Class 10 Steel Hex Nuts
| Zinc Yellow Chromate Plated Steel Hex Nuts, Class 10, DIN 934 | |||||||
| Part # | Thread Size | Pitch (mm) | Width (mm) | Height (mm) | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| HN-1603 | M3 | 0.5 | 5.5 | 2.4 | 25 | $21.74 | Add to Order |
| HN-1604 | M4 | 0.7 | 7 | 3.2 | 50 | $22.09 | Add to Order |
| HN-1605 | M5 | 0.8 | 8 | 4 | 100 | $27.66 | Add to Order |
| HN-1606 | M6 | 1 | 10 | 5 | 100 | $23.86 | Add to Order |
| HN-1607 | M8 | 1.25 | 13 | 6.5 | 100 | $38.05 | Add to Order |
| HN-1608 | M10 | 1.5 | 17 | 8 | 50 | $36.20 | Add to Order |
| HN-1609 | M12 | 1.75 | 19 | 10 | 25 | $37.28 | Add to Order |
| HN-1610 | M14 | 2 | 22 | 11 | 10 | $26.10 | Add to Order |
| HN-1611 | M16 | 2 | 24 | 13 | 10 | $30.72 | Add to Order |
| HN-1612 | M18 | 2.5 | 27 | 15 | 5 | $21.00 | Add to Order |
| HN-1613 | M20 | 2.5 | 30 | 16 | 5 | $31.54 | Add to Order |
| HN-1614 | M22 | 2.5 | 32 | 18 | 1 | $7.73 | Add to Order |
| HN-1615 | M24 | 3 | 36 | 19 | 1 | $9.43 | Add to Order |
| HN-1616 | M30 | 3.5 | 46 | 24 | 1 | $16.32 | Add to Order |
| HN-1617 | M36 | 4 | 55 | 29 | 1 | $28.08 | Add to Order |
| Rev. 06-24, 10-23, 12-22, 02-22 | |||||||
| Steel Hex Nuts, Class 10, DIN 934 | |||||||
| Part # | Thread Size | Pitch (mm) | Width (mm) | Height (mm) | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| HN-1768 | M3 | 0.5 | 5.5 | 2.4 | 25 | $22.66 | Add to Order |
| HN-1769 | M4 | 0.7 | 7 | 3.2 | 100 | $20.33 | Add to Order |
| HN-1770 | M5 | 0.8 | 8 | 4 | 100 | $9.60 | Add to Order |
| HN-1771 | M6 | 1 | 10 | 5 | 100 | $11.28 | Add to Order |
| HN-1772 | M8 | 1.25 | 13 | 6.5 | 100 | $19.70 | Add to Order |
| HN-1773 | M10 | 1.5 | 17 | 8 | 50 | $31.40 | Add to Order |
| HN-1774 | M12 | 1.75 | 19 | 10 | 25 | $24.99 | Add to Order |
| HN-574 | M12 | 1.75 | 22 | 10 | 5 | $24.21 | Add to Order |
| HN-1775 | M14 | 2 | 22 | 11 | 25 | $21.00 | Add to Order |
| HN-1776 | M16 | 2 | 24 | 13 | 10 | $10.71 | Add to Order |
| HN-575 | M16 | 2 | 27 | 13 | 5 | $17.60 | Add to Order |
| HN-1777 | M18 | 2.5 | 27 | 15 | 10 | $48.01 | Add to Order |
| HN-1778 | M20 | 2.5 | 30 | 16 | 5 | $10.08 | Add to Order |
| HN-576 | M20 | 2.5 | 32 | 16 | 5 | $23.67 | Add to Order |
| HN-577 | M24 | 3 | 41 | 19 | 1 | $8.82 | Add to Order |
| HN-1779 | M24 | 3 | 36 | 19 | 5 | $20.48 | Add to Order |
| HN-1780 | M30 | 3.5 | 46 | 24 | 1 | $5.99 | Add to Order |
| HN-1781 | M36 | 4 | 55 | 29 | 1 | $21.00 | Add to Order |
| Rev. 04-23, 01-23, 12-22, 02-22 | |||||||
| Zinc Plated Steel Flanged Hex Nuts Class 10 DIN 6923 | |||||||||
| Part # | Thread Size | Pitch (mm) | Width (mm) | Height (mm) | Flange Dia. (mm) | Flange Thick. (mm) | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| HN-2637 | M6 | 1 | 10 | 6 | 14.2 | 1.1 | 100 | $13.99 | Add to Order |
| HN-2638 | M8 | 1.25 | 13 | 8 | 17.9 | 1.2 | 100 | $35.01 | Add to Order |
| HN-2639 | M10 | 1.5 | 15 | 10 | 21.8 | 1.5 | 50 | $27.99 | Add to Order |
| HN-2640 | M12 | 1.75 | 18 | 12 | 26 | 1.8 | 25 | $19.24 | Add to Order |
| HN-2641 | M16 | 2 | 24 | 16 | 34.5 | 2.4 | 10 | $27.30 | Add to Order |
| Rev. 12-22, 02-22 | |||||||||
| Black Phosphate Steel Flanged Hex Nuts Class 10 DIN 6923 | |||||||||
| Part # | Thread Size | Pitch (mm) | Width (mm) | Height (mm) | Flange Dia. (mm) | Flange Thick. (mm) | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| HN-2642 | M6 | 1 | 10 | 6 | 14.2 | 1.1 | 100 | $21.00 | Add to Order |
| HN-2643 | M8 | 1.25 | 13 | 8 | 17.9 | 1.2 | 100 | $35.01 | Add to Order |
| HN-2644 | M10 | 1.5 | 15 | 10 | 21.8 | 1.5 | 50 | $31.50 | Add to Order |
| HN-2645 | M12 | 1.75 | 18 | 12 | 26 | 1.8 | 25 | $24.51 | Add to Order |
| HN-2646 | M16 | 2 | 24 | 16 | 34.5 | 2.4 | 10 | $22.24 | Add to Order |
| Rev. 12-22, 02-22 | |||||||||
| Zinc Plated Steel Hex Nuts, Class 10 | |||||||
| Part # | Thread Size | Pitch (mm) | Width (mm) | Height (mm) | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| HN-570 | M12 | 1.75 | 22 | 10 | 5 | $26.42 | Add to Order |
| HN-571 | M16 | 2 | 27 | 13 | 5 | $19.80 | Add to Order |
| HN-572 | M20 | 2.5 | 32 | 16 | 5 | $28.62 | Add to Order |
| HN-573 | M24 | 3 | 41 | 19 | 1 | $11.99 | Add to Order |
| Rev. 12-22, 02-22 | |||||||
