Zinc Plated Steel Flat Head Phillips Drive Metric Machine Screws
Machine Screws - Metric Flat Head Phillips Drive, Zinc Plated, Class 6h, fully threaded, 90° bevel under head provides flush surface within countersunk holes.
Steel - Rockwell Hardness B60, tensile strength 60,000 psi. Zinc Plated - Good rust resistance.
| Metric
Steel Phillips Flat Head Machine Screws DIN 965, 60,000 PSI Tensile, FT |
|||||||||
| Part # | Thread Size | Pitch | Length (mm) | Head Dia. (mm) | Head Height (mm) | Drive | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| MSS-4800 | M2 | 0.4 mm | 3 | 3.8 | 1.2 | No. 1 | 100 | $11.63 | Add to Order |
| MSS-5750 | M2 | 0.4 mm | 4 | 3.8 | 1.2 | No. 1 | 100 | $10.90 | Add to Order |
| MSS-4802 | M2 | 0.4 mm | 5 | 3.8 | 1.2 | No. 1 | 100 | $8.40 | Add to Order |
| MSS-4803 | M2 | 0.4 mm | 6 | 3.8 | 1.2 | No. 1 | 100 | $9.11 | Add to Order |
| MSS-4804 | M2 | 0.4 mm | 8 | 3.8 | 1.2 | No. 1 | 100 | $8.32 | Add to Order |
| MSS-5766 | M2 | 0.4 mm | 10 | 3.8 | 1.2 | No. 1 | 100 | $7.33 | Add to Order |
| MSS-5746 | M2 | 0.4 mm | 12 | 3.8 | 1.2 | No. 1 | 100 | $10.21 | Add to Order |
| MSS-5747 | M2 | 0.4 mm | 16 | 3.8 | 1.2 | No. 1 | 100 | $11.32 | Add to Order |
| MSS-4808 | M2 | 0.4 mm | 20 | 3.8 | 1.2 | No. 1 | 100 | $15.18 | Add to Order |
| MSS-5748 | M2.5 | 0.45 mm | 4 | 4.7 | 1.5 | No. 1 | 100 | $10.50 | Add to Order |
| MSS-4810 | M2.5 | 0.45 mm | 5 | 4.7 | 1.5 | No. 1 | 100 | $10.50 | Add to Order |
| MSS-5749 | M2.5 | 0.45 mm | 6 | 4.7 | 1.5 | No. 1 | 100 | $8.51 | Add to Order |
| MSS-4801 | M2.5 | 0.45 mm | 8 | 4.7 | 1.5 | No. 1 | 100 | $8.23 | Add to Order |
| MSS-5669 | M2.5 | 0.45 mm | 10 | 4.7 | 1.5 | No. 1 | 100 | $10.14 | Add to Order |
| MSS-5699 | M2.5 | 0.45 mm | 12 | 4.7 | 1.5 | No. 1 | 100 | $11.80 | Add to Order |
| MSS-5700 | M2.5 | 0.45 mm | 16 | 4.7 | 1.5 | No. 1 | 100 | $11.80 | Add to Order |
| MSS-5001 | M2.5 | 0.45 mm | 20 | 4.7 | 1.5 | No. 1 | 100 | $11.80 | Add to Order |
| MSS-4989 | M2.5 | 0.45 mm | 25 | 4.7 | 1.5 | No. 1 | 100 | $14.43 | Add to Order |
| MSS-5701 | M3 | 0.5 mm | 4 | 5.6 | 1.65 | No. 1 | 100 | $10.23 | Add to Order |
| MSS-4991 | M3 | 0.5 mm | 5 | 5.6 | 1.65 | No. 1 | 100 | $9.26 | Add to Order |
| MSS-4992 | M3 | 0.5 mm | 6 | 5.6 | 1.65 | No. 1 | 100 | $7.64 | Add to Order |
