Black Oxide Button Head Hex Drive Machine Screws
Machine Screws - Button Head Hex Drive, Black Oxide, Class 2A.
| Black Oxide Steel Button Head Hex Drive Machine Screws | |||||||||
| Part # | Thread Size | Length | Min. Thread Length | Head Dia. | Head Height | Drive Size | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| MSS-8237 | 0-80 | 1/8" | __ | 0.114" | 0.032" | 1/32" | 25 | $15.20 | Add to Order |
| MSS-8238 | 0-80 | 3/16" | __ | 0.114" | 0.032" | 1/32" | 25 | $15.39 | Add to Order |
| MSS-8239 | 0-80 | 1/4" | __ | 0.114" | 0.032" | 1/32" | 25 | $15.73 | Add to Order |
| MSS-8240 | 0-80 | 3/8" | __ | 0.114" | 0.032" | 1/32" | 25 | $19.76 | Add to Order |
| MSS-8241 | 0-80 | 1/2" | __ | 0.114" | 0.032" | 1/32" | 10 | $19.03 | Add to Order |
| MSS-8242 | 1-64 | 1/4" | __ | 0.139" | 0.039" | 3/64" | 10 | $11.07 | Add to Order |
| MSS-8243 | 1-72 | 1/8" | __ | 0.139" | 0.039" | 3/64" | 25 | $15.39 | Add to Order |
| MSS-8244 | 1-72 | 3/16" | __ | 0.139" | 0.039" | 3/64" | 25 | $15.73 | Add to Order |
| MSS-8245 | 1-72 | 1/4" | __ | 0.139" | 0.039" | 3/64" | 25 | $16.28 | Add to Order |
| MSS-8246 | 2-56 | 1/16" | __ | 0.164" | 0.046" | 3/64" | 25 | $25.41 | Add to Order |
| MSS-8247 | 2-56 | 3/32" | __ | 0.164" | 0.046" | 3/64" | 25 | $20.83 | Add to Order |
| MSS-8248 | 2-56 | 1/8" | __ | 0.164" | 0.046" | 3/64" | 25 | $14.41 | Add to Order |
| MSS-8249 | 2-56 | 5/32" | __ | 0.164" | 0.046" | 3/64" | 25 | $27.03 | Add to Order |
| MSS-8250 | 2-56 | 3/16" | __ | 0.164" | 0.046" | 3/64" | 25 | $10.33 | Add to Order |
| MSS-8251 | 2-56 | 1/4" | __ | 0.164" | 0.046" | 3/64" | 25 | $9.79 | Add to Order |
| MSS-8252 | 2-56 | 5/16" | __ | 0.164" | 0.046" | 3/64" | 25 | $8.02 | Add to Order |
| MSS-8253 | 2-56 | 3/8" | __ | 0.164" | 0.046" | 3/64" | 25 | $9.41 | Add to Order |
| MSS-8254 | 2-56 | 7/16" | __ | 0.164" | 0.046" | 3/64" | 25 | $15.73 | Add to Order |
| MSS-8255 | 2-56 | 1/2" | __ | 0.164" | 0.046" | 3/64" | 25 | $10.16 | Add to Order |
| MSS-8256 | 2-56 | 5/8" | __ | 0.164" | 0.046" | 3/64" | 25 | $20.83 | Add to Order |
| MSS-8257 | 2-56 | 3/4" | __ | 0.164" | 0.046" | 3/64" | 25 | $21.08 | Add to Order |
| MSS-8258 | 2-56 | 1" | __ | 0.164" | 0.046" | 3/64" | 25 | $22.07 | Add to Order |
| MSS-8259 | 2-64 | 1/4" | __ | 0.164" | 0.046" | 3/64" | 5 | $18.75 | Add to Order |
| MSS-8260 | 2-64 | 3/8" | __ | 0.164" | 0.046" | 3/64" | 5 | $22.91 | Add to Order |
| MSS-8261 | 2-64 | 1/2" | __ | 0.164" | 0.046" | 3/64" | 5 | $25.01 | Add to Order |
| MSS-8262 | 3-48 | 1/8" | __ | 0.188" | 0.052" | 1/16" | 25 | $22.85 | Add to Order |
| MSS-8263 | 3-48 | 3/16" | __ | 0.188" | 0.052" | 1/16" | 10 | $22.68 | Add to Order |
| MSS-8264 | 3-48 | 1/4" | __ | 0.188" | 0.052" | 1/16" | 10 | $23.92 | Add to Order |
| MSS-8265 | 3-48 | 3/8" | __ | 0.188" | 0.052" | 1/16" | 10 | $23.31 | Add to Order |
| MSS-8266 | 3-48 | 1/2" | __ | 0.188" | 0.052" | 1/16" | 50 | $19.03 | Add to Order |
| MSS-8267 | 3-48 | 5/8" | __ | 0.188" | 0.052" | 1/16" | 25 | $24.76 | Add to Order |
| MSS-8268 | 3-56 | 1/4" | __ | 0.188" | 0.052" | 1/16" | 10 | $19.03 | Add to Order |
| MSS-8269 | 3-56 | 3/8" | __ | 0.188" | 0.052" | 1/16" | 10 | $19.80 | Add to Order |
