Zinc Plated Steel Flat Head Slotted Drive Machine Screws
Machine Screws - 82°Flat Head Slotted Drive, Zinc Plated, Class 2A, *fully threaded, bevel under head provides flush surface within countersunk holes.
Steel - Rockwell Hardness B60, tensile strength 60,000 psi. Zinc Plated - Good rust resistance.
| Zinc Plated Steel Slotted Flat Head Machine Screws ASME B18.6.3 - 60,000 PSI Tensile Strength |
||||||||
| Part # | Thread Size | Length | Head Profile | Head Dia. | Head Height | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| MSS-3416 | 3-48 | 3/16" | Standard | 0.187" | 0.059" | 100 | $5.40 | Add to Order |
| MSS-3417 | 3-48 | 1/4" | Standard | 0.187" | 0.059" | 100 | $11.05 | Add to Order |
| MSS-5078 | 3-48 | 5/16" | Standard | 0.187" | 0.059" | 100 | $23.02 | Add to Order |
| MSS-5079 | 3-48 | 3/8" | Standard | 0.187" | 0.059" | 100 | $14.01 | Add to Order |
| MSS-5080 | 3-48 | 1/2" | Standard | 0.187" | 0.059" | 100 | $7.62 | Add to Order |
| MSS-5081 | 3-48 | 3/4" | Standard | 0.187" | 0.059" | 100 | $20.06 | Add to Order |
| MSS-5095 | 3-48 | 1" | Standard | 0.187" | 0.059" | 100 | $17.43 | Add to Order |
| MSS-5072 | 4-40 | 3/16" | Undercut | 0.212" | 0.047" | 100 | $16.59 | Add to Order |
| MSS-5085 | 4-40 | 1/4" | Standard | 0.212" | 0.067" | 100 | $3.74 | Add to Order |
| MSS-5086 | 4-40 | 5/16" | Standard | 0.212" | 0.067" | 100 | $2.69 | Add to Order |
| MSS-5087 | 4-40 | 3/8" | Standard | 0.212" | 0.067" | 100 | $2.67 | Add to Order |
| MSS-5088 | 4-40 | 1/2" | Standard | 0.212" | 0.067" | 100 | $3.53 | Add to Order |
| MSS-5089 | 4-40 | 5/8" | Standard | 0.212" | 0.067" | 100 | $6.09 | Add to Order |
| MSS-5090 | 4-40 | 3/4" | Standard | 0.212" | 0.067" | 100 | $6.78 | Add to Order |
| MSS-5091 | 4-40 | 1" | Standard | 0.212" | 0.067" | 100 | $4.05 | Add to Order |
| MSS-5092 | 4-40 | 1 1/2" | Standard | 0.212" | 0.067" | 100 | $8.97 | Add to Order |
| MSS-5093 | 5-40 | 1/4" | Standard | 0.237" | 0.075" | 100 | $8.86 | Add to Order |
| MSS-5061 | 5-40 | 5/16" | Standard | 0.237" | 0.075" | 100 | $31.50 | Add to Order |
| MSS-10512 | 5-40 | 3/8" | Standard | 0.237" | 0.053" | 100 | $23.16 | Add to Order |
| MSS-5084 | 5-40 | 1/2" | Standard | 0.237" | 0.075" | 100 | $4.94 | Add to Order |
| MSS-5082 | 5-40 | 5/8" | Standard | 0.237" | 0.075" | 100 | $6.36 | Add to Order |
| MSS-5050 | 5-40 | 3/4" | Standard | 0.237" | 0.075" | 100 | $54.52 | Add to Order |
| MSS-5051 | 5-40 | 1" | Standard | 0.237" | 0.075" | 100 | $17.51 | Add to Order |
| MSS-5052 | 5-40 | 1 1/4" | Standard | 0.237" | 0.075" | 100 | $14.95 | Add to Order |