| MSS-4993 | M3 | 0.5 mm | 8 | 5.6 | 1.65 | No. 1 | 100 | $6.72 | Add to Order |
| MSS-4994 | M3 | 0.5 mm | 10 | 5.6 | 1.65 | No. 1 | 100 | $7.25 | Add to Order |
| MSS-4995 | M3 | 0.5 mm | 12 | 5.6 | 1.65 | No. 1 | 100 | $7.56 | Add to Order |
| MSS-4996 | M3 | 0.5 mm | 14 | 5.6 | 1.65 | No. 1 | 100 | $9.43 | Add to Order |
| MSS-4997 | M3 | 0.5 mm | 16 | 5.6 | 1.65 | No. 1 | 100 | $8.93 | Add to Order |
| MSS-10318 | M3 | 0.5 mm | 18 | 5.6 | 1.65 | No. 1 | 100 | $11.59 | Add to Order |
| MSS-5702 | M3 | 0.5 mm | 20 | 5.6 | 1.65 | No. 1 | 100 | $5.54 | Add to Order |
| MSS-5712 | M3 | 0.5 mm | 25 | 5.6 | 1.65 | No. 1 | 100 | $10.08 | Add to Order |
| MSS-5521 | M3 | 0.5 mm | 30 | 5.6 | 1.65 | No. 1 | 100 | $13.82 | Add to Order |
| MSS-10319 | M3 | 0.5 mm | 35 | 5.6 | 1.65 | No. 1 | 100 | $25.20 | Add to Order |
| MSS-4990 | M3 | 0.5 mm | 40 | 5.6 | 1.65 | No. 1 | 100 | $16.38 | Add to Order |
| MSS-5704 | M3 | 0.5 mm | 45 | 5.6 | 1.65 | No. 1 | 50 | $17.64 | Add to Order |
| MSS-5697 | M3 | 0.5 mm | 50 | 5.6 | 1.65 | No. 1 | 50 | $6.89 | Add to Order |
| MSS-10320 | M3 | 0.5 mm | 60 | 5.6 | 1.65 | No. 1 | 10 | $14.49 | Add to Order |
| MSS-5706 | M3.5 | 0.6 mm | 6 | 6.5 | 1.93 | No. 2 | 100 | $6.59 | Add to Order |
| MSS-5707 | M3.5 | 0.6 mm | 8 | 6.5 | 1.93 | No. 2 | 100 | $9.18 | Add to Order |
| MSS-5708 | M3.5 | 0.6 mm | 10 | 6.5 | 1.93 | No. 2 | 100 | $11.80 | Add to Order |
| MSS-5709 | M3.5 | 0.6 mm | 12 | 6.5 | 1.93 | No. 2 | 100 | $9.53 | Add to Order |
| MSS-5710 | M3.5 | 0.6 mm | 16 | 6.5 | 1.93 | No. 2 | 100 | $14.85 | Add to Order |
| MSS-5682 | M3.5 | 0.6 mm | 20 | 6.5 | 1.93 | No. 2 | 100 | $19.13 | Add to Order |
| MSS-5705 | M3.5 | 0.6 mm | 25 | 6.5 | 1.93 | No. 2 | 100 | $28.85 | Add to Order |
| MSS-5703 | M3.5 | 0.6 mm | 30 | 6.5 | 1.93 | No. 2 | 50 | $14.89 | Add to Order |
| MSS-5695 | M4 | 0.7 mm | 5 | 7.5 | 2.2 | No. 2 | 100 | $15.75 | Add to Order |
| MSS-5694 | M4 | 0.7 mm | 6 | 7.5 | 2.2 | No. 2 | 100 | $7.25 | Add to Order |
| MSS-5693 | M4 | 0.7 mm | 8 | 7.5 | 2.2 | No. 2 | 100 | $8.34 | Add to Order |
| MSS-5692 | M4 | 0.7 mm | 10 | 7.5 | 2.2 | No. 2 | 100 | $6.72 | Add to Order |
| MSS-5691 | M4 | 0.7 mm | 12 | 7.5 | 2.2 | No. 2 | 100 | $7.27 | Add to Order |
| MSS-5690 | M4 | 0.7 mm | 14 | 7.5 | 2.2 | No. 2 | 100 | $10.08 | Add to Order |