| MSS-8270 | 3-56 | 1/2" | __ | 0.188" | 0.052" | 1/16" | 10 | $21.34 | Add to Order |
| MSS-8271 | 4-40 | 1/8" | __ | 0.213" | 0.059" | 1/16" | 50 | $29.55 | Add to Order |
| MSS-8272 | 4-40 | 3/16" | __ | 0.213" | 0.059" | 1/16" | 100 | $30.98 | Add to Order |
| MSS-8273 | 4-40 | 1/4" | __ | 0.213" | 0.059" | 1/16" | 100 | $31.42 | Add to Order |
| MSS-8274 | 4-40 | 5/16" | __ | 0.213" | 0.059" | 1/16" | 100 | $29.42 | Add to Order |
| MSS-8275 | 4-40 | 3/8" | __ | 0.213" | 0.059" | 1/16" | 100 | $33.39 | Add to Order |
| MSS-8276 | 4-40 | 7/16" | __ | 0.213" | 0.059" | 1/16" | 100 | $30.39 | Add to Order |
| MSS-8277 | 4-40 | 1/2" | __ | 0.213" | 0.059" | 1/16" | 100 | $29.80 | Add to Order |
| MSS-8278 | 4-40 | 9/16" | __ | 0.213" | 0.059" | 1/16" | 50 | $33.71 | Add to Order |
| MSS-8279 | 4-40 | 5/8" | __ | 0.213" | 0.059" | 1/16" | 50 | $17.79 | Add to Order |
| MSS-8280 | 4-40 | 3/4" | __ | 0.213" | 0.059" | 1/16" | 50 | $18.04 | Add to Order |
| MSS-8281 | 4-40 | 7/8" | __ | 0.213" | 0.059" | 1/16" | 50 | $18.38 | Add to Order |
| MSS-8282 | 4-40 | 1" | 3/4" | 0.213" | 0.059" | 1/16" | 50 | $19.59 | Add to Order |
| MSS-8283 | 4-40 | 1 1/4" | __ | 0.213" | 0.059" | 1/16" | 25 | $32.68 | Add to Order |
| MSS-8284 | 4-40 | 1 1/2" | __ | 0.213" | 0.059" | 1/16" | 10 | $38.16 | Add to Order |
| MSS-8285 | 4-40 | 2" | __ | 0.213" | 0.059" | 1/16" | 10 | $31.50 | Add to Order |
| MSS-8286 | 4-48 | 1/4" | __ | 0.213" | 0.059" | 1/16" | 25 | $18.75 | Add to Order |
| MSS-8287 | 4-48 | 3/8" | __ | 0.213" | 0.059" | 1/16" | 25 | $19.76 | Add to Order |
| MSS-8288 | 4-48 | 1/2" | __ | 0.213" | 0.059" | 1/16" | 25 | $20.83 | Add to Order |
| MSS-8289 | 5-40 | 3/16" | __ | 0.238" | 0.066" | 5/64" | 50 | $38.09 | Add to Order |
| MSS-8290 | 5-40 | 1/4" | __ | 0.238" | 0.066" | 5/64" | 100 | $27.74 | Add to Order |
| MSS-8291 | 5-40 | 5/16" | __ | 0.238" | 0.066" | 5/64" | 50 | $34.29 | Add to Order |
| MSS-8292 | 5-40 | 3/8" | __ | 0.238" | 0.066" | 5/64" | 50 | $18.38 | Add to Order |
| MSS-8293 | 5-40 | 1/2" | __ | 0.238" | 0.066" | 5/64" | 50 | $27.59 | Add to Order |
| MSS-8294 | 5-40 | 5/8" | __ | 0.238" | 0.066" | 5/64" | 50 | $28.81 | Add to Order |
| MSS-8295 | 5-40 | 3/4" | __ | 0.875" | 0.265" | 5/16" | 50 | $28.77 | Add to Order |
| MSS-8296 | 5-44 | 1/4" | __ | 0.238" | 0.066" | 5/64" | 10 | $23.79 | Add to Order |
| MSS-8297 | 5-44 | 3/8" | __ | 0.238" | 0.066" | 5/64" | 10 | $27.57 | Add to Order |
| MSS-8298 | 5-44 | 1/2" | __ | 0.238" | 0.066" | 5/64" | 10 | $31.10 | Add to Order |
| MSS-8299 | 6-32 | 1/8" | __ | 0.262" | 0.073" | 5/64" | 50 | $27.78 | Add to Order |
| MSS-8300 | 6-32 | 3/16" | __ | 0.262" | 0.073" | 5/64" | 50 | $35.57 | Add to Order |
| MSS-8301 | 6-32 | 1/4" | __ | 0.262" | 0.073" | 5/64" | 100 | $31.50 | Add to Order |
| MSS-8302 | 6-32 | 5/16" | __ | 0.262" | 0.073" | 5/64" | 50 | $18.50 | Add to Order |
| MSS-8303 | 6-32 | 3/8" | __ | 0.262" | 0.073" | 5/64" | 100 | $31.82 | Add to Order |
| MSS-8304 | 6-32 | 7/16" | __ | 0.262" | 0.073" | 5/64" | 100 | $30.53 | Add to Order |
| MSS-8305 | 6-32 | 1/2" | __ | 0.262" | 0.073" | 5/64" | 100 | $34.31 | Add to Order |
| MSS-8306 | 6-32 | 9/16" | __ | 0.262" | 0.073" | 5/64" | 10 | $26.65 | Add to Order |
