18-8 Stainless Steel Button Head Torx Drive Machine Screws
Machine Screws - Button Head Torx Drive, Class 2A, Fully Threaded
18-8 Stainless Steel - Excellent corrosion resistance, mildly magnetic
| 18-8 Stainless Steel Button Head Torx Machine Screws | |||||||||||
| Part # | Thread Size | Length | FT/PT | Min, Thread Length | Head Dia. | Head Height | Drive Size | Drive | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MSS-9663 | 000-120 | 1/16" | FT | __ | 0.065" | 0.018" | Torx Plus | IP1, T1 | 100 | $29.74 | Add to Order |
| MSS-9664 | 000-120 | 3/32" | FT | __ | 0.065" | 0.018" | Torx Plus | IP1, T1 | 100 | $29.78 | Add to Order |
| MSS-9665 | 000-120 | 1/8" | FT | __ | 0.065" | 0.018" | Torx Plus | IP1, T1 | 25 | $38.37 | Add to Order |
| MSS-9666 | 000-120 | 3/16" | FT | __ | 0.065" | 0.018" | Torx Plus | IP1, T1 | 25 | $38.89 | Add to Order |
| MSS-9667 | 000-120 | 1/4" | FT | __ | 0.065" | 0.018" | Torx Plus | IP1, T1 | 25 | $39.42 | Add to Order |
| MSS-9668 | 00-90 | 1/16" | FT | __ | 0.089" | 0.025" | Torx Plus | IP2, T2 | 100 | $29.76 | Add to Order |
| MSS-9669 | 00-90 | 3/32" | FT | __ | 0.089" | 0.025" | Torx Plus | IP2, T2 | 100 | $29.82 | Add to Order |
| MSS-9670 | 00-90 | 1/8" | FT | __ | 0.089" | 0.025" | Torx Plus | IP2, T2 | 25 | $36.29 | Add to Order |
| MSS-9671 | 00-90 | 3/16" | FT | __ | 0.089" | 0.025" | Torx Plus | IP2, T2 | 25 | $36.56 | Add to Order |
| MSS-9672 | 00-90 | 1/4" | FT | __ | 0.089" | 0.025" | Torx Plus | IP2, T2 | 25 | $36.81 | Add to Order |
| MSS-9673 | 00-96 | 1/8" | FT | __ | 0.089" | 0.025" | Torx Plus | IP2, T2 | 100 | $29.99 | Add to Order |
| MSS-9674 | 00-96 | 3/16" | FT | __ | 0.089" | 0.025" | Torx Plus | IP2, T2 | 100 | $30.14 | Add to Order |
| MSS-9675 | 00-96 | 1/4" | FT | __ | 0.089" | 0.025" | Torx Plus | IP2, T2 | 100 | $30.28 | Add to Order |
| MSS-9676 | 0-80 | 1/8" | FT | __ | 0.114" | 0.032" | Torx Plus | IP5, T5 | 25 | $31.37 | Add to Order |
| MSS-9677 | 0-80 | 3/16" | FT | __ | 0.114" | 0.032" | Torx Plus | IP5, T5 | 25 | $31.63 | Add to Order |
| MSS-9678 | 0-80 | 1/4" | FT | __ | 0.114" | 0.032" | Torx Plus | IP5, T5 | 25 | $31.90 | Add to Order |
| MSS-9679 | 0-80 | 3/8" | FT | __ | 0.114" | 0.032" | Torx | T5 | 100 | $31.92 | Add to Order |
| MSS-9680 | 0-80 | 1/2" | FT | __ | 0.114" | 0.032" | Torx | T5 | 100 | $32.84 | Add to Order |
| MSS-9681 | 2-56 | 3/32" | FT | __ | 0.164" | 0.046" | Torx | T6 | 100 | $32.32 | Add to Order |
| MSS-9682 | 2-56 | 1/8" | FT | __ | 0.164" | 0.046" | Torx Plus | IP6, T6 | 25 | $23.94 | Add to Order |
| MSS-9683 | 2-56 | 3/16" | FT | __ | 0.164" | 0.046" | Torx Plus | IP6, T6 | 25 | $24.63 | Add to Order |
| MSS-9684 | 2-56 | 1/4" | FT | __ | 0.164" | 0.046" | Torx Plus | IP6, T6 | 25 | $24.89 | Add to Order |
| MSS-9685 | 2-56 | 5/16" | FT | __ | 0.164" | 0.046" | Torx Plus | IP6, T6 | 25 | $25.16 | Add to Order |
| MSS-9686 | 2-56 | 3/8" | FT | __ | 0.164" | 0.046" | Torx Plus | IP6, T6 | 25 | $25.41 | Add to Order |
| MSS-9687 | 2-56 | 1/2" | FT | __ | 0.164" | 0.046" | Torx Plus | IP6, T6 | 25 | $25.81 | Add to Order |
