Brass Flat Head Slotted Drive Metric Machine Screws
Machine Screws - Metric Flat Head Slotted Drive, Class 6g, DIN 963, fully threaded, 90° bevel under head provides flush surface within countersunk holes.
Brass - Nonmagnetic and good corrosion resistance, Rockwell hardness B55, tensile strength 53,000 psi.
| Metric
Brass Slotted Flat Head Machine Screws DIN 963, ISO 2009, 50,000 PSI Tensile, FT |
||||||||
| Part # | Thread Size (mm) | Pitch mm | Length (mm) | Head Dia. (mm) | Head Height. (mm) | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| MSS-10528 | M2 | 0.4 mm | 4 | 3.8 | 1.2 | 50 | $21.00 | Add to Order |
| MSS-10529 | M2 | 0.4 mm | 5 | 3.8 | 1.2 | 50 | $23.26 | Add to Order |
| MSS-3148 | M2 | 0.4 mm | 6 | 3.8 | 1.2 | 50 | $25.38 | Add to Order |
| MSS-3116 | M2 | 0.4 mm | 10 | 3.8 | 1.2 | 50 | $25.78 | Add to Order |
| MSS-3139 | M2 | 0.4 mm | 12 | 3.8 | 1.2 | 50 | $29.60 | Add to Order |
| MSS-3137 | M3 | 0.5 mm | 6 | 5.5 | 1.65 | 50 | $17.32 | Add to Order |
| MSS-3105 | M3 | 0.5 mm | 8 | 5.5 | 1.65 | 50 | $14.22 | Add to Order |
| MSS-3106 | M3 | 0.5 mm | 10 | 5.5 | 1.65 | 50 | $14.22 | Add to Order |
| MSS-10530 | M3 | 0.5 mm | 12 | 5.5 | 1.65 | 50 | $17.40 | Add to Order |
| MSS-10531 | M3 | 0.5 mm | 16 | 5.5 | 1.65 | 50 | $17.36 | Add to Order |
| MSS-3107 | M4 | 0.7 mm | 8 | 7.5 | 2.2 | 50 | $25.20 | Add to Order |
| MSS-3108 | M4 | 0.7 mm | 10 | 7.5 | 2.2 | 50 | $27.60 | Add to Order |
| MSS-3109 | M4 | 0.7 mm | 12 | 7.5 | 2.2 | 50 | $27.60 | Add to Order |
| MSS-3110 | M4 | 0.7 mm | 16 | 7.5 | 2.2 | 100 | $15.56 | Add to Order |
| MSS-3111 | M4 | 0.7 mm | 20 | 7.5 | 2.2 | 25 | $21.00 | Add to Order |
| MSS-3112 | M4 | 0.7 mm | 25 | 7.5 | 2.2 | 25 | $21.00 | Add to Order |
| MSS-3113 | M5 | 0.8 mm | 10 | 9.2 | 2.5 | 25 | $19.60 | Add to Order |
| MSS-3126 | M5 | 0.8 mm | 12 | 9.2 | 2.5 | 25 | $20.80 | Add to Order |
| MSS-3115 | M5 | 0.8 mm | 16 | 9.2 | 2.5 | 25 | $23.20 | Add to Order |
| MSS-3104 | M5 | 0.8 mm | 20 | 9.2 | 2.5 | 25 | $28.60 | Add to Order |
| MSS-3117 | M5 | 0.8 mm | 25 | 9.2 | 2.5 | 25 | $33.00 | Add to Order |
| MSS-3118 | M6 | 1 mm | 12 | 11 | 3 | 25 | $28.80 | Add to Order |
| MSS-3119 | M6 | 1 mm | 16 | 11 | 3 | 10 | $14.40 | Add to Order |
| MSS-3120 | M6 | 1 mm | 20 | 11 | 3 | 10 | $18.40 | Add to Order |
| MSS-3121 | M6 | 1 mm | 25 | 11 | 3 | 10 | $18.40 | Add to Order |
| MSS-3122 | M6 | 1 mm | 30 | 11 | 3 | 10 | $24.00 | Add to Order |