| MSS-8307 | 6-32 | 5/8" | __ | 0.262" | 0.073" | 5/64" | 100 | $37.51 | Add to Order |
| MSS-8308 | 6-32 | 3/4" | __ | 0.262" | 0.073" | 5/64" | 50 | $22.03 | Add to Order |
| MSS-8309 | 6-32 | 7/8" | __ | 0.262" | 0.073" | 5/64" | 50 | $22.28 | Add to Order |
| MSS-8310 | 6-32 | 1" | 3/4" | 0.262" | 0.073" | 5/64" | 50 | $23.90 | Add to Order |
| MSS-8311 | 6-32 | 1 1/8" | __ | 0.262" | 0.073" | 5/64" | 10 | $34.29 | Add to Order |
| MSS-8312 | 6-32 | 1 1/4" | 3/4" | 0.262" | 0.073" | 5/64" | 25 | $14.62 | Add to Order |
| MSS-8313 | 6-32 | 1 1/2" | 3/4" | 0.262" | 0.073" | 5/64" | 25 | $18.23 | Add to Order |
| MSS-8314 | 6-32 | 1 3/4" | __ | 0.262" | 0.073" | 5/64" | 10 | $16.00 | Add to Order |
| MSS-8315 | 6-32 | 2" | __ | 0.262" | 0.073" | 5/64" | 10 | $16.44 | Add to Order |
| MSS-8316 | 6-32 | 3" | 49/64" | 0.262" | 0.073" | 5/64" | 5 | $24.78 | Add to Order |
| MSS-8317 | 6-40 | 1/4" | __ | 0.262" | 0.073" | 5/64" | 25 | $21.44 | Add to Order |
| MSS-8318 | 6-40 | 3/8" | __ | 0.262" | 0.073" | 5/64" | 25 | $22.60 | Add to Order |
| MSS-8319 | 6-40 | 1/2" | __ | 0.262" | 0.073" | 5/64" | 25 | $23.81 | Add to Order |
| MSS-8320 | 8-32 | 1/8" | __ | 0.312" | 0.087" | 3/32" | 25 | $22.93 | Add to Order |
| MSS-8321 | 8-32 | 5/32" | __ | 0.312" | 0.087" | 3/32" | 10 | $23.48 | Add to Order |
| MSS-8322 | 8-32 | 3/16" | __ | 0.312" | 0.087" | 3/32" | 50 | $26.48 | Add to Order |
| MSS-8323 | 8-32 | 1/4" | __ | 0.312" | 0.087" | 3/32" | 100 | $29.80 | Add to Order |
| MSS-8324 | 8-32 | 5/16" | __ | 0.312" | 0.087" | 3/32" | 50 | $19.09 | Add to Order |
| MSS-8325 | 8-32 | 3/8" | __ | 0.312" | 0.087" | 3/32" | 100 | $42.78 | Add to Order |
| MSS-8326 | 8-32 | 7/16" | __ | 0.312" | 0.087" | 3/32" | 50 | $23.98 | Add to Order |
| MSS-8327 | 8-32 | 1/2" | __ | 0.312" | 0.087" | 3/32" | 100 | $42.90 | Add to Order |
| MSS-8328 | 8-32 | 9/16" | __ | 0.312" | 0.087" | 3/32" | 25 | $27.72 | Add to Order |
| MSS-8329 | 8-32 | 5/8" | __ | 0.312" | 0.087" | 3/32" | 50 | $25.83 | Add to Order |
| MSS-8330 | 8-32 | 3/4" | __ | 0.312" | 0.087" | 3/32" | 50 | $26.50 | Add to Order |
| MSS-8331 | 8-32 | 7/8" | __ | 0.312" | 0.087" | 3/32" | 25 | $17.35 | Add to Order |
| MSS-8332 | 8-32 | 1" | 7/8" | 0.312" | 0.087" | 3/32" | 50 | $47.10 | Add to Order |
| MSS-8333 | 8-32 | 1 1/8" | __ | 0.312" | 0.087" | 3/32" | 10 | $26.65 | Add to Order |
| MSS-8334 | 8-32 | 1 1/4" | 7/8" | 0.312" | 0.087" | 3/32" | 10 | $43.39 | Add to Order |
| MSS-8335 | 8-32 | 1 3/8" | __ | 0.312" | 0.087" | 3/32" | 10 | $29.17 | Add to Order |
| MSS-8336 | 8-32 | 1 1/2" | 7/8" | 0.312" | 0.087" | 3/32" | 10 | $46.18 | Add to Order |
| MSS-8337 | 8-32 | 1 3/4" | __ | 0.312" | 0.087" | 3/32" | 10 | $21.32 | Add to Order |
| MSS-8338 | 8-32 | 2" | __ | 0.312" | 0.087" | 3/32" | 5 | $16.32 | Add to Order |
| MSS-8339 | 8-32 | 2 1/4" | __ | 0.312" | 0.087" | 3/32" | 5 | $25.33 | Add to Order |
| MSS-8340 | 8-32 | 2 1/2" | 53/64" | 0.312" | 0.087" | 3/32" | 50 | $34.59 | Add to Order |
| MSS-8341 | 8-32 | 3" | 53/64" | 0.312" | 0.087" | 3/32" | 50 | $34.88 | Add to Order |
| MSS-8342 | 8-36 | 1/4" | __ | 0.312" | 0.087" | 3/32" | 50 | $23.98 | Add to Order |
| MSS-8343 | 8-36 | 3/8" | __ | 0.312" | 0.087" | 3/32" | 50 | $27.09 | Add to Order |
