Nylon 6/6 Pan Head Phillips Metric Machine Screws
Machine Screws - Pan Head Phillips, Fully Threaded.
| Metric White Nylon Pan Head Phillips Screws, Full Threads, Natural | |||||||||
| Part # | Thread Size | Pitch | Length (mm) | Head Dia. (mm) | Head Height (mm) | Drive Size | Pkg Qty. | Pkg Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| MSS-7290 | M2 | 0.4 mm | 4 | 4 | 1.6 | No. 0 | 100 | $18.77 | Add to Order |
| MSS-7291 | M2 | 0.4 mm | 5 | 4 | 1.6 | No. 0 | 100 | $18.84 | Add to Order |
| MSS-7292 | M2 | 0.4 mm | 6 | 4 | 1.6 | No. 0 | 100 | $18.92 | Add to Order |
| MSS-7293 | M2 | 0.4 mm | 8 | 4 | 1.6 | No. 0 | 100 | $28.92 | Add to Order |
| MSS-7294 | M2 | 0.4 mm | 10 | 4 | 1.6 | No. 0 | 100 | $29.06 | Add to Order |
| MSS-7295 | M2 | 0.4 mm | 12 | 4 | 1.6 | No. 0 | 100 | $29.40 | Add to Order |
| MSS-7296 | M2 | 0.4 mm | 16 | 4 | 1.6 | No. 0 | 100 | $29.53 | Add to Order |
| MSS-7297 | M2.5 | 0.45 mm | 4 | 5 | 2.1 | No. 0 | 100 | $18.77 | Add to Order |
| MSS-7298 | M2.5 | 0.45 mm | 5 | 5 | 2.1 | No. 0 | 100 | $18.84 | Add to Order |
| MSS-7299 | M2.5 | 0.45 mm | 6 | 5 | 2.1 | No. 0 | 100 | $18.92 | Add to Order |
| MSS-7300 | M2.5 | 0.45 mm | 8 | 5 | 2.1 | No. 0 | 100 | $19.09 | Add to Order |
| MSS-7301 | M2.5 | 0.45 mm | 10 | 5 | 2.1 | No. 0 | 100 | $19.24 | Add to Order |
| MSS-7302 | M3 | 0.5 mm | 4 | 5.6 | 2.4 | No. 1 | 100 | $18.77 | Add to Order |
| MSS-7303 | M3 | 0.5 mm | 5 | 5.6 | 2.4 | No. 1 | 100 | $28.58 | Add to Order |
| MSS-7304 | M3 | 0.5 mm | 6 | 5.6 | 2.4 | No. 1 | 100 | $28.58 | Add to Order |
| MSS-7305 | M3 | 0.5 mm | 8 | 5.6 | 2.4 | No. 1 | 100 | $28.81 | Add to Order |
| MSS-7306 | M3 | 0.5 mm | 10 | 5.6 | 2.4 | No. 1 | 100 | $29.06 | Add to Order |
| MSS-7307 | M3 | 0.5 mm | 12 | 5.6 | 2.4 | No. 1 | 100 | $29.40 | Add to Order |
| MSS-7308 | M3 | 0.5 mm | 16 | 5.6 | 2.4 | No. 1 | 100 | $29.53 | Add to Order |
| MSS-7309 | M3 | 0.5 mm | 20 | 5.6 | 2.4 | No. 1 | 100 | $29.69 | Add to Order |
| MSS-7310 | M3 | 0.5 mm | 25 | 5.6 | 2.4 | No. 1 | 100 | $29.90 | Add to Order |
| MSS-7311 | M3 | 0.5 mm | 30 | 5.6 | 2.4 | No. 1 | 100 | $30.26 | Add to Order |
| MSS-7312 | M4 | 0.7 mm | 6 | 8 | 3.1 | No. 2 | 100 | $30.98 | Add to Order |
| MSS-7313 | M4 | 0.7 mm | 8 | 8 | 3.1 | No. 2 | 100 | $30.98 | Add to Order |
| MSS-7314 | M4 | 0.7 mm | 10 | 8 | 3.1 | No. 2 | 100 | $31.10 | Add to Order |
| MSS-7315 | M4 | 0.7 mm | 12 | 8 | 3.1 | No. 2 | 100 | $31.29 | Add to Order |