| MSS-9688 | 2-56 | 3/4" | PT | 43/64" | 0.164" | 0.046" | Torx | T6 | 100 | $36.92 | Add to Order |
| MSS-9689 | 2-56 | 1" | PT | 43/64" | 0.164" | 0.046" | Torx | T6 | 100 | $39.82 | Add to Order |
| MSS-9690 | 4-40 | 1/8" | FT | __ | 0.213" | 0.059" | Torx Plus | IP8, T8 | 25 | $22.60 | Add to Order |
| MSS-9691 | 4-40 | 3/16" | FT | __ | 0.213" | 0.059" | Torx Plus | IP8, T8 | 25 | $23.08 | Add to Order |
| MSS-9692 | 4-40 | 1/4" | FT | __ | 0.213" | 0.059" | Torx Plus | IP8, T8 | 25 | $23.33 | Add to Order |
| MSS-9693 | 4-40 | 5/16" | FT | __ | 0.213" | 0.059" | Torx Plus | IP8, T8 | 25 | $23.58 | Add to Order |
| MSS-9694 | 4-40 | 3/8" | FT | __ | 0.213" | 0.059" | Torx Plus | IP8, T8 | 25 | $23.86 | Add to Order |
| MSS-9695 | 4-40 | 1/2" | FT | __ | 0.213" | 0.059" | Torx Plus | IP8, T8 | 25 | $24.11 | Add to Order |
| MSS-9696 | 4-40 | 5/8" | FT | __ | 0.213" | 0.059" | Torx | T8 | 100 | $35.05 | Add to Order |
| MSS-9697 | 4-40 | 3/4" | FT | __ | 0.213" | 0.059" | Torx | T8 | 100 | $36.12 | Add to Order |
| MSS-9698 | 4-40 | 1" | PT | 0.724" | 0.213" | 0.059" | Torx | T8 | 100 | $41.45 | Add to Order |
| MSS-9699 | 6-32 | 1/8" | FT | __ | 0.262" | 0.073" | Torx | T10 | 100 | $32.84 | Add to Order |
| MSS-9700 | 6-32 | 3/16" | FT | __ | 0.262" | 0.073" | Torx | T10 | 100 | $32.28 | Add to Order |
| MSS-9701 | 6-32 | 1/4" | FT | __ | 0.262" | 0.073" | Torx Plus | IP10, T10 | 25 | $24.36 | Add to Order |
| MSS-9702 | 6-32 | 5/16" | FT | __ | 0.262" | 0.073" | Torx | T10 | 100 | $35.26 | Add to Order |
| MSS-9703 | 6-32 | 3/8" | FT | __ | 0.262" | 0.073" | Torx Plus | IP10, T10 | 25 | $24.61 | Add to Order |
| MSS-9704 | 6-32 | 1/2" | FT | __ | 0.262" | 0.073" | Torx Plus | IP10, T10 | 25 | $23.98 | Add to Order |
| MSS-9705 | 6-32 | 5/8" | FT | __ | 0.262" | 0.073" | Torx Plus | IP10, T10 | 25 | $25.94 | Add to Order |
| MSS-9706 | 6-32 | 3/4" | FT | __ | 0.262" | 0.073" | Torx Plus | IP10, T10 | 25 | $25.28 | Add to Order |
| MSS-9707 | 6-32 | 1" | FT | __ | 0.262" | 0.073" | Torx Plus | IP10, T10 | 25 | $21.25 | Add to Order |
| MSS-9708 | 6-32 | 1 1/2" | FT | __ | 0.262" | 0.073" | Torx | T10 | 50 | $15.92 | Add to Order |
| MSS-9709 | 8-32 | 3/16" | FT | __ | 0.312" | 0.087" | Torx | T15 | 100 | $35.93 | Add to Order |
| MSS-9710 | 8-32 | 1/4" | FT | __ | 0.312" | 0.087" | Torx Plus | IP15, T15 | 25 | $25.41 | Add to Order |
| MSS-9711 | 8-32 | 5/16" | FT | __ | 0.312" | 0.087" | Torx | T15 | 100 | $15.29 | Add to Order |
| MSS-9712 | 8-32 | 3/8" | FT | __ | 0.312" | 0.087" | Torx Plus | IP15, T15 | 25 | $23.86 | Add to Order |
| MSS-9713 | 8-32 | 1/2" | FT | __ | 0.312" | 0.087" | Torx Plus | IP15, T15 | 25 | $21.25 | Add to Order |
| MSS-9714 | 8-32 | 5/8" | FT | __ | 0.312" | 0.087" | Torx Plus | IP15, T15 | 25 | $28.27 | Add to Order |
| MSS-9715 | 8-32 | 3/4" | FT | __ | 0.312" | 0.087" | Torx Plus | IP15, T15 | 25 | $26.25 | Add to Order |
| MSS-9716 | 8-32 | 1" | FT | __ | 0.312" | 0.087" | Torx Plus | IP15, T15 | 25 | $25.85 | Add to Order |
| MSS-9717 | 8-32 | 1 1/4" | FT | __ | 0.312" | 0.087" | Torx | T15 | 50 | $21.42 | Add to Order |
