18-8 Stainless Steel Cheese Head Phillips Metric Machine Screws
Machine Screws - Cheese Head Phillips Drive, Class 2A, fully threaded, combines head height and head diameter to maximize driving power, round top and flat bearing surface.
18-8 Stainless Steel - Excellent corrosion resistance, mildly magnetic
| 18-8 Stainless Steel Cheese Head Phillips Machine Screws Passivated, Full Threads, 100,000 PSI Tensile, ASME B18.6.3, ISO 7048 |
|||||||||
| Part # | Thread Size (mm) | Pitch (mm) | Length (mm) | Head Dia. (mm) | Head Height (mm) | Drive Size | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| MSS-6076 | M2 | 0.4 mm | 3 | 3.8 | 1.4 | No. 1 | 50 | $18.90 | Add to Order |
| MSS-6077 | M2 | 0.4 mm | 4 | 3.8 | 1.4 | No. 1 | 50 | $22.43 | Add to Order |
| MSS-6078 | M2 | 0.4 mm | 5 | 3.8 | 1.4 | No. 1 | 50 | $20.03 | Add to Order |
| MSS-6091 | M2 | 0.4 mm | 6 | 3.8 | 1.4 | No. 1 | 50 | $24.04 | Add to Order |
| MSS-7561 | M2 | 0.4 mm | 8 | 3.8 | 1.4 | No. 1 | 100 | $20.60 | Add to Order |
| MSS-6080 | M2.5 | 0.45 mm | 4 | 4.5 | 1.8 | No. 1 | 50 | $21.76 | Add to Order |
| MSS-6070 | M2.5 | 0.45 mm | 6 | 4.5 | 1.8 | No. 1 | 50 | $24.61 | Add to Order |
| MSS-6082 | M2.5 | 0.45 mm | 8 | 4.5 | 1.8 | No. 1 | 50 | $25.64 | Add to Order |
| MSS-6083 | M2.5 | 0.45 mm | 10 | 4.5 | 1.8 | No. 1 | 50 | $26.90 | Add to Order |
| MSS-6084 | M3 | 0.5 mm | 4 | 5.5 | 2 | No. 2 | 50 | $26.90 | Add to Order |
| MSS-7562 | M3 | 0.5 mm | 5 | 5.5 | 2 | No. 2 | 100 | $37.78 | Add to Order |
| MSS-6085 | M3 | 0.5 mm | 6 | 5.5 | 2 | No. 2 | 50 | $27.70 | Add to Order |
| MSS-6086 | M3 | 0.5 mm | 8 | 5.5 | 2 | No. 2 | 50 | $28.10 | Add to Order |
| MSS-6087 | M3 | 0.5 mm | 10 | 5.5 | 2 | No. 2 | 50 | $28.50 | Add to Order |
| MSS-7563 | M3 | 0.5 mm | 12 | 5.5 | 2 | No. 2 | 50 | $29.19 | Add to Order |
| MSS-7564 | M4 | 0.7 mm | 6 | 7 | 2.6 | No. 2 | 25 | $24.04 | Add to Order |
| MSS-6088 | M4 | 0.7 mm | 8 | 7 | 2.6 | No. 2 | 25 | $20.92 | Add to Order |
| MSS-6089 | M4 | 0.7 mm | 10 | 7 | 2.6 | No. 2 | 25 | $21.76 | Add to Order |
| MSS-6090 | M4 | 0.7 mm | 12 | 7 | 2.6 | No. 2 | 25 | $24.91 | Add to Order |
| MSS-7565 | M4 | 0.7 mm | 16 | 7 | 2.6 | No. 2 | 25 | $26.33 | Add to Order |
| MSS-6116 | M5 | 0.8 mm | 8 | 8.5 | 3.3 | No. 2 | 25 | $23.75 | Add to Order |
| MSS-6150 | M5 | 0.8 mm | 10 | 8.5 | 3.3 | No. 2 | 25 | $27.20 | Add to Order |
| MSS-6113 | M5 | 0.8 mm | 12 | 8.5 | 3.3 | No. 2 | 10 | $19.24 | Add to Order |
| MSS-7566 | M5 | 0.8 mm | 16 | 8.5 | 3.3 | No. 2 | 10 | $19.57 | Add to Order |
| MSS-7567 | M5 | 0.8 mm | 20 | 8.5 | 3.3 | No. 2 | 10 | $20.60 | Add to Order |
| MSS-6140 | M6 | 1 mm | 8 | 10 | 3.9 | No. 3 | 10 | $14.99 | Add to Order |
| MSS-7568 | M6 | 1 mm | 10 | 10 | 3.9 | No. 3 | 10 | $20.60 | Add to Order |
| MSS-6141 | M6 | 1 mm | 12 | 10 | 3.9 | No. 3 | 10 | $17.51 | Add to Order |
| MSS-6142 | M6 | 1 mm | 16 | 10 | 3.9 | No. 3 | 10 | $18.77 | Add to Order |
| MSS-7569 | M6 | 1 mm | 20 | 10 | 3.9 | No. 3 | 10 | $20.83 | Add to Order |
| Rev. 11-22, 03-22 | |||||||||
