655 Alloy Silicone Bronze Rods
Unpolished Mill Finish, H04 Temper
Yield Strength: 40K to 55K psi, ASTM B98
| Part # | Diameter | Length | Price Each | Order Online |
|---|---|---|---|---|
| MR-1816 | .250" | 36" | $38.44 | Add to Order |
| MR-368 | .250" | 72" | $85.23 | Add to Order |
| MR-1817 | .312" | 36" | $72.44 | Add to Order |
| MR-369 | .312" | 72" | $164.65 | Add to Order |
| MR-1818 | .375" | 36" | $78.37 | Add to Order |
| MR-370 | .375" | 72" | $173.78 | Add to Order |
| MR-1820 | .500" | 36" | $113.86 | Add to Order |
| MR-373 | .500" | 72" | $238.05 | Add to Order |
| MR-1821 | .625" | 36" | $186.24 | Add to Order |
| MR-374 | .625" | 72" | $389.41 | Add to Order |
| MR-1822 | .750" | 36" | $282.16 | Add to Order |
| MR-376 | .750" | 72" | $589.97 | Add to Order |
| MR-1824 | 1.00" | 36" | $400.20 | Add to Order |
| MR-378 | 1.00" | 72" | $745.83 | Add to Order |
| MR-1825 | 1.25" | 36" | $631.04 | Add to Order |
| MR-1815 | 1.25" | 72" | $1,319.46 | Add to Order |
| MR-1826 | 1.50" | 36" | $870.94 | Add to Order |
| MR-379 | 1.50" | 72" | $1,623.11 | Add to Order |
| Rev. 03-25, 01-24, 10-23, 05-23 | ||||
Tolerances
| Straightness | .031" | |
| Length | +/-.50" | |
| Diameter | .187 - .5" | +/-.002" |
| Diameter | .625" - 1" | +/-.003" |
| Diameter | 1.25" and Up | +/-.004" |
Composition:
Iron: 0.8 max
Lead: 0.05 max
Manganese: 0.5 - 1.3
Silicon: 2.8 - 3.8
Zinc: 1.5 max
Properties:
Density (lb / cu. in.): 0.308
Electrical Resistivity (microhm-cm (at 68 Deg F)): 148
Melting Point (Deg F): 1780
Modulus of Elasticity Tension: 15000
