Brass Flat Head Phillips Metric Machine Screws
Machine Screws - Metric Flat Head Phillips Drive, Class 6g, DIN 965, Fully Threaded, 90° Bevel under head
Brass - Nonmagnetic and good corrosion resistance
| Metric Brass FT Phillips Flat Head Machine Screws | |||||||||
| Part # | Thread Size (mm) | Pitch (mm) | Length (mm) | Head Dia. (mm) | Head Height (mm) | Drive | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| MSS-5775 | M3 | 0.5 mm | 6 | 5.6 | 1.65 | No. 1 | 100 | $20.94 | Add to Order |
| MSS-4787 | M3 | 0.5 mm | 8 | 5.6 | 1.65 | No. 1 | 100 | $24.82 | Add to Order |
| MSS-5767 | M3 | 0.5 mm | 10 | 5.6 | 1.65 | No. 1 | 100 | $23.54 | Add to Order |
| MSS-5760 | M4 | 0.7 mm | 8 | 7.5 | 2.2 | No. 2 | 50 | $19.06 | Add to Order |
| MSS-5769 | M4 | 0.7 mm | 10 | 7.5 | 2.2 | No. 2 | 50 | $19.60 | Add to Order |
| MSS-4793 | M4 | 0.7 mm | 12 | 7.5 | 2.2 | No. 2 | 25 | $11.76 | Add to Order |
| MSS-5770 | M5 | 0.8 mm | 10 | 9.2 | 2.5 | No. 2 | 25 | $17.62 | Add to Order |
| MSS-5771 | M5 | 0.8 mm | 12 | 9.2 | 2.5 | No. 2 | 25 | $17.86 | Add to Order |
| MSS-5772 | M5 | 0.8 mm | 16 | 9.2 | 2.5 | No. 2 | 10 | $11.18 | Add to Order |
| MSS-5773 | M6 | 1 mm | 12 | 11 | 3 | No. 3 | 10 | $12.56 | Add to Order |
| MSS-5774 | M6 | 1 mm | 16 | 11 | 3 | No. 3 | 10 | $13.54 | Add to Order |
| MSS-5752 | M6 | 1 mm | 20 | 11 | 3 | No. 3 | 10 | $14.90 | Add to Order |
| MSS-10359 | M6 | 1 mm | 25 | 11 | 3 | No. 3 | 10 | $11.58 | Add to Order |
| Rev. 03-25, 08-23, 11-22, 03-22 | |||||||||