| MSS-9718 | 8-32 | 1 1/2" | FT | __ | 0.312" | 0.087" | Torx | T15 | 50 | $20.79 | Add to Order |
| MSS-9719 | 10-24 | 3/8" | FT | __ | 0.361" | 0.101" | Torx | T25 | 100 | $25.62 | Add to Order |
| MSS-9720 | 10-24 | 1/2" | FT | __ | 0.361" | 0.101" | Torx | T25 | 100 | $24.53 | Add to Order |
| MSS-9721 | 10-24 | 3/4" | FT | __ | 0.361" | 0.101" | Torx | T25 | 50 | $19.66 | Add to Order |
| MSS-9722 | 10-24 | 1" | FT | __ | 0.361" | 0.101" | Torx | T25 | 50 | $23.90 | Add to Order |
| MSS-9723 | 10-24 | 1 1/2" | FT | __ | 0.361" | 0.101" | Torx | T25 | 50 | $33.26 | Add to Order |
| MSS-9724 | 10-32 | 1/4" | FT | __ | 0.361" | 0.101" | Torx | T25 | 50 | $18.75 | Add to Order |
| MSS-9725 | 10-32 | 3/8" | FT | __ | 0.361" | 0.101" | Torx | T25 | 50 | $20.29 | Add to Order |
| MSS-9726 | 10-32 | 1/2" | FT | __ | 0.361" | 0.101" | Torx | T25 | 50 | $21.11 | Add to Order |
| MSS-9727 | 10-32 | 3/4" | FT | __ | 0.361" | 0.101" | Torx | T25 | 50 | $23.75 | Add to Order |
| MSS-9728 | 10-32 | 1" | FT | __ | 0.361" | 0.101" | Torx | T25 | 50 | $27.93 | Add to Order |
| MSS-9729 | 1/4"-20 | 1/4" | FT | __ | 0.437" | 0.132" | Torx | T27 | 50 | $18.90 | Add to Order |
| MSS-9730 | 1/4"-20 | 3/8" | FT | __ | 0.437" | 0.132" | Torx | T27 | 25 | $18.92 | Add to Order |
| MSS-9731 | 1/4"-20 | 1/2" | FT | __ | 0.437" | 0.132" | Torx | T27 | 25 | $19.97 | Add to Order |
| MSS-9732 | 1/4"-20 | 5/8" | FT | __ | 0.437" | 0.132" | Torx | T27 | 25 | $22.13 | Add to Order |
| MSS-9733 | 1/4"-20 | 3/4" | FT | __ | 0.437" | 0.132" | Torx | T27 | 25 | $22.58 | Add to Order |
| MSS-9734 | 1/4"-20 | 1" | FT | __ | 0.437" | 0.132" | Torx | T27 | 10 | $10.52 | Add to Order |
| MSS-9735 | 1/4"-20 | 1 1/4" | PT | 1" | 0.437" | 0.132" | Torx | T27 | 10 | $11.97 | Add to Order |
| MSS-9736 | 1/4"-20 | 1 1/2" | PT | 1" | 0.437" | 0.132" | Torx | T27 | 10 | $14.34 | Add to Order |
| MSS-9737 | 1/4"-20 | 2" | FT | __ | 0.437" | 0.132" | Torx | T27 | 10 | $13.23 | Add to Order |
| MSS-9738 | 5/16"-18 | 1/2" | FT | __ | 0.547" | 0.166" | Torx | T40 | 10 | $12.92 | Add to Order |
| MSS-9739 | 5/16"-18 | 5/8" | FT | __ | 0.547" | 0.166" | Torx | T40 | 10 | $14.43 | Add to Order |
| MSS-9740 | 5/16"-18 | 3/4" | FT | __ | 0.547" | 0.166" | Torx | T40 | 10 | $15.08 | Add to Order |
| MSS-9741 | 5/16"-18 | 1" | FT | __ | 0.547" | 0.166" | Torx | T40 | 10 | $16.74 | Add to Order |
| MSS-9742 | 5/16"-18 | 1 1/2" | FT | __ | 0.547" | 0.166" | Torx | T40 | 10 | $14.22 | Add to Order |
| MSS-9743 | 5/16"-18 | 2" | FT | __ | 0.547" | 0.166" | Torx | T40 | 10 | $22.68 | Add to Order |
| MSS-9744 | 3/8"-16 | 3/4" | FT | __ | 0.656" | 0.199" | Torx | T45 | 5 | $18.67 | Add to Order |
| MSS-9745 | 3/8"-16 | 1" | FT | __ | 0.656" | 0.199" | Torx | T45 | 5 | $18.96 | Add to Order |
| MSS-9746 | 3/8"-16 | 1 1/4" | FT | __ | 0.656" | 0.199" | Torx | T45 | 5 | $22.11 | Add to Order |
| MSS-9747 | 3/8"-16 | 1 1/2" | PT | 1 1/4" | 0.656" | 0.199" | Torx | T45 | 5 | $24.04 | Add to Order |
| MSS-9748 | 3/8"-16 | 2" | FT | __ | 0.656" | 0.199" | Torx | T45 | 5 | $19.64 | Add to Order |
| Rev. 10-23, 08-23, 02-23, 11-22 | |||||||||||
