Nylon 6/6 Flat Head Slotted Drive Metric Machine Screws
Machine Screws - 82°Flat Head Slotted Drive, Class 2A, fully threaded.
Nylon 6/6 - Non conductive, chemical and solvent resistant, except mineral acids. Temperature range -40°/+185°F. Absorbs moisture, can affect dimensions and properties. Off White.
| Metric Nylon
Slotted Flat Head Machine Screws ASME B18.6.3, Natural, -40° to 185°, FT |
||||||||
| Part # | Thread Size (mm) | Pitch (mm) | Length (mm) | Head Dia. (mm) | Head Height. (mm) | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| MSS-10667 | M2 | 0.4 mm | 4 | 4.4 | 1.2 | 100 | $23.08 | Add to Order |
| MSS-10668 | M2 | 0.4 mm | 5 | 4.4 | 1.2 | 100 | $23.16 | Add to Order |
| MSS-10669 | M2 | 0.4 mm | 6 | 4.4 | 1.2 | 100 | $23.18 | Add to Order |
| MSS-10670 | M2 | 0.4 mm | 8 | 4.4 | 1.2 | 100 | $28.81 | Add to Order |
| MSS-10671 | M2 | 0.4 mm | 10 | 4.4 | 1.2 | 100 | $29.06 | Add to Order |
| MSS-10672 | M2 | 0.4 mm | 12 | 4.4 | 1.2 | 100 | $29.42 | Add to Order |
| MSS-10673 | M2 | 0.4 mm | 16 | 4.4 | 1.2 | 100 | $29.53 | Add to Order |
| MSS-10674 | M3 | 0.5 mm | 5 | 6.3 | 1.7 | 100 | $28.58 | Add to Order |
| MSS-10675 | M3 | 0.5 mm | 6 | 6.3 | 1.7 | 100 | $28.58 | Add to Order |
| MSS-10676 | M3 | 0.5 mm | 8 | 6.3 | 1.7 | 100 | $28.81 | Add to Order |
| MSS-10677 | M3 | 0.5 mm | 10 | 6.3 | 1.7 | 100 | $29.06 | Add to Order |
| MSS-10678 | M3 | 0.5 mm | 12 | 6.3 | 1.7 | 100 | $29.42 | Add to Order |
| MSS-10679 | M3 | 0.5 mm | 16 | 6.3 | 1.7 | 100 | $29.53 | Add to Order |
| MSS-10680 | M3 | 0.5 mm | 20 | 6.3 | 1.7 | 100 | $29.78 | Add to Order |
| MSS-10681 | M3 | 0.5 mm | 25 | 6.3 | 1.7 | 100 | $29.90 | Add to Order |
| MSS-10682 | M3 | 0.5 mm | 30 | 6.3 | 1.7 | 100 | $30.26 | Add to Order |
| MSS-10683 | M4 | 0.7 mm | 6 | 9.4 | 2.7 | 100 | $22.13 | Add to Order |
| MSS-10684 | M4 | 0.7 mm | 8 | 9.4 | 2.7 | 100 | $22.28 | Add to Order |
| MSS-10685 | M4 | 0.7 mm | 10 | 9.4 | 2.7 | 100 | $22.43 | Add to Order |
| MSS-10686 | M4 | 0.7 mm | 12 | 9.4 | 2.7 | 100 | $22.55 | Add to Order |
| MSS-10687 | M4 | 0.7 mm | 16 | 9.4 | 2.7 | 100 | $22.68 | Add to Order |
| MSS-10688 | M4 | 0.7 mm | 20 | 9.4 | 2.7 | 100 | $22.70 | Add to Order |
| MSS-10689 | M4 | 0.7 mm | 25 | 9.4 | 2.7 | 100 | $22.85 | Add to Order |
| MSS-10690 | M4 | 0.7 mm | 30 | 9.4 | 2.7 | 100 | $23.56 | Add to Order |
| MSS-10691 | M4 | 0.7 mm | 35 | 9.4 | 2.7 | 100 | $23.81 | Add to Order |
| MSS-10692 | M5 | 0.8 mm | 8 | 10.4 | 2.7 | 100 | $33.47 | Add to Order |
| MSS-10693 | M5 | 0.8 mm | 10 | 10.4 | 2.7 | 100 | $33.73 | Add to Order |
| MSS-10694 | M5 | 0.8 mm | 12 | 10.4 | 2.7 | 100 | $33.96 | Add to Order |
| MSS-10695 | M5 | 0.8 mm | 16 | 10.4 | 2.7 | 100 | $34.08 | Add to Order |
| MSS-10696 | M5 | 0.8 mm | 20 | 10.4 | 2.7 | 100 | $34.31 | Add to Order |
| MSS-10697 | M5 | 0.8 mm | 25 | 10.4 | 2.7 | 100 | $34.57 | Add to Order |
| MSS-10698 | M5 | 0.8 mm | 30 | 10.4 | 2.7 | 100 | $35.36 | Add to Order |
| MSS-10699 | M5 | 0.8 mm | 40 | 10.4 | 2.7 | 100 | $35.41 | Add to Order |
| MSS-10700 | M6 | 1 mm | 8 | 12.6 | 3.3 | 100 | $38.49 | Add to Order |
| MSS-10701 | M6 | 1 mm | 10 | 12.6 | 3.3 | 100 | $38.62 | Add to Order |
| MSS-10702 | M6 | 1 mm | 12 | 12.6 | 3.3 | 100 | $38.75 | Add to Order |
| MSS-10703 | M6 | 1 mm | 16 | 12.6 | 3.3 | 100 | $38.87 | Add to Order |
| MSS-10704 | M6 | 1 mm | 20 | 12.6 | 3.3 | 100 | $39.23 | Add to Order |
| MSS-10705 | M6 | 1 mm | 25 | 12.6 | 3.3 | 100 | $39.46 | Add to Order |
| MSS-10706 | M6 | 1 mm | 30 | 12.6 | 3.3 | 100 | $27.01 | Add to Order |
| MSS-10707 | M6 | 1 mm | 35 | 12.6 | 3.3 | 100 | $40.43 | Add to Order |
| MSS-1708 | M6 | 1 mm | 40 | 12.6 | 3.3 | 100 | $29.02 | Add to Order |
| MSS-10709 | M6 | 1 mm | 45 | 12.6 | 3.3 | 100 | $41.01 | Add to Order |
| MSS-10710 | M6 | 1 mm | 50 | 12.6 | 3.3 | 100 | $41.14 | Add to Order |
| MSS-10711 | M8 | 1.25 mm | 16 | 17.3 | 4.6 | 25 | $21.29 | Add to Order |
| MSS-10712 | M8 | 1.25 mm | 20 | 17.3 | 4.6 | 25 | $21.29 | Add to Order |
| MSS-10713 | M8 | 1.25 mm | 25 | 17.3 | 4.6 | 25 | $21.99 | Add to Order |
| MSS-10714 | M8 | 1.25 mm | 30 | 17.3 | 4.6 | 25 | $22.70 | Add to Order |
| MSS-10715 | M8 | 1.25 mm | 50 | 17.3 | 4.6 | 25 | $22.70 | Add to Order |
| Rev. 10-23, 08-23, 02-23, 11-22 | ||||||||
