | M4 | 0.7 mm | 18 | 8 | 3.2 | No. 2 | 50 | $33.87 | Add to Order |
| MSS-989 | M4 | 0.7 mm | 20 | 8 | 3.2 | No. 2 | 50 | $26.50 | Add to Order |
| MSS-990 | M4 | 0.7 mm | 25 | 8 | 3.2 | No. 2 | 50 | $33.18 | Add to Order |
| MSS-991 | M4 | 0.7 mm | 30 | 8 | 3.2 | No. 2 | 50 | $34.10 | Add to Order |
| MSS-6254 | M4 | 0.7 mm | 35 | 8 | 3.2 | No. 2 | 50 | $50.57 | Add to Order |
| MSS-992 | M4 | 0.7 mm | 40 | 8 | 3.2 | No. 2 | 50 | $31.71 | Add to Order |
| MSS-6288 | M4 | 0.7 mm | 45 | 8 | 3.2 | No. 2 | 25 | $31.82 | Add to Order |
| MSS-6323 | M4 | 0.7 mm | 50 | 8 | 3.2 | No. 2 | 25 | $34.06 | Add to Order |
| MSS-6324 | M4 | 0.7 mm | 60 | 8 | 3.2 | No. 2 | 10 | $17.77 | Add to Order |
| MSS-6325 | M5 | 0.8 mm | 6 | 10 | 3.9 | No. 2 | 25 | $24.04 | Add to Order |
| MSS-6326 | M5 | 0.8 mm | 8 | 10 | 3.9 | No. 2 | 25 | $26.04 | Add to Order |
| MSS-993 | M5 | 0.8 mm | 10 | 10 | 3.9 | No. 2 | 50 | $25.12 | Add to Order |
| MSS-994 | M5 | 0.8 mm | 12 | 10 | 3.9 | No. 2 | 50 | $31.06 | Add to Order |
| MSS-6327 | M5 | 0.8 mm | 14 | 10 | 3.9 | No. 2 | 25 | $26.25 | Add to Order |
| MSS-995 | M5 | 0.8 mm | 16 | 10 | 3.9 | No. 2 | 50 | $31.25 | Add to Order |
| MSS-6328 | M5 | 0.8 mm | 18 | 10 | 3.9 | No. 2 | 25 | $28.14 | Add to Order |
| MSS-996 | M5 | 0.8 mm | 20 | 10 | 3.9 | No. 2 | 25 | $15.71 | Add to Order |
| MSS-6329 | M5 | 0.8 mm | 25 | 10 | 3.9 | No. 2 | 10 | $18.21 | Add to Order |
| MSS-6330 | M5 | 0.8 mm | 30 | 10 | 3.9 | No. 2 | 10 | $20.03 | Add to Order |
| MSS-6331 | M5 | 0.8 mm | 35 | 10 | 3.9 | No. 2 | 10 | $21.76 | Add to Order |
| MSS-6344 | M5 | 0.8 mm | 40 | 10 | 3.9 | No. 2 | 10 | $23.35 | Add to Order |
| MSS-6333 | M5 | 0.8 mm | 45 | 10 | 3.9 | No. 2 | 10 | $24.97 | Add to Order |
| MSS-6322 | M5 | 0.8 mm | 50 | 10 | 3.9 | No. 2 | 10 | $26.67 | Add to Order |
| MSS-6335 | M5 | 0.8 mm | 60 | 10 | 3.9 | No. 2 | 10 | $30.22 | Add to Order |
| MSS-6336 | M5 | 0.8 mm | 70 | 10 | 3.9 | No. 2 | 10 | $34.00 | Add to Order |
| MSS-6337 | M5 | 0.8 mm | 80 | 10 | 3.9 | No. 2 | 5 | $26.00 | Add to Order |
| MSS-6338 | M6 | 1 mm | 8 | 12 | 4.7 | No. 3 | 10 | $21.53 | Add to Order |
| MSS-997 | M6 | 1 mm | 10 | 12 | 4.7 | No. 3 | 25 | $15.94 | Add to Order |
| MSS-1010 | M6 | 1 mm | 12 | 12 | 4.7 | No. 3 | 25 | $22.41 | Add to Order |
| MSS-999 | M6 | 1 mm | 16 | 12 | 4.7 | No. 3 | 25 | $24.34 | Add to Order |
| MSS-988 | M6 | 1 mm | 20 | 12 | 4.7 | No. 3 | 25 | $26.84 | Add to Order |
| MSS-6339 | M6 | 1 mm | 25 | 12 | 4.7 | No. 3 | 10 | $27.72 | Add to Order |
| MSS-6340 | M6 | 1 mm | 30 | 12 | 4.7 | No. 3 | 10 | $30.11 | Add to Order |
| MSS-6341 | M6 | 1 mm | 35 | 12 | 4.7 | No. 3 | 10 | $32.17 | Add to Order |
| MSS-6342 | M6 | 1 mm | 40 | 12 | 4.7 | No. 3 | 5 | $19.30 | Add to Order |
| MSS-6343 | M6 | 1 mm | 45 | 12 | 4.7 | No. 3 | 5 | $20.43 | Add to Order |
| MSS-6311 | M6 | 1 mm | 50 | 12 | 4.7 | No. 3 | 5 | $21.63 | Add to Order |
| MSS-6309 | M6 | 1 mm | 60 | 12 | 4.7 | No. 3 | 5 | $24.11 | Add to Order |
| MSS-6332 | M6 | 1 mm | 70 | 12 | 4.7 | No. 3 | 5 | $26.63 | Add to Order |
| MSS-6301 | M6 | 1 mm | 80 | 12 | 4.7 | No. 3 | 5 | $29.09 | Add to Order |
| MSS-6302 | M8 | 1.25 mm | 12 | 16 | 6.1 | No. 4 | 5 | $24.11 | Add to Order |
| MSS-6303 | M8 | 1.25 mm | 16 | 16 | 6.1 | No. 4 | 5 | $24.38 | Add to Order |
| MSS-6304 | M8 | 1.25 mm | 20 | 16 | 6.1 | No. 4 | 5 | $26.00 | Add to Order |
| MSS-6305 | M8 | 1.25 mm | 25 | 16 | 6.1 | No. 4 | 5 | $28.39 | Add to Order |
| MSS-6306 | M8 | 1.25 mm | 30 | 16 | 6.1 | No. 4 | 5 | $30.64 | Add to Order |
| MSS-6307 | M8 | 1.25 mm | 35 | 16 | 6.1 | No. 4 | 5 | $34.17 | Add to Order |
| MSS-6308 | M8 | 1.25 mm | 40 | 16 | 6.1 | No. 4 | 1 | $6.32 | Add to Order |
| MSS-6369 | M8 | 1.25 mm | 45 | 16 | 6.1 | No. 4 | 1 | $7.04 | Add to Order |
| MSS-6321 | M8 | 1.25 mm | 50 | 16 | 6.1 | No. 4 | 1 | $7.25 | Add to Order |
| MSS-6310 | M8 | 1.25 mm | 60 | 16 | 6.1 | No. 4 | 1 | $8.19 | Add to Order |
| Rev. 10-23, 08-23, 02-23, 11-22 | |||||||||