| MSS-8344 | 8-36 | 1/2" | __ | 0.312" | 0.087" | 3/32" | 50 | $26.08 | Add to Order |
| MSS-8345 | 10-24 | 3/16" | __ | 0.361" | 0.101" | 1/8" | 50 | $34.29 | Add to Order |
| MSS-8346 | 10-24 | 1/4" | __ | 0.361" | 0.101" | 1/8" | 100 | $32.11 | Add to Order |
| MSS-8347 | 10-24 | 5/16" | __ | 0.361" | 0.101" | 1/8" | 50 | $22.89 | Add to Order |
| MSS-8348 | 10-24 | 3/8" | __ | 0.361" | 0.101" | 1/8" | 100 | $44.86 | Add to Order |
| MSS-8349 | 10-24 | 7/16" | __ | 0.361" | 0.101" | 1/8" | 50 | $24.80 | Add to Order |
| MSS-8350 | 10-24 | 1/2" | __ | 0.361" | 0.101" | 1/8" | 50 | $24.57 | Add to Order |
| MSS-8351 | 10-24 | 9/16" | __ | 0.361" | 0.101" | 1/8" | 10 | $17.79 | Add to Order |
| MSS-8352 | 10-24 | 5/8" | __ | 0.361" | 0.101" | 1/8" | 50 | $25.62 | Add to Order |
| MSS-8353 | 10-24 | 3/4" | __ | 0.361" | 0.101" | 1/8" | 50 | $27.26 | Add to Order |
| MSS-8354 | 10-24 | 7/8" | __ | 0.361" | 0.101" | 1/8" | 50 | $31.16 | Add to Order |
| MSS-8355 | 10-24 | 1" | __ | 0.361" | 0.101" | 1/8" | 50 | $29.11 | Add to Order |
| MSS-8356 | 10-24 | 1 1/8" | __ | 0.361" | 0.101" | 1/8" | 10 | $23.33 | Add to Order |
| MSS-8357 | 10-24 | 1 1/4" | 7/8" | 0.361" | 0.101" | 1/8" | 25 | $40.07 | Add to Order |
| MSS-8358 | 10-24 | 1 1/2" | 7/8" | 0.361" | 0.101" | 1/8" | 25 | $37.57 | Add to Order |
| MSS-8359 | 10-24 | 1 3/4" | 7/8" | 0.361" | 0.101" | 1/8" | 10 | $17.66 | Add to Order |
| MSS-8360 | 10-24 | 2" | 7/8" | 0.361" | 0.101" | 1/8" | 10 | $22.70 | Add to Order |
| MSS-8361 | 10-24 | 2 1/2" | 0.88" | 0.361" | 0.101" | 1/8" | 50 | $35.20 | Add to Order |
| MSS-8362 | 10-24 | 3" | 0.88" | 0.361" | 0.101" | 1/8" | 50 | $35.66 | Add to Order |
| MSS-8363 | 10-32 | 1/8" | __ | 0.361" | 0.101" | 1/8" | 10 | $29.55 | Add to Order |
| MSS-8364 | 10-32 | 3/16" | __ | 0.361" | 0.101" | 1/8" | 25 | $19.55 | Add to Order |
| MSS-8365 | 10-32 | 1/4" | __ | 0.361" | 0.101" | 1/8" | 100 | $31.73 | Add to Order |
| MSS-8366 | 10-32 | 5/16" | __ | 0.361" | 0.101" | 1/8" | 25 | $12.79 | Add to Order |
| MSS-8367 | 10-32 | 3/8" | __ | 0.361" | 0.101" | 1/8" | 100 | $36.60 | Add to Order |
| MSS-8368 | 10-32 | 7/16" | __ | 0.361" | 0.101" | 1/8" | 50 | $19.09 | Add to Order |
| MSS-8369 | 10-32 | 1/2" | __ | 0.361" | 0.101" | 1/8" | 50 | $24.57 | Add to Order |
| MSS-8370 | 10-32 | 9/16" | __ | 0.361" | 0.101" | 1/8" | 25 | $20.50 | Add to Order |
| MSS-8371 | 10-32 | 5/8" | __ | 0.361" | 0.101" | 1/8" | 50 | $26.50 | Add to Order |
| MSS-8372 | 10-32 | 3/4" | __ | 0.361" | 0.101" | 1/8" | 50 | $37.13 | Add to Order |
| MSS-8373 | 10-32 | 7/8" | __ | 0.361" | 0.101" | 1/8" | 50 | $37.21 | Add to Order |
| MSS-8374 | 10-32 | 1" | __ | 0.361" | 0.101" | 1/8" | 50 | $37.55 | Add to Order |
| MSS-8375 | 10-32 | 1 1/8" | __ | 0.361" | 0.101" | 1/8" | 25 | $24.30 | Add to Order |
| MSS-8376 | 10-32 | 1 1/4" | 7/8" | 0.361" | 0.101" | 1/8" | 10 | $32.95 | Add to Order |
| MSS-8377 | 10-32 | 1 1/2" | 7/8" | 0.361" | 0.101" | 1/8" | 10 | $26.00 | Add to Order |
| MSS-8378 | 10-32 | 1 3/4" | 7/8" | 0.361" | 0.101" | 1/8" | 10 | $22.03 | Add to Order |
| MSS-8379 | 10-32 | 2" | 7/8" | 0.361" | 0.101" | 1/8" | 10 | $22.70 | Add to Order |