| MSS-5054 | 5-40 | 2" | Standard | 0.237" | 0.075" | 100 | $12.64 | Add to Order |
| MSS-5055 | 6-32 | 3/16" | Undercut | 0.262" | 0.059" | 100 | $8.46 | Add to Order |
| MSS-5056 | 6-32 | 1/4" | Standard | 0.262" | 0.083" | 100 | $3.97 | Add to Order |
| MSS-5057 | 6-32 | 5/16" | Standard | 0.262" | 0.083" | 100 | $4.62 | Add to Order |
| MSS-5058 | 6-32 | 3/8" | Standard | 0.262" | 0.083" | 100 | $2.27 | Add to Order |
| MSS-5071 | 6-32 | 7/16" | Standard | 0.262" | 0.083" | 100 | $9.03 | Add to Order |
| MSS-5060 | 6-32 | 1/2" | Standard | 0.262" | 0.083" | 100 | $1.89 | Add to Order |
| MSS-5470 | 6-32 | 5/8" | Standard | 0.262" | 0.083" | 100 | $3.93 | Add to Order |
| MSS-5498 | 6-32 | 3/4" | Standard | 0.262" | 0.083" | 100 | $3.15 | Add to Order |
| MSS-5499 | 6-32 | 7/8" | Standard | 0.262" | 0.083" | 100 | $6.66 | Add to Order |
| MSS-5500 | 6-32 | 1" | Standard | 0.262" | 0.083" | 100 | $5.31 | Add to Order |
| MSS-5501 | 6-32 | 1 1/4" | Standard | 0.262" | 0.083" | 100 | $8.53 | Add to Order |
| MSS-5502 | 6-32 | 1 1/2" | Standard | 0.262" | 0.083" | 100 | $6.85 | Add to Order |
| MSS-5503 | 6-32 | 1 3/4" | Standard | 0.262" | 0.083" | 100 | $11.21 | Add to Order |
| MSS-5504 | 6-32 | 2" | Standard | 0.262" | 0.083" | 100 | $4.73 | Add to Order |
| MSS-5505 | 6-32 | 2 1/4" | Standard | 0.262" | 0.083" | 100 | $14.07 | Add to Order |
| MSS-3418 | 6-32 | 2 1/2" | Standard | 0.262" | 0.083" | 100 | $7.41 | Add to Order |
| MSS-4010 | 6-32 | 3" | Standard | 0.262" | 0.083" | 100 | $24.38 | Add to Order |
| MSS-4011 | 6-32 | 4" | Standard | 0.262" | 0.083" | 50 | $25.45 | Add to Order |
| MSS-5062 | 8-32 | 3/16" | Undercut | 0.312" | 0.070" | 100 | $25.52 | Add to Order |
| MSS-5063 | 8-32 | 1/4" | Undercut | 0.312" | 0.070" | 100 | $28.71 | Add to Order |
| MSS-5064 | 8-32 | 5/16" | Standard | 0.312" | 0.100" | 100 | $18.79 | Add to Order |
| MSS-5065 | 8-32 | 3/8" | Standard | 0.312" | 0.100" | 100 | $4.52 | Add to Order |
| MSS-5066 | 8-32 | 1/2" | Standard | 0.312" | 0.100" | 100 | $4.91 | Add to Order |
| MSS-5067 | 8-32 | 5/8" | Standard | 0.312" | 0.100" | 100 | $7.94 | Add to Order |
| MSS-5068 | 8-32 | 3/4" | Standard | 0.312" | 0.100" | 100 | $3.74 | Add to Order |
| MSS-5069 | 8-32 | 7/8" | Standard | 0.312" | 0.100" | 100 | $16.86 | Add to Order |
| MSS-5106 | 8-32 | 1" | Standard | 0.312" | 0.100" | 100 | $7.62 | Add to Order |
| MSS-5059 | 8-32 | 1 1/4" | Standard | 0.312" | 0.100" | 100 | $15.79 | Add to Order |
| MSS-5094 | 8-32 | 1 1/2" | Standard | 0.312" | 0.100" | 100 | $9.95 | Add to Order |