| MSS-7316 | M4 | 0.7 mm | 16 | 8 | 3.1 | No. 2 | 100 | $31.44 | Add to Order |
| MSS-7317 | M4 | 0.7 mm | 20 | 8 | 3.1 | No. 2 | 100 | $31.67 | Add to Order |
| MSS-7318 | M4 | 0.7 mm | 25 | 8 | 3.1 | No. 2 | 100 | $31.71 | Add to Order |
| MSS-7319 | M4 | 0.7 mm | 30 | 8 | 3.1 | No. 2 | 100 | $32.66 | Add to Order |
| MSS-7320 | M4 | 0.7 mm | 35 | 8 | 3.1 | No. 2 | 100 | $33.01 | Add to Order |
| MSS-7321 | M5 | 0.8 mm | 8 | 9.5 | 3.7 | No. 2 | 100 | $33.47 | Add to Order |
| MSS-7322 | M5 | 0.8 mm | 10 | 9.5 | 3.7 | No. 2 | 100 | $33.73 | Add to Order |
| MSS-7323 | M5 | 0.8 mm | 12 | 9.5 | 3.7 | No. 2 | 100 | $33.96 | Add to Order |
| MSS-7324 | M5 | 0.8 mm | 16 | 9.5 | 3.7 | No. 2 | 100 | $34.08 | Add to Order |
| MSS-7325 | M5 | 0.8 mm | 20 | 9.5 | 3.7 | No. 2 | 100 | $34.31 | Add to Order |
| MSS-7326 | M5 | 0.8 mm | 25 | 9.5 | 3.7 | No. 2 | 100 | $34.57 | Add to Order |
| MSS-7327 | M5 | 0.8 mm | 30 | 9.5 | 3.7 | No. 2 | 100 | $35.03 | Add to Order |
| MSS-7328 | M6 | 1 mm | 8 | 12 | 4.6 | No. 3 | 100 | $38.51 | Add to Order |
| MSS-7329 | M6 | 1 mm | 10 | 12 | 4.6 | No. 3 | 100 | $38.62 | Add to Order |
| MSS-7330 | M6 | 1 mm | 12 | 12 | 4.6 | No. 3 | 100 | $38.75 | Add to Order |
| MSS-7331 | M6 | 1 mm | 16 | 12 | 4.6 | No. 3 | 100 | $38.87 | Add to Order |
| MSS-7332 | M6 | 1 mm | 20 | 12 | 4.6 | No. 3 | 100 | $39.23 | Add to Order |
| MSS-7333 | M6 | 1 mm | 25 | 12 | 4.6 | No. 3 | 100 | $39.46 | Add to Order |
| MSS-7334 | M6 | 1 mm | 30 | 12 | 4.6 | No. 3 | 100 | $39.94 | Add to Order |
| MSS-7335 | M6 | 1 mm | 35 | 12 | 4.6 | No. 3 | 100 | $40.43 | Add to Order |
| MSS-7336 | M6 | 1 mm | 40 | 12 | 4.6 | No. 3 | 100 | $40.78 | Add to Order |
| MSS-7337 | M6 | 1 mm | 45 | 12 | 4.6 | No. 3 | 100 | $41.01 | Add to Order |
| MSS-7338 | M6 | 1 mm | 50 | 12 | 4.6 | No. 3 | 100 | $41.14 | Add to Order |
| MSS-7339 | M8 | 1.25 mm | 16 | 16 | 6 | No. 4 | 25 | $29.86 | Add to Order |
| MSS-7340 | M8 | 1.25 mm | 20 | 16 | 6 | No. 4 | 25 | $29.93 | Add to Order |
| MSS-7341 | M8 | 1.25 mm | 25 | 16 | 6 | No. 4 | 25 | $30.07 | Add to Order |
| MSS-7342 | M8 | 1.25 mm | 30 | 16 | 6 | No. 4 | 25 | $30.11 | Add to Order |
| MSS-7343 | M8 | 1.25 mm | 50 | 16 | 6 | No. 4 | 25 | $31.67 | Add to Order |
| MSS-7344 | M10 | 1.5 mm | 20 | 20 | 7.5 | No. 4 | 50 | $39.33 | Add to Order |
| MSS-7345 | M10 | 1.5 mm | 25 | 20 | 7.5 | No. 4 | 50 | $40.82 | Add to Order |
| MSS-7346 | M10 | 1.5 mm | 30 | 20 | 7.5 | No. 4 | 50 | $42.38 | Add to Order |
| Rev. 08-23, 11-22, 09-22, 03-22 | |||||||||