| MSS-8380 | 10-32 | 2 1/4" | 0.88" | 0.361" | 0.101" | 1/8" | 50 | $34.57 | Add to Order |
| MSS-8381 | 10-32 | 2 1/2" | __ | 0.361" | 0.101" | 1/8" | 10 | $15.18 | Add to Order |
| MSS-8382 | 10-32 | 3" | __ | 0.361" | 0.101" | 1/8" | 10 | $16.57 | Add to Order |
| MSS-8383 | 12-24 | 3/8" | __ | 0.413" | 0.114" | 5/32" | 10 | $20.45 | Add to Order |
| MSS-8384 | 12-24 | 1/2" | __ | 0.410" | 0.115" | 9/64" | 50 | $25.85 | Add to Order |
| MSS-8385 | 12-24 | 5/8" | __ | 0.413" | 0.114" | 5/32" | 10 | $22.20 | Add to Order |
| MSS-8386 | 12-24 | 3/4" | __ | 0.410" | 0.115" | 9/64" | 50 | $27.85 | Add to Order |
| MSS-8387 | 12-24 | 1" | __ | 0.410" | 0.115" | 9/64" | 50 | $29.27 | Add to Order |
| MSS-8388 | 1/4"-20 | 3/16" | __ | 0.437" | 0.132" | 5/32" | 10 | $26.65 | Add to Order |
| MSS-8389 | 1/4"-20 | 1/4" | __ | 0.437" | 0.132" | 5/32" | 25 | $28.14 | Add to Order |
| MSS-8390 | 1/4"-20 | 5/16" | __ | 0.437" | 0.132" | 5/32" | 25 | $21.78 | Add to Order |
| MSS-8391 | 1/4"-20 | 3/8" | __ | 0.437" | 0.132" | 5/32" | 50 | $21.92 | Add to Order |
| MSS-8392 | 1/4"-20 | 7/16" | __ | 0.437" | 0.132" | 5/32" | 25 | $23.08 | Add to Order |
| MSS-8393 | 1/4"-20 | 1/2" | __ | 0.437" | 0.132" | 5/32" | 50 | $18.61 | Add to Order |
| MSS-8394 | 1/4"-20 | 9/16" | __ | 0.437" | 0.132" | 5/32" | 10 | $20.94 | Add to Order |
| MSS-8395 | 1/4"-20 | 5/8" | __ | 0.437" | 0.132" | 5/32" | 50 | $23.31 | Add to Order |
| MSS-8396 | 1/4"-20 | 3/4" | __ | 0.437" | 0.132" | 5/32" | 50 | $24.84 | Add to Order |
| MSS-8397 | 1/4"-20 | 7/8" | __ | 0.437" | 0.132" | 5/32" | 50 | $23.90 | Add to Order |
| MSS-8398 | 1/4"-20 | 1" | __ | 0.437" | 0.132" | 5/32" | 50 | $26.78 | Add to Order |
| MSS-8399 | 1/4"-20 | 1 1/8" | __ | 0.437" | 0.132" | 5/32" | 10 | $24.93 | Add to Order |
| MSS-8400 | 1/4"-20 | 1 1/4" | 1" | 0.437" | 0.132" | 5/32" | 25 | $51.77 | Add to Order |
| MSS-8401 | 1/4"-20 | 1 3/8" | __ | 0.437" | 0.132" | 5/32" | 10 | $30.47 | Add to Order |
| MSS-8402 | 1/4"-20 | 1 1/2" | __ | 0.437" | 0.132" | 5/32" | 10 | $28.56 | Add to Order |
| MSS-8403 | 1/4"-20 | 1 5/8" | __ | 0.437" | 0.132" | 5/32" | 10 | $38.09 | Add to Order |
| MSS-8404 | 1/4"-20 | 1 3/4" | 1" | 0.437" | 0.132" | 5/32" | 10 | $32.03 | Add to Order |
| MSS-8405 | 1/4"-20 | 2" | 1" | 0.437" | 0.132" | 5/32" | 10 | $26.71 | Add to Order |
| MSS-8406 | 1/4"-20 | 2 1/4" | __ | 0.437" | 0.132" | 5/32" | 10 | $19.38 | Add to Order |
| MSS-8407 | 1/4"-20 | 2 1/2" | 1" | 0.437" | 0.132" | 5/32" | 10 | $28.01 | Add to Order |
| MSS-8408 | 1/4"-20 | 2 3/4" | __ | 0.437" | 0.132" | 5/32" | 10 | $24.53 | Add to Order |
| MSS-8409 | 1/4"-20 | 3" | 1" | 0.437" | 0.132" | 5/32" | 10 | $42.02 | Add to Order |
| MSS-8410 | 1/4"-20 | 3 1/4" | 1" | 0.437" | 0.132" | 5/32" | 50 | $35.68 | Add to Order |
| MSS-8411 | 1/4"-20 | 3 1/2" | __ | 0.437" | 0.132" | 5/32" | 10 | $28.96 | Add to Order |
| MSS-8412 | 1/4"-20 | 4" | __ | 0.437" | 0.132" | 5/32" | 10 | $33.33 | Add to Order |
| MSS-8413 | 1/4"-28 | 3/16" | __ | 0.437" | 0.132" | 5/32" | 10 | $28.31 | Add to Order |
| MSS-8414 | 1/4"-28 | 1/4" | __ | 0.437" | 0.132" | 5/32" | 25 | $19.13 | Add to Order |
| MSS-8415 | 1/4"-28 | 5/16" | __ | 0.437" | 0.132" | 5/32" | 25 | $22.85 | Add to Order |