| MSS-5689 | M4 | 0.7 mm | 16 | 7.5 | 2.2 | No. 2 | 100 | $9.24 | Add to Order |
| MSS-10321 | M4 | 0.7 mm | 18 | 7.5 | 2.2 | No. 2 | 100 | $10.92 | Add to Order |
| MSS-5688 | M4 | 0.7 mm | 20 | 7.5 | 2.2 | No. 2 | 100 | $9.37 | Add to Order |
| MSS-10322 | M4 | 0.7 mm | 22 | 7.5 | 2.2 | No. 2 | 100 | $19.09 | Add to Order |
| MSS-5759 | M4 | 0.7 mm | 25 | 7.5 | 2.2 | No. 2 | 100 | $16.80 | Add to Order |
| MSS-5751 | M4 | 0.7 mm | 30 | 7.5 | 2.2 | No. 2 | 100 | $23.06 | Add to Order |
| MSS-5744 | M4 | 0.7 mm | 35 | 7.5 | 2.2 | No. 2 | 100 | $17.87 | Add to Order |
| MSS-5753 | M4 | 0.7 mm | 40 | 7.5 | 2.2 | No. 2 | 50 | $24.89 | Add to Order |
| MSS-5754 | M4 | 0.7 mm | 45 | 7.5 | 2.2 | No. 2 | 50 | $18.52 | Add to Order |
| MSS-5755 | M4 | 0.7 mm | 50 | 7.5 | 2.2 | No. 2 | 50 | $15.44 | Add to Order |
| MSS-5756 | M4 | 0.7 mm | 60 | 7.5 | 2.2 | No. 2 | 50 | $14.32 | Add to Order |
| MSS-5757 | M4 | 0.7 mm | 70 | 7.5 | 2.2 | No. 2 | 25 | $31.50 | Add to Order |
| MSS-5711 | M4 | 0.7 mm | 80 | 7.5 | 2.2 | No. 2 | 25 | $17.85 | Add to Order |
| MSS-4775 | M5 | 0.8 mm | 6 | 9.2 | 2.5 | No. 2 | 100 | $11.49 | Add to Order |
| MSS-5761 | M5 | 0.8 mm | 8 | 9.2 | 2.5 | No. 2 | 100 | $10.98 | Add to Order |
| MSS-5727 | M5 | 0.8 mm | 10 | 9.2 | 2.5 | No. 2 | 100 | $13.61 | Add to Order |
| MSS-5667 | M5 | 0.8 mm | 12 | 9.2 | 2.5 | No. 2 | 100 | $14.05 | Add to Order |
| MSS-5668 | M5 | 0.8 mm | 14 | 9.2 | 2.5 | No. 2 | 100 | $16.15 | Add to Order |
| MSS-4780 | M5 | 0.8 mm | 16 | 9.2 | 2.5 | No. 2 | 100 | $16.36 | Add to Order |
| MSS-10323 | M5 | 0.8 mm | 18 | 9.2 | 2.5 | No. 2 | 100 | $20.37 | Add to Order |
| MSS-5687 | M5 | 0.8 mm | 20 | 9.2 | 2.5 | No. 2 | 100 | $17.28 | Add to Order |
| MSS-5686 | M5 | 0.8 mm | 25 | 9.2 | 2.5 | No. 2 | 100 | $25.20 | Add to Order |
| MSS-5520 | M5 | 0.8 mm | 30 | 9.2 | 2.5 | No. 2 | 100 | $25.20 | Add to Order |
| MSS-5012 | M5 | 0.8 mm | 35 | 9.2 | 2.5 | No. 2 | 100 | $26.15 | Add to Order |
| MSS-5685 | M5 | 0.8 mm | 40 | 9.2 | 2.5 | No. 2 | 100 | $31.25 | Add to Order |
| MSS-5000 | M5 | 0.8 mm | 50 | 9.2 | 2.5 | No. 2 | 100 | $33.20 | Add to Order |
| MSS-5026 | M5 | 0.8 mm | 60 | 9.2 | 2.5 | No. 2 | 25 | $16.76 | Add to Order |
| MSS-5027 | M5 | 0.8 mm | 70 | 9.2 | 2.5 | No. 2 | 25 | $34.78 | Add to Order |