| MSS-5120 | 8-32 | 1 3/4" | Standard | 0.312" | 0.100" | 100 | $10.02 | Add to Order |
| MSS-5121 | 8-32 | 2" | Standard | 0.312" | 0.100" | 100 | $18.38 | Add to Order |
| MSS-5122 | 8-32 | 2 1/4" | Standard | 0.312" | 0.100" | 100 | $4.89 | Add to Order |
| MSS-5123 | 8-32 | 2 1/2" | Standard | 0.312" | 0.100" | 100 | $26.06 | Add to Order |
| MSS-5124 | 8-32 | 3" | Standard | 0.312" | 0.100" | 100 | $27.80 | Add to Order |
| MSS-5125 | 8-32 | 4" | Standard | 0.312" | 0.100" | 50 | $25.20 | Add to Order |
| MSS-5126 | 10-24 | 1/4" | Undercut | 0.362" | 0.081" | 100 | $11.57 | Add to Order |
| MSS-5127 | 10-24 | 3/8" | Standard | 0.362" | 0.116" | 100 | $5.50 | Add to Order |
| MSS-5128 | 10-24 | 1/2" | Standard | 0.362" | 0.116" | 100 | $3.51 | Add to Order |
| MSS-5142 | 10-24 | 5/8" | Standard | 0.362" | 0.116" | 100 | $10.56 | Add to Order |
| MSS-5130 | 10-24 | 3/4" | Standard | 0.362" | 0.116" | 100 | $6.55 | Add to Order |
| MSS-5119 | 10-24 | 7/8" | Standard | 0.362" | 0.116" | 100 | $13.99 | Add to Order |
| MSS-5132 | 10-24 | 1" | Standard | 0.362" | 0.116" | 100 | $8.86 | Add to Order |
| MSS-5133 | 10-24 | 1 1/4" | Standard | 0.362" | 0.116" | 100 | $3.76 | Add to Order |
| MSS-5134 | 10-24 | 1 1/2" | Standard | 0.362" | 0.116" | 100 | $11.51 | Add to Order |
| MSS-5135 | 10-24 | 1 3/4" | Standard | 0.362" | 0.116" | 100 | $14.01 | Add to Order |
| MSS-5136 | 10-24 | 2" | Standard | 0.362" | 0.116" | 100 | $15.60 | Add to Order |
| MSS-5137 | 10-24 | 2 1/2" | Standard | 0.362" | 0.116" | 100 | $14.74 | Add to Order |
| MSS-5138 | 10-24 | 3" | Standard | 0.362" | 0.116" | 100 | $24.80 | Add to Order |
| MSS-5139 | 10-24 | 3 1/2" | Standard | 0.362" | 0.116" | 50 | $24.49 | Add to Order |
| MSS-5140 | 10-24 | 4" | Standard | 0.362" | 0.116" | 100 | $27.72 | Add to Order |
| MSS-5108 | 10-24 | 5" | Standard | 0.362" | 0.116" | 25 | $19.15 | Add to Order |
| MSS-5131 | 10-24 | 6" | Standard | 0.362" | 0.116" | 25 | $22.22 | Add to Order |
| MSS-5129 | 10-32 | 1/4" | Undercut | 0.362" | 0.081" | 100 | $9.98 | Add to Order |
| MSS-5097 | 10-32 | 5/16" | Undercut | 0.362" | 0.081" | 100 | $10.33 | Add to Order |
| MSS-5098 | 10-32 | 3/8" | Standard | 0.362" | 0.116" | 100 | $6.59 | Add to Order |
| MSS-5099 | 10-32 | 1/2" | Standard | 0.362" | 0.116" | 100 | $9.85 | Add to Order |
| MSS-5100 | 10-32 | 5/8" | Standard | 0.362" | 0.116" | 100 | $13.23 | Add to Order |
| MSS-5101 | 10-32 | 3/4" | Standard | 0.362" | 0.116" | 100 | $12.96 | Add to Order |
| MSS-5102 | 10-32 | 7/8" | Standard | 0.362" | 0.116" | 100 | $6.09 | Add to Order |
