18-8 Stainless Steel Flat Head Phillips Machine Screws, Black Oxide Coated
Machine Screws - Flat Head Phillips Drive, Black Oxide Coated, Class 2A, fully threaded, 82° bevel under head provides flush surface within countersunk holes.
18-8 Stainless Steel - Excellent corrosion resistance, mildly magnetic, Rockwell hardness is B80, tensile strength 75,000 psi.
.JPG)
| Black Oxide 18-8 Stainless Steel Phillips Drive Flat Head Machine Screws | |||||||||
| Part # | Thread Size | Length | Type | Head Dia. | Head Height | Drive Size | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| MSS-10073 | 0-80 | 1/8" | Undercut | 0.112" | 0.025" | No. 0 | 100 | $19.12 | Add to Order |
| MSS-10074 | 0-80 | 3/16" | Standard | 0.112" | 0.035" | No. 0 | 100 | $19.38 | Add to Order |
| MSS-10075 | 0-80 | 1/4" | Standard | 0.112" | 0.035" | No. 0 | 100 | $20.88 | Add to Order |
| MSS-6424 | 2-56 | 1/8" | Undercut | 0.162" | 0.036" | No. 1 | 100 | $10.76 | Add to Order |
| MSS-4790 | 2-56 | 3/16" | Standard | 0.162" | 0.051" | No. 1 | 100 | $14.06 | Add to Order |
| MSS-4791 | 2-56 | 1/4" | Standard | 0.162" | 0.051" | No. 1 | 100 | $9.22 | Add to Order |
| MSS-6393 | 2-56 | 5/16" | Standard | 0.162" | 0.051" | No. 1 | 100 | $13.90 | Add to Order |
| MSS-4792 | 2-56 | 3/8" | Standard | 0.162" | 0.051" | No. 1 | 100 | $10.44 | Add to Order |
| MSS-5931 | 2-56 | 1/2" | Standard | 0.162" | 0.051" | No. 1 | 100 | $11.46 | Add to Order |
| MSS-10076 | 2-56 | 5/8" | Standard | 0.162" | 0.051" | No. 1 | 100 | $13.18 | Add to Order |
| MSS-6394 | 4-40 | 1/8" | Undercut | 0.212" | 0.047" | No. 1 | 100 | $11.56 | Add to Order |
| MSS-6395 | 4-40 | 3/16" | Undercut | 0.212" | 0.047" | No. 1 | 100 | $11.58 | Add to Order |
| MSS-4761 | 4-40 | 1/4" | Standard | 0.212" | 0.067" | No. 1 | 100 | $9.86 | Add to Order |
| MSS-6396 | 4-40 | 5/16" | Standard | 0.212" | 0.067" | No. 1 | 100 | $12.62 | Add to Order |
| MSS-5922 | 4-40 | 3/8" | Standard | 0.212" | 0.067" | No. 1 | 100 | $12.40 | Add to Order |
| MSS-6397 | 4-40 | 7/16" | Standard | 0.212" | 0.067" | No. 1 | 100 | $16.52 | Add to Order |
| MSS-5923 | 4-40 | 1/2" | Standard | 0.212" | 0.067" | No. 1 | 100 | $16.86 | Add to Order |
| MSS-6398 | 4-40 | 5/8" | Standard | 0.212" | 0.067" | No. 1 | 100 | $15.46 | Add to Order |
| MSS-6399 | 4-40 | 3/4" | Standard | 0.212" | 0.067" | No. 1 | 100 | $16.12 | Add to Order |
| MSS-6400 | 4-40 | 1" | Standard | 0.212" | 0.067" | No. 1 | 100 | $21.14 | Add to Order |
| MSS-10077 | 4-40 | 1 1/4" | Standard | 0.212" | 0.067" | No. 1 | 100 | $19.76 | Add to Order |
| MSS-10078 | 4-40 | 1 1/2" | Standard | 0.212" | 0.067" | No. 1 | 100 | $23.38 | Add to Order |
| MSS-5924 | 6-32 | 1/4" | Standard | 0.262" | 0.083" | No. 2 | 100 | $15.00 | Add to Order |
| MSS-4751 | 6-32 | 5/16" | Standard | 0.262" | 0.083" | No. 2 | 100 | $14.96 | Add to Order |
| MSS-5926 | 6-32 | 3/8" | Standard | 0.262" | 0.083" | No. 2 | 100 | $17.02 | Add to Order |
| MSS-10079 | 6-32 | 7/16" | Standard | 0.262" | 0.083" | No. 2 | 100 | $23.92 | Add to Order |
| MSS-5927 | 6-32 | 1/2" | Standard | 0.262" | 0.083" | No. 2 | 100 | $18.36 | Add to Order |
| MSS-4754 | 6-32 | 5/8" | Standard | 0.262" | 0.083" | No. 2 | 100 | $26.06 | Add to Order |
| MSS-5940 | 6-32 | 3/4" | Standard | 0.262" | 0.083" | No. 2 | 100 | $21.42 | Add to Order |
| MSS-10080 | 6-32 | 7/8" | Standard | 0.262" | 0.083" | No. 2 | 100 | $21.38 | Add to Order |
| MSS-6413 | 6-32 | 1" | Standard | 0.262" | 0.083" | No. 2 | 100 | $24.58 | Add to Order |
