Nylon 6/6 Metric Cheese Head Slotted Machine Screws
Machine Screws - Cheese Head Slotted, Class 2A, fully threaded, combines head height and head diameter to maximize driving power.
Nylon 6/6 - Non conductive, chemical and solvent resistant, except mineral acids. Temperature range -40°/+185°F. Absorbs moisture, can affect dimensions and properties. Off White.
| Plastic
Cheese Head Slotted Machine Screws Natural, -40° to 185° |
||||||||
| Part # | Thread Size (mm) | Pitch (mm) | Length (mm) | Head Dia. (mm) | Head Height. (mm) | Pkg Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| MSS-3894 | M2 | 0.4 mm | 8 | 3.8 | 1.3 | 100 | $28.81 | Add to Order |
| MSS-3898 | M2 | 0.4 mm | 10 | 3.8 | 1.3 | 100 | $29.06 | Add to Order |
| MSS-3868 | M2 | 0.4 mm | 12 | 3.8 | 1.3 | 100 | $29.42 | Add to Order |
| MSS-3859 | M2 | 0.4 mm | 16 | 3.8 | 1.3 | 100 | $29.53 | Add to Order |
| MSS-3942 | M3 | 0.5 mm | 5 | 5.5 | 2 | 100 | $28.58 | Add to Order |
| MSS-3863 | M3 | 0.5 mm | 6 | 5.5 | 2 | 100 | $28.58 | Add to Order |
| MSS-3867 | M3 | 0.5 mm | 8 | 5.5 | 2 | 100 | $28.81 | Add to Order |
| MSS-3871 | M3 | 0.5 mm | 10 | 5.5 | 2 | 100 | $29.06 | Add to Order |
| MSS-3875 | M3 | 0.5 mm | 12 | 5.5 | 2 | 100 | $29.42 | Add to Order |
| MSS-3901 | M3 | 0.5 mm | 16 | 5.5 | 2 | 100 | $29.53 | Add to Order |
| MSS-3930 | M3 | 0.5 mm | 20 | 5.5 | 2 | 100 | $29.69 | Add to Order |
| MSS-3935 | M3 | 0.5 mm | 25 | 5.5 | 2 | 100 | $29.90 | Add to Order |
| MSS-3926 | M3 | 0.5 mm | 30 | 5.5 | 2 | 100 | $30.26 | Add to Order |
| MSS-4166 | M4 | 0.7 mm | 6 | 7 | 2.6 | 100 | $31.00 | Add to Order |
| MSS-4170 | M4 | 0.7 mm | 8 | 7 | 2.6 | 100 | $20.75 | Add to Order |
| MSS-4161 | M4 | 0.7 mm | 10 | 7 | 2.6 | 100 | $31.10 | Add to Order |
| MSS-4176 | M4 | 0.7 mm | 12 | 7 | 2.6 | 100 | $31.33 | Add to Order |
| MSS-4179 | M4 | 0.7 mm | 16 | 7 | 2.6 | 100 | $31.46 | Add to Order |
| MSS-4150 | M4 | 0.7 mm | 20 | 7 | 2.6 | 100 | $31.67 | Add to Order |
| MSS-4173 | M4 | 0.7 mm | 25 | 7 | 2.6 | 100 | $31.71 | Add to Order |
| MSS-4141 | M4 | 0.7 mm | 30 | 7 | 2.6 | 100 | $32.66 | Add to Order |
| MSS-4143 | M4 | 0.7 mm | 35 | 7 | 2.6 | 100 | $33.01 | Add to Order |
| MSS-4160 | M5 | 0.8 mm | 8 | 8.5 | 3.3 | 100 | $33.47 | Add to Order |
| MSS-4138 | M5 | 0.8 mm | 10 | 8.5 | 3.3 | 100 | $33.73 | Add to Order |
| MSS-4155 | M5 | 0.8 mm | 12 | 8.5 | 3.3 | 100 | $33.87 | Add to Order |
| MSS-4158 | M5 | 0.8 mm | 16 | 8.5 | 3.3 | 100 | $34.08 | Add to Order |
| MSS-4209 | M5 | 0.8 mm | 20 | 8.5 | 3.3 | 100 | $34.31 | Add to Order |
| MSS-4463 | M5 | 0.8 mm | 25 | 8.5 | 3.3 | 100 | $34.57 | Add to Order |
| MSS-4213 | M5 | 0.8 mm | 30 | 8.5 | 3.3 | 100 | $35.01 | Add to Order |
| MSS-4217 | M5 | 0.8 mm | 40 | 8.5 | 3.3 | 100 | $35.41 | Add to Order |
| MSS-4231 | M6 | 1 mm | 8 | 10 | 3.9 | 100 | $38.49 | Add to Order |
| MSS-4223 | M6 | 1 mm | 10 | 10 | 3.9 | 100 | $35.03 | Add to Order |
| MSS-4226 | M6 | 1 mm | 12 | 10 | 3.9 | 100 | $38.64 | Add to Order |
| MSS-4220 | M6 | 1 mm | 16 | 10 | 3.9 | 100 | $38.87 | Add to Order |
| MSS-4218 | M6 | 1 mm | 20 | 10 | 3.9 | 100 | $39.23 | Add to Order |
| MSS-4190 | M6 | 1 mm | 25 | 10 | 3.9 | 100 | $39.46 | Add to Order |
| MSS-4192 | M6 | 1 mm | 30 | 10 | 3.9 | 100 | $39.94 | Add to Order |
| MSS-4207 | M6 | 1 mm | 35 | 10 | 3.9 | 100 | $40.43 | Add to Order |
| MSS-4200 | M6 | 1 mm | 40 | 10 | 3.9 | 100 | $40.78 | Add to Order |
| MSS-4202 | M6 | 1 mm | 45 | 10 | 3.9 | 100 | $41.01 | Add to Order |
| MSS-4162 | M6 | 1 mm | 50 | 10 | 3.9 | 100 | $41.14 | Add to Order |
| MSS-4444 | M8 | 1.25 mm | 16 | 13 | 5 | 25 | $29.86 | Add to Order |
| MSS-4449 | M8 | 1.25 mm | 20 | 13 | 5 | 25 | $29.93 | Add to Order |
| MSS-4452 | M8 | 1.25 mm | 25 | 13 | 5 | 25 | $30.07 | Add to Order |
| MSS-4457 | M8 | 1.25 mm | 30 | 13 | 5 | 25 | $30.11 | Add to Order |
| MSS-4460 | M8 | 1.25 mm | 50 | 13 | 5 | 25 | $31.67 | Add to Order |
| Rev. 03-24, 08-23, 01-23, 11-22 | ||||||||