| MSS-5103 | 10-32 | 1" | Standard | 0.362" | 0.116" | 100 | $12.73 | Add to Order |
| MSS-5104 | 10-32 | 1 1/4" | Standard | 0.362" | 0.116" | 100 | $14.85 | Add to Order |
| MSS-5105 | 10-32 | 1 1/2" | Standard | 0.362" | 0.116" | 100 | $19.55 | Add to Order |
| MSS-5118 | 10-32 | 1 3/4" | Standard | 0.362" | 0.116" | 100 | $24.19 | Add to Order |
| MSS-5107 | 10-32 | 2" | Standard | 0.362" | 0.116" | 100 | $24.55 | Add to Order |
| MSS-5096 | 10-32 | 2 1/2" | Standard | 0.362" | 0.116" | 100 | $31.06 | Add to Order |
| MSS-3422B | 10-32 | 3" | Standard | 0.362" | 0.116" | 100 | $13.99 | Add to Order |
| MSS-3420 | 10-32 | 3 1/2" | Standard | 0.362" | 0.116" | 50 | $33.16 | Add to Order |
| MSS-3409 | 10-32 | 4" | Standard | 0.362" | 0.116" | 50 | $56.99 | Add to Order |
| MSS-3422 | 12-24 | 3/8" | Undercut | 0.412" | 0.092" | 100 | $36.12 | Add to Order |
| MSS-3423 | 12-24 | 1/2" | Standard | 0.412" | 0.132" | 100 | $11.47 | Add to Order |
| MSS-3424 | 12-24 | 5/8" | Standard | 0.412" | 0.132" | 100 | $6.53 | Add to Order |
| MSS-3425 | 12-24 | 3/4" | Standard | 0.412" | 0.132" | 100 | $10.52 | Add to Order |
| MSS-3426 | 12-24 | 1" | Standard | 0.412" | 0.132" | 100 | $20.98 | Add to Order |
| MSS-3427 | 12-24 | 1 1/2" | Standard | 0.412" | 0.132" | 100 | $25.56 | Add to Order |
| MSS-3428 | 12-24 | 2" | Standard | 0.412" | 0.132" | 100 | $23.79 | Add to Order |
| MSS-3429 | 12-24 | 2 1/2" | Standard | 0.412" | 0.132" | 50 | $20.31 | Add to Order |
| MSS-3430 | 1/4"-20 | 3/8" | Undercut | 0.477" | 0.107" | 100 | $15.23 | Add to Order |
| MSS-3398 | 1/4"-20 | 1/2" | Standard | 0.477" | 0.153" | 100 | $14.95 | Add to Order |
| MSS-3421 | 1/4"-20 | 5/8" | Standard | 0.477" | 0.153" | 100 | $12.26 | Add to Order |
| MSS-3419 | 1/4"-20 | 3/4" | Standard | 0.477" | 0.153" | 100 | $18.10 | Add to Order |
| MSS-3387 | 1/4"-20 | 7/8" | Standard | 0.477" | 0.153" | 100 | $16.34 | Add to Order |
| MSS-3388 | 1/4"-20 | 1" | Standard | 0.477" | 0.153" | 100 | $10.90 | Add to Order |
| MSS-3389 | 1/4"-20 | 1 1/8" | Standard | 0.477" | 0.153" | 100 | $19.53 | Add to Order |
| MSS-3390 | 1/4"-20 | 1 1/4" | Standard | 0.477" | 0.153" | 100 | $11.70 | Add to Order |
| MSS-3391 | 1/4"-20 | 1 1/2" | Standard | 0.477" | 0.153" | 100 | $21.27 | Add to Order |
| MSS-3392 | 1/4"-20 | 1 3/4" | Standard | 0.477" | 0.153" | 100 | $26.19 | Add to Order |
| MSS-3393 | 1/4"-20 | 2" | Standard | 0.477" | 0.153" | 100 | $24.57 | Add to Order |
| MSS-3394 | 1/4"-20 | 2 1/4" | Standard | 0.477" | 0.153" | 100 | $26.15 | Add to Order |
