Brass Fillister Head Slotted Drive Machine Screws
Machine Screws - Fillister Head Slotted Drive, Class 2A, fully threaded, round top and flat bearing surface.
Brass - Nonmagnetic and good corrosion resistance, Rockwell hardness B55, tensile strength 53,000 psi.
| Brass Fillister Head Slotted Machine Screws Full Threads, ASME B18.6.3, Tensile Strength 50,000 PSI |
|||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| MSS-130 | 2-56 | 1/4" | 0.140" | 0.083" | 100 | $14.52 | Add to Order |
| MSS-128 | 2-56 | 3/8" | 0.140" | 0.083" | 100 | $14.85 | Add to Order |
| MSS-096 | 2-56 | 1/2" | 0.140" | 0.083" | 100 | $15.94 | Add to Order |
| MSS-097 | 4-40 | 1/4" | 0.183" | 0.107" | 100 | $14.66 | Add to Order |
| MSS-098 | 4-40 | 3/8" | 0.183" | 0.107" | 100 | $16.72 | Add to Order |
| MSS-099 | 4-40 | 1/2" | 0.183" | 0.107" | 100 | $16.97 | Add to Order |
| MSS-100 | 4-40 | 3/4" | 0.183" | 0.107" | 100 | $22.66 | Add to Order |
| MSS-101 | 6-32 | 1/4" | 0.226" | 0.132" | 100 | $20.75 | Add to Order |
| MSS-102 | 6-32 | 3/8" | 0.226" | 0.132" | 100 | $21.95 | Add to Order |
| MSS-103 | 6-32 | 1/2" | 0.226" | 0.132" | 100 | $26.19 | Add to Order |
| MSS-104 | 6-32 | 5/8" | 0.226" | 0.132" | 100 | $30.16 | Add to Order |
| MSS-117 | 6-32 | 3/4" | 0.226" | 0.132" | 100 | $34.21 | Add to Order |
| MSS-106 | 6-32 | 1" | 0.226" | 0.132" | 100 | $37.25 | Add to Order |
| MSS-095 | 8-32 | 1/4" | 0.270" | 0.156" | 100 | $27.32 | Add to Order |
| MSS-108 | 8-32 | 3/8" | 0.270" | 0.156" | 100 | $27.85 | Add to Order |
| MSS-109 | 8-32 | 1/2" | 0.270" | 0.156" | 100 | $31.46 | Add to Order |
| MSS-110 | 8-32 | 5/8" | 0.270" | 0.156" | 50 | $20.10 | Add to Order |
| MSS-111 | 8-32 | 3/4" | 0.270" | 0.156" | 50 | $22.24 | Add to Order |
| MSS-112 | 8-32 | 1" | 0.270" | 0.156" | 50 | $28.33 | Add to Order |
| MSS-113 | 10-24 | 3/8" | 0.313" | 0.180" | 50 | $24.82 | Add to Order |
| MSS-114 | 10-24 | 1/2" | 0.313" | 0.180" | 50 | $24.00 | Add to Order |
| MSS-115 | 10-24 | 5/8" | 0.313" | 0.180" | 50 | $27.38 | Add to Order |
| MSS-152 | 10-24 | 3/4" | 0.313" | 0.180" | 50 | $29.29 | Add to Order |
| MSS-105 | 10-24 | 1" | 0.313" | 0.180" | 25 | $18.94 | Add to Order |
| MSS-140 | 10-32 | 1/4" | 0.313" | 0.180" | 100 | $39.04 | Add to Order |
| MSS-166 | 10-32 | 3/8" | 0.313" | 0.180" | 50 | $23.63 | Add to Order |
| MSS-167 | 10-32 | 1/2" | 0.313" | 0.180" | 50 | $24.00 | Add to Order |
| MSS-168 | 10-32 | 5/8" | 0.313" | 0.180" | 50 | $27.38 | Add to Order |
| MSS-169 | 10-32 | 3/4" | 0.313" | 0.180" | 50 | $29.29 | Add to Order |
| MSS-170 | 10-32 | 1" | 0.313" | 0.180" | 25 | $18.94 | Add to Order |
| MSS-171 | 1/4"-20 | 3/8" | 0.414" | 0.237" | 25 | $19.82 | Add to Order |
| MSS-172 | 1/4"-20 | 1/2" | 0.414" | 0.237" | 25 | $22.37 | Add to Order |
| MSS-173 | 1/4"-20 | 5/8" | 0.414" | 0.237" | 25 | $24.80 | Add to Order |
| MSS-174 | 1/4"-20 | 3/4" | 0.414" | 0.237" | 25 | $26.73 | Add to Order |
| MSS-3179 | 1/4"-20 | 1" | 0.414" | 0.237" | 50 | $27.28 | Add to Order |
| Rev. 10-23, 08-23, 02-23, 11-22 | |||||||
