Zinc Plated Slotted Fillister Head Machine Screws
Machine Screws - Fillister Head Slotted Drive, Zinc Plated, Class 2A, *Fully Threaded.
Steel / Zinc Plated - Good Rust Resistance.
| Zinc Plated Steel Slotted Fillister Head FT Machine Screws | |||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| MSS-9315 | 4-40 | 3/16" | 0.183" | 0.107" | 100 | $20.16 | Add to Order |
| MSS-4938 | 4-40 | 1/4" | 0.183" | 0.107" | 100 | $12.31 | Add to Order |
| MSS-4939 | 4-40 | 3/8" | 0.183" | 0.107" | 100 | $13.55 | Add to Order |
| MSS-4940 | 4-40 | 1/2" | 0.183" | 0.107" | 100 | $14.34 | Add to Order |
| MSS-9316 | 4-40 | 3/4" | 0.183" | 0.107" | 100 | $23.23 | Add to Order |
| MSS-4941 | 6-32 | 1/4" | 0.226" | 0.132" | 100 | $12.79 | Add to Order |
| MSS-4942 | 6-32 | 5/16" | 0.226" | 0.132" | 100 | $9.05 | Add to Order |
| MSS-4943 | 6-32 | 3/8" | 0.226" | 0.132" | 100 | $9.09 | Add to Order |
| MSS-4944 | 6-32 | 1/2" | 0.226" | 0.132" | 100 | $11.05 | Add to Order |
| MSS-4945 | 6-32 | 5/8" | 0.226" | 0.132" | 100 | $28.67 | Add to Order |
| MSS-4946 | 6-32 | 3/4" | 0.226" | 0.132" | 100 | $6.83 | Add to Order |
| MSS-4959 | 6-32 | 1" | 0.226" | 0.132" | 100 | $22.98 | Add to Order |
| MSS-4948 | 8-32 | 1/4" | 0.270" | 0.156" | 100 | $12.31 | Add to Order |
| MSS-4937 | 8-32 | 5/16" | 0.270" | 0.156" | 100 | $13.17 | Add to Order |
| MSS-4950 | 8-32 | 3/8" | 0.270" | 0.156" | 100 | $9.95 | Add to Order |
| MSS-4951 | 8-32 | 1/2" | 0.270" | 0.156" | 100 | $12.87 | Add to Order |
| MSS-4952 | 8-32 | 5/8" | 0.270" | 0.156" | 100 | $16.17 | Add to Order |
| MSS-4953 | 8-32 | 3/4" | 0.270" | 0.156" | 100 | $11.51 | Add to Order |
| MSS-4954 | 8-32 | 1" | 0.270" | 0.156" | 100 | $17.60 | Add to Order |
| MSS-4955 | 8-32 | 1 1/4" | 0.270" | 0.156" | 100 | $20.92 | Add to Order |
| MSS-4956 | 8-32 | 1 1/2" | 0.270" | 0.156" | 100 | $24.09 | Add to Order |
| MSS-4957 | 10-24 | 3/8" | 0.313" | 0.180" | 100 | $11.82 | Add to Order |
| MSS-5637 | 10-24 | 1/2" | 0.313" | 0.180" | 100 | $12.29 | Add to Order |
| MSS-4914 | 10-24 | 3/4" | 0.313" | 0.180" | 100 | $18.04 | Add to Order |
| MSS-5636 | 10-24 | 1" | 0.313" | 0.180" | 100 | $18.75 | Add to Order |
| MSS-4696 | 10-24 | 1 1/4" | 0.313" | 0.180" | 100 | $21.92 | Add to Order |
| MSS-5618 | 10-24 | 1 1/2" | 0.313" | 0.180" | 100 | $31.29 | Add to Order |
| MSS-4698 | 10-24 | 2" | 0.313" | 0.180" | 50 | $19.40 | Add to Order |
| MSS-4699 | 10-32 | 1/4" | 0.313" | 0.180" | 100 | $15.96 | Add to Order |
| MSS-5603 | 10-32 | 3/8" | 0.313" | 0.180" | 100 | $15.48 | Add to Order |
| MSS-4701 | 10-32 | 1/2" | 0.313" | 0.180" | 100 | $14.97 | Add to Order |
| MSS-4702 | 10-32 | 5/8" | 0.313" | 0.180" | 100 | $17.49 | Add to Order |
| MSS-4703 | 10-32 | 3/4" | 0.313" | 0.180" | 100 | $20.20 | Add to Order |
| MSS-4704 | 10-32 | 1" | 0.313" | 0.180" | 100 | $30.52 | Add to Order |
| MSS-5634 | 10-32 | 1 1/4" | 0.313" | 0.180" | 100 | $25.35 | Add to Order |
| MSS-4706 | 10-32 | 1 1/2" | 0.313" | 0.180" | 100 | $28.37 | Add to Order |
| MSS-5591 | 10-32 | 1 3/4" | 0.313" | 0.180" | 50 | $27.87 | Add to Order |
| MSS-5592 | 10-32 | 2" | 0.313" | 0.180" | 50 | $17.22 | Add to Order |
| MSS-4709 | 12-24 | 1/2" | 0.357" | 0.205" | 100 | $18.69 | Add to Order |
| MSS-5593 | 12-24 | 3/4" | 0.357" | 0.205" | 100 | $22.03 | Add to Order |
| MSS-5594 | 12-24 | 1" | 0.357" | 0.205" | 100 | $27.85 | Add to Order |
| MSS-5595 | 12-24 | 1 1/4" | 0.357" | 0.205" | 50 | $16.46 | Add to Order |
| MSS-5596 | 12-24 | 1 1/2" | 0.357" | 0.205" | 25 | $29.36 | Add to Order |
| MSS-4714 | 12-24 | 2" | 0.357" | 0.205" | 25 | $35.57 | Add to Order |
| MSS-9317B | 1/4"-20 | 3/8" | 0.414" | 0.237" | 50 | $20.60 | Add to Order |
| MSS-5597 | 1/4"-20 | 1/2" | 0.414" | 0.237" | 100 | $22.20 | Add to Order |
| MSS-4716 | 1/4"-20 | 5/8" | 0.414" | 0.237" | 100 | $29.51 | Add to Order |
| MSS-4684 | 1/4"-20 | 3/4" | 0.414" | 0.237" | 100 | $31.86 | Add to Order |
| MSS-4707 | 1/4"-20 | 1" | 0.414" | 0.237" | 100 | $33.56 | Add to Order |
| MSS-5598 | 1/4"-20 | 1 1/4" | 0.414" | 0.237" | 50 | $27.05 | Add to Order |
| MSS-5599 | 1/4"-20 | 1 1/2" | 0.414" | 0.237" | 50 | $30.95 | Add to Order |
| MSS-4674 | 1/4"-20 | 2" | 0.414" | 0.237" | 25 | $30.62 | Add to Order |
| MSS-4675 | 1/4"-20 | 3" | 0.414" | 0.237" | 10 | $24.65 | Add to Order |
| MSS-124 | 5/16"-18 | 3/4" | 0.518" | 0.295" | 50 | $30.35 | Add to Order |
| MSS-125 | 5/16"-18 | 1" | 0.518" | 0.295" | 50 | $40.15 | Add to Order |
| Rev. 03-25, 06-24, 10-23, 08-23 | |||||||