| MSS-3395 | 1/4"-20 | 2 1/2" | Standard | 0.477" | 0.153" | 100 | $30.14 | Add to Order |
| MSS-3408 | 1/4"-20 | 2 3/4" | Standard | 0.477" | 0.153" | 25 | $29.67 | Add to Order |
| MSS-3397 | 1/4"-20 | 3" | Standard | 0.477" | 0.153" | 25 | $11.32 | Add to Order |
| MSS-3386 | 1/4"-20 | 3 1/2" | Standard | 0.477" | 0.153" | 25 | $17.14 | Add to Order |
| MSS-3399 | 1/4"-20 | 4" | Standard | 0.477" | 0.153" | 25 | $18.25 | Add to Order |
| MSS-3400 | 1/4"-20 | 4 1/2" | Standard | 0.477" | 0.153" | 25 | $21.21 | Add to Order |
| MSS-3401 | 1/4"-20 | 5" | Standard | 0.477" | 0.153" | 25 | $20.98 | Add to Order |
| MSS-3402 | 1/4"-20 | 5 1/2" | Standard | 0.477" | 0.153" | 10 | $21.27 | Add to Order |
| MSS-3403 | 1/4"-20 | 6" | Standard | 0.477" | 0.153" | 10 | $13.86 | Add to Order |
| MSS-3404 | 1/4"-28 | 1/2" | Standard | 0.477" | 0.153" | 25 | $22.91 | Add to Order |
| MSS-3405 | 1/4"-28 | 5/8" | Standard | 0.477" | 0.153" | 25 | $27.01 | Add to Order |
| MSS-3406 | 1/4"-28 | 3/4" | Standard | 0.477" | 0.153" | 10 | $12.43 | Add to Order |
| MSS-3443 | 1/4"-28 | 1" | Standard | 0.477" | 0.153" | 10 | $23.33 | Add to Order |
| MSS-3396 | 5/16"-18 | 1/2" | Undercut | 0.597" | 0.134" | 50 | $22.24 | Add to Order |
| MSS-3431 | 5/16"-18 | 5/8" | Standard | 0.597" | 0.191" | 100 | $21.34 | Add to Order |
| MSS-3457 | 5/16"-18 | 3/4" | Standard | 0.597" | 0.191" | 100 | $24.30 | Add to Order |
| MSS-3458 | 5/16"-18 | 7/8" | Standard | 0.597" | 0.191" | 100 | $37.15 | Add to Order |
| MSS-3459 | 5/16"-18 | 1" | Standard | 0.597" | 0.191" | 100 | $40.64 | Add to Order |
| MSS-3460 | 5/16"-18 | 1 1/4" | Standard | 0.597" | 0.191" | 50 | $24.59 | Add to Order |
| MSS-3461 | 5/16"-18 | 1 1/2" | Standard | 0.597" | 0.191" | 100 | $47.50 | Add to Order |
| MSS-3462 | 5/16"-18 | 1 3/4" | Standard | 0.597" | 0.191" | 25 | $18.25 | Add to Order |
| MSS-3463 | 5/16"-18 | 2" | Standard | 0.597" | 0.191" | 25 | $20.29 | Add to Order |
| MSS-3464 | 5/16"-18 | 2 1/4" | Standard | 0.597" | 0.191" | 25 | $22.91 | Add to Order |
| MSS-3465 | 5/16"-18 | 2 1/2" | Standard | 0.597" | 0.191" | 25 | $21.74 | Add to Order |
| MSS-3479 | 5/16"-18 | 3" | Standard | 0.597" | 0.191" | 25 | $25.14 | Add to Order |
| MSS-3467 | 5/16"-18 | 3 1/2" | Standard | 0.597" | 0.191" | 25 | $27.76 | Add to Order |
| MSS-3456 | 5/16"-18 | 4" | Standard | 0.597" | 0.191" | 10 | $14.49 | Add to Order |
| MSS-3469 | 5/16"-18 | 4 1/2" | Standard | 0.597" | 0.191" | 10 | $16.67 | Add to Order |
| MSS-3470 | 5/16"-18 | 5" | Standard | 0.597" | 0.191" | 10 | $18.92 | Add to Order |
