Nylon 6/6 Pan Head Phillips Machine Screws
Machine Screws - Pan Head Phillips, Class 2A, Fully Threaded.
| White Nylon Pan Head Phillips Machine Screws, Full Threads, Natural | ||||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Drive Size | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| MSS-7215 | 0-80 | 1/8" | 0.116" | 0.044" | No. 0 | 100 | $30.56 | Add to Order |
| MSS-7216 | 0-80 | 3/16" | 0.116" | 0.044" | No. 0 | 100 | $31.67 | Add to Order |
| MSS-7217 | 0-80 | 1/4" | 0.116" | 0.044" | No. 0 | 100 | $32.84 | Add to Order |
| MSS-7218 | 2-56 | 3/32" | 0.160" | 0.058" | No. 1 | 100 | $22.43 | Add to Order |
| MSS-7219 | 2-56 | 1/8" | 0.160" | 0.058" | No. 1 | 100 | $17.56 | Add to Order |
| MSS-7220 | 2-56 | 3/16" | 0.160" | 0.058" | No. 1 | 100 | $17.64 | Add to Order |
| MSS-7221 | 2-56 | 1/4" | 0.160" | 0.058" | No. 1 | 100 | $17.70 | Add to Order |
| MSS-7222 | 2-56 | 5/16" | 0.160" | 0.058" | No. 1 | 100 | $17.81 | Add to Order |
| MSS-7223 | 2-56 | 3/8" | 0.160" | 0.058" | No. 1 | 100 | $17.89 | Add to Order |
| MSS-7224 | 2-56 | 7/16" | 0.160" | 0.058" | No. 1 | 100 | $18.25 | Add to Order |
| MSS-7225 | 2-56 | 1/2" | 0.160" | 0.058" | No. 1 | 100 | $18.29 | Add to Order |
| MSS-7226 | 2-56 | 3/4" | 0.160" | 0.058" | No. 1 | 100 | $18.31 | Add to Order |
| MSS-7227 | 2-56 | 1" | 0.160" | 0.058" | No. 1 | 100 | $18.73 | Add to Order |
| MSS-7228 | 4-40 | 1/8" | 0.215" | 0.075" | No. 1 | 100 | $28.35 | Add to Order |
| MSS-7229 | 4-40 | 3/16" | 0.215" | 0.075" | No. 1 | 100 | $17.64 | Add to Order |
| MSS-7230 | 4-40 | 1/4" | 0.215" | 0.075" | No. 1 | 100 | $17.98 | Add to Order |
| MSS-7231 | 4-40 | 9/32" | 0.215" | 0.075" | No. 1 | 100 | $17.75 | Add to Order |
| MSS-7232 | 4-40 | 5/16" | 0.215" | 0.075" | No. 1 | 100 | $17.81 | Add to Order |
| MSS-7233 | 4-40 | 3/8" | 0.215" | 0.075" | No. 1 | 100 | $17.89 | Add to Order |
| MSS-7234 | 4-40 | 1/2" | 0.215" | 0.075" | No. 1 | 100 | $18.29 | Add to Order |
| MSS-7235 | 4-40 | 5/8" | 0.215" | 0.075" | No. 1 | 100 | $18.25 | Add to Order |
| MSS-7236 | 4-40 | 3/4" | 0.215" | 0.075" | No. 1 | 100 | $18.31 | Add to Order |
| MSS-7237 | 4-40 | 1" | 0.215" | 0.075" | No. 1 | 100 | $18.73 | Add to Order |
| MSS-7238 | 6-32 | 3/16" | 0.263" | 0.092" | No. 2 | 100 | $18.25 | Add to Order |
| MSS-7239 | 6-32 | 1/4" | 0.263" | 0.092" | No. 2 | 100 | $18.31 | Add to Order |
| MSS-7240 | 6-32 | 5/16" | 0.263" | 0.092" | No. 2 | 100 | $18.73 | Add to Order |
| MSS-7241 | 6-32 | 3/8" | 0.263" | 0.092" | No. 2 | 100 | $18.82 | Add to Order |
| MSS-7242 | 6-32 | 1/2" | 0.263" | 0.092" | No. 2 | 100 | $18.90 | Add to Order |
| MSS-7243 | 6-32 | 5/8" | 0.263" | 0.092" | No. 2 | 100 | $19.01 | Add to Order |
| MSS-7244 | 6-32 | 3/4" | 0.263" | 0.092" | No. 2 | 100 | $19.07 | Add to Order |
| MSS-7245 | 6-32 | 1" | 0.263" | 0.092" | No. 2 | 100 | $19.49 | Add to Order |
| MSS-7246 | 8-32 | 1/4" | 0.320" | 0.110" | No. 2 | 100 | $19.45 | Add to Order |
| MSS-7247 | 8-32 | 3/8" | 0.320" | 0.110" | No. 2 | 100 | $19.51 | Add to Order |
| MSS-7248 | 8-32 | 1/2" | 0.320" | 0.110" | No. 2 | 100 | $19.59 | Add to Order |
| MSS-7249 | 8-32 | 5/8" | 0.320" | 0.110" | No. 2 | 100 | $19.66 | Add to Order |
| MSS-7250 | 8-32 | 3/4" | 0.320" | 0.110" | No. 2 | 100 | $19.72 | Add to Order |
