Metric 316 Stainless Flat Head Phillips Machine Screws
Machine Screws - Metric Flat Head Phillips Drive, Class 6g, DIN 965, Fully Threaded, 90° Bevel under the head.
316 Stainless Steel - Excellent corrosion resistance, withstands chemicals, mildly magnetic.
| Metric 316 Stainless Steel Phillips Flat Head FT Machine Screws | |||||||||
| Part # | Thread Size | Pitch | Length (mm) | Head Dia. (mm) | Head Height (mm) | Drive | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| MSS-10201 | M2 | 0.4 mm | 3 | 3.8 | 1.2 | No. 1 | 50 | $20.16 | Add to Order |
| MSS-5507 | M2 | 0.4 mm | 4 | 3.8 | 1.2 | No. 1 | 50 | $23.00 | Add to Order |
| MSS-5496 | M2 | 0.4 mm | 5 | 3.8 | 1.2 | No. 1 | 25 | $14.36 | Add to Order |
| MSS-5509 | M2 | 0.4 mm | 6 | 3.8 | 1.2 | No. 1 | 25 | $14.62 | Add to Order |
| MSS-5510 | M2 | 0.4 mm | 8 | 3.8 | 1.2 | No. 1 | 25 | $14.85 | Add to Order |
| MSS-5511 | M2 | 0.4 mm | 10 | 3.8 | 1.2 | No. 1 | 25 | $14.99 | Add to Order |
| MSS-10202 | M2 | 0.4 mm | 12 | 3.8 | 1.2 | No. 1 | 100 | $23.52 | Add to Order |
| MSS-10203 | M2 | 0.4 mm | 16 | 3.8 | 1.2 | No. 1 | 100 | $26.88 | Add to Order |
| MSS-10204 | M2 | 0.4 mm | 20 | 3.8 | 1.2 | No. 1 | 100 | $31.92 | Add to Order |
| MSS-10205 | M2.5 | 0.45 mm | 3 | 4.7 | 1.5 | No. 1 | 100 | $31.08 | Add to Order |
| MSS-5512 | M2.5 | 0.45 mm | 4 | 4.7 | 1.5 | No. 1 | 50 | $19.09 | Add to Order |
| MSS-5513 | M2.5 | 0.45 mm | 5 | 4.7 | 1.5 | No. 1 | 25 | $11.40 | Add to Order |
| MSS-5514 | M2.5 | 0.45 mm | 6 | 4.7 | 1.5 | No. 1 | 25 | $12.18 | Add to Order |
| MSS-5515 | M2.5 | 0.45 mm | 8 | 4.7 | 1.5 | No. 1 | 25 | $12.73 | Add to Order |
| MSS-10206 | M2.5 | 0.45 mm | 10 | 4.7 | 1.5 | No. 1 | 100 | $24.36 | Add to Order |
| MSS-10207 | M2.5 | 0.45 mm | 12 | 4.7 | 1.5 | No. 1 | 100 | $33.60 | Add to Order |
| MSS-10208 | M2.5 | 0.45 mm | 16 | 4.7 | 1.5 | No. 1 | 100 | $30.24 | Add to Order |
| MSS-5516 | M3 | 0.5 mm | 4 | 5.6 | 1.65 | No. 1 | 25 | $21.19 | Add to Order |
| MSS-5517 | M3 | 0.5 mm | 5 | 5.6 | 1.65 | No. 1 | 50 | $4.12 | Add to Order |
| MSS-5518 | M3 | 0.5 mm | 6 | 5.6 | 1.65 | No. 1 | 50 | $5.84 | Add to Order |
| MSS-5376 | M3 | 0.5 mm | 8 | 5.6 | 1.65 | No. 1 | 50 | $7.25 | Add to Order |
| MSS-5402 | M3 | 0.5 mm | 10 | 5.6 | 1.65 | No. 1 | 50 | $8.51 | Add to Order |
| MSS-5403 | M3 | 0.5 mm | 12 | 5.6 | 1.65 | No. 1 | 100 | $16.19 | Add to Order |
| MSS-10209 | M3 | 0.5 mm | 14 | 5.6 | 1.65 | No. 1 | 100 | $26.88 | Add to Order |
| MSS-5404 | M3 | 0.5 mm | 16 | 5.6 | 1.65 | No. 1 | 50 | $11.91 | Add to Order |
| MSS-10210 | M3 | 0.5 mm | 18 | 5.6 | 1.65 | No. 1 | 50 | $21.00 | Add to Order |
| MSS-5405 | M3 | 0.5 mm | 20 | 5.6 | 1.65 | No. 1 | 50 | $11.30 | Add to Order |
| MSS-10211 | M3 | 0.5 mm | 25 | 5.6 | 1.65 | No. 1 | 50 | $23.10 | Add to Order |
| MSS-10212 | M3 | 0.5 mm | 30 | 5.6 | 1.65 | No. 1 | 50 | $31.50 | Add to Order |
| MSS-10213 | M3 | 0.5 mm | 40 | 5.6 | 1.65 | No. 1 | 25 | $15.75 | Add to Order |
| MSS-10214 | M4 | 0.7 mm | 5 | 7.5 | 2.2 | No. 2 | 50 | $19.74 | Add to Order |
| MSS-5406 | M4 | 0.7 mm | 6 | 7.5 | 2.2 | No. 2 | 100 | $24.19 | Add to Order |
| MSS-5407 | M4 | 0.7 mm | 8 | 7.5 | 2.2 | No. 2 | 100 | $18.61 | Add to Order |
| MSS-5408 | M4 | 0.7 mm | 10 | 7.5 | 2.2 | No. 2 | 50 | $8.72 | Add to Order |