| MSS-8416 | 1/4"-28 | 3/8" | __ | 0.437" | 0.132" | 5/32" | 50 | $21.95 | Add to Order |
| MSS-8417 | 1/4"-28 | 1/2" | __ | 0.437" | 0.132" | 5/32" | 50 | $21.99 | Add to Order |
| MSS-8418 | 1/4"-28 | 5/8" | __ | 0.437" | 0.132" | 5/32" | 50 | $23.35 | Add to Order |
| MSS-8419 | 1/4"-28 | 3/4" | __ | 0.437" | 0.132" | 5/32" | 50 | $24.86 | Add to Order |
| MSS-8420 | 1/4"-28 | 1" | __ | 0.437" | 0.132" | 5/32" | 50 | $26.88 | Add to Order |
| MSS-8421 | 1/4"-28 | 1 1/4" | __ | 0.437" | 0.132" | 5/32" | 25 | $28.88 | Add to Order |
| MSS-8422 | 1/4"-28 | 1 1/2" | 1" | 0.437" | 0.132" | 5/32" | 25 | $47.94 | Add to Order |
| MSS-8423 | 1/4"-28 | 1 3/4" | __ | 0.437" | 0.132" | 5/32" | 25 | $33.33 | Add to Order |
| MSS-8424 | 1/4"-28 | 2" | __ | 0.437" | 0.132" | 5/32" | 10 | $15.73 | Add to Order |
| MSS-8425 | 1/4"-28 | 3" | __ | 0.437" | 0.132" | 5/32" | 10 | $37.34 | Add to Order |
| MSS-8426 | 5/16"-18 | 1/4" | __ | 0.547" | 0.166" | 3/16" | 25 | $37.59 | Add to Order |
| MSS-8427 | 5/16"-18 | 5/16" | __ | 0.547" | 0.166" | 3/16" | 25 | $25.07 | Add to Order |
| MSS-8428 | 5/16"-18 | 3/8" | __ | 0.547" | 0.166" | 3/16" | 50 | $23.90 | Add to Order |
| MSS-8429 | 5/16"-18 | 7/16" | __ | 0.547" | 0.166" | 3/16" | 10 | $19.03 | Add to Order |
| MSS-8430 | 5/16"-18 | 1/2" | __ | 0.547" | 0.166" | 3/16" | 50 | $24.21 | Add to Order |
| MSS-8431 | 5/16"-18 | 9/16" | __ | 0.547" | 0.166" | 3/16" | 10 | $30.47 | Add to Order |
| MSS-8432 | 5/16"-18 | 5/8" | __ | 0.547" | 0.166" | 3/16" | 50 | $30.47 | Add to Order |
| MSS-8433 | 5/16"-18 | 3/4" | __ | 0.547" | 0.166" | 3/16" | 50 | $31.94 | Add to Order |
| MSS-8434 | 5/16"-18 | 7/8" | __ | 0.547" | 0.166" | 3/16" | 50 | $30.60 | Add to Order |
| MSS-8435 | 5/16"-18 | 1" | __ | 0.547" | 0.166" | 3/16" | 50 | $30.70 | Add to Order |
| MSS-8436 | 5/16"-18 | 1 1/8" | __ | 0.547" | 0.166" | 3/16" | 10 | $31.98 | Add to Order |
| MSS-8437 | 5/16"-18 | 1 1/4" | 1 1/8" | 0.547" | 0.166" | 3/16" | 10 | $22.81 | Add to Order |
| MSS-8438 | 5/16"-18 | 1 3/8" | __ | 0.547" | 0.166" | 3/16" | 10 | $16.34 | Add to Order |
| MSS-8439 | 5/16"-18 | 1 1/2" | 1 1/8" | 0.547" | 0.166" | 3/16" | 10 | $27.24 | Add to Order |
| MSS-8440 | 5/16"-18 | 1 3/4" | __ | 0.547" | 0.166" | 3/16" | 10 | $19.32 | Add to Order |
| MSS-8441 | 5/16"-18 | 2" | __ | 0.547" | 0.166" | 3/16" | 10 | $13.21 | Add to Order |
| MSS-8442 | 5/16"-18 | 2 1/4" | 1 1/8" | 0.547" | 0.166" | 3/16" | 10 | $23.29 | Add to Order |
| MSS-8443 | 5/16"-18 | 2 1/2" | __ | 0.547" | 0.166" | 3/16" | 10 | $14.60 | Add to Order |
| MSS-8444 | 5/16"-18 | 2 3/4" | __ | 0.547" | 0.166" | 3/16" | 10 | $17.85 | Add to Order |
| MSS-8445 | 5/16"-18 | 3" | __ | 0.547" | 0.166" | 3/16" | 10 | $19.07 | Add to Order |
| MSS-8446 | 5/16"-18 | 3 1/2" | __ | 0.547" | 0.166" | 3/16" | 10 | $30.39 | Add to Order |
| MSS-8447 | 5/16"-18 | 4" | __ | 0.547" | 0.166" | 3/16" | 10 | $31.40 | Add to Order |
| MSS-8448 | 5/16"-24 | 3/8" | __ | 0.547" | 0.166" | 3/16" | 50 | $28.31 | Add to Order |
| MSS-8449 | 5/16"-24 | 1/2" | __ | 0.547" | 0.166" | 3/16" | 25 | $15.90 | Add to Order |
| MSS-8450 | 5/16"-24 | 5/8" | __ | 0.547" | 0.166" | 3/16" | 25 | $15.86 | Add to Order |
| MSS-8451 | 5/16"-24 | 3/4" | __ | 0.547" | 0.166" | 3/16" | 25 | $13.92 | Add to Order |
