18-8 Stainless Black Oxide Pan Head Phillips Machine Screws
Machine Screws - Pan Head Phillips Drive, Black Oxide Finish, Class 2A, Fully Threaded.
18-8 Stainless Steel - Excellent corrosion resistance, mildly magnetic.
| Black Oxide 18-8 Stainless Steel Pan Head Phillips Machine Screws | ||||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Drive Size | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| MSS-6247 | 0-80 | 1/8" | 0.116" | 0.044" | No. 0 | 50 | $24.00 | Add to Order |
| MSS-6248 | 0-80 | 3/16" | 0.116" | 0.044" | No. 0 | 50 | $13.13 | Add to Order |
| MSS-6249 | 0-80 | 1/4" | 0.116" | 0.044" | No. 0 | 50 | $19.49 | Add to Order |
| MSS-6250 | 0-80 | 5/16" | 0.116" | 0.044" | No. 0 | 50 | $20.64 | Add to Order |
| MSS-6251 | 0-80 | 3/8" | 0.116" | 0.044" | No. 0 | 50 | $23.37 | Add to Order |
| MSS-6219 | 0-80 | 1/2" | 0.116" | 0.044" | No. 0 | 50 | $23.67 | Add to Order |
| MSS-1415 | 2-56 | 1/8" | 0.167" | 0.063" | No. 1 | 100 | $17.89 | Add to Order |
| MSS-1416 | 2-56 | 3/16" | 0.167" | 0.063" | No. 1 | 100 | $5.42 | Add to Order |
| MSS-1417 | 2-56 | 1/4" | 0.167" | 0.063" | No. 1 | 100 | $12.20 | Add to Order |
| MSS-1418 | 2-56 | 5/16" | 0.167" | 0.063" | No. 1 | 100 | $9.26 | Add to Order |
| MSS-1419 | 2-56 | 3/8" | 0.167" | 0.063" | No. 1 | 100 | $13.19 | Add to Order |
| MSS-6217 | 2-56 | 7/16" | 0.167" | 0.063" | No. 1 | 100 | $14.20 | Add to Order |
| MSS-1420 | 2-56 | 1/2" | 0.167" | 0.063" | No. 1 | 100 | $14.66 | Add to Order |
| MSS-6240 | 2-56 | 5/8" | 0.167" | 0.063" | No. 1 | 100 | $17.49 | Add to Order |
| MSS-6209 | 2-56 | 3/4" | 0.167" | 0.063" | No. 1 | 100 | $16.55 | Add to Order |
| MSS-6210 | 2-56 | 1" | 0.167" | 0.063" | No. 1 | 100 | $18.54 | Add to Order |
| MSS-1433 | 4-40 | 1/8" | 0.219" | 0.080" | No. 1 | 100 | $13.99 | Add to Order |
| MSS-1422 | 4-40 | 3/16" | 0.219" | 0.080" | No. 1 | 100 | $16.23 | Add to Order |
| MSS-1411 | 4-40 | 1/4" | 0.219" | 0.080" | No. 1 | 100 | $14.76 | Add to Order |
| MSS-1424 | 4-40 | 5/16" | 0.219" | 0.080" | No. 1 | 100 | $17.01 | Add to Order |
| MSS-1425 | 4-40 | 3/8" | 0.219" | 0.080" | No. 1 | 100 | $17.22 | Add to Order |
| MSS-6211 | 4-40 | 7/16" | 0.219" | 0.080" | No. 1 | 100 | $16.70 | Add to Order |
| MSS-1426 | 4-40 | 1/2" | 0.219" | 0.080" | No. 1 | 100 | $18.14 | Add to Order |
| MSS-6212 | 4-40 | 9/16" | 0.219" | 0.080" | No. 1 | 100 | $18.40 | Add to Order |
| MSS-1427 | 4-40 | 5/8" | 0.219" | 0.080" | No. 1 | 100 | $21.65 | Add to Order |
| MSS-1428 | 4-40 | 3/4" | 0.219" | 0.080" | No. 1 | 100 | $22.30 | Add to Order |
| MSS-6213 | 4-40 | 7/8" | 0.219" | 0.080" | No. 1 | 100 | $28.04 | Add to Order |
| MSS-1429 | 4-40 | 1" | 0.219" | 0.080" | No. 1 | 100 | $27.85 | Add to Order |
| MSS-7031 | 4-40 | 1 1/4" | 0.219" | 0.080" | No. 1 | 50 | $22.64 | Add to Order |
