2024 Aluminum Flat Head Phillips Machine Screws
Machine Screws - Flat Head Slotted Drive, Class 2A, Fully Threaded, Bevel under head
2024-T4 Aluminum Alloy - Heat treated, nonmagnetic, mild resistance to corrosion due to weather
| 2024 Aluminum FT Flat Head Phillips Machine Screws | |||||||||
| Part # | Thread Size | Length | Type | Head Dia. | Head Height | Drive Size | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| MSS-10360 | 4-40 | 3/16" | Undercut | 0.215" | 0.067" | No. 1 | 10 | $18.86 | Add to Order |
| MSS-10361 | 4-40 | 1/4" | Standard | 0.215" | 0.067" | No. 1 | 10 | $19.14 | Add to Order |
| MSS-10362 | 4-40 | 5/16" | Standard | 0.215" | 0.067" | No. 1 | 10 | $19.42 | Add to Order |
| MSS-10363 | 4-40 | 3/8" | Standard | 0.215" | 0.067" | No. 1 | 5 | $9.44 | Add to Order |
| MSS-10364 | 4-40 | 1/2" | Standard | 0.215" | 0.067" | No. 1 | 10 | $18.86 | Add to Order |
| MSS-10365 | 4-40 | 3/4" | Standard | 0.215" | 0.067" | No. 1 | 10 | $19.14 | Add to Order |
| MSS-10366 | 4-40 | 1" | Standard | 0.215" | 0.067" | No. 1 | 10 | $19.42 | Add to Order |
| MSS-10367 | 6-32 | 3/16" | Undercut | 0.262" | 0.083" | No. 2 | 10 | $18.58 | Add to Order |
| MSS-10368 | 6-32 | 1/4" | Standard | 0.262" | 0.083" | No. 2 | 10 | $18.86 | Add to Order |
| MSS-10369 | 6-32 | 3/8" | Standard | 0.262" | 0.083" | No. 2 | 10 | $19.14 | Add to Order |
| MSS-10370 | 6-32 | 1/2" | Standard | 0.262" | 0.083" | No. 2 | 10 | $19.42 | Add to Order |
| MSS-10371 | 6-32 | 5/8" | Standard | 0.262" | 0.083" | No. 2 | 10 | $19.72 | Add to Order |
| MSS-10372 | 6-32 | 3/4" | Standard | 0.262" | 0.083" | No. 2 | 10 | $20.00 | Add to Order |
| MSS-10373 | 6-32 | 1" | Standard | 0.262" | 0.083" | No. 2 | 10 | $20.28 | Add to Order |
| MSS-10374 | 8-32 | 1/4" | Undercut | 0.312" | 0.1" | No. 2 | 10 | $20.58 | Add to Order |
| MSS-10375 | 8-32 | 3/8" | Standard | 0.312" | 0.1" | No. 2 | 10 | $21.72 | Add to Order |
| MSS-10376 | 8-32 | 1/2" | Standard | 0.312" | 0.1" | No. 2 | 10 | $22.86 | Add to Order |
| MSS-10377 | 8-32 | 3/4" | Standard | 0.312" | 0.1" | No. 2 | 10 | $23.42 | Add to Order |
| MSS-10378 | 8-32 | 1" | Standard | 0.312" | 0.1" | No. 2 | 10 | $24.00 | Add to Order |
| MSS-10379 | 10-24 | 1/2" | Standard | 0.362" | 0.116" | No. 2 | 10 | $23.14 | Add to Order |
| MSS-10380 | 10-24 | 3/4" | Standard | 0.362" | 0.116" | No. 2 | 10 | $24.28 | Add to Order |
| MSS-10381 | 10-24 | 1" | Standard | 0.362" | 0.116" | No. 2 | 10 | $25.42 | Add to Order |
| MSS-10382 | 10-32 | 1/2" | Standard | 0.362" | 0.116" | No. 2 | 10 | $23.14 | Add to Order |
| MSS-10383 | 10-32 | 3/4" | Standard | 0.362" | 0.116" | No. 2 | 10 | $24.28 | Add to Order |
| MSS-10384 | 10-32 | 1" | Standard | 0.362" | 0.116" | No. 2 | 10 | $25.42 | Add to Order |
| MSS-10385 | 1/4"-20 | 1/2" | Standard | 0.507" | 0.153" | No. 3 | 5 | $21.42 | Add to Order |
| MSS-10386 | 1/4"-20 | 3/4" | Standard | 0.507" | 0.153" | No. 3 | 1 | $4.42 | Add to Order |
| MSS-10387 | 1/4"-20 | 1" | Standard | 0.507" | 0.153" | No. 3 | 5 | $22.86 | Add to Order |
| MSS-10388 | 1/4"-20 | 1 1/2" | Standard | 0.507" | 0.153" | No. 3 | 5 | $24.28 | Add to Order |
| MSS-10389 | 5/16"-18 | 3/4" | Standard | 0.635" | 0.191" | No. 4 | 5 | $22.86 | Add to Order |
| MSS-10390 | 5/16"-18 | 1" | Standard | 0.635" | 0.191" | No. 4 | 5 | $24.28 | Add to Order |
| MSS-10391 | 5/16"-18 | 1 1/2" | Standard | 0.635" | 0.191" | No. 4 | 5 | $25.72 | Add to Order |
| MSS-10392B | 5/16"-18 | 2" | Standard | 0.635" | 0.191" | No. 4 | 5 | $27.14 | Add to Order |
| Rev. 11-22, 03-22 | |||||||||