| MSS-8452 | 5/16"-24 | 1" | __ | 0.547" | 0.166" | 3/16" | 25 | $14.51 | Add to Order |
| MSS-8453 | 5/16"-24 | 1 1/4" | __ | 0.547" | 0.166" | 3/16" | 25 | $32.00 | Add to Order |
| MSS-8454 | 5/16"-24 | 1 1/2" | __ | 0.547" | 0.166" | 3/16" | 25 | $30.64 | Add to Order |
| MSS-8455 | 5/16"-24 | 2" | __ | 0.547" | 0.166" | 3/16" | 10 | $20.16 | Add to Order |
| MSS-8456 | 3/8"-16 | 1/4" | __ | 0.656" | 0.199" | 7/32" | 5 | $24.23 | Add to Order |
| MSS-8457 | 3/8"-16 | 3/8" | __ | 0.656" | 0.199" | 7/32" | 10 | $33.41 | Add to Order |
| MSS-8458 | 3/8"-16 | 1/2" | __ | 0.656" | 0.199" | 7/32" | 50 | $37.21 | Add to Order |
| MSS-8459 | 3/8"-16 | 5/8" | __ | 0.656" | 0.199" | 7/32" | 50 | $37.25 | Add to Order |
| MSS-8460 | 3/8"-16 | 3/4" | __ | 0.656" | 0.199" | 7/32" | 25 | $21.55 | Add to Order |
| MSS-8461 | 3/8"-16 | 7/8" | __ | 0.656" | 0.199" | 7/32" | 25 | $22.45 | Add to Order |
| MSS-8462 | 3/8"-16 | 1" | __ | 0.656" | 0.199" | 7/32" | 25 | $24.95 | Add to Order |
| MSS-8463 | 3/8"-16 | 1 1/8" | __ | 0.656" | 0.199" | 7/32" | 10 | $34.29 | Add to Order |
| MSS-8464 | 3/8"-16 | 1 1/4" | __ | 0.656" | 0.199" | 7/32" | 25 | $23.63 | Add to Order |
| MSS-8465 | 3/8"-16 | 1 3/8" | __ | 0.656" | 0.199" | 7/32" | 10 | $38.09 | Add to Order |
| MSS-8466 | 3/8"-16 | 1 1/2" | 1 1/4" | 0.656" | 0.199" | 7/32" | 10 | $35.93 | Add to Order |
| MSS-8467 | 3/8"-16 | 1 5/8" | __ | 0.656" | 0.199" | 7/32" | 5 | $23.39 | Add to Order |
| MSS-8468 | 3/8"-16 | 1 3/4" | 1 1/4" | 0.656" | 0.199" | 7/32" | 10 | $39.94 | Add to Order |
| MSS-8469 | 3/8"-16 | 2" | 1 1/4" | 0.656" | 0.199" | 7/32" | 10 | $41.60 | Add to Order |
| MSS-8470 | 3/8"-16 | 2 1/4" | 1 1/4" | 0.656" | 0.199" | 7/32" | 10 | $42.92 | Add to Order |
| MSS-8471 | 3/8"-16 | 2 1/2" | __ | 0.656" | 0.199" | 7/32" | 10 | $20.43 | Add to Order |
| MSS-8472 | 3/8"-16 | 2 3/4" | 1 1/4" | 0.656" | 0.199" | 7/32" | 10 | $44.77 | Add to Order |
| MSS-8473 | 3/8"-16 | 3" | 1 1/4" | 0.656" | 0.199" | 7/32" | 10 | $46.05 | Add to Order |
| MSS-8474 | 3/8"-16 | 3 1/2" | __ | 0.656" | 0.199" | 7/32" | 5 | $20.96 | Add to Order |
| MSS-8475 | 3/8"-16 | 4" | __ | 0.656" | 0.199" | 7/32" | 5 | $24.76 | Add to Order |
| MSS-8476 | 3/8"-16 | 5" | 1 1/4" | 0.656" | 0.199" | 7/32" | 1 | $8.61 | Add to Order |
| MSS-8477 | 3/8"-24 | 3/8" | __ | 0.656" | 0.199" | 7/32" | 5 | $20.96 | Add to Order |
| MSS-8478 | 3/8"-24 | 1/2" | __ | 0.656" | 0.199" | 7/32" | 50 | $37.23 | Add to Order |
| MSS-8479 | 3/8"-24 | 5/8" | __ | 0.656" | 0.199" | 7/32" | 50 | $30.87 | Add to Order |
| MSS-8480 | 3/8"-24 | 3/4" | __ | 0.656" | 0.199" | 7/32" | 25 | $24.57 | Add to Order |
| MSS-8481 | 3/8"-24 | 1" | __ | 0.656" | 0.199" | 7/32" | 25 | $30.43 | Add to Order |
| MSS-8482 | 3/8"-24 | 1 1/4" | __ | 0.656" | 0.199" | 7/32" | 25 | $18.40 | Add to Order |
| MSS-8483 | 3/8"-24 | 1 1/2" | __ | 0.656" | 0.199" | 7/32" | 10 | $14.60 | Add to Order |
| MSS-8484 | 3/8"-24 | 2" | __ | 0.656" | 0.199" | 7/32" | 10 | $17.18 | Add to Order |
| MSS-8485 | 7/16"-14 | 3/4" | __ | 0.765" | 0.231" | 1/4" | 5 | $34.27 | Add to Order |
| MSS-8486 | 7/16"-14 | 1" | __ | 0.746" | 0.218" | 1/4" | 1 | $5.59 | Add to Order |