| MSS-3471 | 5/16"-18 | 6" | Standard | 0.597" | 0.191" | 10 | $19.28 | Add to Order |
| MSS-3472 | 3/8"-16 | 1/2" | Undercut | 0.717" | 0.161" | 50 | $24.44 | Add to Order |
| MSS-10513 | 3/8"-16 | 5/8" | Standard | 0.717" | 0.230" | 25 | $20.29 | Add to Order |
| MSS-3473 | 3/8"-16 | 3/4" | Standard | 0.717" | 0.230" | 25 | $17.72 | Add to Order |
| MSS-484 | 3/8"-16 | 1" | Standard | 0.717" | 0.230" | 25 | $14.62 | Add to Order |
| MSS-3474 | 3/8"-16 | 1 1/4" | Standard | 0.717" | 0.230" | 25 | $15.60 | Add to Order |
| MSS-3475 | 3/8"-16 | 1 1/2" | Standard | 0.717" | 0.230" | 25 | $20.69 | Add to Order |
| MSS-10514 | 3/8"-16 | 1 3/4" | Standard | 0.717" | 0.230" | 25 | $25.91 | Add to Order |
| MSS-486 | 3/8"-16 | 2" | Standard | 0.717" | 0.230" | 25 | $24.74 | Add to Order |
| MSS-3476 | 3/8"-16 | 2 1/2" | Standard | 0.717" | 0.230" | 25 | $28.71 | Add to Order |
| MSS-487 | 3/8"-16 | 3" | Standard | 0.717" | 0.230" | 10 | $16.46 | Add to Order |
| MSS-3477 | 3/8"-16 | 3 1/2" | Standard | 0.717" | 0.230" | 10 | $15.16 | Add to Order |
| MSS-3445 | 3/8"-16 | 4" | Standard | 0.717" | 0.230" | 10 | $15.62 | Add to Order |
| MSS-3468 | 3/8"-16 | 4 1/2" | Standard | 0.717" | 0.230" | 10 | $17.58 | Add to Order |
| MSS-3466 | 3/8"-16 | 5" | Standard | 0.717" | 0.230" | 10 | $19.61 | Add to Order |
| MSS-3434 | 3/8"-16 | 5 1/2" | Standard | 0.717" | 0.230" | 10 | $20.20 | Add to Order |
| MSS-3435 | 3/8"-16 | 6" | Standard | 0.717" | 0.230" | 10 | $18.48 | Add to Order |
| MSS-10515 | 1/2"-13 | 3/4" | Standard | 0.815" | 0.223" | 10 | $24.59 | Add to Order |
| MSS-3436 | 1/2"-13 | 1" | Standard | 0.815" | 0.223" | 50 | $33.39 | Add to Order |
| MSS-3437 | 1/2"-13 | 1 1/4" | Standard | 0.815" | 0.223" | 50 | $41.96 | Add to Order |
| MSS-3438 | 1/2"-13 | 1 1/2" | Standard | 0.815" | 0.223" | 50 | $37.17 | Add to Order |
| MSS-10516 | 1/2"-13 | 1 3/4" | Standard | 0.815" | 0.223" | 5 | $14.78 | Add to Order |
| MSS-3439 | 1/2"-13 | 2" | Standard | 0.815" | 0.223" | 10 | $22.07 | Add to Order |
| MSS-3440 | 1/2"-13 | 2 1/2" | Standard | 0.815" | 0.223" | 10 | $23.23 | Add to Order |
| MSS-3441 | 1/2"-13 | 3" | Standard | 0.815" | 0.223" | 5 | $19.01 | Add to Order |
| MSS-3442 | 1/2"-13 | 3 1/2" | Standard | 0.815" | 0.223" | 5 | $20.98 | Add to Order |
| MSS-3455 | 1/2"-13 | 4" | Standard | 0.815" | 0.223" | 5 | $24.04 | Add to Order |
| MSS-3444 | 1/2"-13 | 5" | Standard | 0.815" | 0.223" | 5 | $25.03 | Add to Order |
| MSS-3433 | 1/2"-13 | 6" | Standard | 0.815" | 0.223" | 5 | $34.50 | Add to Order |
| Rev. 01-24, 10-23, 08-23, 02-23 | ||||||||
