Class 8 Zinc Plated Steel Hex Nuts
| Class 8 Zinc Plated Steel Hex Nuts | |||||||
| Part # | Thread Size | Pitch (mm) | Width (mm) | Height (mm) | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| HN-1655 | M2 | 0.4 | 4 | 1.6 | 100 | $2.69 | Add to Order |
| HN-1656 | M2.5 | 0.45 | 5 | 2 | 100 | $4.66 | Add to Order |
| HN-1657 | M3 | 0.5 | 5.5 | 2.4 | 100 | $4.18 | Add to Order |
| HN-1658 | M4 | 0.7 | 7 | 3.2 | 100 | $4.91 | Add to Order |
| HN-1659 | M5 | 0.8 | 8 | 4 | 100 | $7.48 | Add to Order |
| HN-529 | M6 | 1 | 10 | 5 | 100 | $6.09 | Add to Order |
| HN-530 | M7 | 1 | 11 | 5.5 | 100 | $11.26 | Add to Order |
| HN-531 | M8 | 1.25 | 13 | 6.5 | 100 | $11.42 | Add to Order |
| HN-1745 | M8 | 1 | 13 | 6.5 | 100 | $17.91 | Add to Order |
| HN-532 | M10 | 1.5 | 17 | 8 | 100 | $28.08 | Add to Order |
| HN-1690 | M10 | 1.25 | 17 | 8 | 50 | $30.47 | Add to Order |
| HN-1691 | M10 | 1 | 17 | 8 | 50 | $34.38 | Add to Order |
| HN-1692 | M12 | 1.5 | 19 | 10 | 25 | $15.18 | Add to Order |
| HN-1693 | M12 | 1.25 | 19 | 10 | 25 | $20.03 | Add to Order |
| HN-1694 | M12 | 1 | 19 | 10 | 10 | $24.21 | Add to Order |
| HN-533 | M12 | 1.75 | 19 | 10 | 50 | $19.57 | Add to Order |
| HN-534B | M14 | 2 | 22 | 11 | 25 | $29.55 | Add to Order |
| HN-1695 | M14 | 1.5 | 22 | 11 | 25 | $29.27 | Add to Order |
| HN-1696 | M16 | 1.5 | 24 | 13 | 25 | $45.34 | Add to Order |
| HN-534 | M16 | 2 | 24 | 13 | 25 | $20.10 | Add to Order |
| HN-536 | M18 | 2.5 | 27 | 15 | 10 | $17.47 | Add to Order |
| HN-1697 | M18 | 1.5 | 27 | 15 | 10 | $26.17 | Add to Order |
| HN-1698 | M20 | 1.5 | 30 | 16 | 10 | $26.19 | Add to Order |
| HN-537 | M20 | 2.5 | 30 | 16 | 10 | $18.82 | Add to Order |
| HN-1699 | M22 | 1.5 | 32 | 18 | 1 | $8.95 | Add to Order |
| HN-1700 | M24 | 2 | 36 | 19 | 1 | $11.36 | Add to Order |
| HN-538 | M24 | 3 | 36 | 19 | 10 | $26.50 | Add to Order |
| HN-1701 | M24 | 1.5 | 36 | 19 | 1 | $9.49 | Add to Order |
| HN-1702 | M30 | 2 | 46 | 24 | 1 | $19.91 | Add to Order |
| HN-539 | M30 | 3.5 | 46 | 24 | 1 | $10.25 | Add to Order |
| HN-540 | M36 | 4 | 55 | 29 | 1 | $18.92 | Add to Order |
| Rev. 08-26, 05-26, 03-25, 10-23 | |||||||
| Class 8 Plain Steel Hex Nuts | |||||||
| Part # | Thread Size | Pitch (mm) | Width (mm) | Height (mm) | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| HN-1728 | M2 | 0.4 | 4 | 1.6 | 100 | $8.40 | Add to Order |
| HN-1729 | M2.5 | 0.45 | 5 | 2 | 100 | $8.80 | Add to Order |
| HN-1730 | M3 | 0.5 | 5.5 | 2.4 | 100 | $5.50 | Add to Order |
| HN-1731 | M4 | 0.7 | 7 | 3.2 | 100 | $8.00 | Add to Order |
| HN-1732 | M5 | 0.8 | 8 | 4 | 100 | $8.51 | Add to Order |
| HN-1733 | M6 | 1 | 10 | 5 | 100 | $7.46 | Add to Order |
| HN-1734 | M7 | 1 | 11 | 5.5 | 100 | $16.99 | Add to Order |
| HN-1735 | M8 | 1.25 | 13 | 6.5 | 100 | $20.31 | Add to Order |
| HN-1736 | M10 | 1.5 | 17 | 8 | 100 | $34.13 | Add to Order |
| HN-1737 | M12 | 1.75 | 19 | 10 | 100 | $40.38 | Add to Order |
| HN-1738 | M14 | 2 | 22 | 11 | 25 | $29.29 | Add to Order |
| HN-1739 | M16 | 2 | 24 | 13 | 50 | $27.30 | Add to Order |
| HN-1740 | M18 | 2.5 | 27 | 15 | 25 | $29.93 | Add to Order |
| HN-1741 | M20 | 2.5 | 30 | 16 | 10 | $22.26 | Add to Order |
| HN-1742 | M24 | 3 | 36 | 19 | 10 | $37.28 | Add to Order |
| HN-1743 | M30 | 3.5 | 46 | 24 | 5 | $23.52 | Add to Order |
| HN-1744 | M36 | 4 | 55 | 29 | 5 | $33.50 | Add to Order |
| Rev. 08-26, 03-25, 04-23, 01-23 | |||||||