| MSS-7251 | 8-32 | 1" | 0.320" | 0.110" | No. 2 | 100 | $19.76 | Add to Order |
| MSS-7252 | 8-32 | 1 1/4" | 0.320" | 0.110" | No. 2 | 100 | $23.56 | Add to Order |
| MSS-7253 | 8-32 | 1 1/2" | 0.320" | 0.110" | No. 2 | 100 | $23.75 | Add to Order |
| MSS-7254 | 10-24 | 1/4" | 0.365" | 0.125" | No. 2 | 100 | $20.87 | Add to Order |
| MSS-7255 | 10-24 | 3/8" | 0.373" | 0.150" | No. 2 | 100 | $13.73 | Add to Order |
| MSS-7256 | 10-24 | 1/2" | 0.365" | 0.125" | No. 2 | 100 | $21.46 | Add to Order |
| MSS-7257 | 10-24 | 3/4" | 0.365" | 0.125" | No. 2 | 100 | $21.65 | Add to Order |
| MSS-7258 | 10-24 | 1" | 0.365" | 0.125" | No. 2 | 100 | $21.74 | Add to Order |
| MSS-7259 | 10-24 | 1 1/2" | 0.365" | 0.125" | No. 2 | 100 | $22.24 | Add to Order |
| MSS-7260 | 10-32 | 1/8" | 0.365" | 0.125" | No. 2 | 100 | $20.77 | Add to Order |
| MSS-7261 | 10-32 | 1/4" | 0.365" | 0.125" | No. 2 | 100 | $20.87 | Add to Order |
| MSS-7262 | 10-32 | 3/8" | 0.365" | 0.125" | No. 2 | 100 | $21.38 | Add to Order |
| MSS-7263 | 10-32 | 1/2" | 0.365" | 0.125" | No. 2 | 100 | $21.48 | Add to Order |
| MSS-7264 | 10-32 | 5/8" | 0.365" | 0.125" | No. 2 | 100 | $21.55 | Add to Order |
| MSS-7265 | 10-32 | 3/4" | 0.365" | 0.125" | No. 2 | 100 | $21.65 | Add to Order |
| MSS-7266 | 10-32 | 1" | 0.365" | 0.125" | No. 2 | 100 | $21.74 | Add to Order |
| MSS-7267 | 10-32 | 1 1/2" | 0.365" | 0.125" | No. 2 | 100 | $22.24 | Add to Order |
| MSS-7268 | 10-32 | 2" | 0.365" | 0.125" | No. 2 | 100 | $28.16 | Add to Order |
| MSS-7269 | 1/4"-20 | 1/4" | 0.485" | 0.165" | No. 3 | 100 | $29.27 | Add to Order |
| MSS-7270 | 1/4"-20 | 3/8" | 0.492" | 0.198" | No. 2 | 100 | $29.27 | Add to Order |
| MSS-7271 | 1/4"-20 | 1/2" | 0.485" | 0.165" | No. 3 | 100 | $29.97 | Add to Order |
| MSS-7272 | 1/4"-20 | 5/8" | 0.485" | 0.165" | No. 3 | 100 | $30.09 | Add to Order |
| MSS-7273 | 1/4"-20 | 3/4" | 0.485" | 0.165" | No. 3 | 100 | $30.18 | Add to Order |
| MSS-7274 | 1/4"-20 | 1" | 0.485" | 0.165" | No. 3 | 100 | $30.41 | Add to Order |
| MSS-7275 | 1/4"-20 | 1 1/2" | 0.485" | 0.165" | No. 3 | 100 | $31.48 | Add to Order |
| MSS-7276 | 1/4"-20 | 2" | 0.485" | 0.165" | No. 3 | 100 | $31.73 | Add to Order |
| MSS-7277 | 1/4"-28 | 1/2" | 0.492" | 0.198" | No. 2 | 100 | $42.21 | Add to Order |
| MSS-7278 | 1/4"-28 | 3/4" | 0.492" | 0.198" | No. 2 | 100 | $19.61 | Add to Order |
| MSS-7279 | 1/4"-28 | 1" | 0.492" | 0.198" | No. 2 | 100 | $19.80 | Add to Order |
| MSS-7280 | 5/16"-18 | 1/2" | 0.625" | 0.218" | No. 4 | 10 | $14.01 | Add to Order |
| MSS-7281 | 5/16"-18 | 3/4" | 0.625" | 0.218" | No. 4 | 10 | $15.39 | Add to Order |
| MSS-7282 | 5/16"-18 | 1" | 0.625" | 0.218" | No. 4 | 10 | $16.80 | Add to Order |
| MSS-7283 | 5/16"-18 | 1 1/2" | 0.625" | 0.218" | No. 4 | 10 | $18.21 | Add to Order |
| MSS-7284 | 5/16"-18 | 2" | 0.625" | 0.218" | No. 4 | 10 | $19.59 | Add to Order |
| MSS-7285 | 3/8"-16 | 1/2" | 0.750" | 0.261" | No. 5 | 10 | $17.49 | Add to Order |
| MSS-7286 | 3/8"-16 | 3/4" | 0.750" | 0.261" | No. 5 | 10 | $18.90 | Add to Order |
| MSS-7287 | 3/8"-16 | 1" | 0.750" | 0.261" | No. 5 | 10 | $20.31 | Add to Order |
| MSS-7288 | 3/8"-16 | 1 1/2" | 0.750" | 0.261" | No. 5 | 10 | $21.69 | Add to Order |
| MSS-7289 | 3/8"-16 | 2" | 0.750" | 0.261" | No. 5 | 10 | $23.10 | Add to Order |
| Rev. 10-23, 08-23, 11-22, 03-22 | ||||||||