| MSS-8487 | 7/16"-14 | 1 1/4" | __ | 0.750" | 0.220" | 1/4" | 1 | $6.59 | Add to Order |
| MSS-8488 | 7/16"-14 | 1 1/2" | __ | 0.750" | 0.220" | 1/4" | 1 | $10.44 | Add to Order |
| MSS-8489 | 7/16"-20 | 1" | __ | 0.750" | 0.220" | 1/4" | 1 | $21.08 | Add to Order |
| MSS-8490 | 1/2"-13 | 1/2" | __ | 0.875" | 0.265" | 5/16" | 5 | $28.56 | Add to Order |
| MSS-8491 | 1/2"-13 | 5/8" | __ | 0.875" | 0.265" | 5/16" | 5 | $26.67 | Add to Order |
| MSS-8492 | 1/2"-13 | 3/4" | __ | 0.875" | 0.265" | 5/16" | 10 | $37.36 | Add to Order |
| MSS-8493 | 1/2"-13 | 7/8" | __ | 0.875" | 0.265" | 5/16" | 10 | $26.65 | Add to Order |
| MSS-8494 | 1/2"-13 | 1" | __ | 0.875" | 0.265" | 5/16" | 10 | $18.10 | Add to Order |
| MSS-8495 | 1/2"-13 | 1 1/8" | __ | 0.875" | 0.265" | 5/16" | 10 | $38.09 | Add to Order |
| MSS-8496 | 1/2"-13 | 1 1/4" | __ | 0.875" | 0.265" | 5/16" | 10 | $21.23 | Add to Order |
| MSS-8497 | 1/2"-13 | 1 1/2" | __ | 0.875" | 0.265" | 5/16" | 10 | $19.36 | Add to Order |
| MSS-8498 | 1/2"-13 | 1 3/4" | __ | 0.875" | 0.265" | 5/16" | 10 | $49.27 | Add to Order |
| MSS-8499 | 1/2"-13 | 2" | __ | 0.875" | 0.265" | 5/16" | 10 | $29.40 | Add to Order |
| MSS-8500 | 1/2"-13 | 2 1/4" | __ | 0.875" | 0.265" | 5/16" | 5 | $25.45 | Add to Order |
| MSS-8501 | 1/2"-13 | 2 1/2" | 1 1/2" | 0.875" | 0.265" | 5/16" | 5 | $39.92 | Add to Order |
| MSS-8502 | 1/2"-13 | 3" | __ | 0.875" | 0.265" | 5/16" | 5 | $29.27 | Add to Order |
| MSS-8503 | 1/2"-13 | 3 1/2" | __ | 0.875" | 0.265" | 5/16" | 1 | $12.03 | Add to Order |
| MSS-8504 | 1/2"-13 | 4" | __ | 0.875" | 0.265" | 5/16" | 1 | $14.39 | Add to Order |
| MSS-8505 | 1/2"-20 | 3/4" | __ | 0.875" | 0.265" | 5/16" | 5 | $22.11 | Add to Order |
| MSS-8506 | 1/2"-20 | 1" | __ | 0.875" | 0.265" | 5/16" | 5 | $15.62 | Add to Order |
| MSS-8507 | 1/2"-20 | 1 1/4" | __ | 0.875" | 0.265" | 5/16" | 5 | $19.66 | Add to Order |
| MSS-8508 | 1/2"-20 | 1 1/2" | __ | 0.875" | 0.265" | 5/16" | 5 | $22.74 | Add to Order |
| MSS-8509 | 1/2"-20 | 2" | __ | 0.875" | 0.265" | 5/16" | 1 | $12.20 | Add to Order |
| MSS-8510 | 5/8"-11 | 3/4" | __ | 1.000" | 0.331" | 3/8" | 1 | $7.92 | Add to Order |
| MSS-8511 | 5/8"-11 | 1" | __ | 1.000" | 0.331" | 3/8" | 5 | $38.35 | Add to Order |
| MSS-8512 | 5/8"-11 | 1 1/4" | __ | 1.000" | 0.331" | 3/8" | 5 | $39.33 | Add to Order |
| MSS-8513 | 5/8"-11 | 1 1/2" | __ | 1.000" | 0.331" | 3/8" | 5 | $49.01 | Add to Order |
| MSS-8514 | 5/8"-11 | 1 3/4" | __ | 1.000" | 0.331" | 3/8" | 5 | $17.51 | Add to Order |
| MSS-8515 | 5/8"-11 | 2" | __ | 1.000" | 0.331" | 3/8" | 1 | $10.12 | Add to Order |
| MSS-8516 | 5/8"-11 | 2 1/2" | __ | 1.000" | 0.331" | 3/8" | 1 | $9.24 | Add to Order |
| MSS-8517 | 5/8"-11 | 3" | __ | 1.000" | 0.331" | 3/8" | 1 | $9.85 | Add to Order |
| MSS-8518 | 5/8"-18 | 1" | __ | 1.000" | 0.331" | 3/8" | 1 | $35.13 | Add to Order |
| MSS-8519 | 5/8"-18 | 1 1/2" | __ | 1.000" | 0.331" | 3/8" | 1 | $37.86 | Add to Order |
| MSS-8520 | 5/8"-18 | 2" | __ | 1.000" | 0.331" | 3/8" | 1 | $43.22 | Add to Order |
| MSS-8521 | 3/4"-10 | 2" | __ | 1.100" | 0.375" | 7/16" | 1 | $43.22 | Add to Order |
| MSS-8522 | 3/4"-10 | 3" | __ | 1.100" | 0.375" | 7/16" | 1 | $48.57 | Add to Order |
| Rev. 08-23, 11-22, 03-22 | |||||||||