| MSS-6214 | 4-40 | 1 1/2" | 0.219" | 0.080" | No. 1 | 50 | $19.07 | Add to Order |
| MSS-6215 | 4-40 | 2" | 0.219" | 0.080" | No. 1 | 50 | $28.85 | Add to Order |
| MSS-6216 | 6-32 | 1/8" | 0.270" | 0.097" | No. 2 | 100 | $31.25 | Add to Order |
| MSS-1430 | 6-32 | 3/16" | 0.270" | 0.097" | No. 2 | 100 | $19.66 | Add to Order |
| MSS-1431 | 6-32 | 1/4" | 0.270" | 0.097" | No. 2 | 100 | $16.30 | Add to Order |
| MSS-1468 | 6-32 | 5/16" | 0.270" | 0.097" | No. 2 | 100 | $20.14 | Add to Order |
| MSS-1421 | 6-32 | 3/8" | 0.270" | 0.097" | No. 2 | 100 | $19.28 | Add to Order |
| MSS-6229 | 6-32 | 7/16" | 0.270" | 0.097" | No. 2 | 100 | $22.53 | Add to Order |
| MSS-1456 | 6-32 | 1/2" | 0.270" | 0.097" | No. 2 | 100 | $21.84 | Add to Order |
| MSS-1482 | 6-32 | 5/8" | 0.270" | 0.097" | No. 2 | 50 | $25.75 | Add to Order |
| MSS-1483 | 6-32 | 3/4" | 0.270" | 0.097" | No. 2 | 50 | $14.24 | Add to Order |
| MSS-6218 | 6-32 | 7/8" | 0.270" | 0.097" | No. 2 | 50 | $17.47 | Add to Order |
| MSS-1484 | 6-32 | 1" | 0.270" | 0.097" | No. 2 | 50 | $22.68 | Add to Order |
| MSS-6207 | 6-32 | 1 1/4" | 0.270" | 0.097" | No. 2 | 50 | $24.13 | Add to Order |
| MSS-1485 | 6-32 | 1 1/2" | 0.270" | 0.097" | No. 2 | 50 | $25.35 | Add to Order |
| MSS-7032 | 6-32 | 2" | 0.270" | 0.097" | No. 2 | 25 | $13.33 | Add to Order |
| MSS-7033 | 8-32 | 3/16" | 0.322" | 0.115" | No. 2 | 100 | $20.41 | Add to Order |
| MSS-1486 | 8-32 | 1/4" | 0.322" | 0.115" | No. 2 | 100 | $27.34 | Add to Order |
| MSS-1487 | 8-32 | 5/16" | 0.322" | 0.115" | No. 2 | 100 | $28.16 | Add to Order |
| MSS-1488 | 8-32 | 3/8" | 0.322" | 0.115" | No. 2 | 100 | $24.26 | Add to Order |
| MSS-1489 | 8-32 | 1/2" | 0.322" | 0.115" | No. 2 | 100 | $28.77 | Add to Order |
| MSS-1490 | 8-32 | 5/8" | 0.322" | 0.115" | No. 2 | 100 | $27.15 | Add to Order |
| MSS-1504 | 8-32 | 3/4" | 0.322" | 0.115" | No. 2 | 100 | $32.38 | Add to Order |
| MSS-1492 | 8-32 | 1" | 0.322" | 0.115" | No. 2 | 50 | $28.22 | Add to Order |
| MSS-6220 | 8-32 | 1 1/4" | 0.322" | 0.115" | No. 2 | 25 | $21.02 | Add to Order |
| MSS-6221 | 8-32 | 1 1/2" | 0.322" | 0.115" | No. 2 | 25 | $23.90 | Add to Order |
| MSS-7034 | 8-32 | 2" | 0.322" | 0.115" | No. 2 | 25 | $25.62 | Add to Order |
| MSS-7035 | 10-24 | 1/4" | 0.373" | 0.133" | No. 2 | 100 | $27.05 | Add to Order |
| MSS-1481 | 10-24 | 3/8" | 0.373" | 0.133" | No. 2 | 100 | $31.02 | Add to Order |
| MSS-1494 | 10-24 | 1/2" | 0.373" | 0.133" | No. 2 | 100 | $38.72 | Add to Order |
| MSS-1495 | 10-24 | 5/8" | 0.373" | 0.133" | No. 2 | 100 | $41.29 | Add to Order |
| MSS-1496 | 10-24 | 3/4" | 0.373" | 0.133" | No. 2 | 50 | $25.79 | Add to Order |
| MSS-6222 | 10-24 | 1" | 0.373" | 0.133" | No. 2 | 25 | $25.73 | Add to Order |
| MSS-6223 | 10-24 | 1 1/2" | 0.373" | 0.133" | No. 2 | 10 | $13.92 | Add to Order |
| MSS-1497 | 10-32 | 1/4" | 0.373" | 0.133" | No. 2 | 100 | $36.46 | Add to Order |
