2024 Aluminum Alloy Flat Head Slotted Drive Machine Screws
Machine Screws - Flat Head Slotted Drive, Class 2A, fully threaded, bevel under head provides flush surface within countersunk holes.
2024-T4 Aluminum Alloy � Heat treated, nonmagnetic, good electrical conductor, mild resistance to corrosion due to weather, minimum tensile strength is 55,000 psi.
.JPG)
| Aluminum Slotted Flat Head Machine Screws ASME B18.6.3, 50,000 PSI Tensile, FT |
||||||||
| Part # | Thread Size | Length | Type | Head Dia. | Head Height | Pkg. Qty | Price Each | Order Online |
|---|---|---|---|---|---|---|---|---|
| MSS-3446 | 6-32 | 3/4" | Standard | 0.262" | 0.083" | 50 | $24.12 | Add to Order |
| MSS-3447 | 8-32 | 1/4" | Undercut | 0.312" | 0.070" | 25 | $23.76 | Add to Order |
| MSS-3448 | 8-32 | 1/2" | Standard | 0.312" | 0.100" | 25 | $20.96 | Add to Order |
| MSS-3449 | 8-32 | 3/4" | Standard | 0.312" | 0.100" | 25 | $20.48 | Add to Order |
| MSS-3450 | 8-32 | 1" | Standard | 0.312" | 0.100" | 25 | $25.00 | Add to Order |
| MSS-3451 | 10-24 | 1" | Standard | 0.362" | 0.116" | 25 | $28.26 | Add to Order |
| MSS-3452 | 10-24 | 1 1/4" | Standard | 0.362" | 0.116" | 25 | $29.70 | Add to Order |
| MSS-3453 | 10-32 | 3/8" | Standard | 0.362" | 0.116" | 25 | $26.12 | Add to Order |
| MSS-3598 | 10-32 | 1/2" | Standard | 0.362" | 0.116" | 25 | $31.84 | Add to Order |
| MSS-3410 | 1/4"-20 | 3/8" | Undercut | 0.477" | 0.107" | 25 | $26.18 | Add to Order |
| MSS-3572 | 1/4"-20 | 1/2" | Standard | 0.477" | 0.153" | 25 | $27.80 | Add to Order |
| MSS-10753 | 1/4"-20 | 3/4" | Standard | 0.477" | 0.153" | 10 | $13.34 | Add to Order |
| MSS-3692 | 1/4"-20 | 1" | Standard | 0.477" | 0.153" | 25 | $41.58 | Add to Order |
| MSS-3693 | 1/4"-20 | 1 1/2" | Standard | 0.477" | 0.153" | 25 | $32.00 | Add to Order |
| MSS-3694 | 1/4"-20 | 1 3/4" | Standard | 0.477" | 0.153" | 10 | $18.24 | Add to Order |
| MSS-10754 | 5/16"-18 | 3/4" | Standard | 0.597" | 0.191" | 10 | $19.10 | Add to Order |
| MSS-10755 | 5/16"-18 | 1" | Standard | 0.597" | 0.191" | 5 | $18.98 | Add to Order |
| Rev. 08-23, 11-22, 03-22 | ||||||||