| MSS-5409 | M4 | 0.7 mm | 12 | 7.5 | 2.2 | No. 2 | 50 | $8.84 | Add to Order |
| MSS-10215 | M4 | 0.7 mm | 14 | 7.5 | 2.2 | No. 2 | 50 | $25.20 | Add to Order |
| MSS-5410 | M4 | 0.7 mm | 16 | 7.5 | 2.2 | No. 2 | 50 | $9.11 | Add to Order |
| MSS-10216 | M4 | 0.7 mm | 18 | 7.5 | 2.2 | No. 2 | 50 | $29.40 | Add to Order |
| MSS-5424 | M4 | 0.7 mm | 20 | 7.5 | 2.2 | No. 2 | 50 | $13.84 | Add to Order |
| MSS-5412 | M4 | 0.7 mm | 25 | 7.5 | 2.2 | No. 2 | 50 | $20.73 | Add to Order |
| MSS-10217 | M4 | 0.7 mm | 30 | 7.5 | 2.2 | No. 2 | 50 | $32.76 | Add to Order |
| MSS-10218 | M4 | 0.7 mm | 40 | 7.5 | 2.2 | No. 2 | 25 | $27.30 | Add to Order |
| MSS-10219 | M4 | 0.7 mm | 50 | 7.5 | 2.2 | No. 2 | 25 | $36.96 | Add to Order |
| MSS-10220 | M5 | 0.8 mm | 6 | 9.2 | 2.5 | No. 2 | 50 | $25.20 | Add to Order |
| MSS-10221 | M5 | 0.8 mm | 8 | 9.2 | 2.5 | No. 2 | 50 | $26.04 | Add to Order |
| MSS-5401 | M5 | 0.8 mm | 10 | 9.2 | 2.5 | No. 2 | 50 | $15.16 | Add to Order |
| MSS-5414 | M5 | 0.8 mm | 12 | 9.2 | 2.5 | No. 2 | 50 | $26.02 | Add to Order |
| MSS-10222 | M5 | 0.8 mm | 14 | 9.2 | 2.5 | No. 2 | 50 | $33.60 | Add to Order |
| MSS-5415 | M5 | 0.8 mm | 16 | 9.2 | 2.5 | No. 2 | 25 | $10.02 | Add to Order |
| MSS-5416 | M5 | 0.8 mm | 20 | 9.2 | 2.5 | No. 2 | 25 | $9.49 | Add to Order |
| MSS-5417 | M5 | 0.8 mm | 25 | 9.2 | 2.5 | No. 2 | 25 | $14.89 | Add to Order |
| MSS-5418 | M5 | 0.8 mm | 30 | 9.2 | 2.5 | No. 2 | 25 | $11.70 | Add to Order |
| MSS-5419 | M5 | 0.8 mm | 40 | 9.2 | 2.5 | No. 2 | 10 | $9.37 | Add to Order |
| MSS-10223 | M6 | 1 mm | 8 | 11 | 3 | No. 3 | 50 | $35.70 | Add to Order |
| MSS-5420 | M6 | 1 mm | 10 | 11 | 3 | No. 3 | 25 | $14.51 | Add to Order |
| MSS-5421 | M6 | 1 mm | 12 | 11 | 3 | No. 3 | 25 | $15.29 | Add to Order |
| MSS-10224 | M6 | 1 mm | 14 | 11 | 3 | No. 3 | 25 | $31.50 | Add to Order |
| MSS-5422 | M6 | 1 mm | 16 | 11 | 3 | No. 3 | 25 | $11.47 | Add to Order |
| MSS-10225 | M6 | 1 mm | 18 | 11 | 3 | No. 3 | 25 | $37.80 | Add to Order |
| MSS-5390 | M6 | 1 mm | 20 | 11 | 3 | No. 3 | 25 | $13.02 | Add to Order |
| MSS-5413 | M6 | 1 mm | 25 | 11 | 3 | No. 3 | 10 | $9.37 | Add to Order |
| MSS-5411 | M6 | 1 mm | 30 | 11 | 3 | No. 3 | 10 | $7.69 | Add to Order |
| MSS-5379 | M6 | 1 mm | 35 | 11 | 3 | No. 3 | 10 | $12.12 | Add to Order |
| MSS-5380 | M6 | 1 mm | 40 | 11 | 3 | No. 3 | 10 | $11.97 | Add to Order |
| MSS-10226 | M6 | 1 mm | 50 | 11 | 3 | No. 3 | 10 | $18.48 | Add to Order |
| MSS-5381 | M8 | 1.25 mm | 12 | 14.5 | 4 | No. 4 | 5 | $14.66 | Add to Order |
| MSS-5382 | M8 | 1.25 mm | 16 | 14.5 | 4 | No. 4 | 5 | $20.64 | Add to Order |
| MSS-5383 | M8 | 1.25 mm | 20 | 14.5 | 4 | No. 4 | 5 | $16.46 | Add to Order |
| MSS-5384 | M8 | 1.25 mm | 25 | 14.5 | 4 | No. 4 | 5 | $18.59 | Add to Order |
| MSS-10227 | M8 | 1.25 mm | 30 | 14.5 | 4 | No. 4 | 10 | $29.32 | Add to Order |
| MSS-10228 | M8 | 1.25 mm | 40 | 14.5 | 4 | No. 4 | 10 | $46.20 | Add to Order |
| MSS-10229 | M10 | 1.5 mm | 20 | 18 | 5 | No. 4 | 5 | $31.50 | Add to Order |
| MSS-10230 | M10 | 1.5 mm | 25 | 18 | 5 | No. 4 | 5 | $29.40 | Add to Order |
| MSS-10231 | M10 | 1.5 mm | 30 | 18 | 5 | No. 4 | 5 | $34.44 | Add to Order |
| Rev. 10-23, 08-23, 02-23, 11-22 | |||||||||