| MSS-6224 | 10-32 | 5/16" | 0.373" | 0.133" | No. 2 | 50 | $30.77 | Add to Order |
| MSS-1498 | 10-32 | 3/8" | 0.373" | 0.133" | No. 2 | 100 | $31.02 | Add to Order |
| MSS-1499 | 10-32 | 1/2" | 0.373" | 0.133" | No. 2 | 100 | $38.72 | Add to Order |
| MSS-1500 | 10-32 | 5/8" | 0.373" | 0.133" | No. 2 | 100 | $41.29 | Add to Order |
| MSS-1501 | 10-32 | 3/4" | 0.373" | 0.133" | No. 2 | 50 | $25.79 | Add to Order |
| MSS-6225 | 10-32 | 7/8" | 0.373" | 0.133" | No. 2 | 25 | $29.82 | Add to Order |
| MSS-1502 | 10-32 | 1" | 0.373" | 0.133" | No. 2 | 50 | $36.31 | Add to Order |
| MSS-6226 | 10-32 | 1 1/4" | 0.373" | 0.133" | No. 2 | 10 | $12.87 | Add to Order |
| MSS-6227 | 10-32 | 1 1/2" | 0.373" | 0.133" | No. 2 | 10 | $14.57 | Add to Order |
| MSS-7036 | 10-32 | 2" | 0.373" | 0.133" | No. 2 | 25 | $17.89 | Add to Order |
| MSS-6139 | 1/4"-20 | 1/4" | 0.492" | 0.175" | No. 3 | 25 | $34.40 | Add to Order |
| MSS-6242 | 1/4"-20 | 3/8" | 0.492" | 0.175" | No. 3 | 10 | $12.92 | Add to Order |
| MSS-1470 | 1/4"-20 | 1/2" | 0.492" | 0.175" | No. 3 | 50 | $32.70 | Add to Order |
| MSS-1493 | 1/4"-20 | 5/8" | 0.492" | 0.175" | No. 3 | 25 | $22.95 | Add to Order |
| MSS-1491 | 1/4"-20 | 3/4" | 0.492" | 0.175" | No. 3 | 25 | $22.74 | Add to Order |
| MSS-1459 | 1/4"-20 | 1" | 0.492" | 0.175" | No. 3 | 25 | $34.27 | Add to Order |
| MSS-7037 | 1/4"-20 | 1 1/4" | 0.492" | 0.175" | No. 3 | 10 | $11.36 | Add to Order |
| MSS-6182 | 1/4"-20 | 1 1/2" | 0.492" | 0.175" | No. 3 | 10 | $29.25 | Add to Order |
| MSS-7038 | 1/4"-20 | 1 3/4" | 0.492" | 0.175" | No. 3 | 10 | $13.44 | Add to Order |
| MSS-6093 | 1/4"-20 | 2" | 0.492" | 0.175" | No. 3 | 5 | $16.78 | Add to Order |
| MSS-7039 | 1/4"-20 | 2 1/2" | 0.492" | 0.175" | No. 3 | 10 | $16.82 | Add to Order |
| MSS-7040 | 1/4"-20 | 3" | 0.492" | 0.175" | No. 3 | 10 | $19.47 | Add to Order |
| MSS-7041 | 1/4"-28 | 1/2" | 0.492" | 0.175" | No. 3 | 25 | $19.28 | Add to Order |
| MSS-7042 | 1/4"-28 | 3/4" | 0.492" | 0.175" | No. 3 | 25 | $20.52 | Add to Order |
| MSS-7043 | 1/4"-28 | 1" | 0.492" | 0.175" | No. 3 | 25 | $21.92 | Add to Order |
| MSS-7044 | 5/16"-18 | 1/2" | 0.615" | 0.218" | No. 4 | 10 | $24.02 | Add to Order |
| MSS-7045 | 5/16"-18 | 3/4" | 0.615" | 0.218" | No. 4 | 10 | $13.13 | Add to Order |
| MSS-7046 | 5/16"-18 | 1" | 0.615" | 0.218" | No. 4 | 10 | $15.52 | Add to Order |
| MSS-7047 | 5/16"-18 | 1 1/2" | 0.615" | 0.218" | No. 4 | 10 | $17.75 | Add to Order |
| MSS-7048 | 5/16"-18 | 2" | 0.615" | 0.218" | No. 4 | 5 | $11.91 | Add to Order |
| MSS-7049 | 3/8"-16 | 3/4" | 0.740" | 0.261" | No. 4 | 10 | $21.92 | Add to Order |
| MSS-7050 | 3/8"-16 | 1" | 0.740" | 0.261" | No. 4 | 5 | $13.38 | Add to Order |
| MSS-7051B | 3/8"-16 | 1 1/2" | 0.740" | 0.261" | No. 4 | 5 | $16.28 | Add to Order |
| Rev. 10-23, 08-23, 02-23, 11-22 | ||||||||