| MSS-10081 | 6-32 | 1 1/4" | Standard | 0.262" | 0.083" | No. 2 | 50 | $13.72 | Add to Order |
| MSS-6402 | 6-32 | 1 1/2" | Standard | 0.262" | 0.083" | No. 2 | 50 | $17.94 | Add to Order |
| MSS-6391 | 6-32 | 2" | Standard | 0.262" | 0.083" | No. 2 | 50 | $26.46 | Add to Order |
| MSS-6404 | 8-32 | 1/4" | Undercut | 0.312" | 0.07" | No. 2 | 100 | $19.34 | Add to Order |
| MSS-10082 | 8-32 | 5/16" | Standard | 0.312" | 0.1" | No. 2 | 100 | $19.16 | Add to Order |
| MSS-4756 | 8-32 | 3/8" | Standard | 0.312" | 0.1" | No. 2 | 100 | $19.70 | Add to Order |
| MSS-10083 | 8-32 | 7/16" | Standard | 0.312" | 0.1" | No. 2 | 100 | $21.42 | Add to Order |
| MSS-5920 | 8-32 | 1/2" | Standard | 0.312" | 0.1" | No. 2 | 100 | $25.06 | Add to Order |
| MSS-5932 | 8-32 | 5/8" | Standard | 0.312" | 0.1" | No. 2 | 100 | $32.42 | Add to Order |
| MSS-4771 | 8-32 | 3/4" | Standard | 0.312" | 0.1" | No. 2 | 100 | $29.90 | Add to Order |
| MSS-10084 | 8-32 | 1" | Standard | 0.312" | 0.1" | No. 2 | 50 | $13.46 | Add to Order |
| MSS-10085 | 8-32 | 1 1/4" | Standard | 0.312" | 0.1" | No. 2 | 50 | $23.24 | Add to Order |
| MSS-10086 | 8-32 | 1 1/2" | Standard | 0.312" | 0.1" | No. 2 | 50 | $23.48 | Add to Order |
| MSS-5934 | 10-24 | 3/8" | Standard | 0.362" | 0.116" | No. 2 | 50 | $17.98 | Add to Order |
| MSS-5935 | 10-24 | 1/2" | Standard | 0.362" | 0.116" | No. 2 | 50 | $19.26 | Add to Order |
| MSS-10087 | 10-24 | 5/8" | Standard | 0.362" | 0.116" | No. 2 | 50 | $18.22 | Add to Order |
| MSS-4762 | 10-24 | 3/4" | Standard | 0.362" | 0.116" | No. 2 | 50 | $23.54 | Add to Order |
| MSS-5937 | 10-24 | 1" | Standard | 0.362" | 0.116" | No. 2 | 50 | $30.00 | Add to Order |
| MSS-10088 | 10-24 | 1 1/4" | Standard | 0.362" | 0.116" | No. 2 | 25 | $13.98 | Add to Order |
| MSS-10089 | 10-24 | 1 1/2" | Standard | 0.362" | 0.116" | No. 2 | 25 | $16.16 | Add to Order |
| MSS-4764 | 10-32 | 3/8" | Standard | 0.362" | 0.116" | No. 2 | 50 | $18.00 | Add to Order |
| MSS-4765 | 10-32 | 1/2" | Standard | 0.362" | 0.116" | No. 2 | 50 | $19.26 | Add to Order |
| MSS-4766 | 10-32 | 5/8" | Standard | 0.362" | 0.116" | No. 2 | 50 | $20.34 | Add to Order |
| MSS-4767 | 10-32 | 3/4" | Standard | 0.362" | 0.116" | No. 2 | 50 | $23.54 | Add to Order |
| MSS-4768 | 10-32 | 1" | Standard | 0.362" | 0.116" | No. 2 | 50 | $30.00 | Add to Order |
| MSS-10090 | 10-32 | 1 1/4" | Standard | 0.362" | 0.116" | No. 2 | 25 | $14.92 | Add to Order |
| MSS-10091 | 10-32 | 1 1/2" | Standard | 0.362" | 0.116" | No. 2 | 25 | $16.90 | Add to Order |
| MSS-4769 | 1/4"-20 | 1/2" | Standard | 0.477" | 0.153" | No. 3 | 50 | $31.74 | Add to Order |
| MSS-10092 | 1/4"-20 | 5/8" | Standard | 0.477" | 0.153" | No. 3 | 50 | $21.04 | Add to Order |
| MSS-4770 | 1/4"-20 | 3/4" | Standard | 0.477" | 0.153" | No. 3 | 25 | $20.62 | Add to Order |
| MSS-4834 | 1/4"-20 | 1" | Standard | 0.477" | 0.153" | No. 3 | 25 | $22.78 | Add to Order |
| MSS-5399 | 1/4"-20 | 1 1/4" | Standard | 0.477" | 0.153" | No. 3 | 25 | $31.58 | Add to Order |
| MSS-5905 | 1/4"-20 | 1 1/2" | Standard | 0.477" | 0.153" | No. 3 | 10 | $14.82 | Add to Order |
| MSS-10093 | 1/4"-20 | 2" | Standard | 0.477" | 0.153" | No. 3 | 10 | $15.56 | Add to Order |
| MSS-10094 | 5/16"-18 | 1" | Standard | 0.597" | 0.191" | No. 4 | 10 | $18.80 | Add to Order |
| MSS-10095 | 5/16"-18 | 1 1/2" | Standard | 0.597" | 0.191" | No. 4 | 10 | $23.72 | Add to Order |
| Rev. 06-24, 08-23, 11-22, 03-22 | |||||||||