| MSS-5028 | M5 | 0.8 mm | 80 | 9.2 | 2.5 | No. 2 | 10 | $15.58 | Add to Order |
| MSS-5029 | M6 | 1 mm | 8 | 11 | 3 | No. 3 | 50 | $22.30 | Add to Order |
| MSS-5030 | M6 | 1 mm | 10 | 11 | 3 | No. 3 | 100 | $21.34 | Add to Order |
| MSS-5031 | M6 | 1 mm | 12 | 11 | 3 | No. 3 | 100 | $22.79 | Add to Order |
| MSS-10324 | M6 | 1 mm | 14 | 11 | 3 | No. 3 | 100 | $20.16 | Add to Order |
| MSS-5032 | M6 | 1 mm | 16 | 11 | 3 | No. 3 | 100 | $24.09 | Add to Order |
| MSS-10325 | M6 | 1 mm | 18 | 11 | 3 | No. 3 | 100 | $30.01 | Add to Order |
| MSS-5033 | M6 | 1 mm | 20 | 11 | 3 | No. 3 | 100 | $26.71 | Add to Order |
| MSS-5034 | M6 | 1 mm | 25 | 11 | 3 | No. 3 | 100 | $29.32 | Add to Order |
| MSS-5048 | M6 | 1 mm | 30 | 11 | 3 | No. 3 | 100 | $29.46 | Add to Order |
| MSS-5036 | M6 | 1 mm | 35 | 11 | 3 | No. 3 | 100 | $33.45 | Add to Order |
| MSS-5025 | M6 | 1 mm | 40 | 11 | 3 | No. 3 | 50 | $17.77 | Add to Order |
| MSS-5038 | M6 | 1 mm | 45 | 11 | 3 | No. 3 | 50 | $12.71 | Add to Order |
| MSS-5039 | M6 | 1 mm | 50 | 11 | 3 | No. 3 | 50 | $26.46 | Add to Order |
| MSS-5040 | M6 | 1 mm | 60 | 11 | 3 | No. 3 | 25 | $18.33 | Add to Order |
| MSS-5041 | M6 | 1 mm | 70 | 11 | 3 | No. 3 | 10 | $14.78 | Add to Order |
| MSS-5042 | M6 | 1 mm | 80 | 11 | 3 | No. 3 | 10 | $19.07 | Add to Order |
| MSS-5043 | M8 | 1.25 mm | 12 | 14.5 | 4 | No. 4 | 10 | $19.40 | Add to Order |
| MSS-10326 | M8 | 1.25 mm | 14 | 14.5 | 4 | No. 4 | 10 | $18.00 | Add to Order |
| MSS-5044 | M8 | 1.25 mm | 16 | 14.5 | 4 | No. 4 | 50 | $30.28 | Add to Order |
| MSS-5045 | M8 | 1.25 mm | 20 | 14.5 | 4 | No. 4 | 50 | $19.95 | Add to Order |
| MSS-5046 | M8 | 1.25 mm | 25 | 14.5 | 4 | No. 4 | 50 | $33.66 | Add to Order |
| MSS-5014 | M8 | 1.25 mm | 30 | 14.5 | 4 | No. 4 | 25 | $26.86 | Add to Order |
| MSS-5037 | M8 | 1.25 mm | 35 | 14.5 | 4 | No. 4 | 50 | $33.45 | Add to Order |
| MSS-5035 | M8 | 1.25 mm | 40 | 14.5 | 4 | No. 4 | 25 | $18.96 | Add to Order |
| MSS-5003 | M8 | 1.25 mm | 50 | 14.5 | 4 | No. 4 | 25 | $19.61 | Add to Order |
| MSS-5004 | M8 | 1.25 mm | 60 | 14.5 | 4 | No. 4 | 10 | $24.97 | Add to Order |
| MSS-5005 | M8 | 1.25 mm | 80 | 14.5 | 4 | No. 4 | 5 | $20.03 | Add to Order |
| Rev. 10-23, 08-23, 02-23, 11-22 | |||||||||
